GENERAL
Project No.: 906047
Quantity: 1 pcs.
Manufacturer: TORNOS
Type: EvoDeco 32/10
Control: Fanuc 31i B5 plus
Year of Make: 2022
Condition: Used machine
Approx (hrs): 17435
Spindle Approx (Hrs): 10233
DESCRIPTION
TURNING
Axles 10
Max. turning diameter 32 mm
Max. speed main spindle 8000 1/min
Axes on the main spindle unit C/Z
Workpiece spindle stroke main spindle 260 mm
Max. speed sub-spindle 8000 1/min
Axes on the sub-spindle unit C
OTHER EQUIPMENT
Splash protection cladding with fully encapsulated working area
Lighting in the work area
Electrostatic oil/emulsion mist extraction system
Scraper Chip Conveyor
Coolant Setup
Coolant temperature control
Preparation for CO2 fire extinguishing system
Parts Discharge Belt
Precast removal device
Bar Feeder/Bar Loader ROBOBAR SBF-532 "3M""
Max. rod diameter 32 (36) mm
Max. rod length 3200 mm
Machine condition light
Automatic central grease lubrication
NOTE
We have described the named product with the greatest possible care.
However, since this does not come from our production, the data
mentioned and the equipment details may differ. We therefore ask you
to consider the description as non-binding and to check the data in
detail during a viewing.
