used Sorting plants for sale

Small vibrating sieve with two decks for three fractions. The diameter of the sieve inserts is 400 mm. This includes a bet with balls that keep the screen insert clean from below. This is suitable, for example, for the screening/classification/quality assurance of copper granules (contamination by plastics or aluminium are sifted) or for the re-treatment of plastic granules from the cable recycling. The sieve is located in our demo pool and is little needed.

Polymer plant incl. motors, tanks and agitators, etc.

TECHNICAL SPECIFICATIONS Manufacturer: DOPPSTADT Designation: Solids separator Design: Semi-mobile, hook lift system Type: GT 130 A Year of construction: 2019 Release medium: water Adjustable incline: up to max. 23° Drive type: Hydraulic Weight: 9,000 kg Transport dimensions (length/width/height): 7,346 x 2,500 x 2,921 mm SPECIFIC COMMENT - Machine for separating mixtures of materials made of buoyant and non-buoyant materials by means of water - Low operating hours - Robust and low-wear design of the machine - Compact transport dimensions as well as easy transport by hook lift truck

Technical data 3-deck ballistic separator:Manufacturer Hartner Maschinenbau GmbH & Co. KG, GermanyType Paper-SortYear of manufacture 2009Angle of inclination 15Throughput capacity with paper approx. 15 t to max. 25 t/hour, depending on materialDimensions of the three ballistic separator segments incl. steel frame and maintenance platform approx. 15,080 x 4,910 x 6,980 mm (l x w x h)Dimensions of the individual ballistic separator segments, without steel frame 5,027 x 3,465 x 2,980 mm (l x w x h)Height of drive axle above ground from infeed conveyor 5,960 mmDimensions of discharge conveyor belt under the ballistic separator 13,457 x 2,506 x 1,561 mmUsable width of discharge conveyor belt 1,950 mmFunctional description:Screening is carried out according to the principle of size sorting. Due to the screen opening and rotation speed can be adjusted to screen out cardboard as well as other im ...

Air-separator for hard material, drum diameter x width: 1,400 x 1,200 mm, feeder 1,000 x 1,500 mm with vibrator, blower with approximately 7,000 cbm flow, including steel-frame, machine is to separate heavy material from light one

Technical data IFE cascade screens (vibrating waste screens):Manufacturer IFE Aufbereitungstechnik GmbH, AustriaType SM 2400 x 5000 F - UW30Year of construction 2009Drive motor 22 kWRated current 43 AScreen dimensions overall 5,000 x 2,400 mm (l x w)Dimensions of individual sieve segment 950 x 800 x 130 mm (l x w x d)Screen hole grid 150 x 125 mmLength of screen fingers (steel tubes in front of the screen segments) 400 mmSwing width max. 18.5 mmWeight approx. 6,600 kgPossible applications:The waste screen is suitable for use in plants for sorting household waste, commercial and industrial waste, paper and cardboard, scrap metal and electrical waste. Blockage-free screening with the most difficult feed materials, with high throughput capacity, no pigtail formation with oversize particles, loosened oversize particle discharge over the entire screen width and no downtimes for screen cleanin ...

ID2842 Knott BSS 19 Evolution year/Bauahr 2017 2995 hours/hours Ballistic disc party Ballistic Disc Separator

As good as new plant for sale Air sifting for substitute fuel, mixed construction waste, bulky waste, household waste Facility can be visited by appointment! Few operating hours Subject to prior sale!

- Complete system - incl. conveyor belt width 2400 mm with NEW CONVEYOR BELT - Incl. discharge hood with separating parting - INCL. BLOWER FOR FOIL SORTING - incl. SOFTWARE UPDATE FROM PELLENC - incl. COMPLETE OVERHAUL IN OUR SPECIALIST WORKSHOP IN D-59329 WADERSLOH - incl. COMPLETE DOCUMENTATION - YEAR OF CONSTRUCTION 2015

- Complete system - incl. conveyor belt width 2400 mm with NEW CONVEYOR BELT - Incl. discharge hood with separating parting - incl. ADDITIONAL METAL DETECTOR - incl. SOFTWARE UPDATE FROM PELLENC - incl. COMPLETE OVERHAUL IN OUR SPECIALIST WORKSHOP IN D-59329 WADERSLOH - incl. COMPLETE DOCUMENTATION - YEAR OF CONSTRUCTION 2015

- Complete system - incl. conveyor belt width 800 mm - Incl. discharge hood with separating parting - incl. SOFTWARE UPDATE FROM PELLENC - incl. COMPLETE OVERHAUL IN OUR SPECIALIST WORKSHOP IN D-59329 WADERSLOH - incl. COMPLETE DOCUMENTATION - YEAR OF CONSTRUCTION 2015

TECHNICAL SPECIFICATIONS Manufacturer: SALA Description: Lamella thickener Type. LT 200-F5 Year of construction: 1992 Total volume: 86.3 cbm Drive Unit Type: SFL 20040 Working torque: 20,000 Nm Shaft speed: 0.4 rpm Gearbox Type: S.O.M. Planetary Gearbox Sheet thickness tank: 6 mm Flocculator: STAMO AB Flocculator power: 1.1 kW

- Non-ferrous eddy current separator type STEINERT - for the sorting of non-ferrous metals such as aluminium or copper - Belt width 1500 mm - incl. control cabinet - Condition outdated -ready for action

ID2836 Construction waste sorting plant / Bauschutt-Sortieranlage year/Year of construction 1995 Construction waste sorting plant, throughput capacity 60,000 kg/h mixed construction waste, 2500-3000 kg/year commercial waste, total 110 KW Sorting system consisting of: bunker conveyor Screening machine (cup screen) Chain conveyor for coarse material Palmiste Tape conveyor belt various chain conveyors Conveyor belts for fines and leftovers screening machine Palm Reading Tape (Ergobelt) Conveyor belt rev. and moveable Electromagnetic belt separator sorting booth Sifter System various conveyor belts sorting status compressor Additional heating for sorting cabin Construction waste sorting plant, throughput 60,000 kg/h mixed construction waste, 2500-3000 kg/year commercial waste, total 110 KW Sorting plant consisting of: Bunker conveyors Screening machine (cup scree ...

Overview of the equipment of a used sorting plant, year of construction 2009, with a sorting capacity of 25,000 t/yearFor sale is a complete used sorting plant for deinking paper, which can also be used for other materials. The plant consists of the following components:1 piece sorting cabin with an integrated office (control room), external dimensions 14,200 x 11,400 x 4,350 / 8,170 mm (l x w x h), with 3 sorting belts and 10 sorting places, air-conditioned (heated).1 piece ventilation system for the sorting plant with 17,600 m³/hour, manufacturer VTS Ventus, type VS-120-R-H/S1 piece infeed conveyor belt, right, no. 10, dimensions 7,360 x 1,200 mm, drive power 3 kW1 piece infeed conveyor belt, centre, no. 11, dimensions 7,360 x 1,200 mm, drive power 3 kW1 piece infeed conveyor, left, no. 12, dimensions 6,360 x 1,200 mm, drive power 3 kW1 piece sorting belt, long, right, no. 15, dimensi ...

Overview of the equipment of a sorting plant, year of construction 2009, extension 2015, with a sorting capacity of 25,000 t/yearFor sale is a complete sorting plant for deinking paper, which can also be used for other materials. The plant consists of the following components:1 piece feeding / dosing bunker with hydraulic moving floor and dosing drum, manufacturer Hartner, type Storage HAT1 piece 3-deck ballistic separator, manufacturer Hartner, type Paper Sort2 pieces overband magnetic separators, manufacturer IFE, type MEQL 1401 S-PS2 pieces cascade screens (vibrating screens), manufacturer IFE, type SM 2400 x 5000 F - UW302 pieces TiTech Autosort, manufacturer TOMRA Sorting GmbH, type TITECH AutoSort 4 (NIR1-VIS) (S-2800) (X-L), incl. accelerating belts1 piece sorting cabin with filter system, air-conditioned (heated), with 3 sorting belts and 10 sorting stations1 piece ventilation sy ...
