Folding machine KRAMER type A-toll. II 1000Fabr. No. 48 287 Year of construction 1990Useful length 1060 mmmax. Sheet thickness 3.75 mmStroke of the upper beam 180 mmAdjustability of the bending beam 60 mmBack gauge 480 mmDrive power of bending beam drive 4 kWAdrive power of upper beam drive 1.5 kWNet connection 400 volts, 50 Hz- manual and semi-automatic control- angle adjustment via angle selector- one-piece pointed rail 135- back gauge with hand crank adjustment and simple measurement scale-

Vacuum cutter Kramer+Grebe VSM 200 Manufacturer Germany Year of production Overhauled Technical data overall dimensions 2800x2300x1700 mm; bowl 200 ltr; 3 knives speeds 1000/1500/3000 rpm; 2 bowl speeds; 2 mixing speeds; hydraulic loader; hydraulic unloader; 6 knives; power supply 400 V, 50 Hz; power: main motor 26/48/85 kW, bowl motor 2,6/5,1 kW, mixing motor 3,2/4,1 kW; unloader motor 1,1 kW, hydraulic system 2,2 kW, vacuum pump Busch 250 m3, 5,5 kW.

Gr. Working width: 1530 mm for sheet metal up to: 2.5 mm opening width upper beam: 290 mm adjustable beam: 90 mm upper cheek drive: 1,1 kW under cheek drive: 3 kW Backgauge: Yes Weight: 2200 kg space requirement: 800 x 3000 x 1380 mm  ...

• more information

Erl Working width: 2040 mm for sheets up to: 3 mm Opening width upper cheek: 90 mm Adjustable bending cheek: 90 mm Upper cheek drive: 1.5 kW Lower cheek drive: 4 kW electr. Connection: 380 V kW Weight: 2600 kg Space requirement: 3050 x 800 x 1350 mm  ...

• more information

Technical data: - bending and rolling by hand, - max working width 1020 mm - max. material thickness St 40 1.25 mm - Bending angle adjustment via end stop 10 - 180 ° - max hub upper cheek approx. 85 mm - max. adjustable bending cheek 20 mm - Shaft diameter 55 mm - Upper shaft can be swivelled - Rear shaft parallel + obliquely adjustable - Space requirement approx. W 1500 x H 1400 x D 750 mm - Weight approx. 400 kg

sheet width: 3100 mm plate thickness: 2 mm : 90 mm adjustable bending rolls: 90 mm : 2 kw : 5 mm weight of the machine ca.: 4000 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.  ...

• more information

Max. bending length: 3000 mm Max. sheet thickness: 3 mm steel Manual backgauge Manual and automatic bending process possible Bending angle adjustable via potentiometer Lifting height of the upper beam variable Bending rail ground Operating instructions Weight: approx. 5,000 kg  ...

• more information

plate thickness: 3 mm Bending Angle: 165 ° : dreiphasig total power requirement: 380 V - 10,5 A 50 HZ weight of the machine ca.: ca. 3.900 kg dimensions of the machine ca.: B 2400 x L 4300 x H 1700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.  ...

• more information

sheet width: 1020 mm plate thickness: 1,5 mm daylight opening: max. 85 mm weight of the machine ca.: 240 kg dimensions of the machine ca.: m Smallest bending width factor 10 x sheet thickness s Smallest inner radius factor 1.5-2 x sheet thickness s Lowering capability of the lower and bending beams 20 mm On this swing-beam bending machine, the beams and side stands are reinforced with particularly strong ribbing. The cross-sections are designed to be strong enough to bend even narrow offsets. On the AML 1000 model, the bending beam is balanced by a gas pressure spring. The opening width of the upper beam and the lowerability of the lower and bending beams are generously dimensioned. The mach ...

Cutter Manufacturer: Kramer Grebe Wetter Bowl made out of stainless steel Dimensions: 290x244x210cm Control voltage: 230V Operating voltage: 400V / 50Hz Power: 74kW  ...
