DIEFFENBACHER PO-F 1250 A hydraulic press was built in Germany in 1981 by J. Dieffenbacher GmbH & Co. The machine was regularly maintained and upgraded throughout its service life. In 2016, a major upgrade was carried out, which included replacing the electrical cabinet, installing light curtains and adding a SIEMENS SIMATIC HMI TOUCH touchscreen operator panel. The piston seals were also replaced and measuring scales were added for precise position measurement of the slider, top ejector and lower die cushion. The DIEFFENBACHER PO-F 1250 A is an extremely versatile hydraulic press for demanding metal forming applications. Its main purpose is die stamping of steel components, calibration o ...

DIEFFENBACHER PO 500A hydraulic press was built in 1978 in Germany by J. Dieffenbacher GmbH & Co. The machine has been regularly maintained and upgraded throughout its service life. In 2017, a major upgrade was carried out, which included replacing the electrical cabinet, installing light curtains and adding a SIEMENS SIMATIC HMI TOUCH touchscreen operator panel. The seals and electrical system were also replaced. The DIEFFENBACHER PO 500A is the perfect choice for even the most demanding metal forming operations. It enables the execution of such operations as die stamping, punching, calibration of forgings and hot and cold bending. All these machining processes are performed with a high  ...

Hot Isostatic Press - HIP Press J. Dieffenbacher HIP 3000 Year: 1989 Complete documentation, electronic control and programs Siemens PC 677 and PLC available. For more technical information, see photo nameplate The facility was only used to a small extent for scientific experiments. Subject to prior sale - errors possible! Internal reference number: D-1222

pressure: . t stroke: 500 mm daylight: 800 mm arbor support: 3000 Ram: 600x250 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Banning feed unit Adjustable supports (1300 mm each) 2 x roller conveyors (4000 x 800) Storage area (4000 x 1600) The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, ple ...

pressure: 2000 /1000 t distance between columns: 2650 mm stroke: 500 mm column travel -side: 500 x 1000 mm diameter of piston: 710 mm number of pistons: 2 distance between table / ram: 1000 mm operating pressure: 130 / 230 bar dayligth: 800 mm table length: 2500 mm table width: 1600 mm table height: 250 mm draw back pressure: 500 kN number of T-slots: 8 turning speeds: 1500 U/min rapid speed: 120 - 140 mm/min closing speed: max. 120 - 140 mm/sec. hydraulical ram locking: return of plunger by small single cylinders: 100 - 110 mm/sec cutting sound absorber: 300 t die cushion capacity: 200 t die cushion stroke: 250 mm speed of die cushion: 100 mm/sec voltage: 380 V frequency: 50 Hz quantity of ...

pressure: 320 t throat: 800 mm stroke: 630 mm distance between table / ram: max. 1000 mm ram head dimension: 710 x 600 mm table-size: 800 x 1200 mm work height max.: 1015 mm quantity of oil: 1100 l Number of working hours: 7663 h weight of the machine ca.: 15 t dimensions: ca. 1600 x 2200 x 4800 mm dimensions of switch cabinet: ca. 1200 x 400 x 1800 mm Tested for function. During the test run it is noticed that the press ram not 100% leak-proof. In addition, the cable for manual operation was mended several times. Upper cover is missing, since this was dismantled by the customer due to crane use. Operating instructions and electrical plans available. The data for this ad was created with M ...

Short-cycle press Fabr. Dieffenbacher Dimensions plates: 560 x 220 cm Heating Medium: Thermal Oil  ...

• more information

pressure:1000 t distance between columns:3030 mm stroke:350 mm Distance table/ram, max. stroke up, adjustment up:1400 mm table surface area:3000 x 2000 mm table height over floor:430 mm side window:1450 x 1400 mm ram surface:3000 x 2000 mm speed down:300 mm/s speed up:340 mm/s working speed:18 - 44 mm/s return capacity:120 t oil volume:4400 l width with platform:4950 mm power capacity:2 x 90,0 + 10,0 kW weight:87,0 t Dimensions (WxDxH):4,35 x 3,65 x 7,55 m height over floor:6,05 m height beneath floor:1,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:500 t distance between columns:1910 mm stroke:500 mm Distance table/ram, max. stroke up, adjustment up:700 mm table surfache without cutting impact cushions:1910 x 1360 mm table surfache with cutting impact cushions:1600 x 1360 mm table height over floor:800 mm ram surface:1600 x 1270 mm Side window:600 mm speed down:400 mm/s speed up:330 mm/s working speed:10 - 28 mm/s oil volume:1200 l power requirement:60,0 kW weight:40,0 t Dimensions (WxDxH):3,6 x 2,5 x 5,0 m height over floor:4,5 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 cutting impact cushioning:hydraulic ram interlocking:hydraulic

Used Used Presses Preform PET ENGEL 2004: Year: 2004 Condition: Good Used Presses Preform PET ENGEL: Model: MacPET 4550-320 maszyna nr 52890 Year: 2004 Speed: preform 24,5g ca 21.900 pcs/hrs preform 29,0g ca 20.100 pcs/hr Number of molds: 72 Code: W 111 More details: https://bottlingscout.com ...

• more information
