a e used for sale

Manufacturer: IMA , Type: Advantage 5620, Year: 2001, Program: IMA, Control: IMA, Min-max edge material mm: 0,5-3, Work piece width min-max mm: 70-1300, Min.-max. workpiece length in mm: 150-3000, Min.-max. workpiece height in mm: 10-50, Edgeband height max mm: 45, Min-max feed m/min: ca. 20, Premilling: yes, IR zone: yes, Lasertechnik: yes, Kw-Leistung Laser: yes, Strip magazin: yes, Min.-max. batten magazine mm: yes, Mitre stations: yes, Pre-milling: yes, Bevel milling: yes, Corner tracing type: yes, Grooves, slewable-controlled: yes, Type of scraper: yes, Cleaning nozzles: yes, Edge sanding: yes, Profile sanding top bottom: Rolle, Roller/belt: 6, Year :2001

Manufacturer: Arminius Kantenschleifmaschine, Type: SP 33, Year: ca.1993, Monting of the machine: Bürste/längs/längs/radius oben, Sanding belt hight: ca.50, Sanding belt length max mm: 2150 X 50, Work piece hight min-max mm: 8-50, Work piece width min-max mm: 75, Feeding speed min-max m/min: 5-15, Length of the machine mm: ca.4500, 1st sanding motor controlled and tiltable: Bürste, Frequency controlled: regelbar, Power kW: 0,75, 2nd sanding motor controlled and tiltable: yes, Frequency controlled: regelbar, Power kW: 0,75, 3rd sanding motor controlled and tiltable: yes, Frequency controlled: regelbar, Power kW: 0,75, Frequency controlled: regelbar, Power kW: 0,75, Belt clamping pneumatically: yes, Hight adjustment by hand wheel: yes, radius sanding device: oben, Oscillation: yes, Hight adjustment: yes, Year :ca.1993

Key data: 72 mm, 28 , 50 U/min

Parallel twin screw extruder Cincinnati ARGOS 72R-28D Output capacity: max. 400 kg/h (depending on material and processing conditions) Power main drive: 47 kW (AC motor) Screw diameter: 72 mm, L/D = 28 Screw speed: max. 50 rpm Screw geometry for u-PVC pipe or technical profiles Original screws and barrels in very good condition 12 x Tool heating zones 3-ph/5-pin CEE 32A/10.5 kW 1 x adapter heating zone 1-ph/5-pin CEE 32A/5.5 kW 13 x TC Type J 16 mm Tuchel C70B 3-pin 4 m Incl. mass pressure and temperature sensor Successor interface: Interface 1 (analogue) and Can Open Bus 3 x Add on Plasticolor 0–10V Machine control Cincinnati EXc ProXP Horizontal conveyor incl. material hopper Total connected load: 184 kW Dimensions (L x W x H): 4,018 x 1,250 x 2,463 mm Weight: 4,700 kg Condition: used, overhauled & functionally tested

Key data: 250 mm

Milling cutter diameter 250 mm Pneumatic workpiece clamps Manual feed weight: approx. 160 kg

CONTROLS   CNC controls WORKING RANGE -WIRE CUTTING-   X-axis travel: 500 mm   Y-axis travel: 350 mm   z-axis travel (vertical): 426 mm   conical operation for max.: 30 °   U-axis travel: 140 mm   V-axis travel: 140 mm WIRE SYSTEM   wire diameter (min): 0.15 mm   wire diameter (max): 0.33 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 1940 mm   space requirements -front/back-: 2300 mm   total height: 2600 mm   total weight approx.: 4200 kg

Excellent condition - Fully operational - Loading / Transport possible! Feed 10 m/min joint trimming unit Yes snipping unit Ja/Yes profile trimming unit Yes flat scraping unit Yes profile scraping unit Yes

Excellent condition - Fully operational - Loading / Transport possible! total length: 5250 mm Jointing cutter: 2 pcs. DIA Single Edge Feed: Available suction diameter: 80 mm Chip Collection Box (Crosscut Saw) extension arm (extendable to the front) quick heating adhesive container 50 Hz 35.7 A Adhesive application rapid heating tank heating power 3.2 kW application roller motor power 0.18 kW Cross-Cut Saw Unit motor power 1 x 0.37 kW speed approx. 15000 rpm Corner trimming cutter motor power 1 x 0.37 kW speed approx. 12000 min -1 Accessories with roller conveyor including work cabinet, with edges, 6 drawers DIA jointing cutter 100 x 45.5 x 30 x Z2 DIA jointing cutter 3 pcs. new 100 x 45,5 x 30 x Z2 Leitz reversible knife 12 x 12 x 1.5 circular saw blades Leuco 110 x 3.6 x 22 T = 20

Right-hand version Workpiece dimensions: max. length 3000 mm, min. 250 mm, max. thickness 100 mm, min. 30 mm, width 200 mm Overhead cutting saw, 3 kW, 3000 rpm, manual horizontal movement over 120 mm, 400 mm blade, cutting height 100 mm 1 vertical shaft, 340 mm long, 40 mm diameter, 7.5 kW, 3100 rpm, suction port with 150 mm diameter (x2), max. tool diameter: 320 mm Carriage with pneumatic clamping 1100 x 500 mm table Stop, positioning from -45? to 45? Motorized carriage with electronic control 2-32 m/min

Agie Wire Cutting EDM Machine High-Precision Wire EDM System This 2018 Agie AC Progress VP3 represents top-tier wire electrical discharge machining (EDM), offering flawless contour accuracy and superior surface finishes for critical components. Technical Details ‍ 1. Machine identification data Name: Wire Cutting EDM Machine (Electric Discharge Machining) Manufacturer: Agie Model: AC Progress VP3 Machine number: 591.3.020.530 Year of manufacture: 2018 2. Operational parameters Travel (X / Y / Z): 500 x 350 x 426 mm Travel (U / V): ± 70 mm Max. taper angle: 30° at 100 mm height Max. workpiece dimensions (X / Y / Z): 1050 x 650 x 420 mm Max. workpiece weight (without water): 400 kg Max. workpiece weight (with water): 800 kg Wire diameters: 0.15 – 0.33 mm Generator: IPG-VPC Max. cutting rate: > 500 mm²/min Best surface roughness: Ra 0.2  ...

Agie Wire Cutting EDM Machine Precision Wire Cutting EDM Machine A staple in advanced toolmaking, this 2006 Agiecut Progress V3 delivers highly reliable and accurate wire EDM capabilities for intricate metal cutting applications. Technical Details ‍ 1. Machine identification data Name: Wire Cutting EDM Machine (Electric Discharge Machining) Manufacturer: Agie Model: Agiecut Progress V3 Machine number: 333.010.008 Year of manufacture: 2006 Control: AGIEVision 5 2. Operational parameters Working area (X / Y / Z): 500 x 350 x 426 mm U-V Axis: +/- 30° / +/- 70 mm Max. workpiece dimensions (L x W x H): 1,050 x 650 x 420 mm Max. workpiece weight (with/without Dielectric): 800 kg / 400 kg Resolution of axes: 0.0001 mm Positioning speed: Up to 3 m/min Clamping system: Universal beams with fixing holes Cutting wire diameter: 0.2 – 0.33 mm  ...

This AGIE Agiecut VERTEX 3 Erosion machine was manufactured in the year 2006 in Switzerland and has 37021 erosion hours. It is equipped with an Agievision 5 Software version 07.08.01 control unit.

Edgebander manufactured in 2010. This HOMAG KAL 210 Ambition 2264 is a used single-sided edge banding machine. If you are looking to get high-quality edge banding capabilities, consider the HOMAG KAL 210 Ambition 2264 machine we have for sale. Contact us for further details.

This 3-axis AgieCharmilles Robofrom 20 die-sinking EDM machine was manufactured in 1996. It features a maximum electrode weight of 25 kg and a table size of 397 x 300 mm. The machine has an impressive axis travel of X=300 mm, Y=250 mm, and Z=250 mm. If you are looking to get high-quality die-sinking capabilities, consider the AgieCharmilles Robofrom 20 machine we have for sale. Contact us for further details.

This 5-axis Sodick AQ535L wire EDM machine was manufactured in 2007. It features an X-axis travel of 550 mm, Y-axis travel of 350 mm, and Z-axis travel of 300 mm. The work table size is 790 x 500 mm, with a maximum workpiece weight capacity of 800 kg. If you are looking to get high-quality wire EDM capabilities, consider the Sodick AQ535L machine we have for sale. Contact us for further details.

This 5-axis Sodick AQ537L wire EDM machine was manufactured in 2005. It features an X-axis travel of 570 mm, Y-axis travel of 370 mm, and Z-axis travel of 350 mm, along with a work table size of 806 x 496 mm. With a maximum workpiece weight of 1000 kg, this machine is designed for precision cutting. If you are looking to get high-quality wire EDM capabilities, consider the Sodick AQ537L machine we have for sale. Contact us for further details.

Excellent condition - Fully operational - Loading / Transport possible! maximum workpiece thickness 45 mm minimum workpiece length 220 to 350 mm maximum edge material height 50 mm minimum edge material length for fixed dimensions 330 to 400 mm maximum edge material protrusion top and bottom 2.5 mm Edge material protrusion front approx 10 to 20 mm Edge material rear protrusion ca 10 to 30 mm . minimum workpiece width 90 mm minimum workpiece thickness 10 mm maximum length with extension arm 4269 mm Working length with boom 4269 mm Depth with roller plates 1425 mm Working table height 888 mm Working width with support pushed in 210 mm Working table width with support rail extended 680 mm With milling unit

This 4-axis AgieCharmilles Roboform 54 was manufactured in 2000. It features an X-axis travel of 500 mm, Y-axis travel of 350 mm, and Z-axis travel of 256 mm. The machine can accommodate workpieces up to 850 x 650 x 256 mm and has a maximum workpiece weight of 400 kg. If you are looking to get high-quality die-sinking capabilities, consider the AgieCharmilles Roboform 54 machine we have for sale. Contact us for further details.

Description Filter Hose for Alko Mobil Jet 140 to 300 Material: Polyester, BIA Cat: M, antistatic, Weight 460 g/m² We manufacture every filter size! Prices, delivery times and payment terms on request. Telephone advice at: 05656-9239404

Manufacturer: ABB Type: CCV (IEC 60298 compliant) Function: Protection and medium-voltage network power supply ⚡ Electrical characteristics Rated voltage (your): 12 kV Withstand voltage at power frequency (Ud): 28 kV – 1 min Lightning shock withstand voltage (Up): 95 kV peak Rated Frequency (fr): 50 Hz Rated Current (Ir): 630 A Short-term ampacity (Ik): 21 kA Short Circuit Duration (tk): 3 s Partitioning class: PM (metallic) Ingress protection: IP2X Ambient temperature: -25°C to +40°C Internal bow type: AFLR (on request)

External RIP and Developer

Code: 0256 Brand: STEFANI Model: ACTIVA 1-73 - CE Standard Automatic edge bander with grinding unit for edges in wood, veneer, pvc, abs, furniture and various - CE Standard Technical data: Edge thickness min/max 0,6-25 mm Coil material thickness min/max 0,3-3 mm Min/max panel height mm 10-60 Min panel width mm 70 Automatic pressure bar lifting Feed speed variator 8-30 mt/min Controlled guide before grinding Group of 2 grinders for panel grinding - N° 2 motors - Suction mouth diameter 120 mm Glue tank pre-melting unit Gluing unit: N° 1 pneumatic pressure roller diameter 180 - N° 3 pneumatic pressure rollers diameter 100 Soundproof protection cabin Tilting end cutting unit - Diameter of blades mm 140 - Rpm 12000 Trimming unit: Tool diameter mm 80 - Motors Kw 0,75 - Rpm 12000 Bevelling unit : Tool diameter mm 80 - Motors Kw 0,75 - Rpm 12000 Rounding unit with 4 mo ...

Optima/alpha pack complete production and packaging line for ELISA test kits, comprising Optima ImmuCoat coating system for the manufacture of 96-well microtitre plates for ELISA tests, B&R machine control with touchscreen control panel. Operation and process steps: 1. Feeding and preparation: Microtiter plates are automatically removed from destackers and transferred to the transport system. 2. Deionisation: To eliminate static charges, the plates are deionised, which is crucial for uniform coating. 3. Coding: Each plate is assigned a unique serial number, which is recorded in the system control for quality control purposes. Keyence printer. 4. Coating: The system precisely dispenses the biological components (such as antibodies or proteins) into the wells of the 96-well plate. The system can coat up to 1.200 plates per hour. 5. Product selection: The system allows the use of up to 12 b ...

Wire cutter Type: AU-1000 iA Manufacturer: ACCUTEX Year: 2015 Max size of the work piece:1330 x 900 x 595 mm Max. weight of the work piece: 5000kg X/Y/Z/U/V 800 / 600 / 400 / 150 / 150 mm Diameter of the wire: 0.15-03 mm Continuously controlled 4 axes X, Y, U, V Drive system using AC servo drives Max. cut cone ± 22.5 °/ 100 mm Accuracy class of ball screws rpm C1 - the highest Filter system capacity l Main tank 1630 l, secondary tank (Z=600) 1280 l Max. cutting speed mm²/min 250 Dielectric conductivity measurement Auto – 5  200 k-cm Auto dielectric temperature measurement with an accuracy of ± 1°C Input kVA 15 Weight of the machine: 8500 kg Windows CE control system product for vertical alignment paper filter 2 pcs deionization resin - 1st filling container for deionization resin upper and lower nozzles – 2 pcs diamond guide 2 pcs tool for removin ...

Generator: Agiepuls 60 HSF, travel X/Y/Z: 350mm/250mm/350mm, table dimensions X/Y: 600mm/450mm, max. workpiece weight: 400kg, max. workpiece dimensions X/Y/Z: 840mm/600mm/250mm, max. electrode weight: 100kg, machine dimensions X/Y/Z: approx. 2450mm/1750mm/3000mm, weight: approx. 4000kg. The machine has PCB damage. Documentation available. An on-site inspection is possible.

Alfa Laval M/TL Series Plate Heat Exchangers Condition: unused Manufacturer: Alfa Laval Lund AB (Sweden) Type: M/TL Series Gasket Plate Heat Exchanger This type of heat exchanger is often used in: - Food and beverage industry (milk, beer, juice, etc.) - the chemical and pharmaceutical industry - HVAC systems (district heating/cooling) - Industrial process plants for heat recovery and energy optimisation

electric motor, three-phase motor -Manufacturer: ATB Nordenham, explosion-proof electric motor -Type: CD 90L2-8 -Power: 0.55 kW -Speed: 690 rpm -Shaft: Ø 14 x 30 mm -Design: B14 -Protection class: IP55 -Terminal box: EAR 80 -Number: 2x motors available -Price: per piece -Dimensions: 345/176/H270 mm -Weight: 32.1 kg/pc.

This 3-axis Sodick AL60G die-sinking EDM machine was manufactured in 2021. It features a generous X-axis travel of 600 mm, Y-axis travel of 420 mm, and Z-axis travel of 370 mm. The machine has a maximum workpiece weight capacity of 1,500 kg and a work tank fluid level range of 150 to 400 mm. If you are looking to get high-quality die-sinking capabilities, consider the Sodick AL60G machine we have for sale. Contact us for further details.

This 5-axis Sodick ALC800G Premium was manufactured in 2021. It features an X-axis travel of 800 mm, Y-axis travel of 600 mm, and Z-axis travel of 500 mm, providing a versatile working area with a maximum workpiece weight of 3,000 kg. If you are looking to get high-quality wire EDM capabilities, consider the Sodick ALC800G Premium machine we have for sale. Contact us for further details.

Travel X/Y/Z: 350mm/250mm/256mm, travel U/V: +/-70mm, max. taper angle: 30°, max. height: 100mm, rapid traverse: 900mm/min, max. workpiece dimensions X/Y/Z: 750mm/550mm/150mm, max. workpiece weight: 200kg, max. threading height: 250mm, wire tension: 25N. Machine dimensions X/Y/Z: approx. 1650mm/2050mm/2250mm, weight: approx. 2600kg, control: Agievision. Documentation available. An on-site inspection is possible.

Net weight: 1940 kg, power: 13.4 kW, with hydraulic. Loading shovel and 2 pcs. backhoe bucket, dismissed. Operating hours: 3500 h

permissible. Total weight: 12,000 kg, axle load: 8000 kg each

Excellent condition - Fully operational - Loading / Transport possible! Positioning resolution : 0.5 a Tool changer Number of electrodes places: 4 Max. electrode dimension : 75 mm Max. electrode length Electrode length : 280 mm Max. electrode weight : 5 kg Max. total weight : 20 kg The tool changer runs sluggishly and would have to be checked. Machining table Usable area : 800 x 600 mm Load capacity : 1000 kg Number of T-slots for mounting : 5 pcs. Dimension of the grooves : 12 mm Working container Max. internal dimensions : 1200 x 800 x 500 mm Capacity : 475 L Fuse box Cabinet dimensions : 900 x 750 x 1950 mm Cabinet weight : 300 kg Protection class of the cabinet : IP 32 Processing head with high rigidity Max. electrode weight : 100 kg Insulated interface : 250/650 mm

Year of manufacture: 2015 | Key Features: | Manufacturer: Mitutoyo Corporation | Model: PJ-A3000 | Projection Screen: Ø 315 mm | Magnification: 10× standard (optional 20×, 50×, 100×) | Measurement Accuracy: ±0.001 mm (XY resolution) | Table Travel: Various measuring ranges depending on model (up to 200×100 mm) | Illumination: Halogen lamp 24 V / 150 W | Functions: Digital XY readout, angle measurement, RS?232C interface | Max. Workpiece Height: approx. 92.5–123.5 mm | Special Features: Telecentric optical system for distortion-free projection, rotatable table, manual focusing | Condition: Used, tested, and fully functional. | Applications: Ideal for metal and plastic processing, training, laboratories, and precision measurements. | The machine can be inspected under power by appointment. | Technical specifications are subject to change, errors and prior sale reserved.

This vertical plate heat exchanger from GEA Ahlborn is designed for efficient temperature exchange between two liquids. It is made of stainless steel and is designed for a permissible pressure of 16 bar and a permissible temperature of 100 °C, making it suitable for a wide range of industrial and brewing applications. The unit has a robust base construction with supports that ensure stability during operation. With dimensions of 1.55 m (L) × 0.45 m (W) × 1.50 m (H) and a weight of 1,500 kg, it offers a compact yet robust solution for heat transfer needs. Our team at VBW Asset Trade will be happy to answer your questions., Permissible pressure: 16 bar , Permissible temperature: 100 °C, Length: 1,55 m, Width: 0,45 m, Height: 1,50 m, Weight: 1500 kg, Material: stainless steel, Position: vertical, Base construction: mainstays

This plate heat exchanger from APV offers efficient and reliable heat transfer with a capacity of up to 240 hl/h in two stages. With a generous heat exchange area of 134 m² and a robust design for operating pressures up to 23 bar, this unit is well suited for demanding applications in breweries and the beverage industry. Thanks to its solid construction and compact design, it can be easily integrated into existing systems while ensuring high thermal performance and energy efficiency. An excellent and cost-effective solution for wort cooling, product heating, or other process applications. Our team at VBW Asset Trade will be happy to answer your questions., Capacity: 240 hl/h 2 stages, Heat exchange area: 134 m² plate tracery min. 880 mm, max. 910 mm, actual 885 mm, Operating pressure: 23 bar, Length: 2000 mm, Width: 700 mm, Height: 2000 mm

horizontal tubular heat exchanger, Additional title: for CIP or hotwater, Media flow: 500 hl/h, Working pressure orifice baffle: 10 bar, Working pressure piping: 8 bar, Working temperature piping: 200 °C, Length: 1,05 m, Width: 0,6 m, Height: 1,1 m, Weight: 300 kg

Two-stage plate heat exchanger. First stage - Heating: hot water / product Product inlet approx 61-62°C, outlet approx 72°C, flow rate 600 hl/h; Hot water inlet approx 72,5°C, flow rate 750 hl/h Second stage - Regeneration: product / product Product inlet approx. 0-4°C, product outlet approx. 61-62°C, flow rate 600 hl/h; Product inlet approx. 72°C, product outlet approx. 11-14°C, flow rate 600 hl/h, Additional title: 2-stage heat exchanger, Capacity: 600 hl/h, Hot water: 750 hl/h, Operating pressure: 21 bar, Operating temperature: 100 °C, Length: 2,15 m, Width: 0,95 m, Height: 2,15 m, Weight: 5000 kg, Material: EPDM HT / NBR / 1.4439

Technical Specifications & Performance Data The Mondo & Scaglione Used Case Erector from 2005 is a reliable, second hand solution engineered for continuous-duty industrial packaging environments. Purpose-built to erect and square corrugated cases for downstream packing of PET bottles, glass bottles, and aluminum cans, it supports a broad spectrum of beverage production lines handling water, juice, beer, wine, and more. Manufacturer: Mondo & Scaglione Year of manufacture: 2005 Category: Case Erector Nominal speed: up to 1,500 boxes/hour Closure configuration: Single closure station (Closure: 1) Condition: In storage Safety features: Included (guards/interlocks typical for class) Documentation: Manuals available Container ecosystem: Supports lines for PET, glass, and aluminum containers Typical application: Beverage production (water, juice, beer, wine) and general used bottling line opera ...

Technical Specifications & Performance Data The Used Case Erector Acmi 2009 Formacartoni is a robust solution for industrial packaging environments and beverage production lines seeking reliable case forming upstream of filling, capping, labeling, and packing operations. Designed to support high-output facilities, it integrates easily into a used bottling line or a mixed second hand installation handling PET, glass, and aluminum can products. Manufacturer / Model: ACMI Formacartoni Year: 2009 Category: Case Erector Nominal line compatibility: up to 8,000 bph line speeds (case output depends on pack configuration and case count) Condition: In storage (preserved/mothballed) Dimensions (W x L x H): 3200 x 1500 x 2050 mm Electrical: 400 V, 50 Hz, 5.5 kW Safety: Safety features included (guarding and interlocks) Documentation: Operator and technical manuals available Suitable for forming regu ...

Used Case Erector Mondo & Scaglione 376 / C up to 23 box/min This Case Erector not only forms cardboard boxes of the “American” type but also ensures high efficiency and reliability. Additionally, it seals the bottom of each box with hot melt glue, and, most importantly, it processes up to 23 boxes per minute. Therefore, it is perfect for production lines that demand both precision and speed. Carton Magazine and Carton Transfer Carriage First, the machine features a horizontally mounted carton magazine at the lower rear, which optimizes space and provides easy access for loading. Furthermore, the multifunction carton transfer carriage picks, opens, and transfers cartons using an electromechanical control system. As a result, this setup ensures precise, continuous operation and significantly reduces downtime during format changes or adjustments. Flap Closing and Glue Applicati ...

Used filling line for edible oil up to 1800 bph Introduction The filling line for edible oil up to 1800 bph represents an advanced technological solution in the bottling sector. This system, branded Almanah Alman, guarantees efficiency and reliability essential for modern production needs. Capacity and Dimensions Equipped with a production capacity of 1800 bottles per hour for 1 liter PET containers, this line stands out for its high productivity. The overall length of the line is 6.3 meters, an important detail for planning the installation space in its warehouse. Filler Specifications in the Filling Line Used for Edible Oil The heart of Filling Line is the 18-valve filler, which operates through a pressure filling system. This method ensures rapid and efficient distribution of the product in the filling line for edible oil. Which ensures the maintaining, integrity and quality of the ed ...

EQUIPMENT FOR GEOTECHNICAL AND ENVIRONMENTAL INVESTIGATIONS Original Gouda 20 ton static penetrometer for CPT tests, with mechanical tip and 50 operating rods mounted on Mercedes Benz Unimog Mod. U 404.0 Year 1972 Km 32.272, Mercedes-Benz 6 cyl. No. 130925 / 10 / 000070 DPSH heavy dynamic penetrometer for SCPT testing, hydraulic automatic release, vice with rod puller, 50 and 75 kg impact masses, with 15 rods Hydra Mini series portable hydraulic auger on wheels for surface environmental coring, with 250 kgm hydraulic gearbox and 1.00 m useful stroke

Pressure:080 t throat:380 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:472 mm table surface area:840 x 610 mm table height over floor:800 mm passage to the back:520 mm ram surface:650 x 400 mm ram adjustment:70 mm power capacity:7,5 kW weight:6,9 t Dimensions (WxDxH):1,1 x 2,15 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic

pressure:080 t throat:360 mm stroke:8 - 112 mm no. of strokes:78 /min distance table/ram, max. stroke up, adjustment up:467 mm table surface area:900 x 650 mm hole in the table:250 mm table height over floor:800 mm passage to the back:330 mm ram surface:650 x 400 mm ram adjustment:80 mm power requirement:11,0 kW dimensions (WxDxH):1,2 x 2,2 x 2,9 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanisch

pressure:100 t throat:375 mm stroke:20 - 125 mm no. of strokes:30 - 80 /min distance table/ram, max. stroke up, adjustment up:515 mm table surface area:900 x 635 mm hole in the table:280 mm table height over floor:800 mm passage to the back:570 mm ram surface:700 x 450 mm ram adjustment:80 mm power requirement:15,0 kW weight:8,0 t dimensions (WxDxH):1,5 x 2,4 x 3,5 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic

pressure:160 t throat:480 mm stroke fix:fix 180 mm no. of strokes:25 - 70 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1100 x 900 mm Hole in the table:450 mm table height over floor:900 mm passage to the back:700 mm ram surface:900 x 600 mm ram adjustment:144 mm power requirement:30,75 kW weight:15,3 t dimensions (WxDxH):2,0 x 2,4 x 3,75 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic, Desch overload protection in ram:hydraulic ram counterbalance:pneumatic

pressure:315 t throat:480 mm stroke:20 - 190 mm no. of strokes:36 + 45 /min distance table/ram, max. stroke up, adjustment up:615 mm table surface area:1400 x 880 mm hole in the table:250 mm table height over floor:800 mm passage to the back:950 mm ram surface:850 x 630 mm ram adjustment:125 mm power requirement:33,0 kW weight:30,0 t dimensions (WxDxH):2,0 x 3,0 x 4,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic overload protection in ram:hydraulic stroke adjustment:semi-automatic ram adjustment:motoric ram counterbalance:pneumatic

Pressure:080 t throat:345 mm stroke:20 - 160 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:495 mm table surface area:920 x 610 mm table height over floor:800 mm Hole in the table:280 mm passage to the back:670 mm ram surface:650 x 400 mm ram adjustment:50 mm power capacity:10,0 kW weight:7,7 t Dimensions (WxDxH):1,5 x 2,2 x 3,15 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulic ram adjustment:motoric

Complete system installed in 1997 - still in production - Avantra 44S with 3600 dpi - Online Rapiline for Avantra44 - Collecting basket, cable, everything with The whole system was under maintenance contract, is complete tested and cleaned Available: in production
