Part Number 6368 TECHNICAL DATA - max width of the workpiece 230mm - max height of the workpiece 130mm 7 spindles: 1) horizontal bottom 230mm 5,5kW 2) vertical right 130mm 5,5kW 3) vertical left 130mm 5.5kW 4) horizontal top 230mm 7,5kW 5) horizontal upper 230mm 11kW 6) horizontal bottom 230mm 18,5kW 7) universal 230mm adjustable at 360 degrees 5.5kW - all spindles adjustable up/down, right/left - all spindles equipped with an electric brake - spindle diameter 40mm - spindles 4 and 5 electrically adjustable up/down - from above 8 metal pulling introductory shafts, swivel including 2 double - from above 4 pulling rollers, rubber - pressure from above 2pcs - from the ...

TABLE mm 2600 x 530 ROLLS min. ÷ max. mm 0.4 ÷ 3 STRIP FABRIC MAX MM 5 max. workpiece height min. ÷ max. mm 12 ÷ 50 min length or width processable plate mm 190/65 Speed m/min 7  ...

• more information

Specifications: -cutting length 4500 mm -cutting depth 4300 mm -saw height above the table 115 mm -Max. trolley speed 30 m/min -pusher with 8 pneumatic clamps -3 x 1500 x 600 front shelves coated with bakelite -main saw fi 380 mm -saw motor 7.5 kW – weight 4400 kg -scoring motor 1.5 kW -current consumption 55 A -suction 2 x 120.1 x 150 mm -dimensions 7000 x 8200 x 1700 mm

CNC Machining Center SCM Type Z 25 PLUS R4R4 Year of manufacture 2005 Working range X between stops 2500 mm Vertical bores Y 1018 mm Milling Y 1240 mm Plate throughput maximum 180 mm Maximum panel thickness Z = 100 mm Stroke Z axis 200 mm Central lubrication at the top and bottom Drilling unit with 15 vertical spindles 6 horizontal spindles, 4 in the X direction and 2 in the Y direction Spindle speed 4000 rpm. Motor power spindle rotation 2.2 kW Travel speed of the X-Y axes 42.4 m/min. Travel speed Z axis 11.5 m/min. Main spindle approx. 6.6 kW Maximum speed of the main spindle 24000 rpm. Front tool changer with 4 tool holders Rear tool changer with 4 tool holders  ...

This 3-axis SCM TECH Z25 PLUS H-R4 was manufactured in 2005. It features a working area of 2500 x 1000 mm and a travel range of 2980 mm on the X-axis, 1280 mm on the Y-axis, and 200 mm on the Z-axis. The machine is equipped with 16 spindles operating at 4000 rpm and an electric spindle with a maximum speed of 18,000 rpm. If you are looking to get high-quality CNC processing capabilities, consider the SCM TECH Z25 PLUS H-R4 machine we have for sale. Contact us for further details.

CNC Machining Center SCM Type Z 25 PLUS R4R4 Year of manufacture 2005 In 2022 new control system KVARA6 4A AN +6A MECH- ESA-GV (for 9,000 EUROS) Working range X between stops 2500 mm Vertical bores Y 1018 mm Milling Y 1240 mm Plate throughput maximum 180 mm Maximum panel thickness Z = 100 mm Stroke Z axis 200 mm Central lubrication at the top and bottom Drilling unit with 15 vertical spindles 6 horizontal spindles, 4 in the X direction and 2 in the Y direction Spindle speed 4000 rpm. Motor power spindle rotation 2.2 kW Travel speed of the X-Y axes 42.4 m/min. Travel speed Z axis 11.5 m/min. Main spindle approx. 6.6 kW Maximum speed of the main spindle 24000 rpm. Fron ...

4-side Planer SCM P 75 Year of construction 1983 Masch. No. 045 8vsoczcl8 Planing width of 180 mm Planing height of 130 mm 4 spindle length 2500 mm Weight 1670 kg L x W x h: 310 x 120 x 180 cm The machine is in good condition, little used, ready for use. Subject to changes, errors, and intermediate sale! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

ROUTER type SCM R9 ...

• more information

THICKNESS PLANER type SAC SUERI RS 53 S second hand machine CE mark : Yes technical details : useful working width mm. 530 maximum (minimum) working height mm. 300 (3) maximum removal mm. 8 variable feed speed by inverter m / min. 4 ÷ 16 motorized table positioning with electronic reading n.4 knives "Tersa" main motor power Hp 5,5 volt. 380/50

surface planer , thickness planer , spindle moulder . machines SCM L'Invincibile second hand machines in Excellent working conditions NOT separate sale thickness planer model SCM S 63 l'Invincibile : useful working width mm. 630 maximum (minimum) working height mm. 240 (3) maximum removal mm. 8 variable feed speed mt./min. 6 ÷ 18 motorized table positioning with reading n.4 knives "Tersa" main motor power Hp 7,5 volt. 380/50 surface planer model SCM F52 l'Invincibile working width mm. 520 tables length mm. 3000 ground cast iron tops n.4 knives tilting guide up to 45° motor power Hp 5,5 volt. 380/50 spindle moulder with tilting spindle model SCM T160 l’Invin ...
