used Tube Bending Machines for sale

Max tube diameter 76 mm Max thickness 3 mm Max bending degree 180 Bending radius max 260 mm

Max. tube diameter 45 Bending capacity of thick walled tube 2 Arbor length 4.000 mm Equipped with: With dies

Bending capacity: Copper or brass tube: 54 x 4 mm Steel tube: 54 x 2 mm Stainless steel pipe AISI 304/316: 42 x 3 mm Hydraulic tube ST35: 54 x 4 mm Furniture construction tube: 54 x 3 mm Aluminium tube: 54 x 5 mm Gas pipe for piping: 1 1/2 " Maximum bending angle: 210° Engine power: 1,1 kW Voltage: 400 V Machine dimensions (W x D x H) without stand: 800 x 300 x 680 mm Approximate weight: 107 kg Scope of delivery: Bending segment 1/4 "G (Ø 13.72 mm) incl. counter rollers and race Bending segment 1/2 "G (Ø 21.3 mm) incl. counter rollers and race Bending segment 1 "G (Ø 33,7 mm) incl. counter rollers and race Bending segment 1 1/4 "G (Ø 42.25 mm) incl. counter rollers and race

Key data: 32 mm, 2 mm

Inv. Num. : 6997 Type: CMH 32 NC Producer: Cansa Generated: Parameters: Maximum tube diameter: 32 mm Maximum pipe wall thickness: 2 mm Maximum bending angle: 1900 st Power consumption: 4.4 kW Mandrel length: 2000 mm Max pressure: 120 bar Equipment: Hydraulic clamping Hydraulically controlled mandrel Hydraulic collet Colour touch screen Display of the current position of the pipe on the monitor (displacement and rotation) Display of the daily production on the screen of the control system Display error messages on the control system screen Saving created programs in the memory of the control system Ability to store up to 100 bending programs

Description: bending diameter range for bending strength modulus (RS=250N/mm2): ,1.3 m3 maximum pipe diameter: ,32 mm minimum pipe diameter: ,4 mm maximum pipe length for mandrelless bending: ,9999 mm minimum pipe length for bending with a mandrel: ,4450 mm  , single dimensions machine: 5200 x 1000 x 1200 mm control cabinet: ,600 x 900 x1900 mm  , set includes a safety mat, a SICK light curtain and tools but only those visible in separate photos (not mounted on the machine) offer does not include fences or other tools mounted on the machine  , please also have a look at the PDF document of this machine tube length max.: 9,999 mm, weight approx.: 2,000 kg, Approx. Onsite Dimension. (l x w x h): 5,200 x 2,000 x 1,900 mm

Crippa tube bending machine 955LE CNC tube CNC tube bender Ø30 x 2 mm (max. Ø55 mm) - Tube wall thickness – 2.0 mm (max. 2.5 mm) - Tube material - steel - Bend radius 72, 90, 100, 150 mm (max. 250 mm) - 3-axis bending It was never working – new, but the production year ca. 2015

Inv. Num. : 5725 Type: A 89 TNCB Producer: CSM Created: 2014 Parameters: Maximum bending angle: 180 pcs Total power requirement: 15 kW The largest profile: 60x60x6 mm bending radius in the middle of the tube: 350 mm bending radius in the middle of the profile: 300 mm Machine height: 1200 mm Machine length: 4700 mm Machine width: 1200 mm Machine weight: 2500 kg

Hand-hydraulic tube bending machine with hinged bending frame for pipe Ø: 3/8 - 3"

tube diameter: 2 x 3,91 mm STtube diameter: 60 x 4,5 mm GASrevolutions per minute: 2,5 U/minradius: min. 2 x D mmbar material - diameter: 35,0 mmtotal power requirement: 1,5 kWweight: 130 kgFurnishing:- mandrelless tube bending machine- mechan. Angle adjustment via dial- Tool holder: hexagonal 40 mm + 50 mm- Bending angle: 0 ° to 180 ° (max. 210 ° angle of rotation)- Bending radius: R10 to R270 mm- integrated chassis Bending segments on requestThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

tube diameter: 33,7 x 3,4 GAS mmtube diameter: 35,0 x 2,5 STAHL mmbending radius min.: R10 - R 190 mmtube diameter: 35,0 x 1,5 EDELST mmbending angle max.: 0 - 180 °tool taper: 6-kant 40 mmvoltage: 230 Vtotal power requirement: 0,9 kWweight of the machine ca.: 23,0 kgDescription :- MediBender 070 digital- with maximum bending power steel tube 35 x 2.5 mm- Excellent bending quality with very tight bending radii (from 2 x tube Ø) & Bending angles between 0 ° to 180 °- Easy handling- High accuracy and reliability- Quick tool change (within a few seconds)- Easy to transport- A huge selection of inexpensive standard tools (metric, gas inch, inch) Bending segments available for an extra charge STAHL bending segment R-82 G-1 ... 308 euros SLIDING SHOE brass 1 gas = 33.7mm ... 93 eurosThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bending radius min.: 10 - 300 mmBending Angle: 0 - 180 °0: 1,25 / 2,6 U/minMotor Capacity: 1,5 kWweight: 135 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Hydraulic press for crimping hydraulic pipes, equipped with all the necessary matrices for pipes from 0.5 to 50 mm, never used 0 hours packed in wooden crateweight approx.: 310 kg, Approx. Onsite Dimension. (l x w x h): 1,000 x 1,000 x 1,400 mm

Description: Hydraulic press for crimping hydraulic pipes, equipped with all the necessary matrices for pipes from 0.5 to 50 mm, never used 0 hours packed in wooden crateweight approx.: 310 kg, Approx. Onsite Dimension. (l x w x h): 1,000 x 1,000 x 1,400 mm

Description: Unused item: Power: ,380 v  ,dimensions: length 750 mm, width 500 mm, height 950 mm. Weight: 220 kg.  , Prensa para tubos hidráulicosweight approx.: 220 kg, Approx. Onsite Dimension. (l x w x h): 750 x 500 x 950 mm

tube diameter: 16 / 12 mmwall strength: 1,5 mmbending radius min.: je nach Rohr r2 bis 3 x d total power requirement: 1,2 kWweight of the machine ca.: 0,5 tShaft diameter 20 mm (standard)Max. Bending radius 60 mmMax. Bending capacity steel 12 x 1.5Stainless steel 12 x 1Copper soft 16 x 1Length feed (accuracy): with electrical drive 0.1 mmRotation (accuracy): with electrical drive 0.1 °Three-jaw chuck: YesVoltage NC 2 / NC 3: 230V / 400VThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 1050 mmplate thickness: 3,0 mmpre-bending: / required space: 2,08 x 0,7 x 1,25 mweight of the machine ca.: 410 kgSheet width: 1050 mmSheet thickness: 3.3 mmRoller diameter - top: 110 mmRoll diameter - un: 110 mmTotal power requirement: 1.1 kWMachine weight: 1080kgMachine width (mm): 850Machine length (mm): 1820Machine height (mm): 1150The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Pipe grinding / Burnishing - for sanding, satin finishing, and high-gloss polishing - large wrap angle of 270 ° for efficient work - Belt speed continuously adjustable - flexible and handy - perfect for railing construction Connection voltage 230Volt Power 800W Tape dimensions 40 x 760mmweight approx.: 4 kg, Approx. Onsite Dimension. (l x w x h): 60 x 220 x 180 mm

max. tube Ø: 6 - 48.3 mm Max. bending angle: 0 - 360° electr. Connection: 400 V, 1.8 kW Dimensions: 4200 x 1300 x 700 mm Weight: approx. 300 kg

Description: Machine number: 551 Power: 1000 W For pipes up to max. 35 mm diameter (Attention: see photographed technical plate as wall thickness plays a role) With accessories as shown in the picturesweight approx.: 40 kg, Approx. Onsite Dimension. (l x w x h): 700 x 600 x 400 mm

Unbek. Type, YOC ca. 1990, Revision 2002 Specifications: - Bending capacity at 45 kg / mm² up to approx. Ø 25 x 3 mm - Bending angle left + right selectable - Hydr. Double-sided bending function - Hydr. Delivery ° - Drive 400 V / 11 kW - Space requirement approx. W 1750 x H 2200 x D 2300 mm - Weight approx. 1600 kg - with - bending angle adjustment - Hydr. Voltage - Bending tools

Description: serial number: KOSPAR/2025/08/2017 working hours: power on time: approx. 5460 hrs. run time: approx. 3129 hrs. cutting time: approx. 1233 hrs.  , max. component diameter: ,160 mm min. component diameter: ,50 mm max. component length: ,1000 mm min. component length: ,100 mm max. spindle working speed: ,1400 rpm min. spindle working speed: ,600 rpm  , overall dimensions including with all conveyors: ,5500 x 5450 x 2400 mm  , transport dimensions: machine: ,5100 x 1700 x 2400 mm feeder: ,2200 x 1400 x 1300 mm receiver: ,2200 x 1400 x 1300 mm chip conveyor: ,4950 x 1000 x 1900 mm  , tools are not included in the offer except the standard set of 4 clamping jaws  , please also have a look at the videos and the PDF document of this machine weight approx.: 6,700 kg, Approx. Onsite Dimension. (l x w x h) ...

Offer 23246 Specifications: - Bending performance - Tube at 45 kg / mm² Ø 6 - 48 mm - Max. bending angle 180 ° - Max. bending radius 145 mm - Drive 400 V / 1.7 kW - Space requirement approx. W 900 x H 1100 x D 1400 mm - Weight approx. 600 kg -with - Tubular circular saw - Inside and outside pipe end burr device - Mandrel bending device approx. 2000 mm - hydr. Spine Retraction - various bending tools as shown

Description: Set of 5 manual tube bending machines Different sizes New and unused weight approx.: 40 kg, Approx. Onsite Dimension. (l x w x h): 900 x 500 x 500 mm

roll diameter: 50 mmroll diam. toproll: 155 mmroll diam. bottom roll: 155 mmtotal power requirement: 1,5 kWdimensions of the machine ca.: 1000x750x1400 mmweight of the machine ca.: 400 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

tube diameter: max 60 mmwall strength: 3 mmbending capacity pipes: 60 x 3 mmweight of the machine ca.: 2000 kgdimensions of the machine ca.: ca. 8000 x 1300 x 1200 mmincluding a lot of accessories6 mandrels, mandrel extension length 6000 mm and various bending tools (see photos)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Original MINGORI® Model OB40 - Mobile hydraulic tube bending machine with manually operated hand pump, suitable for bending pipes according to DIN, API and ASA standard, as well as coated PE-HD pipes. The machine works in the compression bending process. The greatest surmountable material resistance torque that can be overcome with the machine is about 28 cm³. Maximum bending force 18 tons Maximum bendable pipe diameter 88.9 mm Smallest possible bendable pipe diameter 17.2 mm Smallest bending radius depending on the radius of the bending punch from 46.5 mm to 330 mm Smallest bending angle 110° (this machine also available for bending angles up to 180°) Weight of the basic machine approx. 140 kg The machine is delivered in a storage chest – Dimensions of the chest approx. 102 x 32 cm x H 41 cm Weight basic machine 140 kg With electrically operated hand pump (as mo ...

Specifications Ø tubes / radius in mm: Ø 22 / 67 Ø tubes / radius in mm: Ø 10 / 36

OSTAS ROUND BENDING MACHINE TYPE SMR 1070 x 96 - Capaciteit 1070 x 3 mm - Conisch walsen - Wegdraaibare bovenrol - Voetbediening - Noodstop - Documentatie - 400V DUTCHMACH Metalworking machines ENSCHEDE - NETHERLANDS (3 km from the German border)

OSTAS ROUND BENDING MACHINE TYPE SMR 1070 x 96 - Capaciteite 1070 x 3 mm - Conisch walsen - Pathdraaibare bovenrol - Voetbediening - Noodstop - Documentatie - 400V DUTCHMACH Metalworking machines ENSCHEDE - NETHERLANDS (3 km from the German border)

CNC – controlled profile and tube bending machine for demanding and precise bending work with hollow sections and tubes. With our machines, aluminium – steel / stainless steel – various plastics such as PVC window profiles (depending on the application) can be bent with repeatable accuracy, regardless of the material. Depending on the equipment, our machines can also be used for three-dimensional bending work. Our REPANDUS models can work both horizontally and vertically. The models of the REPANDUS series work with a fixed upper roller and two movable lower rollers – this means that the straight end piece is relatively short compared to machine concepts with fixed lower rollers. The machine body is made of vibration-absorbing cast steel Shaft diameter of upper and lower rollers Ø 70 mm Shafts made of special steel – hardened and ground Bending force 190 kN Maximu ...

Description: Machine number 38003897weight approx.: 100 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 500 x 1,200 mm

Description: tube diameter: 75 mm consisting of three parts:  , 1/3 preparation table: dimensions: 4100 x 700 x 1000 mm 2/3 pipe finishing machine O25 (D=75 mm): dimensions: 6300 x 1000 x 1300 mm 3/3 receiving table: dimensions: 4100 x 600 x 1000 mm  ,please also have a look at the video of this machine weight approx.: 4,000 kg, Approx. Onsite Dimension. (l x w x h): 6,300 x 2,000 x 1,300 mm

Technical data: -Bending performance mandrel bending -maximum Rohrdrm at 45 kg / mm² Ã? 60.3 x 3.2 mm -min tube diameter 20 mm -maximum bending angle 180 ° -Bending direction left + right -Modulus 7,8 cm³ -min. bending radius mid-tube 40 mm -maximum bending radius mid pipe 200 mm -Lift length 5000 mm -maximum bending speed infinitely adjustable up to 3 U/min -Drive 400 V / 4 kW -Space requirement approx. B 1400 x H 1500 X 8000 mm -Weight approx. 1200 kg -Automatic. Bending angle before eligibility - hand positioning adjustment, creep speed control

Max pipe Ø: 60,3 x 3.2 mm maximum bending angle: 180 ° PIN length: 3000 mm Electr. Supply: 380 V, 8.6 kW space: 2400 x 5700 x 1500 mm weight: approx. 2500 kg

Description: SEC-100 TBC is an automatic collaring machine for making manifolds It includes a feed table with either 1- or 2-axis control The tube is fastened from its both ends to the SEC-100 TBC A suitable collaring program is selected from the PC controls and an automatic cycle is started SEC-100 TBC makes all the collars according to the selected program Manual process: • preset the elliptical pilot hole parameters manually. • install the preadjusted collaring head and the clamps accoridng to the tube size. • set the axial tube stop. • mount the tube in the clamps. • push the start-button and the cycle will start. Automatic cycle: • the clamps close and the EC-100 mills the elliptical hole. • when the hole is ready, the EC-100 unit retracts. • the S-100 unit begins the collaring of the tube and the trimming of the collar. • finally the EC-100 returns to the milling  ...

Specifications: - Bending performance - Pipe at 45 kg / mm² Ø 6 - 48 mm - Solid material up to approx. 30 mm - bending angle 180 ° - Bending radius 2 x D - Drive 400 V / 1.5 kW - Space requirement approx. W 4500 x H 1400 x D 1000 mm - Weight approx. 600 kg - with - Digital bending angle display + bending angle fine adjustment - Mandrel bending device 4.5 m. with hydr. Retreat - Bending tools 16 , 25 , 20 , 33.7, 38 mm - Bending blade 3000 mm

Technical data: - Bending capacity - steel pipe of 20 - 60 x 4 mm - - stainless steel pipe of 20 - 50 x 3 mm - max. resistance moment 6.2 cm - max bending angle 180° - max radius 125 mm - Bending speed 8 sec - Drive 400 V / 3 kW - Space requirement approx. L 2400 x H 1600 x D 1000 mm - Weight approx. 1400 kg - with: - Bending angle control via potentiometer with digital display - 6-fold bending angle preselection - Indoor + external pipe deburrer - Bending tools Rx2.5D x 38 ; • 50 , 65 ;

Tubebending machine for tube: dia 6 gt; 48 mm for full material: max 30 mmMax dia tube x thickness: Ø 6 > 48 mm (45 kg / mm²) Max bendingradius: 180° Length: 5500 mm Depth: 1400 mm Height: 1000 mm Weight: 600 kg

Inv. Num. : 5263 Type: DB 642 ST Producer: Transfluid Created: 1999 Parameters: Minimum tube diameter: 6 mm Maximum tube diameter: 42 mm Maximum bending angle: 190 h Machine height: 1150 mm Machine length: 4000 mm Machine width: 650 mm

Description: Pipe grinding machine with 10 grinding rollers: 16.5 - 18.5 - 22.5 - 29.5 - 35 - 39.5 - 45.5 - 9.5 - 57.5 - 73.5 mm Pipe clamping area 90mm Documentation (English) Bandwidth 100 mm Belt length 2000 mm Tube diameter 16.5 - 76 mm Angle adjustable from - to 0 - 65 degrees Connection voltage 400 V Total power requirement 2.2 kW Machine weight approx. 0.17 t Space requirement approx. 1.3 x 0.7 x 1.1 mweight approx.: 170 kg, Approx. Onsite Dimension. (l x w x h): 1,300 x 700 x 1,100 mm

Description: Pipe grinding machine with 10 grinding rollers: 16.5 - 18.5 - 22.5 - 29.5 - 35 - 39.5 - 45.5 - 9.5 - 57.5 - 73.5 mm Pipe clamping area 90mm Bandwidth 100 mm Band length 1250 mm Pipe diameter 20 - 76 mm Angle adjustable from - to 30 - 90 degrees Connection voltage 400 V Total power requirement 2.2 kW Machine weight approx. 0.18 t Space requirement approx. 1.2 x 0.6 x 1.3 mweight approx.: 180 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 600 x 1,300 mm

Description: With various matricesweight approx.: 280 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 400 mm

Description: - Pressing force: 12 to - with different bending inserts from size 15 to 50weight approx.: 30 kg, Approx. Onsite Dimension. (l x w x h): 630 x 200 x 540 mm

weight approx.: 100 kg, Approx. Onsite Dimension. (l x w x h): 1,450 x 260 x 1,200 mm

Description: Tube Bending Machineweight approx.: 750 kg, Approx. Onsite Dimension. (l x w x h): 1,400 x 700 x 1,300 mm

Inv. Num. : 5262 Type: XOTH 40 Producer: Unicorn Generated: Parameters: Maximum tube diameter: 40 mm Maximum pipe wall thickness: 2 mm Total power requirement: 4.6 kW Machine height: 1120 mm Machine length: 4450 mm Machine width: 800 mm Machine weight: 1100 kg

Inv. Num. : 5648 Type: XOTM 60 Producer: UNIT Created: 2004 Parameters: Minimum tube diameter: 20 mm Maximum tube diameter: 60 mm Machine length: 4900 mm Machine weight: 130 kg

Key data: 60 mm, 2 mm

Bending capacity: Ø60 x 2 mm Bending angle: 0 - 180° Turret: 12-way adjustment Mandrel length: 4500 mm Bending tools: - Ø 22 mm - Ø 25 mm - Ø 48 mm Equipped with: - 3 thorns - Mandrel retraction device - Foot pedal - Bending speed adjustment Country of origin: the Netherlands Motor power: 7.5 kW Machine LxWxH: 5350 x 1100 x 1100 mm Machine weight: 2300 kg

TECHNICAL SPECIFICATION  Max. diameter of tube: 65 mm  Max. wall thickness: 2 mmELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 5400 mm  space requirements -front/back-: 1550 mm  total height: 1500 mm  total weight approx.: 6500 kg+ 8-axis CNC pipe and wire bender+ CNC controlled feeder with pneumatic grippers+ separate servo drives for  A-axis:  rotation unit 35 mm  B-axis:  bending heand  C-axis:  feeder  D-axis: &nb sp;mandrel device  L-axis:  slide rail  P-axis:  chucking device  V-axis:  counter holder  Y-axis:  bending  Z-axis: & nbsp;bending head up/downFeedi ...

roll diameter: 350 mm: 110 mmbending speed: 1-5 m/minBending capacity: 157 Wcm³total power requirement: 7,5 kWweight of the machine ca.: 2950 kgDomestic equipments:- Direct drive of all three shafts- Single delivery of the side rollers- Horizontally and vertically usable- Hydraulically movable side rectifier (via control panel)- 2 digital displays for the feed rollers- Hardened rollers- Mobile control panelThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
