Welding Robots used for sale (16)

Cell with welding robot ABB IRB 1400, table 2 pallets Built: 2001 Control: CNC ABB Country of origin: Sweden Max arm area: 1 440 mm Max payload: 5 kg Welding source: KEMPPI 520 R Power from the welding source: 520 A

ABB IRB 1400 M98 – Welding Robot General data: Manufacturer: ABB Model: IRB 1400 M98 Serial number: 156368 Year of manufacture: 1999 Weight: approx. 300 kg Dimensions (L x W x H): approx. 3500 x 2000 x 2500 mm Condition: Functional Description: Industrial welding robot ABB IRB 1400 M98 designed for automated welding applications. The robot ensures high precision, repeatability, and efficiency, making it suitable for industrial production environments. Auction-ID: A7-45351-48

Inv. Num. : 9046 Type: ES 200D Producer: Motoman Created: 2010 Parameters: Maximum arm reach: 2651 mm Number of axles: 6 pieces Maximum load capacity: 200 kg Machine weight: 1130 kg

ABB PS 90/6-57-P-LSS-4280 – Welding Robot General data: Manufacturer: ABB Model: PS 90/6-57-P-LSS-4280 Year of manufacture: 1999 Serial number: 002.8367660 Weight: approx. 300 kg Dimensions (L x W x H): approx. 3500 x 2000 x 2500 mm Description: Industrial welding robot from ABB designed for automated welding applications. The system enables precise and repeatable welding operations, improving productivity and consistency in manufacturing processes. Auction-ID: A7-45351-46

KAWASAKI BA006L welding robot was built in 2019 in China by Kawasaki Precision Machinery (Suzhou) Ltd. The machine designed for arc welding of workpieces is distinguished by its robust arm, high precision and reliability. Each of the 6 axes is driven by powerful servomotors that guarantee excellent movement speed and dynamics. All cabling, on the other hand, is routed inside the through-hole wrist to minimise the wear and the possibility of cable interference with peripheral devices. The KAWASAKI 6-axis robot weighs 160 kg. KAWASAKI BA006L works with a two-axis, electrically driven welding positioner. The device rotates and tilts workpieces during the process, enabling the welding of even the most complex shapes. Both axes are controlled continuously from the robot controller. The robotic welding station is fully complete and consists of the following components: – robot arm: KA ...

current capacity: 13,10 kVAnumber of controlled axis: 6 Payload: 16,00 kgRobot: REIS - SRV16L A1 - axis: 120 °A2 - axis: 195 °A3 - axis: 270 °A4 - axis: 360 °A5 - axis: 246 °A6 - axis: 720 °Welding manipulator: REIS - RDS26 workpiece weight: 2.600 kgRotating speeds: 50 °/sek.table rotating: 360 °table swivelling +/-: 180 Gradslewing speed: 15 °/sek.welding unit: FRONIUS wire dia.: 0,80 - 1,60 mmWire speed: 0,50 - 22,00 m/minControl: total power requirement: 20,00 kWweight of the machine ca.: 18,00 tdimensions of the machine ca.: 10,00 x 4,00 H4,00 m2-station welding cell with- REIS SRV16L vertical articulated arm welding robot- RobotStar V control unit- 2x REIS RDS26 welding turntable- Welder FRONIUS TransPulsSynergic 5000 with cooling unit- Wire-feed-unit FRONIUS 4R/W/E RoboterThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8914 Type: MA 1400 - DX 100 Producer: Yaskawa Created: 2012 Parameters: Maximum arm reach: 1434 mm Number of axles: 6 pieces Maximum load capacity: 3 kg Machine weight: 130 kg

current capacity: 25 kVAnumber of controlled axis: 6 workpiece weight: 10 kgweight of the machine ca.: 1,55 tYear of construction 2020 demonstration machine, as newEasy ARC 01.02 FD-B6 Welbee P500L welding robot stationMIG / MAG / water-cooled / torch RTW5000H / welding robot type FD-B6with welding table 2000x1200mmHole diameter 28 mmThe mobile welding cell for the craft businessSetting range MIG / MAG 20 - 500 ASteplessly adjustable switching levelsDuty cycle at max.current 40 ° C 50%Current at 100% ED 40 ° C 410 AWire feed speed 0 - 22 m / min The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8913 Type: IRB 1600/1.45-8/M200 Producer: ABB Created: 2013 Parameters: Maximum arm reach: 1450 mm Number of axles: 6 pieces Maximum load capacity: 8 kg Machine weight: 250 kg

Robot welding cell incl. positionerHydraulic 3D welding table ABB max. workpiece weight 2 tons and max. diameter 1400 mmRobot IRB 4600 M2004 Welding torch system Wire Select 2.0-Vers.LSQ5/Q80 with 2-fold wire feedThielmann gas nozzle cleaning deviceProtective housing with door for robot welding cell

Inv. Num. : 6169 Type: Motoman DX 100 Producer: YASKAWA Created: 2011 Parameters: Switch-on hours: 12800 h Operating hours: 6000 h Axle number: 6 Max. horizontal reach: 1717 mm Min. vertical reach: 3063 mm Maximum load: 20 kg

Inv. Num. : 8857 Type: IRB 6400 M98 Producer: ABB Created: 2003 Parameters: Maximum arm reach: 2400 mm Number of axles: 6 pieces Maximum load capacity: 120 kg Machine weight: 2030 kg

Inv. Num. : 8814 Type: IRB 2600 Producer: ABB Created: 2014 Parameters: Operating hours: 5162 h Maximum arm reach: 1650 mm Maximum load capacity: 12 kg Machine weight: 150 kg

Inv. Num. : 8813 Type: IRB 2400 Producer: ABB Created: 2011 Parameters: Hours: 22152 h Maximum arm reach: 1500 mm Maximum load capacity: 10 kg Machine weight: 150 kg

PANASONIC TL-1800 GIII welding robot was built in 2021 in Japan by Panasonic Smart Factory Solutions Co., Ltd. The machine, distinguished by its high reliability and ease of operation, is an excellent choice for precision welding of workpieces using the TIG method. Its slim design, combined with the large range of arm movement, allows free operation in all positions, even in hard-to-reach places. The TL 1800 robot arm is offered together with equipment, which includes a controller, a portable control unit and a TIG welder. The total weight of the machine is 215 kg. Technical specifications of the PANASONIC TL-1800 GIII robot - number of axes: 6 - maximum payload: 8 kg - maximum arm reach: 1801.8 mm - robot axis movement range axis 1 (rotating trunk): ± 170° axis 2 (upper arm): -90° / +165° axis 3 (forearm): -80° / +210° axis 4 (rotating wrist): ± 270° axis 5 (bending  ...

Inv. Num. : 8259 Type: S5-A701S Producer: EPSON Created: 2010 Parameters: Control system: EPSON RC 180 Maximum arm reach: 786 mm Axle number: 6 Machine weight: 36 kg
