Manufacturer: Menzel
Type of Machine: Washing Line
Year of Manufacture: 2013
Technical Data
Fabric Type: Warp knit, lace, Raschel goods, tricot
Material Composition:
- 100% Polyamide
- 100% Polyester
- Polyamide/Spandex (Elastane up to 30%)
Dimensions & Weight:
- Material Width: 2,200 – 3,200 mm
- Roller Width: 3,400 mm
- Fabric Weight: 50 – 265 g/m²
Performance:
- Production Speed: up to 40 m/min
- Process: Spun oil removing, water-based washing
Chemicals Used:
- Oil-emulsifier
- Washing/wetting agent
- Alkali
- Acetic acid for pH neutralization
Steel Grades:
- Lateral Frames: AISI 304 (V2A)
- Parts in Contact with Media: AISI 316 (V4A)
Machine Specs:
- Unwinder Diameter: 1400 mm
- Winder Diameter: 1800 mm
Power & Utilities:
- Voltage: 230/400 V, 50 Hz, 3 Phase
- Steam Pressure: 4 – 6 bar
- Compressed Air (Oil-Free): 6 – 7 bar
- Water Pressure: 2 – 3 bar
- Water Consumption: Approx. 5 – 8 l/kg (depending on procedure)
Other Details:
- Operation Side: Left
- Drive Side: Right
- Color of Range: Grey / Steel
