5 axis milling used for sale

Deckel Maho DMC 75 V Linear 5 axis machining center Simultaneous 5 axis Control Unit : HEİDENHAİN İTNC 530 Kinematic calibration Laser Prob X : 885 mm Y : 600 mm Z : 600 mm 30 magazine Table diameter : Ø 750 Turning diameter : 950 mm

Takisawa NEX-108Y CNC Lathe Y and C axis 11/7.5 Kw spindle engine Takisawa A2-6 4000 rpm spindle Chip conveyor Maximum turning length : 431,5 mm Turning diameter : 260 mm Fanuc control unit Machine is like new

Laser Prima Industrie mod. Platinum 1530 Year 2008 CNC Primach P20L Working hours about 25.000 Visible running.

Robot 6-axis ABB IRB 140 Year of construction: 2005 Control: IRC5

6-axis AC servo drive, servo controller, servo inverter, servo amplifier, servo controller, frequency converter, drive controller for robots FANUC type A06B-6105-H0003 No. V07Z08282 Input voltage: 200 - 240 VAC Rated power: 1.5 kW Number of axle outputs: 6 Output current: 6 x 13 A Total output current: max. 78 A Manual No.: B-81465 Standard: EN50178 Built-in PCBs: A16B-2000-0063/07D A16B-3200-0440/05C - Plexiglas cover not included Dimensions W x H x D 70 x 170 x 380 mm Weight 16.5 kg As good as new / unused in the opened original carton from stock dissolution; used

Max. working lenghts 3000mm Max working square 220x220mm Max. working diameter 450mm (when wood round) Stroke axis X 3800mm Stroke axis Y 460mm (plus 230, minus 230) Stroke axis Z 510mm Stroke axis Y2 360mm (turning) Stroke axis Y3 360mm (milling) Stroke axis Y4 360mm (sanding) Stroke axis B (rotary +/- 90°) Power: Axis A (rotary main motor) 22,2 kw 0-1500 upm Axis Y2 11kw 1000-4500 upm Axis Y3 11kw 1000-6000 upm Axis Y4 2,2 kw 3000 upm max. 24.000 upm Electrospindle (HSC) 12 kw max. 24.000 upm Toolchanger 6 positions HSK 63 F Total installed power 70 kw Weight approxm. 9,5 tons - Producer Intorex - Type TMC 3000 - Year of construction 2010 - Location Germany

Timing belt axle FESTO EGC-120-1154-TB-KF-0H-GK 556815 Working stroke: 1154 mm Carriage: 200 x 68 mm Flange (drive): 100 x 100 mm suitable drive motor - see GM892 ! used, checked ! Dimensions: 1600 x 175 x 115 mm

3-axis forward-reverse counter, digital display HEIDENHAIN VRZ 653 B ( VRZ653W ) 205 120 02 115 / 220 V AC 0.4 / 0.2 A for front panel installation: 260 x 200 mm New ! Dimensions: 280 x 155 x 210 mm Dimensions ( packaging ): 350 x 260 x 340 mm

Laser Salvagnini L5 FIBER 3 KLW Year 2011 with automatic stacker Unloading robots Visible in operation Available January 2024

Ref. -No.: 10356 Manufacturer: AGIE CHARMILLES Year of construction: 2007 Type of control: CNC Control: iTNC530 Country of origin: Schweiz X-Travel: 800 mm Y-Travel: 500 mm Z-Travel: 540 mm Main spindle speed range: 16000 RPM Table Dimensions (Lengthxwidth): 910x500 mm Table Load: Vmax = 500kg, 5m/min = 1100kg kg Number of T-slots: 5 Tool change time (chip-to-chip): 8 s Max. Tool Weight: 6 kg Max. Tool Length: 305 mm Max. Tool Diameter: 77 mm Tool change time: 6 s T - slot spacing: 100 mm Numbers Of Tools In Magazin: 24 Tool changer: Doppelarm, seitlich montiert Rapid Traverse X-Axis: 24 m / min Rapid Travel Y-Axis: 24 m / min Rapid Traverse Z-Axis: 20 m / min Further information: Addition: probe

Ref. -No.: 10022 Manufacturer: UNION Year of construction: 2001 Type of control: CNC Control: Heidenhain-Steuerung TNC 310 Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 1600 mm Z-Travel: 2000 mm Machine length: 6950 mm Machine width: 4685 mm Machine Height: 3885 mm Table Height: 1050 mm Spindle Diameter: 110 mm Spindle Taper: ISO 50 Table Dimensions (Lengthxwidth): 1400 x 1600 mm Faceplate speed: 5,6 - 224 RPM Spindle Speed: 5,6 - 1120 RPM Metric thread feeds: 1,25 - 56 mm Drive Capacity - Spindle Motor: 40 kW Weight Of The Machine Ca.: 25 t Bore Depth: W 800 mm Further information: with facing slide 13 inch thread feeds 1 1/8 - 28 Gg / 1 “ YOM: 1990/ Retrofit: 2001

Ref. -No.: 10036 Manufacturer: JOHNFORD Year of construction: 2009 Type of control: CNC Control: Fanuc Series 18i-TB Storage location: Halberstadt Country of origin: Taiwan Machine length: 9800 mm Machine width: 3695 mm Machine Height: 5292 mm Weight Of The Machine Ca.: 32,6 t amount of positions: 12 Bar passage: 165 mm Serial no.: TDF9007 Turning Length: 2000 mm Turning Diameter Over Bed: 1550 mm Swing Diameter Over Bed Slide: 1270 mm Longitudinal Travel (Z-Axis): 2000 mm Spindle Head: A2-15 Spindle Diameter In Front Bearing: 240 mm Spindle Bore: 185 mm Spindle power: 37/30 kW Cross Travel: 685 mm Spindle Speeds: 1000 RPM Rapid Travel Speed X-Axis: 10 m / min Rapid Travel Speed Z-Axis: 12 m / min Tool changer: 12 Pcs

Technical Details: - X axis working area: 5300 mm - Y axis working area: 1300 mm - Working Table Pod and Rail - Main Electrospindle power: 9 KW - Number of controlled axes: 5 axes - Total number of drilling spindles: 32 - Total number of tool changer positions: 8

FINN POWER PRIMA POWER EBe system Year 2011 4kw All-electric machine tower warehouse 10 levels punching machine with electric shear Loading and unloading robots Electric panel bender 2200 height 205 Available April 2024

Industrial Robot Reis Robot Cell with Traversing Axis Manufacturer: Reis Type: RV40 Year of construction: 2004 Cell consisting of: Robot Rice RV40 Tilt&Turn module RDK05 (500 kg) Traversing axis RLV25 Incl. spare parts package Without laser optics !

Axis control, electronic handwheel, control unit -The electronic handwheel was removed from a CNC machining center make: Hitachi Seiki type: HC400. Other spare parts available. -electronic handwheel for Hitachi Seiki type: HC400 -Dimensions: 170/120/H80 mm -Weight: 0.6 kg

Rotary axis drive, drive, limit switch -Manufacturer: Telemecanique -Type: ZCE01 -Number: 5x available -Price: per piece -Minimum purchase: complete -Weight: 0.05 kg

3-axis positioner with tool feed PAGUS 150 / 160 mm travel x: 150 mm travel y: 150 mm travel z: 160 mm manual adjustment by crank wheels ! tool carriage: 100 x 65 mm feed tool carriage: max. 60 mm adjustment by pneumatic cylinder ! base plate: 280 x 153 mm used, tested ! Dimensions: 470 x 460 x 560 mm

Sinumerik 810M GA3 Basket tool changer: 20 x SK30 Tool change under 2 seconds. Spindle Max: 10500 rpm Table size: 2x (660mm x 350mm) Axes travel: X= 550mm Y= 300mm Z= 425mm B= 360 degrees (4th-axis) Under rotary table on the left: Yes. Coolant unit with Knoll swarf conveyor. Weight: 4000Kg CRT screen was upgreaded to TFT. Equiped with 1x 4th axis

Apec G30/20 5 axis bridge machining center Simultaneous Travel: Feed rate: X axis travel 2000 mm X/Y/Z axis rapid traverse 60/60/40 m/min Y axis travel 3000 mm X/Y/Z axis acceleration 0.5G Z axis travel 1000 mm Cutting feed rate 1-20,000mm/min spindle nose to table surface 330-1330 mm Table: Spindle: (APEC MONO SUPPORTING HEAD) Table size 2,000x3,000 mm Spindle taper HSK 63A Table load 8000 kgs/m2 Spindle speed 24000RPM T-slot size 28 mm Spindle motor (S1) 25/30 KW ATC: Spindle torque (S1) 119/143 NM Capacity 20 pc 2 axis head A-Axis C-Axis Tool shank HSK 63A Rotation speed 30 rpm 30 rpm Max. tool weight 15 kgs Max. torque 760 Nm 800 Nm Max. tool dia. (w. adjacent tool) 150 mm Clamping torque 4000 Nm 4000 Nm Max. tool dia. (w/o adjacent tool) 180 mm Rotation angle ± 125∘ ±360∘ Max. tool length 300mm Others: Machine Weight 39000kgs (around) Mo ...

Number of axis : 4 8 Tool Holders 8 Right 8 Left Adjustable 16 Clamp 4 Ground Fixed Security Sensors Windows OS (Software Elucam) X : 6000 mm Y :845 mm Z : 620mm Spinder Speed 24000 11 kW Chip Drawers Available

Deckel Maho DMG HSC 55 Linear 5 axis simultaneous machining center Control Unit: Heidenhain iTNC530 2 pieces Hepa filter and dust collector system Tool holder : HSK50 Spindle power: 29 / 22 [kW] Spindle speed : 42.000 [rpm] X / Y / Z Axis: : 450 / 600 / 400 mm Tool magazine capacity: 120 Tool probe: Heidenhain laser

The VF-2TR is a versatile 5-axis machining center based on the popular VF-2 VMC platform. It provides full simultaneous 5-axis motion, or can position a workpiece to almost any angle for machining. X : 762 mm Z : 406 mm Z : 508 mm

DMG Mori DMU 50 Ecoline 5 axis machining center Machine is in good working condition 10,000 RPM DirectDrive engine Control Unit HEIDENHAIN TNC620 32 Sets of Magazines Tool measuring probe . Chip conveyor . Tool measuring probe . It has automatic track reset feature. It has been serviced by DMG service. Since we know the history of the machine, the previous operations are as follows. -B axis Brake changed -Z axis Ball Screw changed -Y axis Slide + Car ball screw has changed. -Y axis ruler changed. We have all the service records

CNC type: Inovance Power automation Number of axes: 5 X-travel: 230 [mm] Y-travel: 208 [mm] Z-travel: 117 [mm] Rapid movement speed X, Y, Z, A & C: 5000 [mm/min] Dimensions table: Ø 150. C axis angular travel: table revolution: 360 [°] Table orientation Axis A: +/- 120 [°] IBAG HF spindle Max. Spindle: 60000 [rpm] Spindle power: 2 [kW] Auto Automatic tool gripping: Yes Spindle attachment: Er type collet holder Number of tool magazine positions: 12 Blum tool length measuring probe Watering tank with pump: Yes Watering tank capacity: 10 [l] Supply voltage: 230 [V] Dimensions: 1100 x 800 x 1800 [mm] Weight: 540 [Kg] ADDITIONAL INFORMATION: x1 instruction manual x1 operating manual backup machine parameters Machine in very good condition, visible under power for testing on our premises, by appointment.

Mazak Integtex 200-III 5 axis simultaneous CNC Lathe 8 inch Capto 6 Holder 40 Sets Magazine Maintenance done : Chiller unit completely cleaned and maintained Capto holder draw bar system has been changed with original one Tool measuring probe has been changed

DMG CTX 510 Eco XZ and C axis CNC Lathe with live tools 7 live tools Working hour : 36015(Feb 2023) Control Unit : Siemens 810d shopturn Turning length : 1014 mm

Okuma TS-4000YS with C and Y Axis Running time : 7490 Cutting time : 4509 Double chuck C and Y axis Machine is from 2015 but installed in 2016​ Machine is in excellent condition Maximum turning length : 750 mm Maximum turning diameter : 370mm 12+12 turret Fanuc control unit Extras: ​Barload bar feeder(52mm) 4 unit live tool Cooling water pump Air gun system Part catch system Measuring tool for chuck TiwaP-I

The geminiNGM is the 5-axis CNC grinding machine for the serial production of cutting tools. Complete processing around OD and face, up to 300 mm cutting length, diameter up to 300 mm, maximum workpiece length that can be clamped 500 mm. Cutting tools such as end mills, ball nose cutters for mold making, high-performance drills, reamers and profile end mills are all part of the standard requirement. There are specific software packages, grinding processes and clamping systems for the production of shaper cutters with highly dynamic segmented hob grinding, the regrinding of gear cutting tools, end mills, shaper cutters and bevel gear cutters. CNC grinding of knives for the paper, foodstuffs and plastics industries, profile grinding, cylindrical grinding and surface grinding. Numerous accessories for the application spectrum and for increased productivity The machine is in g ...

Michael Deckel S 20 5 Axis CNC tool grinding machine Max. Wheel diameter : 150 mm Rotational speed : 1000-8000 rpm

Cartesian robot 5 axes brand antil 5, model arp 60 weight 1700 kg year 2002 motor 6.6 kW 400 V, works with compressed air at 6 bar of the working area 2000 1500, the robot measures 8100 mm width, 2000h height 3000 over length , Weight of the piece to be handled 50 kg, suitable for bending bulky panels, we sell for little use

Explanation MJT WD6 3D 4020 BLUE WATERJET 6 AXIS 4000X2000 MJT PK005000. HIGH PRESSURE PUMP 5000 BAR MJT KT000100. SAND TANK SM 004. ABRASIVE 80 GARNET Detailed information Sheet metal length Sheet metal width Number of heads Maximum standard steel thickness Working pressure 5000 bar CNC CNC tour Power 40000.0 W Sand recuperation ------------------- Length x Width x Height 3100.0 mm × 5225.0 mm × - Weight 1453.0 kg Active working hours Plug-in working hours Status new In Norman --------- Status packaged

Sparcatron HSW EDM fast hole driller Heidenhain control I bought it from major UK aero engine manufacturer (voltmeter and Ammeter removed by previous owner). 5 axis control Hoffmann EDM 4th 5th axis unit Machine operational 4,620 hrs use Set of machine manuals and diagrams Complete set of spare electronic panels and drives 300mm Z/electrode travel 0.3mm to 3mm Uses deionised water High pressure through electrode flushing Selling due to surplus to requirements/restructuring business Buyer to arrange decommissioning No loading facilities Ex works

5-axis machining center HG GRIMME GSF - MACHINING PLASTICS - RESINS - FOAM MACHINING PLASTICS - RESINS - FOAM machine MODEL GSF 20/10 - YEAR 2009: _ Ibag motor spindle HF80.2 A40 CIP, 40000U/min; 2.5/3.2kw, SKi _ manual tool measurement _ tool lift: height 725mm _ Work area dimensions: 24001200 _ store of 13 tools _ presence of an external HYFRA cooler _ Harmonic drive AG _ PLC: Siemens 840 D

Spinner U1530 Simultaneous 5 axis machining center Table diameter : Ø650mm B axis angle : -50°/+110° C axis : ∞360° Fixed table size: 920mmX540mm X axis : 1530mm Y axis : 530mm Z axis : 465mm +150mm(security distance) Siemens 840D SL

1x Linear robot Reis RL80-13 incl. 2 control cabinets absolutely mint condition Year of construction 2009 there are 2 robots on each beam, a two-axis robot and a three-axis robot the system is dismantled, complete with control cabinets the glass gripper and the Zimmermann & Schilp non-contact glass lifting system are not part of the range of products there are 2 of these double robot systems available incl. loading

BU62-60-30-B-003 built-in rectifier device BUS21-30/60-30-001

Dural Cnc-60 5 axis tube bending machine Machine never used before Max. Tube Diameter: Ø60 mm x 3 mm Max. Center Line Radius : 220 Max. Bending Angle: 190 Max. Tube Length: 2500 Max. Feeding Length With Mandrel (mm): 3700 Bending Speed (°/sec): 80 Feeding Speed (mm/sec): 1~800 Turning Speed (°/sec): 150 Max. Pressure: 160 Total Power (3 Axis) : 17.25 Kw Total Power (4 Axis) : 18 Kw Total Power (5 Axis): 24 Kw

DMG CMX 50 U 5 axis machining center X : 500 mm Y : 450 mm Z : 400 mm Machine is in good working condition

Spinner U-630 5 axis machining center X axis : 630 mm Y axis : 530 mm Z axis : 465 mm 3+2 axis Number of magazine : 32 Siemens control unit Renishaw laser measuring 40 bar through spindle coolant Filtration system

Traub TNS 65 D / 5-axis CNC lathe / control TX 8 D FOR COMPLETE TECHNICAL DATA, SEE "Data Sheets" E2j9tbm -Control - Type TX 8 D -C - Axis -Rod passage approx. 65mm -Hydraulic bar feed

Manufacturer Stama Model MC 734/M Year 2005 Price includes training for one day by the operators on site

Axile G8 5 axis machining center Machine is like new condition 48 ATC 20000 rpm X: 670 mm Y: 820 mm Z: 600 mm

SFY HA-5AX7B 5 axis vertical machining center HEIDENHAIN Control unit 18000 rpm speed 800x550x600 Fully simultaneous simultane

Huron EX10C 5-axis machining center Year 2001 Coolant 60 Bar Vibration sensor Blum laser probe x y z 1200 x 700 x 800mm

5-axis machining center Manufacturer: Deckel Maho Model: DMU 70 V

Brand: PKM Model: Tricept T 9000 V3 Year: 2006 23500 hours Siemens Sinumerik 840d CNC Movements: X=2700 mm, Y=2500 mm, Z=600 mm Spindle speed: max 18000 rpm HSK 63 spindle taper Spindle serial number 202130012 NB: The spindle has been completely overhauled in Germany (50 hours of operation since then) Automatic tool change Cooling System
