CNC wire EDM machine Makino EU 64 Year: 2002 X x Y x Z: 600 x 400 x 260 mm maximum workpiece size X: 940 mm maximum workpiece size Y: 650 mm maximum workpiece size w: 260 mm Table size x 920 mm Table size Y: 600 mm with automatic wire Threading Cutting in the water bath Cooler
; Gross weight [kg]: 3260; Rear tyres remaining: 60; Front tyres remaining: 60; Maximum lift capacity [kg]: 200
; Gross weight [kg]: 3160; Rear tyres remaining: 60; Front tyres remaining: 60; Maximum lift capacity [kg]: 200
; Gross weight [kg]: 3160; Rear tyres remaining: 50; Front tyres remaining: 50; Maximum lift capacity [kg]: 200
Weight approx.: 2800 kg Dimensions (l x w x h) approx.: 2200 x 2200 x 2100 mm Description: HARMILLES ROBOFIL 240 Wire EDM Machine traverse paths X-axis: 350 mm Y-axis: 220 mm Z - axis: 220 mm dimensions of basin: 1000 x 550 x 220 mm clamping plate: 860 x 450 mm with breakthrough: 370 x 240 mm with extensive documentation accessories workbench with contents consisting of clamping material EROWA wire reels 1 tool cabinet with clamping material tool holders
Weight approx.: 100 kg Dimensions (l x w x h) approx.: 700 x 350 x 500 mm Description: 7 reels. See photo
Wire electrode, SG2 welding wire, welding wire -Grossrolle Wire thickness 1.2 mm Wire electrode high-alloy, chemically resistant -4x rolls available Price per package -Weight 12 kg
type JB 260, working width 256 mm, \r\n2 speeds, cap. max. 50 + 42 strokes/min.\r\naccessories: wire cut (1 design), 4 rows,\r\ninput by a chain for plates 256 x 625 mm
table length: 560 mm table width: 445 mm x-axis: 300 mm y-axis: 200 mm z-axis: 250 mm max. size of workpiece LxWxH: 810x580x250 mm dielectric: DA 15 C total power requirement: 15 kW Switch-on hours. 41000 h
Weight approx.: 200 kg Dimensions (l x w x h) approx.: 2200 x 800 x 1200 mm Description: Tabletop approx. 2000 x 750 mm, door and 6 drawers, contents: open-end wrenches, gripping pliers, ratchet box, screw clamps, files, hammers, wire brushes, vice jaw width 125 mm
Control system: CHARMILLES Table surface: 500 x 400 mm Travel distances : X: 350 mm Y: 250 mm Z: 300 mm Distance between the table and the spindle: 500 mm Maximum weight without electrode changer: 50 kg Maximum workpiece weight: 500 kg Motor power: 5 kW Dielectric volume: 350 l VOLTS: 380 / HZ: 50 / KVA: 5 Machine dimensions: 2050 x 1800 x 1550 mm Machine weight: 2300 kg In 2015/2016 DE servis: Complete machine regulation New: (C-axis -TFT screen - fan - USB flash disk-Electric panel) Heat exchanger for 16 electrodes Manual
Procedures: [X x Y x Z] 600 x 400 x 260 mm maximum workpiece size X: 940 mm maximum workpiece size Y: 650 mm maximum workpiece size w: 260 mm with automatic wire Threading U / V - axis: +/-75 mm cutting in a water bath
Wire EDM machine Matra-Fanuc tape-cut M: Year: 06/1986 EDM height: 200 mm Travel: 500 x 300 mm Wide range of accessories and spare parts range
Year of construction: 1972 Wire diameter: 4.0 mm max wire section: 52 mm output: 150-310 / min adjustable maximum shaft length: 40 mm With soundproofing hood and Brankamk monitoring device good condition!
Powerful, water-cooled welding machine with case with wire feed case Capacity: 20 A / 15 V-310 A / 30 V Very good condition!
X, Y, Z displacements: machine L x W x H: 350 X 220 X 220 mm dimensions 2020 X 2050 X 2000 mm machine weight: 3200 kg The machine is in good technical condition, the possibility of testing, by prior arrangement.
Galvanized fence fields, new with concrete feet and joints. Offer: 20 hoarding fields stand type with 21 feet of concrete and 20 connector = 699,00EUR + VAT = 34,95EUR / piece. Also available separately! The fields are with tubular steel frame, the stuffing out of 2.50-3, 00 is welded to the tube mm steel wire inside. The elements are completely galvanized. 1 x construction fence field 2, 00 m x 3, 47 m = 27,90EUR + VAT 1 x construction fence titanium reinforced on the corners at top prices only 29,90EUR + VAT 1 x construction fence / visibility protection net, 1, 76 m x 3, 41 m = 9,90EUR + VAT 1 x construction fence box 1, 20 m x 3, 47 m = 24,90EUR + VAT 1 x Bauzaufeld 2 ...
Bonding process: ultra sound wedge-wedge bonding, program size: 10.000 connection, x-travel: 255mm, y-travel: 180mm, z-travel: 28mm, wire strength: 17.5-85µm, bonding force: 10-150cN, connected load: 2.2kW, length: 1400mm, width: 920mm, height: 1820mm, weight: 1.1t, CE marking is missing and needs to be replaced.
Offered here is a wire drawing machine of manufacturer Jankowski. The machine located in our warehouse in Hagen and can be visited like. Technical data: Manufacturer: Jankowski Type: DVG 700 / 16s Year of construction: 2004 Performance at 50 Hz: 9,2 kW Performance at 87 Hz: 16 kW The honing wheel diameter: 700 mm Towing force: 30,000 N pulling stone size standard: â 43 x 27 mm Control range 1: 10 Min drawing speed: 1.0 m / min Drawing speeds up to 23 m / min Maximum wire diameter (600N / mm2): 12 mm Operating voltage: 230 / 400 V Control voltage: 24 V DC Rated current: 25 A / 400 V Weight: 1800 kg Free loading truck Visit any time by appointment only poss ...
Offered here is a wire drawing machine of manufacturer Herborn Breitenbach The machine located in our warehouse in Hagen and can be visited like. Technical data: Manufacturer: Herborn Breitenbach Year of construction: 1997 Wire material: steel wire Inlet â Ã?: max. 16,5 mm Ready - Ã?: max. 14.9 mm Capstans - Ã¸: 750 mm Working speed: 20 m / min stepless adjustable Power supply: 400 V 50 Hz Drive capacity: three-phase motor 22.0 kW Pulling stone dimensions: D = 60 x 32 mm cylindrical Weight: approx. 2500 kg Free loading truck Visit any time by appointment only possible and desirable. Delivery possible. Please enquire
CNC wire EDM machine, 5-axis, Fanuc Alpha 1C-CE Manufacturer: Fanuc Type: Alpha 1C-CE Year of construction: 1996 Control: Fanuc 16-w Travel (x-Y-Z): 520-370-300 U/V 120-120 Hours of operation: 25779
CNC wire EDM machine, 5-axis, Fanuc Alpha 1iB Manufacturer: Fanuc Type: Alpha 1iB Year of construction: 2003 Control: Fanuc 180 is-wB Travel (x-Y-Z): 550-370-310 U/V 120-120 Hours of operation: 19043 Accessories: -Cooling device for cooling water
BOGE-industry compressor of TOP AIR SC 4-15 bar Super soundproof Piston compressor automatically working, air-cooled, oil lubricated, with CE mark -Space-saving compact design motor and compressor one above the other -Pressure detection via pressure sensor -Precise pressure adjustment via the keyboard -Electromagnetic vent no-load start -Cabinet, completely wired, protection class IP 54 -Mains contactor in the control cabinet -Control transformer to create the control voltage Control: Focus BOGE TOP condition
Machine type MIG/MAG welding unit Make Merkle Type CompactMIG 220 K Supply voltage 3 x 400 volts Setting range 25-220 amps Duty cycle 40% ED 220 amp 60% ED 170 amp Power setting 7 gears Cooling transformer by built-in fan Cooling TIG torch Run portable compact system Wire feed speed 4-roller transmission DV 26 Securing 16 ampere Dimensions L x W x H 870 x 480 x 740 mm Weight 90 kg Optional accessory display Wire automatic Age 12 months State factory held tested very well, including UVV workshop test protocol Welding system supplied with the following accessories: 1 piece welding torch SB 157 G, 3 mtr. long 1 piece earthing cable 4 mtr. ...
gebr. UP - welding machine / welding rectifier make ESAB Model LAE 800. No.: 845 305 186 built in 2001 Welding current 75-800 A Power consumption 100% 800 A Power supply 400 V Hose length approx. 32 m With: Welder/tractor ESAB, model PEG1 DC 1500A Built in 2001, with welding fittings Wire thickness 1.6-4 mm Wire feed speed up to 9 m / min External dimensions rectifier: Width 600 mm Depth 600 mm Height 1100 mm Dimensions tractor: Width 800 mm Depth 1000 mm Height 900 mm Total weight approx. 500 kg
