Manufacturer/manufacturer: Arburg Typ/type: 420C 1300-250 Year/year: 1999 Control/controller: Selogica Clamping force/clamping force: 1000 kN Holmabstand/Dist.Betw.Tiebars: 420 x 420 mm Disk size/platen size: 605 x 605 mm WZ height/mould hight: min 250 mm Opening/opening stroke: 500 mm Plate distance of max/Max open daylight: 750 mm Auger/screw size: 35 mm Stroke volume/shot volume: 144 CC / 132 gram PS spec. Spritzdr / injection pressure: 1820 bar General / General Engine power: 18.5 kW Heating/heating power: 6,5 kW Dimensions/dimensions: 4.3 m x 1.7 m x 1.8 m Weight/weight: 3180 kg Screen text/language: German/English Additional equipment/additional equipment Core ...

Manufacturer/Manufacturer: Arburg Typ/Type: 420C 1000-350 Bau-year year: 1999 Control/Controller: Selogica Clothing Power/Clamping Force: 1000 kN Schliessart/Clamping Type: Hydraulisch/Hydraulic Holmabstand/Dist.Betw.Tiebars: 420 mm x 420 mm Plate's Platen Size: 650 mm x 650 mm WZ Einbauhoehe/Mould hight: min 225/275 mm Oeff-weg/opening stroke: 575 mm Plate distance max/Max. Open Daylight: 800/850 mm Snail/Screw size: 45 mm Lifting volume/shot volume: 206 cc/194 gram hp Spez. Spray./injection pressure: 1670 bar General General Motor/Motor Power: 18.5 kW Heating/heating power: 10.5 kW Dimensions: 4.4 m x 1.7 m x 2 m Weicht/Weight: 5100 kg Screen text/Language: Deutsch/Ge ...

Manufacturer: Arburg Type: 420 C 1000 - 350 Built: 1999 Control: Selogica Closing type: Hydraulic Closing force: 1000 kN Tie bar ratio: 420 mm x 420 mm Plate size: 570 mm x 570 mm Tool installation height: min 250 mm Opening distance: 500 mm Plate spacing max.: 750 mm Screw: 45 mm Lifting volume: 230 cc / 194 gram PS Spray pressure: 1670 bar General Engine: 22 kW Heating: 8.8 kW Dimensions: 4.3 m x 1.7 m x 1.8 m Weight: 3430 kg Screen text: German

Arburg 420C-1000-60-150 ( 123) 2-component with robot and cage Year of production: 2004 TECHNICAL DATA Screw Dia [mm]: 18/30 Shot Weight [g]: 17/65 Injection Pressure [bar]: 2500/2210 Clamping Force [kN]: 1000 Tie Bar Distance [mm]: 420x420 Platen Size [mm]: 570x570 Mould Height min. [mm]: 250 CONTROL Type of Controls: Selogica Monitor: Yes Control Cabinet: Yes Language: German OTHER Power [kW]: 34,5 Workinghours [h]: 61792 Dimensions [m]: 4,6x1,8 Weight [kg]: 4000 CR - CORE PULL R - ROBOT ZP - AIR VALVE

Manufacturer: Arburg Type: 420 C 1000 - 270 Year of construction: 2007 Control: Selogica Closing type: Hydraulic Closing force: 1000 kN Tie bar spacing: 420 mm x 420 mm Plate size: 570 mm x 570 mm Tool height: min 250 mm Opening distance: 500 mm Plate spacing max.: 750 mm Screw: 35 mm Stroke volume: 144 ccm / 132 gram PS Injection pressure: 2000 bar general Engine: 15 kW Heating: 6.4 kW Dimensions: 4.3 m x 1.6 m x 2 m Weight: 3880 kg Screen text: German Optional extras Core train x1 Robot interface

In our stock in Wellingborough, Northamptonshire is this fully refurbished Arburg 420C 1000 – 250 VU injection moulding machine with vertical clamp and injection. Ideal for insert moulding as an operator can easily and ergonomically load inserts. The vertical clamp means inserts are more likely to stay in place. This machine has a 30mm plasticising unit which gives a maximum shot weight of 89 (PS) (g). As you’d expect from us, this machine has been fully refurbished and is now completely fault & leak free. With low lifetime hours of only 23k, it really is in excellent condition throughout. The plasticising unit is holding max pressure throughout the range, the pump is quiet, the platens ...

Arburg 420C-1000-350 (174) with challenge tape Item number: 174 Availability: In stock Year of construction: 2001 Brand: Arburg Specifications Spray weight: 210 g Clamping force: 1,000 kN Screw diameter: 45 mm Spray pressure: 1670 bar Spar spacing: 420x420 mm Clamping plate size: 570x570 mm Tool installation height min.: 250 mm Control: Selogica Language: German Power: 32.2 kW Operating hours: 89,240 h Weight: 3430 kg Dimensions: 4.4x1.7 m Funnel: No Core train: Yes Euromap: Yes Air valve: Yes

Manufacturer: Arburg Type: 420 C 1000 - 350 Year of production: 2004 Control: Selogica Closing type: Hydraulic Closing force: 1000 kN Tie bar spacing: 420 mm x 420 mm Plate size: 570 mm x 570 mm Tool height: min. 250 mm Opening distance: 500 mm Max distance between plates: 750 mm Screw: 30 mm Stroke volume: 106 ccm / 97 gram PS Injection pressure: 2500 bar General Motor: 22 kW Heating: 5,8 kW Dimensions: 4,3 m x 1,6 m x 1,8 m Weight: 3700 kg Screen text: German Additional equipment: Robot Interface

Arburg 420C-1000-290 Injection Moulding Machine with sorting flap Number: 239 Availability: in stock Year of production: 2006 Producer: Arburg Screw diameter[mm]:40 Injection weight [g]: 172 Injection pressure [bar]: 1530 Clamping force [kN]: 1000 Gap spacing [mm]: 420 x 420 Plate size [mm]: 570×570 Min. Form Height [mm]: 250 Control Type: Selogica Tongue: German Installed power [kW]: 21.4 Working hours [h]: 95822 Weight [kg]: 3700 Dimensions [mm]: 4400 × 2000 Feed hopper: NO Robot Nest: Yes Core String: Yes

 ...
