Vertical CNC centre lathe, uses / outdated machine type: Emag VSC 200 control: Siemens 840 C construction year: From the in 1995 to the in 2007 overtakes TECHNICAL DATA: speed area / speeds: [1 / min].: 6,000 Drehmoment:/torque [Nm]: 480 Max dreh-? over bed swing diam .: 290 mms impulse achievement / power: [kW] 34 feed ? / chuck diam. 200 mms revolver / turret: 12-fold, VDI 40, shoemaker powered work witness / driven tools 7.8 kW Verfahrwege: X axis / x-travel: 550 mms Z-Achse/z-travel: 200 mms express way / rapidly travel: (X/Z) [m / min] 30 / 20 prepush / feeds: (X/Z) [m / min]. 11 KN connected load: [KW] 36 kW machine weight: [kg] 6,500 equi ...

grinding diameter: 390 mm grinding length: 650 mm centre height: 200 mm workpiece weight: max. 250 kg x-axis: 380 mm z-axis: 1150 mm sanding disc diameter: 400 mm peripheral speed: 20-50 m/sec workpiece spindle stepless: 1 - 650 U/min tailstock quill taper MT: 4 quill stroke: 45 mm dia. of quill: 50 mm total power requirement: 22 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

EMAG WEISS W 11-CNC SL650Year of manuf. : 2020 Control : Sonstige WEISS CNC Centre width : 650 mm____________Description:In Generel:ear of construction:2020Control system:WEISS CNCCentre width:650 mmCentre height:200 mmGrinding wheel dimensions:400x60 mm + 500x60 mmWorkpiece headstock:Speed:10 -650 rpmWorkpiece weight max.:250 (100) kgSanding diameter max.:390 mmMounting:MK4Grinding headstock:Peripheral speed:20 - 50 m/sGrinding disc dimensions right:500 x 60 mmGrinding disc dimensions left:400 x 60 mmX-axis:380 mmZ-axis:700 mmB-axis:torque motor, infinitely variableTailstock:Pinole diameter:50 mmPionole stroke:45 mmMounting:MK 4Cylinder fine adjustment:+/- 0.04 mmEquipment:Positioning ...

CNC vertical lathe Type: VL 5i F Manufacturer: Emag Year: 2016 number of axes : 2 max clearance diameter : 250 mm max part diameter : 220 mm machining height : 175 mm strokes (X/Z) : 660 / 300 mm quick feed (X/Z) : 60 / 30 m/min turret number of positions : 12 tool-holder : VDI40 spindle power : 28 /18 kW speed : 0 to 4.500 rpm index precision C axis : 0,001° part magazine capacity diameter 30 to 85 mm : 37 pos.,max 4.5 kg part magazine capacity diameter 30 to 160 mm : 22 pos.,max 8 kg part magazine capacity diameter 80 to 220 mm : 16 pos.,max 10 kg part height max : 175 mm voltage : 400 V installed power : 36 kW dimensions floor space: 2266 x 4184 mm height : 3200  ...

An EMAG CNC vertical lathe is available. Chuck diameter: 250mm, orbital diameter: 260mm, travel X/Z: 570mm/200mm, rapid traverse X/Z: 60m/30m/min, feed force X/Z: 5kN, ball screw diameter X/Z: 40mm, spindle bearing diameter front: 110mm, speed: 4500rpm, power: 18/28kW, shank diameter: 40mm, power of driven tools: 12kW, speed: 6000rpm. Machine dimensions X/Y/Z: approx. 2700mm/2100mm/2400mm, weight: approx. 7000kg, switch-on time: 50416h, automatic time: 9016h. Documentation available. On-site inspection is possible.

GENERAL Project No.: 905398 Quantity: 1 pcs. Manufacturer: EMAG Type: VL 3 Control: Fanuc 18i TB Year of construction: 2001/2022 State of condition: Refurbished machine Layers approx.: 2-3 layers DESCRIPTION TURN circulation diameter over bed cover 210 mm chuck diameter 170 mm speed main spindle 7500 1/min power main spindle at ED 10-40/100% 25/16 kW torque main spindle at ED 10-40/100% 134/85 Nm Spindle diameter in the front bearing Main spindle 80 mm Spindle flange size main spindle size 5 (DIN 55026) Axes on the main spindle unit X/Z Travel in X/Y/Z main spindle unit 400/-/200 mm rapid traverse speed in X/Y/Z main spindle unit 60/-/30 m/min Feed force in X/Y/Z ...

swing diameter:200 mm weight of the machine ca.:15 t Distance between tips:832,5 mm turning length:380 mm with chip conveyor and belt filter press, infeed and outfeed belt 2 x 12-position revolvers  ...

• more information

turning diameter:250 mm swing diameter:260 mm Available from October 10, 2025 The system consists of two individual systems that are linked together. No driven tools!  ...

• more information

turning diameter:250 mm swing diameter:260 mm Available from October 10, 2025 The system consists of two individual systems that are linked together. No driven tools!  ...

• more information

Inv. Num. : 7575 Type: VL7 Produzent: Emag Erzeugt: 2010, GO 2012 Parametern: Steuerungssystem: Fanuc 32i TB Max. Drehdurchmesser: 420 mm Maximale Drehzahl der Spindel: 3400 1/min Verfahrwege X: 850 mm Verfahrwege Z: 315 mm Spannfuttergröße: 400 Länge: 5250 mm Breite: 3500 mm Höhe: 3500 mm Gewicht: 9000 kg Ausstattung: Kühlung Späneförderer Angetriebene Werkzeuge Messsonde
