plate bending machine used for sale

Bending capacity: Plate width: 3000 mm Plate thickness 140 mm Thickness max 200 mm depending on plate width and yield strength Technical data: 3100 mm Surface useful length on rolls 940 mm size of Top roll 840 mm size of Lower rolls 210 mm max thickness opening between the rolls 400/50 Vac voltage - rewirable 480/60 220 Hp Power electric installed Configuration installed with the machine Hardened surface of the 3 rolls. Conical plate bending hydraulic attachment with hardened contrast pad. All the 3 rolls driven with axial gearbox and motor each roll independent Calibration system for the re-rolling of welded shells rounding unwanted flat spots. Console electric on wheels with centralized commands joysticks and digital readout. Opening front side hydraulic drop-end to unload closed shells. Variable speed working slow/fast. Emergency systems  ...

Max. length of plate 2000 mm Max. plate thickness 16 mm Number of rolls 3 pcs Max. pre bending capacity 13 mm Main motor power 15 HP

Projection: 880 mm Wheels: Ø 60 x 160 mm Toproll adjustment: 300 mm Machine LxWxH: 1300 x 700 x 1800 mm Machine weight: 300 kg

We sell on behalf a pipe and profile bending machine of the company Knuth (type KPB 50 ). The condition is AS NEW and has a lot of accessories. Pictures to follow

Working length: 2050 mm Round bending: 5 mm Bending: 4 mm Top roller: Ø 150 mm Under-roll: Ø 225 mm Equipped with: - Profile iron bending device - Sentences Profielrollen -Operating instructions Motor power: 3 kW Machine LxWxH: 3300 x 1050 x 700 mm Machine weight: 2000 kg

Outside diameter maximum: 580 mm Inside diameter maximum: 580 mm Pipe length maximum: 1170 mm Angle degrees maximum: 0 Wall Thickness: 1 mm Horizontal bending machineEUROMAC - Digibend 360  Table Length:      1170mm Table Width:       580mm Max. pressing force:36 Beam stroke:       250mm Working speed:     6 - 24mm/min. Return speed:      60mm/min. Power:             5,5kW Capacity flatt:    20 x 200mm x mm Length:            1200mm Width:             1200mm Height:            700mm Weight:            2000kg

sheet width: 700 mm plate thickness: 4,0 mm distance between columns: 720 mm diameter of upper rolls: 95 mm total power requirement: 1,1 KW weight of the machine ca.: 0,37 t dimensions of the machine ca.: 0,95 x 0,76 x 1,25 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bending length: 1540 mm sheet thickness: 1.5 mm steel Roller diameter: 80 mm Motorized rear roller lining with automatic switch-off Clockwise and counterclockwise rotation via foot switch 3 roller drive Safety cable pull switch Conical rounding possible

: neu : ca. 12 - 14 Wochen ab Auf : Italien : 121200 € : 5700 mm : 1100 mm : 1550 mm : 2700 kg : 25 cm³ : 76,1 x 6,8 mm : 2”1/2 mm : 76,2 x 3,8 mm : 63,5 x 63,5 x 5,6 mm : 70 x 50 x 8 mm : 70 x 50 x 6 mm : 79 mm : 250 mm : 20 mm : 195 ° : 5/7 U/min : 27 kW : 200 l FST clamping system (Patented) 6 programmable axes: carriage mobement (Y1 axis), bending plane rotation (B axis), bending angle (C axis), pressure die movement (X2 axis), booster (Y2 axis) and hydraulic mandrel movement (Y3) Touch screen control with 3D display of the tube Anti collision system tube/machine, tube/floo, tube/external elements and tube/equipment Importing files in iges and dxf format (optional) Integrated Wi-Fi FURTHER MANDREL LENGTHS ON REQUEST The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 12 - 14 Wochen ab Auf : Italien : 64000 € : 1299.2 € : 4535 mm : 1145 mm : 1400 mm : 1488 kg : 18 cm³ : 76 x 3,6 mm : 76 x 2,3 mm : 70x70x3 mm : 70x50x3 mm : 70x50x6 mm : 76 mm : 200 mm : 10 mm : 195 ° : 1,5/3 (50/100Hz) : 3 kW : 50 l Three-phase NC electric-hydraulic mandrel bending machine up to 76 mm with 1 controlled axis (bending axis C) New TCPlus control • 7” colour touch screen • Icons for ease use • Automatic mode, manual mode, programming mode • Advanced OFFSET function • Easy language change • Auto-tuning of the main machine components • Programmable bending speed for each single bend of the program • Unlimited programs possibility (USB port) • Every program can contain up to 30 different bends • Available extensions of 2 meters each (optional) • Tie bar (optional - art. TB80-TI) The data for this ad was created with ModulMWS - the so ...

: neu : ca. 12 - 14 Wochen ab Auf : Italien : 35300 € : 723.65 € : 4000 mm : 950 mm : 1250 mm : 850 kg : 10 cm³ : 64 x 3,3 mm : 2 mm : 60,3 x 2,2 mm : 60 x 60 x 2 mm : 40 x 60 x 4 mm : 60 x 40 x 3 mm : 76 mm : 200 mm : 20 mm : 210 ° : 4,2 kW : 15 l with mandrel 3 m length FST closure system (Patented) with auxiliary system for stabilizing the hydraulic pressure of the slide Programmable C-axis bending Positioning of the 2-axis manual spindle carriage (Y1=Feed and B=Rotation) with high resolution encoder and standard adjustable mechanical stops Multifunction control keyboard integrated in the machine body with microprocessor control with multifunctional menu 30 programs of 9 bends each can be memorized Screen for digital display for carriage feed (Y1 Axis) and rotation (B Axis) External pressure gauges for easy setting of the system and closing pressure Variable bending speed up to  ...

: neu : ca. 12 - 14 Wochen ab Auf : Italien : 29300 € : 600.65 € : 4000 mm : 950 mm : 1250 mm : 430 kg : 6 cm³ : 50 x 3,31 mm : Ø 1”1/4 mm : Ø 50 x 2,5 mm : 40 x 40 x 4 mm : 25 x 50 x 6 mm : 50 x 25 x 2,7 mm : 60 mm : 200 mm : 20 mm : 210 ° : 1,25 / 2,5 : 3,5 kW : 15 l With mandrel 3 m length Can be used with or withoud mandrel Two bending speeds Programmable bend sequencing and mandrel retraction Independent clamp and pressure die adjustment Micrometer wiper die adjustment Auxiliary system for stabilizing the hydraulic slide pressure Quick tool change system With pneumatic material clamping and DRO system for linear and rotational positioning ALTERNATIVELY: model with mandrel 6 m length price on request The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: Haeusler Type: VRM HY 4000 x 45 Stock number: 0973 Year of construction: 2001 Bending length: 4000 mm Bending strength: 45 mm Bending (cold): 38 mm Drive power: 100 kW Number of reels: 4 Adjustable rollers: 3 Type of adjustment of the rollers: hydraulic Top roll diameter: 710 mm Underroll diameter: 640 mm Side roller diameter: 520 mm Working speed: 2+4 m/min (up to 8m/min) Machine weight (with roller): 78 t Accessories Electronic synchronization Air-cooled oil cooler Upper support device Side cylinder support device (10t) Inlet table (20t) hydr. Bubble storage Cone bending device

Working width: 2000 mm bending capacity: 72.0 mm Bend: 66.0 mm Number of driven rollers: 3 Diameter top roll: 500 mm Diameter lateral underrollers: 420 mm conical bending device by inclination of the two side rollers hydraulic folding bearings Motor power: 56 kW mobile control panel with digital display Net weight: approx. 28 tons

The motorized bending machine is in used condition and is fully functional. Ideal for the production of round or square air ducts. -Incl. Console to edit material in roll form - incl. double foot switch for clockwise and clockwise rotation - Usable width 1000 mm - Roller diameter 56 mm Condition see pictures. Visit and demonstration possible. The indicated price is a net price for collection ex works. A chargeable transport within Germany can be organized on request.

The bending machine is in used condition and is fully functional. Ideal for the production of round or square air ducts. - Usable width 1000 mm - Roller diameter 50 mm Condition see pictures. Visit and demonstration possible. The indicated price is a net price for collection ex works. A chargeable transport within Germany can be organized on request.

: 40 mm roll diameter: 137 mm : 7 Upm engine output: 1,1 kW weight: 350 kg dimensions of the machine ca.: 1050 x 530 x 1250 mm Features: 2 rollers powered settings readout on scale easy reach emergency button supplied with standard roller set optional: various roller sets (available on request) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Stock number: 3774 PROFILE BENDING MACHINE Manufacturer: KUMLA - ROUNDO, Type: Z-30 Machine NO.: 5017, Year of construction: 1990 Specifications: Wave dia. 110/90 mm Round steel 60 mm Flat steel 200 x 30 Special roll mm Stainless steel upright 100 x 20 mm Angle steel 90 x 90 x 9 mm Speed 7.5 m/min Square steel 55 x 55 mm Total power 4 kW Hydraulic. 3-reels. Horizontal/Vertical Accessories: Digital Various matrices. Length: 1250 mm, Height: 1550 mm, Width: 1100 mm, Weight: 2100 kg

dia. range 0,5-4,0 mm width of band 60 x 2 mm punching power 9 to feeding length 270 mm stroke of slide 45 mm output - strokes/min 350 number of slides 5

Bobbio CNC 502 spring coiling

BTS 200 spring coiling machine + AB1 decoiler cap wire diameter: 0,4 gt; 1,5 mm winding diameter: max 40 mm 18 gt; 445 pieces/min power: 1,5 kW length: 990 mm width: 1000 mm height: 1600 mm weight: 610 kg nbsp; extension springs - compression springs - conical springs - biconicalsprings with winding on the right or on the left

BTO 236 spring coiling machine + AB1 decoiler cap wire diameter: 1 gt; 3 mm winding diameter: max 70 mm max spring length: 180 mm max length of leg: 80 mm speed: 80 m/min power: min 9 kW / max 13,4 kW length: 1500 mm width: 1100 mm height: 1500 mm weight: 1300 kg

BX 400 spring coiling machine + AB2 decoiler cap wire diameter: 0,8 gt; 4 mm winding diameter: max 70 mm speed: 180 m/min (max 90 pieces/min) power: 6 kW length: 1400 mm width: 1350 mm height: 1900 mm weight: 2200 kg nbsp; extension springs - compression springs - conical springs - biconicalsprings with winding on the right or on the left

BTO 215 spring coiling machine + AB1 decoiler cap wire diameter: 0,2 gt; 1,5 mm winding diameter: max 45 mm max spring length: 100 mm max length of leg: 60 mm speed: 80 m/min power: min 3 kW / max 5,2 kW length: 1300 mm width: 900 mm height: 1300 mm weight: 620 kg

max wire diameter: 4 mm max strip width: 40 mm table dimensions: 860 x 860 mm internal diameter of tube support: 100 mm max 9 toolholders can be installed on the table

max wire diameter: 4 mm max strip width: 40 mm table dimensions: 860 x 860 mm internal diameter of tube support: 100 mm max 9 toolholders can be installed on the table

Tube range up to: 48,3x3,25mm (E235mitRm =2xD) Bending radius up to: 125 mm Control: electronic ( + known 4-fold bending angle preselection ) Bending angle maximum: 180° Bending speed: 20°/s Dimensions L / W / H: 2380 / 800 / 1250 mm Weight: approx. 650 kg Electr. Power: 2.4 kW incl. sawing unit with visualization of the saw position via line laser Deburring unit, drive unit for assembly attachments Tube positioning - length and twisting 2-axis positioning indicator, premature mandrel retraction Auto. Mandrel lubrication (minimum quantities) Interface for network connection and data import

Manufacturer: Kottmann & Berger Type: BVA 3 Year of construction: 2001 Rated power: 5 kW Pressure: max. 6 bar Bending diameter (steel): 32 mm Bending radius: 1.5 x D – 2.5 x D Machine weight: 0,7 t

Motorized three-roll bending machine Fasti 2040x2mm Roller diameter approx. 105mm sheet thickness over the entire length 2mm Foot switch GS identifier Hndxqcbkg Dimensions: LxWxH approx. 3x1x1.2 meters Weight approx. 1300Kg

Wire diameter: 1 mm Number of bending slides: 1   CNC Brand: _Unknown / Other Integrated C-Axis 0-40 Rpm Min. distance table to quill : 215 Max. distance table to quill: 615 With seperate coolant tank X-Axis:                 700mm Y-Axis:                 500mm Z-Axis:                 400mm Table size L x W / or ø:870 x 550mm Table load:             50 Feed rate X-Axis:       1500mm/min. Feed rate Y-Axis:       1500mm/min. Feed rate Z-Axis:       1500mm/min. Length:                 3000mm Width:                  3000mm Height:         ...

: R10-R260 bending speed: 2,5 U/min : 42x3 mm : 42x2,5 mm : 30 mm : 54x2 mm total power requirement: 1,5 kW weight of the machine ca.: 80 kg dimensions of the machine ca.: 410x1000x570 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 1600 mm plate thickness: 16,0 mm ST pre-bending: 13,0 mm ST diameter of upper rolls: 230 mm side roll diameter: 0 mm diameter of lower rolls: 0 mm total power requirement: 0 kW weight of the machine ca.: 0 kg. dimensions of the machine ca.: 0 mm Furnishing: - electro-hydraulic 4-roller bending machine - 2x driven main rollers (upper & lower roller) - with hydraulic conical bending device - Induction hardened rollers - including straightening function for welded pipes - Control unit / display with touch screen function digital position display for the two side rollers - mobile control panel - 2x bending speeds selectable - hydraulic folding bearing - Safety device (safety line with switch unit) - Pressure gauge / pressure indicator for the rollers - CE mark + declaration of conformity - Operation manual The data for this ad was created with ModulMWS - the software solution ...

I - beam section - flat steel: 80 x 20 (d 1200) mm I-beam section - upend: 80 x 25 (d 2100) mm L-beam: 50 x 50 x 6 (d 1000) mm bar material - diameter: 40,0 (d 800) mm square material: 60x60x3 ( d 4000 ) mm rectangle: 80x30x3 ( d 6000 ) mm roll surface width: 177x60 (18x5 Nut) mm tool adaptor: 60 mm range L-W-H: 940 x 1260 x 1390 mm bar material dia. max.: 70 x 2 (d 1600) mm turning speeds: 6,4 m/min. total power requirement: 4,75 kW weight: 1080 kg range L-W-H: 950 x 1400 x 1450 mm Furnishing: - electro-hydraulic ring/profile bending machine - Hydraulic lower/side roller adjustment for extra small bending radii - Lower/side roller can be delivered individually - 3x powered rollers - divided roller segments - Digital position display of the bottom/side rollers Display with TouchScree function - hardened tool holder (42CrMo4) - Machine base - 2x manually adjustable side guides - Horizon ...

L-beam: 40 x 5 (d 500) mm I - beam section - flat steel: 80 x 15 (d 700) mm I-beam section - upend: 50 x 10 (d 800) mm round material: 30,0 (d 700) mm bar material dia. max.: 60 x 2 (d 1200) mm square material: 50 x 30 x 3 mm range L-W-H: 670 x 530 x 1350 mm weight: 185 kg total power requirement: 0,75 kW Furnishing: - Robust electro-motor ring/profile bending machine - Horizontal and vertical work possible Machine head foldable by 90° - 1x free moving footswitch - segmented standard rollers (divided) - 2x motor driven rollers - manual delivery of the top roller - analogue position display of the top rollers (scale) - manually adjustable lateral/straightening rollers - CE mark / declaration of conformity - User manual in German The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

I-beam section - upend: 100 x 20 (d 2100) mm bar material dia. max.: 100 x 3 (d 3000) mm L-beam: 80x80x8 (d 2000) mm square material: 50 x 25 x 2 (d 600) mm I - beam section - flat steel: 120 x 30 (d 600) max.140b mm bar material - diameter: 60,0 (d 1000) mm tool taper: 80,0 mm turning speeds: 4,2 m/min. weight: 1.600 kg range L-W-H: 1240 x 1375 x 1540 mm Ausstattung: - elektro-hydraulische Ring-/Profilbiegemaschine - hydraulische Unter-/Seitenwalzenverstellung für extra kleine Biegeradien - Unter-/Seitenwalze einzel zustellbar - 3x angetriebene Walzen - geteile Walzensegmente - digitale Positionsanzeige der Unter-/Seitenwalzen Anzeige mit TouchScree Funktion - gehärtete Werkzeugaufnahme (42CrMo4) - Maschinenuntergestell - 2x hydraulisch zustellbare Seitenführungen - horizontaler und vertikaler Arbeitseinsatz möglich - freibewegliches Bedienpult - Manometer / Druckanzeige für die  ...

: neu : 2022 : 9630 : prompt, Zwischenverkauf v : Türkei : 3700 € : 1 : 30 mm : 148 mm : 118 mm : 2 : 0,75 kW : 2 m/min : 50x10 mm / 800 mm, 20x6 m : 80x15 mm / 700 mm, 30 x 6 : 30x30 mm / 900 mm, 10x10 : Ø 30 mm / 900 mm, Ø 10 mm : Ø 60x1,5 mm / 1.000 mm, Ø : 50x30x3 mm / 1.200 mm, 40 : 40x40x3 mm / 1.200 mm, 30 : 40x40x5 mm / 600 mm, 30x3 : 35x35x5 mm / 600 mm, 30x3 : 600 mm : 800 mm : 1450 mm : 220 kg 2 mech. driven rolls strong cast steel construction shafts made of special steel,hardened and ground top roll manual adjustable hardened universal rolls lateral rolls adjustable in 1 axis horizontal and vertical operation double foot pedal forfor- and backward drive machine and equipment accordingto the CE regulations user manual in GERMAN or ENGLISH (sample photo) WE HAVE MORE THAN 210 REFERENCES! The data for this ad was created with ModulMWS - the software solution of LogoTec ...

sheet width: 2050 mm plate thickness: 4,5 mm max. plate thickness: 4,0 mm anbiegen roll length: 2050 mm min. dia.: 210 mm roll diam. toproll: 140 mm weight: 1550 kg range L-W-H: 3220 x 1200 x 900 mm Exhibition machine - unused (!) Special price on request List manufacturer price: 21.400 euros Machine with special equipment Furnishing: - Electrically driven top and bottom rollers - Top roller can be swung out, with folding bearing - Conical bending device - asymmetrical roller arrangement - self-braking main motor - separate control and operating panel - Profile inserts in the rollers - Safety line - User manual in German - CE mark / declaration of conformity Special equipment included in the price: - hardened rollers - Motorized rear roller adjustment - digital position display for the rear roller - 2x bending speeds The data for this ad was created with ModulMWS - the software sol ...

: 35 mm : 35 mm bar material dia. max.: 70 x 2 mm rectangle: 60 x 60 x 3 mm flat steel: 60 x 10 mm Axis diameter: 50 mm work speed: 4,3 m/min total power requirement: 1,5 kW weight of the machine ca.: 0,4 t dimensions of the machine ca.: 0,9 x 0,95 x 1,4 m Profile bending machine with: - Foot pedal right/left rotation - Hardened special steel shafts - 1 set of standard rollers - 2 rollers are driven The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

profile height: 300 mm 3 driven castors Capacity: 27 t Front roller spacing infinitely adjustable with digital display Control can be operated both manually and with PC At the moment without roller sets, as individually adaptable

sheet width: 1290 mm plate thickness: 6 mm pre-bending: ja roll diameter: 140 mm roll speed: 1 - 6 m/min total power requirement: 2,2 kW weight of the machine ca.: 1120 kg Asymmetry roll arrangement, pre-bending ist possible. This new machine is in the following sizes obtainable: working length from 1040 until 2540 mm, max. plate thickness ( 400 N/mm² ) from 1 until 6,5 mm. We are distributor only for Germany. Machine dealer with own stock of 1600 m². The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 50 mm : 8,5 U/min : 100 kN roll diameter: 162 mm Drive: 1,5 kW weight: 450 kg range L-W-H: 1100x800x1500 mm Equipment / Accessories: - Two driven rollers - Hydraulic delivery of the upper roller - Digital display with memory function - Working position horizontal and vertical - Bearings with tapered roller bearings - Use of replaceable slide rails on the guide carriage - Footswitch - standard roller set The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : 2023 : 9654 : prompt, Zwischenverkauf v : Türkei : 2400 € : 1 : 1 : 1050 mm : 1 mm : 56 mm : 1400 mm : 700 mm : 1120 mm : 185 kg 3 Walzen asymmetric rolls - prebending longitudinal grooves in lower and lateral roll Infeed of the lower roller by a central lever - with gear reduction machine stand user manual in GERMAN orENGLISH The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Rolls Bending Machine ZOPF ZB 70/2M Year of construction: 1999 Bending capacity: Ø 70 mm Shaft diameter: Ø 40 mm Roll diameter: 152 / 162 mm Lower shafts spacing: 300 mm Adjusting way: 120 mm 2 driven rollers, knurled surface Manual adjusting of the center roller Working position horizontal and vertical Delivered with many rollers (see photos) Machine in very good condition Voltage: 380 V Width: 900 mm Depth: 1100 mm Total height: 1300 mm Weight: approx 500 kg

: neu : 2023 : 9691 : Mai 2023, Zwischenverkauf : Türkei : 29670 € : 85 mm : 247 mm : 3 : 7.5 kW : 80x20 mm / 500 mm, 30x10 : 120x30 mm / 650 mm, 50x10 : 50x50 mm / 500 mm, 30x30 : Ø 50 mm / 500 mm, Ø 20 mm : Ø 100x2,5 mm / 1.300 mm, : 80x40x4 mm : 70x70x4 mm : 80x8 mm / 1.200 mm, 30x3 : 80x8 mm / 800 mm, 30x3 mm : 1580 mm : 1200 mm : 1410 mm : 2350 kg 3 driven rolls (hydromotor and planetary gear) strong welded steel construction lower rolls hydr. adjustable digital read-out for lower rolls positions plane rolls lateral rolls (forward-backward hydraulic, rest manual) horizontal and vertical operation Control console forfor- andbackward drive machine and equipment according to theCE regulations INCL. OPTION: CONTINUOUS SPEED WE HAVE MORE THAN 235 REFERENCES! The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : 9670 : prompt, Zwischenverkauf v : Türkei : 18100 € : 1 : 60 mm : 177 mm : 3 : 3.7 kW : 6 m/min : 70x10 mm / 600 mm, 30x10 : 90x25 mm / 500 mm, 50x5 m : 40x40 mm / 500 mm, 20x20 : Ø. 40 mm / 500 mm, Ø 20 m : Ø 60x2 mm / 600 mm, Ø 20x : 80x40x3 mm : 60x60x4 mm : 50x5 mm / 1.000 mm, 30x4 : 50x5 mm / 500 mm, 30x3 mm : 1160 mm : 1000 mm : 1175 mm : 1194 kg 3 driven rolls strong welded steel construction lower rolls hydr. adjustable digital read-out for lower rollspositions on seperate control panel plane and hardened universal rolls lateral rolls adjustablein 3 axes manual/hydr. horizontal and vertical operation for- and backward drive machine and equipment accordingto the CE regulations user manual in GERMAN and ENGLISH WE HAVE MORE THAN 235 REFERENCES! The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: VEB Type: RV16 Machinable cross-section: 120 x 140 mm Weight: 2.7 t

mandrel bending machine Tansfluid DB 628 Year of construction: year 1995 Drive power Drive power 1.5 kW Drive drive hydraulic cylinder & roller chain Pipe range bending type 4-28 mm Bending angle bending angle 190° (without tube) Bending radius bending radius 1.5 x D – 2.0 x D Nominal pressure nominal pressure 250 bar Operating pressure 3095 mm n. right. Flow rate delivery rate 4.5 l/min

3-roll hydraulic 3000x30 mm pre-pinch planetary MG model G3030 year 2021 -Plate width 3000 mm -Capacity thickness 30 mm -Pre-pinch 25 mm -width on the rolls 3100 mm -upper roll size 400 mm -lower rolls size 380 mm -Hardened rolls surface. -All driven 3rolls gear box motorized each synchronized rotation -Conical plate bending attachment , rolls tilting & contrast roller. -Operator console with directional joysticks and digital readouts -Front drop-end open hydraulic -Emergency and safety installation -User manuals and instruction books. -Electric power 25 HP on the hydraulic unit. -V400/50

3-roll bending machine SCHÄFER type SRMVS Masch. Nr. Year of manufacture: 1973 , sheet length: 2000 mm, sheet thickness: 16 mm, top roll, diameter 250 mm, bottom roll, diameter 230 mm , roll speed 7 rpm. Rolling speed approx. 5 meters min. Mains connection 380 volts, 50 Hz. - all 3 rollers driven - symmetrical roller arrangement - motorized upper roller adjustment- conical bending via inclined adjustment of the upper roller with coupling for one-sided adjustment - lateral start-up for conical bending - motorized lower roller adjustment , individually for the front and rear roller- right and left rotation via control button in the control panel - swing-out hinged bearing and spindle support to relieve the upper roller Dimensions L x W x H 4200 x 1900 x 2200 mm Weight 10.6 ton. good condition; used

- Working range pipe Ø 20 to 60.3 mm (wall thickness 2.3 mm / mild steel) - Preselection 4 bending angles by rotary control - Bending, deburring - Pipe extension length 4,500 mm - Rotation angle unit manual - Spine retreat
