Year of Build 2003 (0450)
FANUC 16i-T control with 9 axes,
9 axes (X/C1/Y/E/B/A/X/c2),
Rod Ø max. 13 mm
Turning length max. 205 mm,
Main spindle, speed max. 12,000 rpm, C-axis,
Sub-spindle with collet, speed max. 12,000 rpm, C-axis,
4-fold tool holder
3 cross drilling rigs
8-station turret
various additional tool holders, quills,
Fire extinguishing system Kraft und Bauer
Parts Conveyor Belt
Manuals Operation/Programming/Electrics/Spare Parts
Operating Tool Machine
Up to 29 turning tools and up to 19 operated tools Tools possible
9.0KVA
Fuel tank capacity 170L
Charging magazine FMB Turbo 2-16 /3200/A / from Ø2- Ø20 mm /
Coolant Insert of Machine: Oil
Machine dimensions: approx. 2700 x 1400 x 1700 [mm]
Machine weight: approx. 1700 [kg]
Dimensions loading magazine: approx. 4300 x 600 x 1800 [mm]
Weight loading magazine: approx. 700 [kg]
Dimensions of the peripheral HD system: approx. 1500 x 500 x1000
[mm]
Weight of peripheral HD system: approx. 250 [kg]
Dimensions of peripherals & accessories: approx. 1200 x 800 x 1000
[mm]
Weight of peripherals & accessories: approx. 200 [kg]
Dimensions of peripherals & accessories: approx. 1200 x 800 x 1000
[mm]
Weight of peripherals & accessories: approx. 200 [kg]
The machine can be viewed by appointment electricity.
Changes and errors in the technical data and specifications as well as
prior sale reserved!
Year 2003 (0450)
FANUC 16i-T control with 9 axes,
9 axes (X / C1 / Y / E / B / A / X / c2),
bar Ø max. 13 mm
turning length max. 205 mm,
main spindle, speed max. 12,000 rpm, C-axis,
counter spindle with collet, speed max. 12.000 rpm, C-axis,
4-fold tool holder
3 cross drilling units
turret with 8 stations
various additional tool holders, quills,
Extinguishing system Kraft and Bauer
parts conveyor belt
manuals operation/programming/electrical/spare parts
Operating tools machine
Up to 29 turning tools and up to 19 M51257993 applied tools
possible
9.0KVA
Tank capacity 170L
Loading magazine FMB Turbo 2-16 /3200/A / from Ø2- Ø20 mm /
Machine coolant: oil
dimensions machine: approx. 2700 x 1400 x 1700 [mm]
weight of machine: approx. 1700 [kg]
Dimensions loading magazine: approx. 4300 x 600 x 1800 [mm].
Weight of loading magazine: approx. 700 [kg]
dimensions peripheral HD system: approx. 1500 x 500 x 1000 [mm]
Weight of HD system peripherals: approx. 250 [kg]
Dimensions periphery & accessories: approx. 1200 x 800 x 1000 [mm]
Weight of peripherals & accessories: approx. 200 [kg]
Dimensions periphery & accessories: approx. 1200 x 800 x 1000 [mm]
weight periphery & accessories: approx. 200 [kg]
The machine can be inspected after appointment current.
Changes and errors in the technical data and information and subject
to prior sale!
Germany
