Injection moulding machine Arburg 370S-700-290 Item number: 232 Availability: In stock Year of Make: 2008 Brand: Arburg Specifications Injection weight: 132 g Clamping force: 700 kN Screw diameter: 35 mm Spray pressure: 2000 bar Tiebar spacing: 370x370 mm Clamping plate size: 510x510 mm Tool installation height min.: 200 mm Plate spacing max: 600 mm Control: Selogica Language: German Power: 23.9 kW Hours: 67848 h Weight: 3300 kg Dimensions: 3.8x1.5 m Funnel: No Euromap: Yes Air Valve: Yes

Arburg 370S 500-70 Year of manufacture: 08.2010 Injection unit: Screw diameter: 25 mm Injection weight: 40 g Spray pressure: 1550 bar Dosing volume: 44 ccm Clamping unit: Clamping force: 50 t Tiebar spacing: 370x370 mm Size of the clamping plates: 510x510 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Euromap 67 Robot interface Air Valve x 8 Hydraulic core pull x 1 Control with hot runners x 6 Hardened injection unit - Bimetal Possibility of adjusting the vertical injection unit with the help of special brackets It is possible to change the screw diameter to 22, 25 or 30 mm Dimensions: Weight: 3170 kg Le ...

Arburg 370S 600-70 Year of Make: 2008 Injection unit: Screw diameter: 25 mm Injection weight: 40 g Spray pressure: 1550 bar Dosing volume: 44 ccm Clamping unit: Clamping force: 60 t Tiebar spacing: 370x370 mm Size of the clamping plates: 510x510 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Euromap 67 Robot interface Air Valve x 8 Hydraulic core pull x 1 Control with hot runners x 6 Hardened injection unit - Bimetal Built-in sorting flap Integrated original Arburg sprue picker on the side Possibility of adjusting the vertical injection unit with the help of special brackets It is possible to change the scr ...

Arburg 370S-600-150 Injection Moulding Machine (258) Number: 258 Availability: in stock Year of production: 2003 Producer: Arburg Condition of Injection Molding Machine: Used Screw diameter [mm]: 35 Injection weight [g]: 97 Injection pressure [bar]: 1620 Clamping force [kN]: 600 Gap spacing [mm]: 370 x 370 Plate size [mm]: 570×570 Minimum mould height [mm]: 200 Control Type: Selogica Tongue: German Installed power [kW]: 22,5 Working time [h]: 68963 Weight [kg]: 3630 Dimensions [mm]: 4000 x 1500 Robot connection: Yes Air Valve: 1x Core string: 1x Feed hopper: NO

clamping force: 700 kN injection volume: 103 cm³ screw diameter: 30 mm platen size: 432 x 310 mm closing stroke: 650 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.  ...

• more information

Arburg 320K 700-250 with the Arburg Multilift H side robot Year of Make: 2005 Injection unit: Screw diameter: 40 mm Injection weight: 158 g Spray pressure: 1390 bar Dosing volume: 188 ccm Clamping unit : Clamping force: 70 t Tiebar spacing: 320x320 mm Size of the clamping plates: 476x476 mm Ejector: hydraulic Clamping unit: toggle lever Control: SELOGICA Additional equipment: Air Valve x 3 Control with hot runners Hardened injection unit - Bimetal Central lubrication Dimensions: Weight: 2350 kg Length/Width/Height: 3.37x1.45x1.99 m Drive: Pumps/motor: 15 kW Heating capacity: 6.1 kW Total power: 21.1 kW All offered machines are started by our service te ...

Manufacturer/Manufacturer: Arburg Type/Type: 370C 600-250 Bau-year year: 1999 Control/Controller: Selogica Clothing Power/Clamping Force: 600 kN Schliessart/Clamping Type: Hydraulisch/Hydraulic Holmabstand/Dist.Betw.Tiebars: 370 mm x 370 mm Plate Groesse/Platen Size: 570 mm x 570 mm WZ Einbauhoehe/Mould hight: min 250 mm Oeff-weg/opening stroke: 500 mm Plate distance max/Max. Open Daylight: 750 mm Snail/Screw size: 40 mm Lifting volume/shot volume: 188 cc/158 gram hp Spez. Spray./injection pressure: 1900 bar General General Motor/Motor Power: 11 kW Heating/heating power: 8.1 kW Dimensions: 4.3 m x 1.7 m x 1.8 m Weichtt/Weight: 3180 kg Screen text/Language: Deutsch/Germa ...

Manufacturer/Manufacturer: Arburg Typ/Type: 370C 800-250 Bau-year year: 2003 Control/Controller: Selogica Clothing kraft/Clamping Force: 800 kN Schliessart/Clamping Type: Hydraulisch/Hydraulic Holmabstand/Dist.Betw.Tiebars: 420 mm x 420 mm Plate Groesse/Platen Size: 570 mm x 570 mm WZ Einbauhoehe/Mould hight: min 250 mm Oeff-weg/opening stroke: 500 mm Plate distance max/Max. Open Daylight: 750 mm Snail/Screw size: 34 mm Lifting volume/shot volume: 144 cc/132 gram hp Spez. Spray./injection pressure: 1820 bar General General Motor/Motor Power: 15 kW Heating/heating power: 8.6 kW Dimensions: 4.2 m x 1.7 m x 1.8 m Weichtt/Weight: 3180 kg Screen text/Language: Deutsch/German ...

Manufacturer/Manufacturer: Arburg Typ/Type: 420C 1300 kN-350 Bau-year year: 1999 Control/Controller: Selogica Closing Power/Clamping Force: 1300 kN Schliessart/Clamping Type: Hydraulisch/Hydraulic Holmabstand/Dist.Betw.Tiebars: 420 mm x 420 mm Plate Groesse/Platen Size: 605 mm x 605 mm WZ Einbauhoehe/Mould hight: min 250 mm Oeff-weg/opening stroke: 500 mm Plate distance max/Max. Open Daylight: 750 mm Snail/Screw size: 40 mm Lifting volume/shot volume: 182 cc/166 gram hp Spez. Spray./injection pressure: 1670 bar General General Motor/Motor Power: 22 kW Heating/heating power: 8 kW Dimensions: 4.3 m x 1.7 m x 1.8 m Weicht/Weight: 5100 kg Screen text/Language: Deutsch/Germa ...

Arburg 470C-2000-675 (No. 40) without picker Built: 1998 TECHNICAL DATA Screw diameter [mm]: 60 Spray weight [g]: 427 Spray pressure [bar]: 1440 Closing force [kN]: 2000 Tie bar distance [mm]: 470x470 Clamping plate size [mm]: 715x715 Tool installation height min. [mm]: 250 Control Control: Selogica Monitor: Yes Control cabinet: Yes Language: Polish, German Other Power [kW]: 45.8 Engine hours [h]: 94737 Weight [kg]: 6630 GR - EUROMAP
