axis used for sale

Gantry system / 3-axis handling system / handling robot 3-axis handling system from the field of plastic films, built in 2014. The machine can no longer be used for this purpose, as the specific units are no longer available. The handling system is very well suited as a base carrier for new applications in automation. Special-purpose machine manufacturers can use the handling system as a cost-effective base carrier for the construction of an automatic processing machine and thus secure cost advantages in the competition. This can be the mechanical processing of soft materials or stirring technology, as a pneumatic motor with a chuck is now attached. Or a handling device for recycling batteries. All linear actuators with drivers are high-quality Festo components. CMXR multi-axis controllers. Dimensions: WxDxH: 2.5 x 2.0 x 2.3 m Weight approx. 1 ton Equipment: Base  ...

Travel X/Y/Z: 450mm/580mm/400mm, swivel range A/B: -110°/+10°, C-axis rotation range: 360°, table dimensions X/Y: 400mm/400mm, tool positions: 30, power-on hours: 56612h, spindle operating hours: 21206h. The machine is located in the United Kingdom. Inspection possible by appointment.

Ref. -No.: 10347 Manufacturer: FPT Year of construction: 2006 Type of control: CNC Control: Heidenhain 530 Country of origin: Italien X-Travel: 12000 mm Y-Travel: 3500 mm Z-Travel: 1500 mm Tool Piece Magazine With: 80 Pcs./pcs. Spindle Speed: 3000 RPM Drive Capacity - Spindle Motor: 37 kW Round table 1 (lxw): 2500x2500 mm Round Table 1 - V: 2000 mm Rotary table 1 max. load: 30000 kg Round table 2 (lxw): 2500x2500 mm Round Table 2 - V: 1500 mm Rotary table 2 max. load: 30000 kg Further information:

5-axis machining center, year 2002, CNC 4045PD. Used machine. More info & price on IndustrialBuyer.

Ref. -No.: 10350 Manufacturer: FPT Year of construction: 2012 Type of control: CNC Control: Heidenhain 530 Storage location: Halberstadt Country of origin: Italien X-Travel: 14000 mm Y-Travel: 5000 mm Z-Travel: 1500 mm W-Axis: 1000 mm Numbers Of Tools In Magazin: 24 Drive Capacity - Spindle Motor: 60 kW Rotary table diameter: 3000x3000 mm Rotary table travel V: 2500 mm Rotary table max. Load: 80000 kg swivel angle: 180 ° Further information: +3D M Sensor +CNC controlled angle head: micro

5-axis machining center, year 2013, CNC WinMax. Used machine. More info & price on IndustrialBuyer.

Ref. -No.: 10036 Manufacturer: JOHNFORD Year of construction: 2009 Type of control: CNC Control: Fanuc Series 18i-TB Storage location: Halberstadt Country of origin: Taiwan Machine length: 9800 mm Machine width: 3695 mm Machine Height: 5292 mm Weight Of The Machine Ca.: 32,6 t amount of positions: 12 Bar passage: 165 mm Serial no.: TDF9007 Turning Length: 2000 mm Turning Diameter Over Bed: 1550 mm Swing Diameter Over Bed Slide: 1270 mm Longitudinal Travel (Z-Axis): 2000 mm Spindle Head: A2-15 Spindle Diameter In Front Bearing: 240 mm Spindle Bore: 185 mm Spindle power: 37/30 kW Cross Travel: 685 mm Spindle Speeds: 1000 RPM Rapid Travel Speed X-Axis: 10 m / min Rapid Travel Speed Z-Axis: 12 m / min Tool changer: 12 Pcs

1x Linear robot Reis RL80-13 incl. 2 control cabinets absolutely mint condition Year of construction 2009 there are 2 robots on each beam, a two-axis robot and a three-axis robot the system is dismantled, complete with control cabinets the glass gripper and the Zimmermann & Schilp non-contact glass lifting system are not part of the range of products there are 2 of these double robot systems available incl. loading

Control: iTNC 530 Max.travel range: X 500 mm Y 450 mm Z 400 mm A +5 / - 110? - manual C nx 360? - manual Spindle speed ? 10000 rpm Taper ? SK 40 Tool changer ? 16 positon measuring probe for parts set up 3 axis + 2 axis (dividing head) Tool pr

Control: iTNC 530 Max.travel range: X 765 mm Y 460 mm Z 560 mm B +30? / -120? C nx 360? Clamping table: 630 x 500 mm Spindle speed ? 12000 rpm Taper ? HSK 63 Tool changer ? 120 positon Twin Pallets Coolant tank:2500l With spindle cooling, mea

Control: Mill plus Max.travel range: X 765 mm Y 460 mm Z 560 mm B +30? / -120? C nx 360? Clamping table: 630 x 500 mm Spindle speed ? 12000 rpm Taper ? HSK 63 Tool changer ? 120 positon Four Pallets Coolant tank:2500l machine has spindle cool

Control: Heidenhain Mill plus Max.travel range: X 1250 mm Y 1000 mm Z 1000 mm B -30? / +180? C nx 360? Clamping table: 1000 x 800 mm Spindle speed ? 10000 rpm Taper ? HSK 100 Tool changer ? 120 positon Twin Pallets Coolant tank: 2000l machine

Control: Mill plus Max.travel range: X 1250 mm Y 1000 mm Z 1000 mm B -30? / +180? C nx 360? Clamping table: 1000 x 800 mm Spindle speed ? 10000 rpm Taper ? HSK 100 Tool changer ? 120 positon Twin Pallets Coolant tank: 2000l machine has spindl

Control: iTNC 530 Max.travel range: X 450 mm Y 650 mm Z 460 mm A -10 / + 110? C nx 360? Spindle speed ? 28000 rpm Taper ? HSK 63 Tool changer ? 120 positon machine has spindle cooling, Erowa clamping system is available, measuring probe for pa

Control: iTNC 530 Max.travel range: X 450 mm Y 650 mm Z 460 mm A -10 / + 110? C nx 360? Spindle speed ? 28000 rpm Taper ? HSK 63 Tool changer ? 120 positon machine has spindle cooling, Erowa clamping system is available, measuring probe for pa

Control: iTNC 530 Max.travel range: X 450 mm Y 650 mm Z 460 mm A -10 / + 110? C nx 360? Spindle speed ? 28000 rpm Taper ? HSK 63 Tool changer ? 60 positon machine has spindle cooling, Erowa clamping system is available, measuring probe for par

Control: iTNC 530 Max.travel range: X 450 mm Y 650 mm Z 460 mm A -10 / + 110? C nx 360? Spindle speed ? 28000 rpm Taper ? HSK 63 Tool changer ? 120 positon machine has spindle cooling, Erowa clamping system is available, measuring probe for pa

with pallet changer for 20 pallets. Control: iTNC 530 Max.travel range: X 885 mm Y 600 mm Z 600 mm A -10 / + 110? C nx 360? Spindle speed ? 28000 rpm Taper ? HSK 63 Tool changer ? 120 positon Exchange of pallets: 20 pallets Coolant tank: 1000l machine ha

Control: iTNC 530 Max.travel range: X 850 mm Y 700 mm Z 500 mm A +/- 115? C nx 360? Spindle speed ? 18000 rpm Taper ? HSK 63 Tool changer ? 38+44 positon Coolant tank: 900l machine has spindle cooling, Erowa clamping system is available, measu

Salvagnini Mod. Performer Year 2000 Manual loading Manual blades

x-travel: 350 mm y-travel: 200 mm z-travel: 350 mm table surface area: 700 x 280 mm spindle taper: SK 40 : 150 - 1660 U/min feeds: 25 - 285 mm/min rapid traverse: 1 m/min quill stroke: 80 mm milling-head swivable +/-: 45 ° total power requirement: 3 kW weight of the machine ca.: 1,2 t dimensions of machine L x W x H: 1,27 x 1,1 x 1,65 m Accessories: vertical head with quill retraction, solid table, univ. table, rotary table 250 mmø, dividing unit with 3-jaw chuck 135 mmø, counter bearing, various tool fixtures, drill chuck, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 7787 Type: JR1.40 Producer: CMS Brembana Created: 2012 Parameters: Work table length: 2600 mm Work table width: 1700 mm A set of tools and gears for various tools (cup wheels/saws/chamfer discs) are available for the machine.

Manufacturer: CMS Model: Avant-1/B-560-TX3/RR with a digital table Year of Manufacture: 2006 Type of Machine: 4-axis CNC machining center with a moving bridge - Moving bridge design with two racks. Fixed table during machining. - Welded steel support frame stabilized by double heat treatment - Mobile bridge supporting a set of two crossed slide carriages for transverse and vertical movement - Travels: o X axis: 5600mm o Y axis: 2050 mm o Z axis: 300 mm - Working and positioning speed: o X axis from 0 to 60 m/min, positioning speed of 60m/min o Y axis from 0 to 100 m/min, positioning speed of 100m/min o Z axis from 0 to 30 m/min, positioning speed of 30m/min - Automatic centralized lubrication - TX3 vertical head with tool changer mounted on Z-TX3/12/L vertical carriage o Head power: 15kw at 18000 rpm o Programmable rotation speed of 1800 to 24000 rpm o HSK63E cone - 2 ...

CMA 5-axis painting robot mod. ROBY 5EX-R - used - N. 5 controlled axes - N. 3 supports - Wrist capacity 3 kg - Self-learning programming -Merry-go-round Number of arms 3 Single arm capacity 25 kg - Workpiece Wheel Servo movement controlled and synchronized - Complete with manual and CE declaration - RETROFIT 2024 (NEW OVERHAUL)

Manufacturer: Homag, Type: Optimat BAZ 311/40/K, Year: 2007, Software: PC85 CNC CORE Z, Feeding speed max m/min: X,Y-80, Z-30, Working range X: 4000, Working range Y-axis: 1220, Working range Z: 12-300, Year :2007

ADIGE BLM LT652 Model : LT652/B Year of Manufacture : 2002 Laser Generator: DC025 (2500 Watts) Loading Length : 6500 Drain Length : 4500 Hours of Electrical Panel : 60433 Tension Laser Ore : 62285 Chiller : recently replaced Disassembly options - available now.

Manufacturer: Format 4, Type: Profit H20, Year: 2014, Feeding speed max m/min: X-80, Y-80, Z-20, Working range X: 3830, Working range Y-axis: 1680, Working range Z: 275, Vacuum pumps m³/h: 90, incl. tools: yes, Gesamtanschluss kw: 18, Weight approx. kg: 3350, Year :2014

Manufacturer: Biesse, Type: Rover 23, Year: 2000, Control: yes, Working range X: 2900, Working range Y-axis: 1300, Working range Z: 140, Milling engine 1 hours power: 7,8, Vertical drills-X: 10, Horizontal drills-X: 6, Weight approx. kg: ca. 3500, Year :2000

Manufacturer: SCM, Type: RECORD 100 AL XL TVN, Year: 2010, Working range X: 3110, Working range Y-axis: 1240, Feeding speed max m/min: X=60, Y=45, Z=30, Number of tables: 1, Traverse table: yes, Vacuum pumps m³/h: 250, Saw unit: yes, Magazine Qty: 12, Year :2010

Manufacturer: IMA, Type: Quadroform C 80/280, Year: 1995, Working range X: 2800, Working range Y-axis: 800, Tool adaption system: HSK 63 F, Milling engine 1 hours power: 7,5, rpm 1): 1500-18000, Number of tool changers: 8, Pickup Wechlser: yes, Vertical drills-X: 5, Drill vertical Y: 9, Number of tables: 1, 2 station allocation: yes, Stops in the table rear: yes, Vacuum pumps m³/h: 80, Saw unit: Wechlser, FREE TEXT: inkl Werkzeuge, Year :1995

Manufacturer: Reichenbacher, Type: Vision 2 Sprint, Year: 1999, Control: Simumerik 840 D, Working range X: 6140, Working range Y-axis: 1600, Working range Z: 480, Feeding speed max m/min: 60, Pendulum processing: yes, Number of milling spindles: 4, Milling engine 1 hours power: 4,8, 2 station allocation: yes, 4 station allocation: yes, Vacuum pumps m³/h: 160, Year :1999

Manufacturer: Busellato, Type: Jet 6000 XXL, Year: 1999, Working range X: 4600, Working range Y-axis: 1700, Working range Z: 150, Vertical drills-X: 11, Drill vertical Y: 9, Horizontal drills-X: 2+2, Drill horizontal Y: 2+2, Year :1999

Manufacturer: IMA, Type: BIMA 610-2H, Year: 1996, Control: num, Working range X: 7000, Working range Y-axis: ca. 1150, Working range Z: 200, C axis: no, Number of milling spindles vertical: 2, Tool adaption system: HSK 63, Milling engine 1 hours power: 7,5, rpm 1): 1800-24000, Milling engine 2 hours power: 7,5, rpm 2): 1800-24000, Tellerwechseler: yes, Number of tools per tool-magazine: 2 X 12, Mitfahrender Werkzeugwechsler: yes, raster table: yes, 4 station allocation: 8, Vacuum pumps m³/h: 250, Werkstückspannsystem: schablone, machine ready for demonstration: yes, Year :1996

Manufacturer: Biesse, Type: Arrow ATS BAZ 3, Year: 2003, Control: Biesse, Working range X: 3000, Working range Y-axis: 1500, C axis: no, Pendulum processing: yes, Number of milling spindles: 0, Number of tool changers: 1, Number of tools per tool-magazine: 8, Vertical drills-X: 20, Drill vertical Y: 15, Horizontal drills-X: 4, Drill horizontal Y: 2, Traverse table: yes, 2 station allocation: yes, Saw unit: yes, Year :2003

Manufacturer: SCM, Type: Record 130, Year: 2001, Control: Num, Working range X: 3080, Working range Y-axis: 1200, Working range Z: 280, Number of milling spindles: 1, Tool adaption system: HSK 63, Milling engine 1 hours power: ca.9, rpm 1): 9000-18000, Number of tool changers: 1, Number of tools per tool-magazine: 12, Mitfahrender Werkzeugwechsler: yes, Vacuum pumps m³/h: 120, Year :2001

Manufacturer: Homag, Type: Genius 20/50/14/G, Year: 1996, Control: Homatic, Work piece width min-max mm: 1400, Min.-max. workpiece length in mm: 5300, Min.-max. workpiece height in mm: 40 / 60, C axis: yes, Tool adaption system: HSK 63F, Milling engine 1 hours power: 12, rpm 1): 1500 - 18.000, Number of tool changers: 1, Number of tools per tool-magazine: 30, Vertical drills-X: 11, raster table: yes, 2 station allocation: yes, Saw unit: yes, Edgebanding unit: yes, Magazine for edges: 1-fach, Edgeband hight mm: 40, Marking laser: yes, Year :1996

Manufacturer: IMA , Type: BIMA 810 V, Year: 2000, Control: IMATRONIC, Software: IMAWOP, Working range X: 5200, Working range Y-axis: 1600, Working range Z: 180, C axis: yes, Pendulum processing: yes, Number of milling spindles vertical: 1, Tool adaption system: HSK 63, Milling engine 1 hours power: 12, Number of tool changers: 1, Number of tools per tool-magazine: 18, Vertical drills-X: 11, Drill vertical Y: 11, 2 station allocation: yes, 4 station allocation: yes, Vacuum pumps m³/h: 2 x 100 , Edgebanding unit: yes, Edgeband hight mm: 55, Year :2000

Manufacturer: SCM, Type: Routomat 3 , Year: 1994, Control: scm, Work piece width min-max mm: 2500 X 1400, Working range X: 2500, Working range Y-axis: 1400, Working range Z: ca.350, C axis: yes, Work piece width min-max mm: 2500 X 1400, Number of milling spindles: 1, Tool adaption system: ISO 30, Milling engine 1 hours power: 7,5, pm: 1500-18000, pm: 1500-18000, Anzahl Werkzeugwechsler: 1, Number of tools per tool-magazine: 6, Alu-Glättisch: Alu Nuttisch, Tool clamping system: vakuum, FREE TEXT: C-Achse muss überholt werden Preis ca.3000 Euro, Year :1994

Tool presettler SOMET type SPS 500 UMash. No. S1-020 Year of construction 1987Table surface 545 x 1000 mmTravel distances X = 500 mm, Y = 340 mmWidth in the portal 550 mmHeight table - lower edge portal 250 mm- Portal longitudinal guidance on the right and left of the table- Adjustment via very fine threaded spindles with handwheel- Quick adjustment via electric unlocking- Projector screen 150 mm with crosshairs and coordinates MEOPTA PMP100- 2 pieces of clamping devices for tool measurement- on substructure with shelf and drawerSpace requirement L

6-Axis AC Servo Drive, Servo Actuator, Servo Inverter, Servo Amplifier, Servo Controller, Frequency Converter, Drive Controller for RobotFANUC Type A06B-6105-H003No. V07Z08282NEU / unusedInput voltage: 200 - 240 VACNornpower: 1.5 kWAnnumber of axis outputs: 6Output current: 6 x 13 AGtotal output current: max. 78 AManual No.: B-81465Standard: EN50178Installed circuit boards: A16B-2000-0063/07D A16B-3200-0440/05C- Plexiglass cover not includedDimensions W x H x D 70 x 170 x 380

6 Axis Robot Servo Controller,Drive, Motion Control, Servo Pack, Servo UnitServo Unit for YASNAC XRC UP6YASKAWA / MOTOMAN Type CACR-UP6AACO/N RA8616-0Y4A-46S/N: D000Z2676590046Version: 6 Axis Module for Robot- Suitable for YASKAWA / MOTOMAN / YASNAC XRC UP6- Interface USB Power Supply Type JUSP-RCP01AACAnmity W x H x D: 270 x 310 x 200 mmWeight: 8.5 kgUsed, very good condition; used
