Vertical Numerically Controlled Machining Centres MORI SEIKI NH 5000/40 DCG

X-travel: 730 mm Y-travel: 730 mm Z-travel: 850 mm CNC controller: FS-31IA (MSX-701 III)
Axes
X-axis travel mm: 730
Y-axis travel mm: 730
Z-axis travel mm: 850
Rapid traverse m/min: 50
Distance spindle nose - table surface mm: 100 – 830
Acceleration in the axes m/s2: 9.8 (X), 10.8 (Y), 6.9 (Z)
Worktable
Number of pallets: 2
Table dimensions mm: 500X500
Maximum workpiece size (D x H) mm: 800 X 1000
Max. workpiece weight kg: 500
APC time s: 7
División estandar Grados: 0.001º
Maximum workpiece rotation diameter mm.: 800
Spindle
Spindle speed rpm: 14.000
Spindle drive power kW: 22/18.5
Tool holder: HSK A63
Bearing Inner Diameter mm.: 40
Spindle torque Nm: 220
Tool system
Tool magazine slots: 120
With free neighboring places mm: 140
With occupied neighboring places mm: 70
Max. Tool Length mm: 500
Max tool weight kg: 12
Tool-to-tool time s: 0,9
Chip-to-chip time s: 3,3
Tool Shanks : BT-40
NUMBER OF TOOL OFFSET PAIRS: 200
Tool clamp power N: 12,6
Equipment
Chip conveyor
Workarea light
4th 351248314 axis
CE 351248314 conformity
Coolant gun
Paper band filter
TOOL LIFE MANAGEMENT
CUSTOM MACRO
UNI-DIRECTIONAL POSITIONING
8-DIGIT TOOL NUMBER
ARBITRARY ANGLE CHAMFER CORNER R COMMAND
Swivel-type operation panel 0º to 90º
Cooling
Tank capacity: 680
High-pressure bar: 12
Machine running times
Rated power kVA: 49
Basic machine dimensions / weight
Length mm: 2.725
Width mm: 4.610
Height mm: 3.138
Weight kg: 12.900
seller offer No. resale CNC0609
