DISKUS used machine for sale

Machine not ready to grind. Suitable for spare parts supply

Workshop overhauled 2024, ready-to-use DISKUS Doppelplan grinding machine, Lower grinding spindle renewed 2024 Machine No. 7078 Specifications: Grinding spindle 2 pieces vertical Workpiece width 5 - 30 mm Max. workpiece height 10 mm Grinding wheel diameter 300 mm Dimensions of grinding tools Ø 300 x 50 x Ø 75 mm Rotational speed grinding wheel 18 m/s Speed 1150 rpm Lower grinding spindle frequency-controlled Machine weight approx. 2.3 t Accessories: IONIC process control, FAUDI water basin with magnetic separator Replacement flanges, transport washers The machine can be viewed by appointment in our factory in Krefeld. Price ACTUAL condition from stock: on request – Errors, changes and prior sale excepted –

Machine grinds in linear pass, Extremely robust design. Specifications: Workspace: Largest sanding width 150 mm Highest working height for new grinding tool (workpiece passage) 50 mm Diameter of the grinding wheels 600 mm Speed upper grinding wheel 765 rpm Lower grinding wheel 765 rpm Circumferential speed: upper grinding wheel 24 m/s Lower grinding wheel 24 m/s Dimensions of the abrasive tools: Ø 600 x 75 x Ø 50 mm Workpiece feed speed infinitely adjustable from 35 to 350 mm/s Grinding wheel infeed: Total travel per grinding wheel 150 mm Grinding wheel feed servo motor controlled Dressing Unit: Servo Motor Controlled Grinding motors: 30KW Ges. Power requirement approx. 62KW Dimensions of the machine: Length approx. 2750 mm Width approx. 2050 mm Height: approx. 3000 mm Footprint: Length: approx. 4350 mm Width: approx. 5020 mm Weight: 6500 kg The m ...

Condition: Workshop overhauled, ready for demonstration and use, tested The DISKUS DDS 457 II CL was completely dismantled, cleaned, defective parts replaced and functionally tested. Specifications Grinding spindle: 2 pieces vertical Grinding process: Continuous process Workpiece width up to 60 mm Max. workpiece height 1-60 mm Grinding wheel diameter: 457 mm Grinding wheel rotation speed 24 m/s Workpiece feed 25 to 250 mm/min Drive power grinding wheel motor 2 x 15 kW Total drive cable approx. 35 kW Machine weight approx. 3.7 t Total space requirement approx. L x W x H 1.4 x 1.0 x 2.7 m Accessories: Replacement flanges – Errors, modifications and prior sale excepted –

The machine has been overhauled in the workshop. It was repaired, defective parts were replaced and functionally tested . The spindle bearing has been renewed, the rotary table drive has been overhauled Specifications Vertical grinding spindle assembly Workpiece diameter up to 30 mm Max. workpiece height 10/20 mm Grinding wheel diameter 300 mm Grinding wheel rotation speed 35 m/s Workpiece feed 1.5 to 15 m/min Drive power grinding wheel motor 2 x 22 kW Total drive cable approx. 50 kW Machine weight approx. 4.5 t Total space requirement approx. L x W x H 3.3 x 2.6 x 2.6 m The DISKUS DDS 300 RPD has been completely dismantled, cleaned, assembled and functionally tested. Spindle bearings and rotary table drive have been overhauled. Equipped by the manufacturer for grinding with CBN discs. The machine can be viewed by arra ...

Diskus Segmented - grinding machine with horizontal grinding spindle , for machining steel / gus / ceramics. the machine has been fully functional for 10 years until it is decommissioned. For the technical data, please refer to the AWF charts attached in the appendix. If you have any questions or would like to make an appointment, please do not hesitate to contact us. Delivery from place. Machine for export.

Discus level sanding machine with Vertikaler-Schleifspindel and Schleifradaufnahme f?r Ceramische-Schleifsegmente. Construction year 1957 the machine is technical and geometrically in very good state. it was waited up to Au?erbetriebsetzung 2006 regelmig. hydraulic table impulse: infinitely variable adjustably vertical delivery: hydraulically Schleifrad-Durchme?er: 600 mms impulse achievement: 22 kW Magnetabme?ung: 300 x 1,000 mms Schleiftischabme?ung: 400 x 1,700 mms

adjustment drive of the grinding spind.slide:0,0025 - 0,05 mm total power requirement:100 kW adjustment of grinding head slide:150 mm weight of the machine ca.:17 t grinding spindle drive:2 x 37 kW grinding width:30-150 mm peripheral speed:34 m/sec workpiece speeds:60 - 300 mm/Sek. grinding height:70 mm grinding wheel diameter:750 mm grinding tools:750 x 75 x 350 mm grinding wheel turning speeds:870 U/Min. max. workpiece diameter:250 mm

CONTROLS   CNC controls SIEMENS 840 D WORKING RANGE (DOUBLE DISC GRINDER)   Grinding wheel diameter: 750 mm   grinding width max. - throughfeed grinding: 180 mm   material thickness max. - throughfeed grindin: 30 mm   grinding width max. - plunge cut grinding: 300 mm   material thickness - plunge cut grinding: 80 mm GRINDING SPINDLE 1   drive power: 48 kW GRINDING SPINDLE 2   drive power: 48 kW COMPONENT-FEEDER   Feeder Design: rotary Feeder   feeder velocity max.: 20 mm/min   feeder velocity min.: 240 mm/min DIMENSIONS / WEIGHTS   space requirements -left/right-: 4900 mm   space requirements -front/back-: 5000 mm   total height: 3100 mm   total weight approx.: 13000 kg with inline measuring system DISKUS IONIC 17A Emulsion treatment syst ...

CONTROLS   CNC controls SIEMENS 840 C WORKING RANGE (DOUBLE DISC GRINDER)   Grinding wheel diameter: 457 mm   grinding width max. - throughfeed grinding: 80 mm   material thickness max. - throughfeed grindin: 20 mm   grinding width max. - plunge cut grinding: 205 mm   material thickness - plunge cut grinding: 80 mm GRINDING SPINDLE 1   drive power: 23 kW GRINDING SPINDLE 2   drive power: 23 kW COMPONENT-FEEDER   Feeder Design: rotary Feeder   feeder velocity max.: 240 mm/min   feeder velocity min.: 20 mm/min Scope of delivery: - Machine - emulsion tank new in 2012 Measuring control IONIC 17A

CONTROLS   conventional WORKING RANGE (DOUBLE DISC GRINDER)   Grinding wheel diameter: 750 mm   grinding width max. - throughfeed grinding: 150 mm   material thickness max. - throughfeed grindin: 70 mm GRINDING SPINDLE 1   spindle revolutions (max): 610 /min GRINDING SPINDLE 2   spindle revolutions (max): 610 /min COMPONENT-FEEDER   Feeder Design: rotary Feeder DIMENSIONS / WEIGHTS   space requirements -left/right-: 5230 mm   space requirements -front/back-: 4460 mm   total height: 3600 mm   total weight approx.: 11000 kg Machine is dismantled and stored

CONTROLS   CNC controls SIEMENS 810 T WORKING RANGE (DOUBLE DISC GRINDER)   Grinding wheel diameter: 750 mm   grinding width max. - throughfeed grinding: 180 mm   material thickness max. - throughfeed grindin: 30 mm   grinding width max. - plunge cut grinding: 180 mm   material thickness - plunge cut grinding: 30 mm COMPONENT-FEEDER   Feeder Design: rotary Feeder ELECTRICAL SPECIFICATIONS   total power consumption: 95 kW Scope of delivery: - Machine - div. flanges and used grinding wheels - Measuring control IONIC 17A Optional: - 270 pcs. grinding segments 22A 100 S 6 B20 - 289 pieces grinding segments 14C 80 L 10 B30 Machine is dismantled and stored

Ref. -No.: 10233 Manufacturer: DISKUS Year of construction: 1973 Type of control: Konventionell Control: N/a Storage location: Halberstadt Country of origin: Deutschland Serial no.: 6984 Weight Of The Machine Ca.: 3 t Further information: Discuss - surface grinding machine

Technical data Work-piece diameter: 5 - 50 mm Max. work-piece height: 1 - 70 mm Arrangement: bilateral (above, below) Grinding wheel: outside diameter: 457 mm inside diameter: 76.2 mm Width / height: 75 mm Grinding wheel speeds: from: 251 rpm up to: 1254 rpm from: 6 - 30 m/s Speed of the work-piece driving plate: from: 21.8 rpm up to: 215 rpm Voltage: 380 Volt Grinding motor power: 2 x 30 kW Total installed power: 35 kW Machine´s weight about: 4000 kg Overall dimensions machine: Length: 2450 mm Width: 1100 mm Height: 2700 mm Various accessories: Measuring instrument: IONIC

Technical data Max. work-piece height: 80 mm Number of grinding heads: 2 Arrangement: horizontal Work-piece driving plate: Grinding wheel: outside diameter: 300 mm inside diameter: 233 mm Width / height: 50 mm Grinding wheel speeds: from: 1530 rpm up to: 24 m/s Work-piece advance: Speed of the work-piece driving plate:: 29.6 - 192 mm/s Voltage: 380 Volt Machine´s weight about: 2500 kg Overall dimensions machine: Length: 3050 mm Width: 1400 mm Height: 1600 mm Various accessories: Measuring instrument: PRETEC Workpiece loader

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Distance between grinding wheels: 0 mm Grinding wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Max. work-piece height: 80 mm Grinding width: 40 mm Grinding wheel: outside diameter: 400 mm inside diameter: 250 mm Width / height: 50 mm Grinding wheel right side: Grinding wheel speeds: from: 134.5 rpm up to: 1435 rpm Peripheral speed: 24 m/s Grinding weehl left side: Rotation speed: 1150 rpm Peripheral speed: 3 - 30 m/s Feed range: 26 - 246 mm/s Voltage: 380 Volt Total installed power: 30 kW Machine´s weight about: 4200 kg Overall dimensions machine: Length: 3300 mm Width: 2600 mm Height: 2300 mm Dimensions electric cabinet: Length: 1800 mm Width: 400 mm Height: 2000 mm Various accessories: Coolant system Wheel trueing attachment Measuring instrument: IONIC Workpiece loader Automatic loading and unloading uni ...

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Distance between grinding wheels: 0 mm Grinding wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Control: SIEMENS 840 D Technical data Grinding dimension: Continuous-cut grinding: 1 - 20 mm Continuous plunge-cut grinding: 1 - 20 mm Dive grinding: 2 - 80 mm Grinding width: Continuous-cut grinding: 8 - 80 mm Continuous plunge-cut grinding: 8 - 80 mm Dive grinding: 205 mm Number of grinding heads: 2 Arrangement: bilateral (above, below) Grinding wheel speeds: from: 24 m/s Diameter of grinding wheel: 457 mm Feed range: 20 - 240 mm/s Cutting speed: 63 m/s Voltage: 380 Volt Grinding motor power: 2 x 23 kW Machine´s weight about: 9000 kg Overall dimensions machine: Length: 4700 mm Width: 4200 mm Height: 3000 mm Various accessories: Workpiece conveyor

grinding length: . mm grinding width: . mm workpiece weight: . kg grinding wheel dia. (unused wheel): 400 mm slide stroke: Vertikal Z = 200 mm slide stroke: Horizontal X = 950 mm speed: 30 m/min grinding spindle drive: 10 kW working spindle drive: 6,3 kW max. workpiece diameter: 150 mm workpiece width - max.: 32 mm grinding wheel diameter: 400 x 120 x 65 mm grinding wheel turning speeds: 0 - 3000 mm-1 peripheral speed: 63 m/sec work piece spindle speed: 0 - 3000 min-1 electrics - voltage/frequency: 400 / 50 V/Hz Control: Siemens 840 D total power requirement: 22 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 2,5 x 2 x 2,2 m CNC-controlled plan-side grinder with 2 spindles with a turning station - CNC control Siemens Sinumerik 840 D The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding height: 50 mm grinding width: 120 mm grinding wheel diameter: 600 mm total power requirement: 85 kW weight of the machine ca.: 9500 kg D I S K U S (Germany) CNC Controlled Double Sided Vertical Spindle Surface Grinder with Rotary Workpiece Feed System and IONIC Size Control Model DDS 600 III PLM - CNC Year 1992 erial No. 7924 _______________________________________________________ Grinding wheel Ø x bore x height, each 600 x 150 x 75 mm Approximate Workpiece dimensions: Grinding height, approx. 1.5 – 50 mm Grinding width, appox. 20 - 120 mm Vertical quill adjustment, each, approx. 150 mm Infeed of grinding wheels via CNC 0.0001 mm Feed of workpiece transportation device, infinitely variable 40 – 235 mm/sec Grinding wheel speed, each (30 m/s) 191 - 955 rpm Grin ...

grinding height: 60 mm grinding width: 120 mm grinding wheel diameter: 600 mm grinding length: mm workpiece height: 60 mm total power requirement: 50 kW weight of the machine ca.: 7000 kg dimensions of the machine ca.: m D I S K U S (Germany) Double Side Vertical Spindle Surface Grinder, C-Frame Design, with Rotary Workpiece Feeding System and Automatic Dressing Device Model DDS 600 CR-A Year 1969 Serial-No. 6672 ______________________________________________________________________ ________ Grinding wheels Ø x bore, each 600 mm Grinding wheels height x width, approx. 60 mm Workpiece dimensions: Grinding height x grinding width, approx. 60 x 120 mm Vertical adjustment of each grinding head 150 mm External Ø of workpiece carrier disk, approx. 810 mm Feeds of rotary workpiece feed system 1 ...
