clamping force: 800 kN injection volume: 177 cm³ screw diameter: 35 mm platen size: 580 x 580 mm Condition: used, Specification: Horizontal injection moulding machine, type: Ergotech viva 80-400 - Internat. Size specification: 800 - 400 injection unit: - Screw diameter: 35 mm - L/D - ratio: 20D - Injection volume: 177 cm³ - Injection pressure: 2387 bar - Cylinder heating: 8,8 kW clamping unit: - Clamping force: 800 kN - Max. opening stroke: 450 mm - Mould installation height: min. 250 mm - Max. platen distance: 700 mm - Mould clamping platens: 580 x 580 mm - Clear column distance: 400 x 400 mm Total machine: - Oil tank filling: 220 ltr. - Pump ...

Demag Ergotech Viva 800-400 (144) Description without funnel General Information SKU: 144 Availability: In stock Year of construction: 2001 Brand: Demag Specifications Injection weight: 205 g Clamping force: 800 kN Screw diameter: 40 mm Spray pressure: 1830 bar Tie bar spacing: 400 x 400 mm Clamping plate size: 590 x 580 mm Tool installation height min.: 250 mm Control: NC4 Language: German Power: 26.1 kW Operating hours: 70180 h Weight: 3600 kg Dimensions: 4.35 x 1.7 m Funnel: No Core train: Yes

clamping force: 1.000 kN injection volume: 203 cm³ screw diameter: 40 mm platen size: 580 x 652 mm Condition: used, Specification: Horizontal 2K-injection moulding machine, injection unit 1: - Screw diameter: 40 mm - injection volume: 230 cm³ - weight: 205 g Clamping unit: - Clamping force: 1000 kN - Centring: 125 mm - Platen size: 580 x 652 mm - Mould size: 400 x 400 mm - Mould thickness min.: 250 mm - Mould thickness max.: 450 mm - 1x core pull - Voltage: 3x 400V, 50Hz, N, PE - Total power: 25 kW - Dimensions L/W/H: approx. 4,350 x 1,400 x 1,900 mm - Weight approx.: 4,750 kg Further DEMAG plastic injection moulding machines and a con ...

DEMAG ERGOTECH VIVA 800-400 injection moulding machine was built in 2001 in Germany by Demag Kunstofftechnik (currently Sumitomo (SHI) Demag Plastics Machinery GmbH). This highly efficient machine is used for the economic production of plastic parts of different colours, shapes and sizes. These parts are produced using the reliable injection moulding method, which involves feeding plasticised plastic into a mould and then clamping it with high press force. The machine’s high-performance components, including a precision mould clamping system operating at a maximum force of 80 tonnes, ensure high repeatability of the manufactured products. The DEMAG injection moulding machine weighs 3750 kg ...

Hydraulic injection moulding machine manufactured in 1999. This DEMAG Ergotech 150-610 Viva features a screw diameter of 45 mm and a maximum daylight between platens of 850 mm. It has a shot weight of 260 g and a maximum mold installation height of 250 mm. If you are looking to get high-quality injection moulding capabilities, consider the DEMAG Ergotech 150-610 Viva machine we have for sale. Contact us for further details.

Eight Arburg injection molding machines, one Engel injection molding machine, and one Demag injection molding machine are available. 1) Arburg 270M 350-90, year of manufacture: 1996, operating hours: approx. 110000h. 2) Arburg 270M 350-90 U, year of manufacture: 1998, operating hours: approx. 108000h. 3) Arburg 270M 350-90, year of manufacture: 1992, operating hours: approx. 178000h. 4) Arburg 420C 1000-250, year of manufacture: 1995, operating hours: approx. 96000h. 5) Arburg 370C 800-225, year of manufacture: 1992, operating hours: approx. 156000h. 6) Arburg 320M 500-90, year of manufacture: 1991, operating hours: approx. 94000h. 7) Arburg 270M 350-90 U, year of manufacture: 1998, operatin ...

clamping force: -- kN injection volume: 230 cm³ screw diameter: 40 mm platen size: 475 x 475 mm Condition: used, Specification: Horizontal injection moulding machine, injection unit: - Screw diameter: 40 mm - Cylinder diameter: 40 mm - Spraying volume: 230 cm³. Clamping unit: - tie bar distance: 475 x 475 mm - Operating hours approx.: 30000 h - Air valve - Core pull - 12-way hot runner controller The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

screw size:45 mm injection shot weight in Polysterol:149 g/PS closing pressure:100 kN  ...

• more information

clamping force: 600 kN injection volume: 106 cm³ screw diameter: 30 mm platen size: 590 x 600 mm Condition: used, Specification: Horizontal injection moulding machine, type: System 60/420-200 - Internat. Size specification: 600 - 200 injection unit: - Screw diameter: 30 mm - L/D - ratio: 20D - Injection volume: 106 cm³ - Injection pressure: 1995 bar - Cylinder heating: 8,3 kW clamping unit: - Clamping force: 600 kN - Max. opening stroke: 450 mm - Mould installation height: min. 250 mm - Max. platen distance: 700 mm - Mould clamping platens: 590 x 600 mm - Clear column distance: 420 x 420 mm Total machine: - Oil tank filling: 180 ltr. - Pump ca ...

clamping force: 6500 kN injection volume: 2011 / 323 cm³ screw diameter: 80 / 45 mm platen size: 1450 x 1350 mm Condition: used, Specification: Horizontal 2K-injection moulding machine, DEMAG ergotech 650-5200-610 incl. handling injection unit 1: - Screw diameter: 80 mm - injection volume: 2.011 cm³ - weight: 1810 g injection unit 2: - Screw diameter: 45 mm - injection volume: 323 cm³ - weight: 290 g Clamping unit: - Clamping force: 6500 kN - Centring: 200 mm - Platen size: 1450 x 1350 mm - Mould size: 1000 x 910 mm - Mould thickness min.: 450 mm - Mould thickness max.: 950 mm - 2x core pull - Handling ...
