Ultra-Turrax Year built: 1983 Diameter: 220 mm Power: 13.5 kW 380/660 Volt 1460 rpm Wavelength: 1100 mm good condition LWH: 1700 x 400 x 350 mm
Kahl Mixer Continuous Mixer Conditioner for Pellet Press Gr.3 used Manufacturer: Amandus Kahl Model: Gr.3 / Gr. III with drive motor ABB motors 380/660 V; 1470 rpm; 30 kW. For continuous conditioning, mixing of bulk materials with fissics as dosing for pellet presses . Use: - For continuous mixing of feed with liquids and steam - For melasses dry chips - In general process technology for moisturizing granular / powdery substances - General: for (all) mixing tasks in which liquids must be entered into solids Tech. Information Manufacturers - Total length approx. 2964 mm - Diameter approx. 550 mm - Total height approx. 900 mm - Distance inlet/outlet (center/middle) approx. 1950 mm - Inlet/output approx. 300x300 mm - Weight approx. 800 kg + motor approx. 245 kg Subject to changes and errors in the technical data, dates and prices as well as intermediate sale.
Type: MRG 121, Y.O.M.: 1989, suitable for welding electrode compounds, with planetary gearbox, 4 kW drive, quick-change device for kneading tool, stainless steel boiler, repainted, 1.1 kW lifting motor, dimensions: 1 m x 0.8 m x 3 m high
vertical belt coil mixer for the food industry in stainless steel Usable volume: 600 litres Cylindrical mixing container with conical transition to the outlet Mixing unit, vertical belt coil circulating in the mixing container Drive mixing unit Geared motor make-up North 7.5 kW, at 61 min-1 as a plug-in gearbox with hollow shaft Engine efficiency class IE3 Shaft sealing due to high-quality shaft sealing rings Feeding with sack hook and support grid Outlet with flat slider in stainless steel hand-operated with knife head 4 kW at 1500 min-1 with liquid addition lance with basic frame On request with control for additional price
Machine name: Paddle dryer used Manufacturer: AVA / Holland Merten GmbH Type: HTK 200 Year of construction: 2002 Speed: 107 rpm Material: Stainless steel Drive motor: 5.5 KW Version: EExdellCT4 Total capacity: 235 liters Wetted parts: stainless steel 1.4571 Gearbox:Helical gear motor Equipment: Double jacket, mechanical seal, wave heating Dimensions: L 3400 x W 1100 x H 1500 mm Empty weight: approx. 1600 kg Tech. Documentation: yes available Note: Operating temperature 130°C Design temperature 200°C Internal pressure mixer -1/+3 bar Pressure double jacket +6 bar Accessories: Base frame, Maierkopf HWR 225 Condition: Used very good Price: on request
Machine name: Continuous horizontal mixer dryer used Manufacturer: AVA / Holland Merten GmbH Type: HTK 200 Year of construction: 2002 Speed: 107 rpm Material: 1.4301 Drive motor: 5.5 kW Hsyqeirqy Version: EExdellCT4 Total capacity: 235 litres Wetted parts: stainless steel 1.4571 Equipment: Double jacket, mechanical seal Dimensions: L 3400 x W 1100 x H 1500 mm Empty weight: approx. 1600 kg Tech. Documentation: Yes Note: Operating temperature 130°C Design temperature 200°C Internal pressure mixer -1/+3 bar Pressure double jacket +6 bar Accessories: Base frame Condition: Used Price: On request
Planetary mixer manufactured by BACHILLER in stainless steel model D411, with a capacity of 600 liters. General characteristics: Manufactured by BACHILLER Model D411 Material Stainless steel Technical characteristics: Capacity 700 litros Dimensions Diámetro 900 mm x 1.000 mm de alto
Planetary mixer manufactured by BACHILLER in stainless steel, with a capacity of 600 litres. General characteristics: Manufactured by BACHILLER Material Stainless steel Technical characteristics: Capacity 600 litros Motor characteristics: Manufactured by ASEA-CES Voltage 660/380 V Power 9.3 kW Rotational speed 1430 rpm Reducer characteristics: Ratio 1-50 Transport characteristics Total length 2700 mm Overall width 1700 mm Total height 2400 mm
Used ribbon mixer, capacity approx. 300 liters. Manufacturer Baker Perkins Ltd.
Gross volume approx. 18 litres, net volume approx. 12 litres Mixer shaft heatable and coolable Double jacket heatable and coolable Product-contacted parts: stainless steel VA Drive is carried out by chain drive and gearmotor Subject to prior sale - Errors possible
Segment belt screw mixer with discharge screw, make baurmeister type:BE 2000, BJ. 1990, Wekstoff stainless steel, capacity 2000 liters, drive power 5.5 kW.
Mixing Boiler capacity total 26 l Useful capacity 15 l mobile table version Product area Material 1.4404 Heating room material 1.4541 Utility space: Operating temperature 99 °C Boiler room: Operating temperature 144 °C Pressure 4 bar Turbo dissolver agitator power 0.75 kW, rated speed 1,390 rpm, sliding ring seal little in operation
Vacuum homogenizing system mobile table version Utility space: Operating temperature 100 °C Pressure -1/+1 bar, vacuum-resistant Content 5 litres Boiler room: Operating temperature 110 °C Pressure 4 bar Power 4.8 kW Agitator with wall wiper 20-160 rpm Left-hand running/right-hand running and reciprocal left-right running Homogenizer 500-6,600 rpm
Homogeneisive for renting Key figures: • Becomix RW60 CD + Feed container 50L • Working volume: 60L and 50L • Anchor agitator with scrapers and power breakers • Homogenizer with right/left barrel (homogenizing/pumping mode) • Circulation line • CIP • Lid hydraulically liftable • Fully automatic, control via touch display • Heating, cooling, vacuum, ... • New seals • Pharmaceutical version, but can also be used in cosmetics The machine is fully serviced and is available for rent. We take care of your project "Turn Key" incl. installation at your company as well as commissioning.
Used stainless steel tank, 260 L volume, agitator, jacket. Made by BIONAZ (France). Outlet dimensions: dia. 860mm, depth 450mm. Water jacket ss, working pressure 6 Bar. The tank has a bottom drain hole with a valve. Additionally, the entire tank is mounted on two hydraulic pistons for tilting emptying. The tank is equipped with a frame agitator with Teflon grinders, driven by an electric motor 1.5 kW, 1400 rpm, 220/380 V, 50 Hz. The tank has a lid on both sides. The whole is mounted on two supports made of stainless steel. The device is equipped with a non-pressurized water / oil jacket.
Bin Blender suitable for mixing, filling and emptying with corresponding mixing containers (10 units with each 150 litre available). Machine incl. separate electric cabinet, operator panel. PLC: Siemens, Simatic S7-300. Load capacity: 800 kg
Machine name: Cone mixer / dryer Manufacturer: Bolz GmbH Type: MF 400 Year of construction: 1991 Material: Stainless steel Designation: Vertical cone mixer Design: The cone mixer is ground on the inside in korn 240 and pickled on the outside. Total capacity: 9250 litres, net capacity: 4000 litres Contact Parts: V4A 1.4401/04 (316) Dimensions: L 2800 x W 2800 x H 5000 mm Empty weight: approx. 4000 kg Tech. Documentation: Yes Remark: Field of application: pharmaceutical, food, chemical Agitator: screw stirrer Voltage: 400 Volt Motor: explosion-proof Temperature: 80 °C without pressure Accessories: Knocker Condition: Used very good Price: On request
The Brogli machine is suitable for powdered and liquid raw product using heat, pressure and mechanical stirring energy to produce homogeneous products for the chemical, pharmaceutical, cosmetic or food industry. Usable volume: 300 liter, volume tot.: 369 liter, min. volume: 100 liter.
The Brogli plant is designed to produce homogeneous products for the chemical, pharmaceutical, cosmetics or the food industry from powdered and liquid raw products using heat, pressure and mechanical stirring energy. Usable volume 200 litres. Plant incl. 3 feed tanks, vacuum pump, spare parts, etc.
Stock# U2347-1 Used mixer by Buhler (CH) type SPM-50-HT with butterfly/tri-foil agitator for work on vacuum. Mixer has contact parts designed in non-corrosive steel. Mixing shaft has length about 1750 mm and is equipped with butterfly agitator, with three paddles and external diameter 1040 mm. Top cover is equipped with two pneumatic accutators and fits mixing pans with diameter 1100 mm. Cover can be rised up to 500 mm. Agitator is belt driven by el motor 45 kW, 1470 rpm, 380/660 V, 50 hz. Mixer is hydraulically risen about up to 90 cm. Machine is equipped with local control panel by Siemens with touchpad and electric cabinet. Machine is also equipped with hydraulicaly operated post for mixing can. Working pressure in mixing tank can reach 0.3 bar. Machine had been working on paints. Mixing pan is not included.
Stock number: L0931-06 Used Cannon type GCI/450 l/MI approximately 450 l working capacity and 638 l total capacity vertical white glass lined reactor. Internal approximately 902 mm diameter x 665 mm diameter straight side. Has clamped dished top and welded dished bottom heads. internal rated full vacuum / 2.76 bar design pressure at -10 /+ 230 C. Carbon steel jacket 85 l capacity rated 5.17 / 4.17 bar design pressure -10/+230 C. Includes 3-blade retreat curve agitator belt driven by 1.5 kW 415 V, 3/50, 1420 rpm motor via highfield gears size 5 gearbox rated 31/3 reduction ratio and mechanical seal.
Used high share mixer made by Machines Colette. Model Gral 300. Material - stainless steel.
Crepaco” twin shaft ribbon mixer 4.000L all stainless steel 2 front discharge guards 2 ABB engines (2 x 22 kW) capacity drum ± 2.300 x 1.850 x 1.000 mm (4.000L) loading : ± 3.200/3.500L (depending on the product) loading height ± 2.800 mm discharging height ± 1.550 mm dimensions (l x w x h) : ± 3.750 x 2.100 x 2.800 mm total height for transport ± 2.700 mm in good condition with new control box
Volume: 400 ltr. Material: Stainless steel
Material: stainless steel Engine: 55 kW Content: 1750 ltr Weight: 3500 kg Length x Width x Height: 3800 mm x 1900 mm x 2300 mm Chopper: 22 kW The machine is like new. We have completely overhauled this machines in 2010. We design and build your entire plant exactly to your needs from new and used machines. Are you looking for something else? Write us below!
Material: Stainless steel Drive: 35 / 50 KW
Material: Stainless steel 1.4571 Drive: 15 KW / 400-4000 RPM Weight: 1100 kg Mixer: Turbulent - mixing plant Speed mixing plant: approx. 400-4000 RPM Operating voltage: 400 V Control voltage: 230 V Frequency: 50 Hz Protection class: IP 54; Additionally available: --> Cabinet --> Documentation.
Material: Stainless steel Content: 4500 ltr L x W x H: 5900 mm x 200 mm x 1600 mm Hydrostatic drive, Strong design, sheath wall thickness 12 mm. Very good, ready-to-use condition.
Offer 7 paint mixing buckets mixing tank agitator tank Drais 300 l rollable (for e.g. Drais color mixing unit (dissolver) type RN 218) Fig. 1-7 The paint mixing buckets were part of a wallpaper production plant in Halle and were used as accessories for the Drais-Farbmischwerk type RN 218 (sold). Technical data (partly estimated or from reference plants): Manufacturer: Drais Designation: Paint mixing bucket Mixing tank Agitator tank Year of construction: probably 1985 Material: sheet steel Inner diameter: 80 cm Height: 80 cm (overall) Weight: approx. 130 kg Quantity: 7 pieces with paint residues. Also available in parts for 290€/piece. further assets from this plant: -for material separation centrifuge SZB0 1000C 960 1/min 6 loads/h The centrifuge was part of a wallpaper production plant. After cleaning the tools, it is used to separate the plastisol from the ...
Turbulent mixer / paddle dryer Manufacturer : Drais Volume : 2500 ltr. Material : wetted areas in stainless steel Drive : 57 / 40 KW Operating pressure : 5 bar Electr. Power supply : 380 V / 50 Hz; --> Machine with extendable mixing unit.
Material: stainless steel Engine: 57 / 40 kW Weight: 7500 kg Length x Width x Height: 2900 mm x 1650 mm x 2000 mm Nominal volume : 2500 ltr. Working pressure : 5 bar electric input power : 380 volt / 50 hertz. Machine with withdrawable mixing device. You can also get the entire system with all components you need. Write us below!
Horizontal batch mixer with 630 l. gross content, pneumatic outlet flap (new cylinder), 37 kW engine, Flender gearbox (N2 = 58.58 UPM) and carbide-armoured mixing tools. Workshop overhauled in 2016; very good condition.
Material: stainless steel Engine: 37 kW Content: 600 ltr Pressure (inner): 6 bar Weight: 750 kg Length x Width x Height: 2500 mm x 950 mm x 1500 mm Very good conditon, ready to work. Do you look for whole plant or have a questions? We have more then 1000 used machines on stock.
All in one reactor . Material: Stainless steel 1.4571 Drive: 4 kW Volume container: 50 ltr. Volume casing: 10 ltr. Pressure inside: - 0.97 / + 3 bar Outside pressure: 5 bar Temperature: 180 ° C; Weight: approx. 2000 kg Length x width x height (mm): 2200 x 1620 x 2065 Machine in excellent condition!
Drais-Spangenberg, dissolver stirrer with scraper, container approx. 100 ltr., double jacket, container and dissolver in Edeltahlk, drive 22 Kw., 400 V. 50z, complete with control cabinet ... Drais-Spangenberg, Dissolver Stierer with Scraper, Vessel approx.100 ltr., Doubel jacket, Vessel and Dissolver are Stainless Steel, Drive is 22 Kw. 400 V. 50 Hz, complete with Controll Panel
Volume: 5 ltr. Material: Stainless steel Drive: 2.7 KW Weight: 200 kg
Intensive mixer from Eirich - model R 11 - made of stainless steel and with 250 L mixing volume in perfect condition. Including (!) complete original control cabinet from Eirich. The mixer is equipped with the effective pin agitator, also made of stainless steel. The machine has always been serviced, the current maintenance report is available. Year of construction: 2006 Operating hours: 2308 filling: 250 L / 300 kg Drive Motor for mixing pan: 5.5 kW Drive Motor for rotor tool: 15 kW Drive Motor for hydraulic power unit: 1.5 kW Lubricating pump/lubricating grease drive motor: 0.21 kW Speeds: Mixing pan: 22 1/min Rotor tool: 113 - 340 1/min Machine weight: approx. 2,000 kg including original automatic Eirich control panel Export shipping possible.
The base area of the platform on the ground is approx. 3.00 m x 3.50 m To this area it is necessary to add a staircase to get to the mixer platform: about 1.00 m in length The platform on which the mixer stands is located at a height of about 2.30 m to 2.40 m above the ground. The top of the mixer is located at a height of 3.20 m above the ground. The height of our containers, which are used to feed the mixer, is 1.80 m. This means that the required total height of this equipment (platform + Eirich mixer R11) is 5.00 m. However, a minimum height of 5.50m under the roof is required to allow access for forklifts. Container diameter of the Eirich R11 mixer: 1.1 m, height 0.75 m, which means a total volume of about 700 liters. Usually we mix 200 to 300 kg, depending on the density of the raw material According to the manufacturer, the Eirich R11 has a usable volume of 250 liters and ...
Ekato Dissolver Agitator EM 040 EX protected version Power 1.3 kW Speed range 80-400 1/min Mixing tank stainless steel 350l can be driven on castors brand new condition
Engelhardt Tea leaf mixer. Suitable for mixing many different products such as tea leaf, spices, herbs, etc. Manufacturer: Engelhardt GmbH ( Germany ) Type: PR 500 Capacity: 100 liter Year: 1984 Power: 380 v.
Material: stainless steel Content: 1400 ltr Length x Width x Height: 2300 mm x 1600 mm x 1700 mm Drive pneumatic Very good condition. You can also get the entire system with all components.
Material: stainless steel Engine: 7,5 kW Convey length: 2850 mm Convey width: 500 mm Very good condition. You can also get the entire system with all components.
Material: stainless steel (1.4541) Engine: 7.5 kW Content: 500 ltr Weight: 1000 kg Length x Width x Height: 1200 mm x 1200 mm x 3100 mm With jacket 22 rpm Very good condition. We plan and build for the complete system from used and new machinery, exactly for your needs. Are you looking for something else? Write us below!
High-efficiency dynamic classifier (separator) for minerals, cement, recycling etc., rotor diameter: 700 mm, turbine wheel equipped with 64 blades, outer ring equipped with 36 manually adjustable counter-blades, incl. drive. In very good condition.
Dynamic airflow separator (sifter) for minerals, cement, recycling etc., rotor diameter: 700 mm, turbine wheel occupied with 64 blades / turbine blades, outer ring occupied with 36 manually adjustable counter wings, incl. drive. In very good condition.
Wing Mixer Wing Wheel Low Speed Mixer Propeller Agitator Propeller Mixer Xylems Flygt Banana SR Agitator used Low speed, highest efficiency Slow-running Flygt agitators are used when large amounts of liquid need to be stirred effectively and optimally during the treatment process. The result is outstanding efficiency. Manufacturer: FLYGT Type: M18-11-4AL / Banana SR agitator Propeller diameter approx. 1800 mm Wing/propeller length approx. 850 mm Wing/propeller width approx. 420 mm Diving motor Flygt 4430.010 690/400 V; 4.8/8.3 A; 50 Hz; IP68 4.0 kW; 1405 rpm Slow running submersible motor agitators Application: - Activated sludge treatment, conventional treatment, oxidation trench - Water reservoirs - Ice-free keeping - Oxygenation in lakes and ports - Biogas production tanks - Wastewater agitator Total approx. 1800 x 1300 x 600 mm Weight approx. 290 ...
Powder dispersing plant Manufacturer: Fristam Type: PE 0320 f Serial number: 0972600002-227933 Built: 2016 Power: 7.5 kW Weight: 160 kg Flow rate: 15-20 m3/h at height=5 m (water) with switchgear, FU speed-controlled Siemens control, connected in the bypass Vessel volume: approx. 450 l Machine in top-notch condition Dimensions LWH: 2100 x 1200 x 1800 mm Total weight: approx. 300 kg
Vacuum processing plant Manufacturer: Fryma Type: Delmix MZM VK-7 Y.O.M.: 1994 Machine No.: M16397 Pressure inside: -1 bar Batch: 7 l for food, cosmetics, pharmaceuticals in sound condition Mobile Dimensions LWH: 900 x 800 x 1350 mm Weight: approx. 120 kg
The Fryma machine is suitable for powdered and liquid raw product using heat, pressure and mechanical stirring energy to produce homogeneous products for the chemical, pharmaceutical, cosmetic or food industry. The homogenizer is composed of heating and cooling with steam, water or thermal oil incl. stirrer. Filling volume: max. 400 liters, min. 105 liters.
The Frymix machine is suitable for powdered and liquid raw product using heat, pressure and mechanical stirring energy to produce homogeneous products for the chemical, pharmaceutical, cosmetic or food industry. Machine comes in explosion proof version, elect. panel, weighing cells etc. Usable volume: 400 liter, volume tot.: 630 liter, min. volume: 60 liter. Attention: it needs a ceiling height of at least. 4.40 m!
