Injection moulding machine Arburg 470s 1100/290 YOC 2017 2 K  ...

• more information

Arburg 470S 1100-400 with the Wittmann W711 robot Year of Make: 2008 Injection unit: Screw diameter: 40 mm Injection weight: 184 g Spray pressure: 2000 bar Dosing volume: 201 cc Clamping unit: Clamping force: 110 t Spar spacing: 470x470 mm Size of the clamping plates: 637x637 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Euromap 67 Robot interface Air Valve x 2 Hydraulic core pull x 1 Control with hot runners x 8 Hardened injection unit - Bimetal Proportional valve on the injection unit – precise injection Conveyor belt integrated with the machine control system Built-in sorting flap It is possible to ch ...

Manufacturer: ARBURG Year of Manufacture: 2023 Condition : New Model: ALLROUNDER 920 S 5000 Configuration: 1300 / 1300 L (Multi-component L-type) Clamping Force: 5,000 kN Injection Units: - IU 1: EUROMAP 1300 - IU 2: EUROMAP 800 It was test-run only twice during commissioning and has not been in production since. Does not include the robots mounted on the machine Find more here - / Contact us at -

Arburg 420C-1300-675 (167) Item number: 167 Availability: In stock Year of construction: 2000 Brand: Arburg Specifications Spray weight: 297 g Clamping force: 1,300 kN Screw diameter: 50 mm Spray pressure: 2080 bar Spar spacing: 420 x 420 mm Clamping plate size: 615 x 615 mm Tool installation height min.: 350 mm Control: Selogica Language: German Power: 44.9 kW Operating hours: 84840 h Weight: 4330 kg Dimensions: 4.9 x 1.8 m Funnel: No Core train: Yes Air valve: Yes

 ...

• more information

Screw diameter; 60 mm Injectable volume / Shot volume: 678 cm3 Injection pressure: 2000 bar Column Passage /Bettween tie bar: 570 x 570 mm Mould tickness thickness: 250 mm max: 550 mm Opening stroke: 450 mm Core Pulling: 2 Robot interface: yes / Yes E67 Options: 12 Zones chauffe - 12 heating way

Clamping unit very well preserved, see pictures, also fits 570A as a spare part  ...

• more information

Manufacturer: Arburg Model:720S 3200/1300 Year of Manufacture: 2010 Operating hours: 84854 Closing force: 320 t Screw diameter: 60 mm Max. injection volume: 664 cm3 Fixing plate: 1030 x 1030 mm Machine weight: 17.5 t Find more here - / Contact us at -  ...

• more information

B&A REF: 9289 TON: 320 SCREW DIAMETER: 60-35-30MM SHOT WEIGHT: 607H / 132P / 97S STROKE VOLUME: 644 / 144 / 106CM3 INJECTION PRESSURE: 2000 / 2000 / 2500 AR PLATEN SIZES: 1040 X 1040MM DBTB: 720 X 720MM MIN MOULD HEIGHT: 300MM MAX MOULD HEIGHT: 700MM MOULD OPENING STROKE: 700MM MAX DAYLIGHT: 1400MM EJECTOR STROKE: 250MM CONTROLS: SELOCIA TOUCH CORE PULLING: 3 AIR VALVES: 2 MOTOR: SERVO HEATING CAPACITY: 22 + 7.7 + 7.7KW ROBOT INTERFACE: EUROMAP 67 ROBOT: MULTILFT SELECT 15KG QUER SCREW DRIVE: ELECTRIC HOT RUNNER: 18 ZONE ACCYMULAQTED: 6

Arburg 420C 1300-675 with the Star Sprue Picker Year of Make: 2002 Injection unit: Screw diameter: 50 mm Injection weight: 297 g Spray pressure: 2080 bar Dosing volume: 353 ccm Clamping unit: Clamping force: 130 t Spar spacing: 420x420 mm Size of the clamping plates: 605x605 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA Additional equipment: Euromap 12 Robot interface Air Valve x 2 Hydraulic core pull x 2 Hardened injection unit - Bimetal Type of injection unit: Vario - This offers the possibility of using the injection unit, e.g. for side spraying Covers from the operator's side open automatically Dimensions: Weight: 4330 kg Length/Width/ ...
