pressure: 60.0 tchamfer lenght: 1270 mmdistance between columns: 1000 mmcolumn arm: 410 mmram stroke speed: 160 mm/secwork speed: 10.0 mm/secreturn speed: 165 mm/secwork stroke: 275 mmdayligth: 530 mmtable height: 900 mmtable width: 90.0 mmback stop - adjustable: max. 800 mmoil volume: 150 ltr.voltage: 400 Vengine output: 7.5 kWWeight: 4320 kgrange L-W-H: 2250 x 1960 x 2750 mm Demonstration/demo machine () From our showroom (like new) With very few operating hours--------------------------------------------------CNC press brake with special equipment Version ERGO - knee room for the operator flexible articulated arm mount for the controller increased installation height increased cylinder stroke as well as increased bending beam speeds-------------------------------------------------- Furnishing:- DELEM CNC control model DA-66T graphic/touch screen 2D graphical programming 17 TFT color s ...
pressure: 150 tstroke: 300 mmtable surface area: 1070 x 290 mmcolumn travel between the guideways: 1070 mmajustment speed: 9.0 mm/secworking feed: 5.0 mm/secreturn speed: 10.0 mm/secengine output: 11.0 kWweight of the machine ca.: 1870 kg.range L-W-H: 2200 x 1300 x 2300 mm Exhibition machine from 2021 with only approximately 2 operating hours Condition as new Special price upon requestFeatures:- Robust electro-hydraulic workshop press with fixed cylinder- Ideal for aligning axles, shafts, etc., but also for pressing in. and out bolts, bearings, bushings, and much more.- Robust welded steel construction for heavy-duty use- Table height adjustment via piston rod Includes round steel chain and 2 locking pins Piston rod with metric mount- 1 set of V-block prism supports- Pressure gauge for pressure display- Simple manual control with: 1 feed speed 1 working speed 1 retraction speed- Piston c ...
pressure: 60.0 tchamfer lenght: 2600 mmdistance between columns: 2050 mmcolumn arm: 310 mmworking feed: 10.0 mm/secreturn speed: 61.0 mm/secstroke: 100 - 140 mmdayligth: 450 mmtable height: 860 mmoil volume: 100 ltr.Control: ELGO P8822 operating pressure: max. 200 barNumber of working hours: ca. 2.370 hvoltage: 380 Vtotal power requirement: 5.5 kWweight of the machine ca.: 5000 kg.range L-W-H: 3000 x 1850 x 2050 mm good / well-maintained condition () with only approx. 2,370 operating hours current new price approx. 60.000 euros special price on requestin checked conditions - machine video -https://www.youtube.com/watch?v=PsUeM3O5wAMEquipment:- NC electro-hydraulic press brake- with ELGO NC control unit P8822 Input of target/actual values for back stop Input of target/actual values for depth adjustment ` swiveling operation, front left manual mode selectable- NC controlled axes: Y1 + Y2 + ...
pressure: 80.0 tchamfer lenght: 2050 mmdistance between columns: 1550 mmcolumn arm: 250 mmtable width: 85.0 / 135 mmstroke: ca. 390 mmdayligth: ca. 585 mmajustment speed: 180 mm/secworking feed: 1.0 - 10.0 mm/secreturn speed: 135 mm/secwork height max.: 1050 mmNumber of working hours: 32.495 hoil volume: 200 loperating pressure: 320 bartotal power requirement: 11.6 KWweight of the machine ca.: 7300 kgrange L-W-H: 3700 x 2000 x 3000 mm Good/well-maintained condition ()- in checked conditions - machinevideo -https://www.youtube.com/watch?v=IKyUmzB0WTI-------------------------- -----------------------CNC electro-hydraulic press brake with: Increased installation height .. approx. 550 mm Increased cylinder stroke .. approx. 390 mm-------------------------------------------------Features:- Robust electro-hydraulic press brake MADE IN GERMANY ()- CYBELEC CNC control DNC 904 PS-A (SN 0332) Pivo ...
pressure: 135 tchamfer lenght: 3050 mmdistance between columns: 2600 mmcolumn arm: 410 mmajustment speed: 160 mm/secworking feed: 10.0 mm/secreturn speed: 120 mm/secstroke: 265 mmdayligth: 530 mmtable height: 900 mmoil volume: 200 ltr.control: DNC 880 S Number of working hours: ~ 17.200 htotal power requirement: 15.0 kWweight of the machine ca.: 10250 kg.range L-W-H: 4570 x 2360 x 2900 mm good condition () current new price approx. 80.000 euros special price on request- in checked condition - machine video -https://www.youtube.com/watch?v=dyv7iQXcRt4Equipment:- electro-hydraulic CNC press brake- two synchronized cylinders with HIGH PERFORMANCE hydraulic components- with CYBELEC CNC control - DNC 880S 2D graphic display for display and multiple simulation graphic 2D programming easy handling automatic bending sequence calculation and collision detection large product and tool library aut ...
pressure: 300 tchamfer lenght: 4100 mmdistance between columns: 3710 mmstroke - stepless adjustable: 250 mmcolumn arm: 330 mmdayligth: 500 mmtable height: 940 mmtable width: 250 mmworking feed: 7.0 mm/secreturn speed: 90.0 mm/secControl: konv. operating pressure: max. 305 barvoltage: 380 Vtotal power requirement: 22.5 kWweight: 25200 kgrange L-W-H: 4320 x 2100 x 3500 mm well-maintained condition ()- in checked condition - machine video -https://www.youtube.com/watch?v=rPOBwTfVReoEquipment:- simple, conventional hydraulic press brake- swiveling control panel, left front- electro-motoric back stop (X axis) adjustment via front control panel (button) with analog position display fine adjustment via handwheel, front- with 3x stop fingers, manually adjustable- electro-motoric depth adjustment (Y1+Y2 axis) with analog position display- 1x split set of 85° deer foot upper tool- 1x MultiV - uni ...
pressure: 175 tchamfer lenght: 3100 mmdistance between columns: 2600 mmcolumn arm: 410 mmram stroke speed: 180 mm/secwork speed: 12.0 mm/minreturn speed: 190 mm/secwork stroke: 275 mmdayligth: 550 mmoil volume: 300 ltr.table height: 900 mmtable width: 90.0 mmvoltage: 400 Volttotal power requirement: 15.0 kWweight: 9800 kgrange L-W-H: 4150 x 2150 x 2800 mm-------------------------------------------------- HIGH-SPEED hydraulic press brake withincreased installation heightincreased cylinder strokeenlarged projection-------------------------------------------------- Furnishing:- DELEM CNC control model DA 66T- swiveling touchscreen control unit- 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning- electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm- on ball screws- controlled electr. Stop fingers Z1 + Z2- split upper deer foot tool Roleri 135.85.R08, System A- ...
pressure: 200 tchamfer lenght: 3100 mmdistance between columns: 2600 mmcolumn arm: 250 mmram stroke speed: 100 mm/secreturn speed: 75,0 mm/secwork speed: 7,0 mm/minwork stroke: 180 mmdayligth: 415 mmoil volume: 200 ltr.table height: 900 mmvoltage: 400 Voltrange L-W-H: 4450x2050x2650 mmFurnishing:- DELEM - CNC control model DA-58T- controlled axes: Y1 - Y2 and X- FIESSLER AKAS - laser protection in front of the machine- Deer foot upper tool- Universal die block- manual table crowning- Safety device: light barrier behind the machine- 2 front support arms- SIEMENS - electrical system- BOSCH / HOERBIGER hydraulic system- CE mark / declaration of conformity- Operating manual: machine and control- Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 400 tchamfer lenght: 4100 mmdistance between columns: 3550 mmcolumn arm: 510 mmram stroke speed: 110 mm/secwork speed: 8.4 mm/secreturn speed: 130 mm/secwork stroke: 375 mmdayligth: 650 mmtable height: 1000 mmtable width: 240 mmback stop - adjustable: max. 800 mmoil volume: 400 ltr.voltage: 400 Volttotal power requirement: 30.0 kWweight: 26409 kgrange L-W-H: 5450 x 2650 x 3470 mm-------------------------------------------------- HIGH-SPEED hydraulic press brake withincreased installation heightincreased cylinder strokeenlarged projection-------------------------------------------------- Furnishing:- DELEM CNC control model DA 66T- swiveling touchscreen control unit- 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning- electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm- on ball screws- controlled electr. Stop fingers Z1 + Z2- split upper deer foot ...
pressure: 40.0 tstroke: 285 mmflat steel: 250 x 24 mmworking feed: 10.0 mm/secreturn speed: 10.0 mm/minwork height max.: 930 mmtable:: 660 x 1250 mmtotal power requirement: 4.0 kWmotor: 400 Volt 50 Hzoil volume: 40.0 lweight: 800 kgrange L-W-H: 1450 x 800 x 1300 mmFurnishing :- electro-hydraulic horizontal bending machine- large, robust machine table made of hardened steel- Machine made of hardened and ground forged steel- Digital display for stroke setting Programming of 1x bend end point & 1x retract point possible- 1x tool set (1x bending punch / 1x 1V die)- infinitely variable adjustment of the bending speed and pressing force- 1x manual material stop- Free-moving dual footswitch- Machine can be moved with a pallet truck/stacker- Operation manualThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 40.0 tchamfer lenght: 1600 mmdistance between columns: 1200 mmcolumn arm: 200 mmram stroke speed: 60.0 mm/secreturn speed: 80. mm/secwork speed: 60.0 mm/secwork stroke: 100 mmtable height: 760 mmtable width: 150 mmoil volume: 130 ltr.voltage: 400 VoltControl: ESA E21 total power requirement: 4.0 kWweight: 3030 kgrange L-W-H: 2050 x 1800 x 2030 mm Demonstration/demo machine () From our showroom (like new) With very few operating hoursFurnishing:- compact hydraulic press brake- BERNARDO NC control model E21- swiveling control panel- electrical adjustment of the backgauge- Back stop on recirculating ball spindles- electrical adjustment of the immersion depth- Laser protection device in front- Upper deer foot tool - divided- Tool holder with quick change system- Universal die block- side + rear protective device- 2x front support arms- movable double foot switch (operation)The data ...
pressure: 20.0 tstroke: 185 mmflat steel: 200 x 12 mmworking feed: 10.0 mm/secreturn speed: 10.0 mm/minwork height max.: 930 mmtable:: 480 x 1060 mmtotal power requirement: 2.2 kWmotor: 400 Volt 50 Hzoil volume: 12.0 ltr.weight: 530 kgrange L-W-H: 1150 x 480 x 1400 mmFurnishing :- electro-hydraulic horizontal bending machine- large, robust machine table made of hardened steel- Machine made of hardened and ground forged steel- Digital display for stroke setting Programming of 1x bend end point & 1x retract point possible- 1x tool set (1x bending punch / 1x 1V die)- infinitely variable adjustment of the bending speed and pressing force- 1x manual material stop- Free-moving dual footswitch- Machine can be moved with a pallet truck/stacker- Operation manualThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 125 tchamfer lenght: 3050 mmdistance between columns: 2550 mmajustment speed: 90.0 mm/secworking feed: 10.0 mm/secreturn speed: 75.0 mm/secstroke: 140 mmdayligth: 375 mmcolumn arm: 250 mmtable width: 90.0 mmwork height max.: ca. 950 mmNumber of working hours: 14.100 htotal power requirement: 13.5 kWweight: 8500 kgrange L-W-H: 3630 x 2300 x 2505 mm From a maintenance workshop Good / well-maintained condition With only approx. 14.100 operating hours ()Equipment:- CNC electro-hydraulic press brake- DELEM CNC control - model DA 58 Swiveling control panel, front left 2D graphic programming & product display Tool & program library- CNC-controlled axes: Y1+Y2 / X1+X2 / R1+R2 / Z1+Z2 / CNC crowning- CNC electro-motorized backgauge (X axes) Stop system with 2x CNC-controlled gantries- CNC electro-motorized height adjustment of the backgauge (R axes)- CNC electro-motorized adjustment of ...
pressure: 125 tchamfer lenght: 3100 mmdistance between columns: 2550 mmthroat: 250 mmstroke: 120 mmajustment speed: 70.0 mm/secworking feed: 7.0 mm/secreturn speed: 60.0 mm/secdayligth: 325 mmtable width: 180 mmwork height max.: 915 mmoil volume: 150 ltr.total power requirement: 12.5 kWweight of the machine ca.: 9100 kg.range L-W-H: 3200 x 1325 x 2470 mm well-maintained condition from a maintenance workshop ()Equipment:- simple, conventional electro-hydraulic press brake with torsion shaft for parallelism of the upper beam- electro-motor-driven back stop, with ball screws (X axis) with 2x manually adjustable stop fingers fine adjustment via handwheel at the front, with analog position display- electro-motor-driven adjustment of the immersion depth (Y1+Y2 axis) with digital position display- swiveling operation, left-hand side- split deer foot + pointing tool- 1x rotatable Multi V univers ...
pressure: 175 tchamfer lenght: 3100 mmdistance between columns: 2600 mmcolumn arm: 410 mmram stroke speed: 160 mm/secwork speed: 10.0 mm/secreturn speed: 120 mm/secwork stroke: 265 mmdayligth: 480 mmtable height: 900 mmtable width: 90.0 mmoil volume: 230 ltr.voltage: 400 Volttotal power requirement: 18.5 kWweight: 10500 kgrange L-W-H: 4100 x 2000 x 2820 mm Demonstration/demo machine () from our exhibition (like NEW) with very few operating hoursALPMAC manufacturer video:https://www.youtube.com/watch?v=_FxXyPAcxlEhttps://www.youtube.c om/watch?v=YfkX9RwWv_0ALPMAC product video Model B:https://www.youtube.com/watch?v=lmT1tfy43WE------------------------- --------------------------------MODEL SERIES B175-3100 - CNC electro-hydraulic press brake with: increased installation height increased cylinder stroke increased projection---------------------------------------------------------! MANUFACT ...
pressure: 56.0 tchamfer lenght: 1400 mmdistance between columns: 1300 mmthroat: 220 mmstroke: 200 mmdayligth: 485 mmwork speed: 8.0 - 10.0 m/minreturn speed: 35.0 mm/secControl: CNC Boschert back stop - adjustable: 0 - 370 mmwork height max.: 915 mmCylinders :: 2 Stückvoltage: 3x 400 Vconnected load: 8.0 kVAweight: 3700 kgrange L-W-H: 2320 x 1280 x 2030 mm very good / well-maintained condition () with lots of bending tools- in checked conditions - machine video -https://www.youtube.com/watch?v=NrpZs6Ar0VoEquipment:- NC electro-hydraulic press brake- BOSCHERT NC control unit, front- NC electro-motorized back stop (X axis) with 2x manually adjustable stop fingers (R+Z axis)- AMADA PROMECAM (SYSTEM A) upper tool holder- AMADA PROMECAM (SYSTEM A) lower tool holder- Handwheel with analog display for adjusting the bending angle- lots of insert tools, including tool cabinet- 1x working cylinde ...
Capacità della pressa: 63 tonnellate Corsa del pistone regolabile: 8 - 60 mm Regolazione della slitta: 80 mm Altezza di chiusura (corsa verso il basso, regolazione verso l'alto): 300 mm Superficie del tavolo: 810 x 550 mm Area della scorrimento: 700 x 420 mm Foro nel tavolo: 550 x 140 mm Distanza tra il vassoio dell'olio: 700 mm Altezza del tavolo sul pavimento: 920 mm Numero di corse: 65 - 400 giri/min Peso della macchina circa: 8 tonnellate Dimensioni L x P x A: 2935 x 1170 x 3000 mm Motore principale: 11 kW
Capacità: 35 ton Profondità della gola: 225 mm Corsa del pistone: 8 - 80 mm Regolazione della slitta: 50 mm Altezza di chiusura (corsa verso il basso, regolazione verso l'alto): 325 mm Superficie del tavolo: 600 x 450 mm Area della guida: 300 x 225 mm Numero di corse: 160 s.p.m. Potenza richiesta: 2,2 kW Dimensioni L x P x A: 1000 x 1600 x 2200 mm Peso della macchina circa: 1,9 ton
Pressa piegatrice con pressa robotizzata Stäubli Produttore: LA G Modello: GBS R 1250 50 La macchina è stata utilizzata solo per un periodo di tempo molto breve.
CONTROLS PC controller BECKHOFF PRESS DESIGN drive system: servohydraulic frame design: H-frame, tie rod quick die change system: yes feedstock transport direction: left to right SLIDE total force (nominal): 1100 to stroke: 130 mm stroke rate (max.): 60 /minCOUNTER RAM nominal force: 330 to stroke: 40 mmV-RING nominal force: 500 to stroke: 40 mmTOOL DIMENSIONS lower table (left-right): 960 mm lower table (front-back): 960 mm upper table (left-right): 960 mm upper table (front-back): 960 mm shut height max.: 470 mmOVERALL SPECIFICATIONS (COIL LINES) sheet width max.: 500 mm sheet thickness max.: 16 mm coil weight max.: 8 to feedstock transport direction: left ...
pressure: 1000 tdistance between columns: 5000 mmstroke: 500 mmHeight of centres: 400 mmMotor output: kWreus: U/minOverall size: 6000 x 2500 mmWeight: 1000 kgDistance between centres: 3500 mmtotal power requirement: kWweight of the machine ca.: 220 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressione: 200 tlunghezza tavola: 1600 mmlarghezza tavola: 1300 mmilluminazione diurna: 1700 mmpotenza totale richiesta: kWpeso della macchina ca.: 19 tdimensioni della macchina ca.: 2,95 5 6 mI dati di questo annuncio sono stati creati con ModulMWS - la soluzione software di LogoTech oHG.
Working width: 2500mm, max. sheet thickness aluminium/steel/stainless steel: 3mm/2mm/1.25mm, feeding length range: 575mm-2500mm, feeding width range: 210mm-1500mm, max. bending height: 200mm, max. negative bend: 35mm, max. diagonal twist: 3300mm, rotary table position: 0°/90°/180°/270°, working height: 1150mm. Clamping stroke: 210mm, clamping force: 240kN, clamping lowering and return speed: 50mm/s, upper beam swivel range: 135°, upper beam swivel speed: 90°/s, lower beam swivel range: 135°, lower beam swivel speed: 90°/s. Machine dimensions X/Y/Z: approx. 4050mm/1600mm/2400mm, weight: approx. 13000kg. Documentation available. An on-site inspection is possible.
DESIGN DELLA PRESSA sistema di azionamento: idraulico design del telaio: telaio a C, su un lato FORZE DI PRESSATURA forza totale (nominale): 12 aCORSA SLIDE : 200 mmSPECIFICHE ELETTRICHE tensione di rete: 380 V frequenza di rete: 50 HzDIMENSIONI / PESI peso totale circa: 1000 kgContaore: 30'181 hultimo controllo di sicurezza: 27.07.2023, tempo di inerzia 38 ms, distanza di inerzia 60 mm
CONTROLS PLC SIEMENS S7 PRESS DESIGN drive system: knuckle-joint frame design: H-frame, monoblock openings in uprights: yes number of suspensions: 2 feedstock transport direction: left to right PRESS FORCES total force (nominal): 315 to nominal work capacity: 38 kNmPRESS TABLE table surface (left-right): 2000 mm table surface (front-back): 1200 mm thickness of bolster plate: 200 mmSLIDE slide force: 315 to table surface (left-right): 1995 mm table surface (front-back): 1100 mm stroke: 160 mm stroke rate (max.): 80 /minSLIDE (MECHAN. PRESS) slide adjustment: 140 mm stroke rate (min.): 20 /min stroke rate (max.): 80 /min main drive power: 90 kWTOOL ASSEMBLY DIMENSIONS& ...
pressure: 100 tthroat: 355 mmstroke: mmtotal power requirement: 11,5 kWweight of the machine ca.: 8,5 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Two press brakes LVD are available. 1) Press brake LVD PPBL-H 100/40, year of manufacture: 1993, pressing force: 1000kN, working length: 4000mm, distance between uprights: 3150mm, ram stroke: 130mm, table-to-ram distance: 310mm, throat depth: 200mm, table width: 180mm, table-to-floor distance: 910mm, closing speed: 80mm/s, working speed: 8mm/s, return speed: 60mm/s, oil capacity: 120l, weight: approx. 8200kg. 2) Press brake LVD PPBL-H 165/40, year of manufacture: 1993, pressing force: 1650kN, working length: 4000mm, distance between uprights: 3150mm, ram stroke: 150mm, table-to-ram distance: 350mm, throat depth: 250mm, table width: 180mm, table-to-floor distance: 930mm, closing speed: 80mm/s, working speed: 7.5mm/s, return speed: 70mm/s, oil capacity: 150l, weight: approx. 10500kg. Documentation available. An on-site inspection is possible. Sale of individual units is possible.
Offerta 25247 Indicazioni: - Forza di pressatura massima 50 t - Corsa massima del pistone ca. 260 millimetri - Velocità di sollevamento rapida ca. 1540 mm/min - Velocità di sollevamento lenta ca. 210 mm/min - Larghezza del supporto ca. 770 millimetri - Profondità del supporto ca. 195 millimetri - Altezza di installazione min. / max. ca. 200 / 1100 millimetri - Tavolo regolabile in altezza con 5 griglie di bulloni a innesto ciascuna ca. 180 millimetri - Piastra di supporto ca. 450 x 450 millimetri - Regolazione in altezza del tavolo con cavo a manovella - Azionamento 400 V / 1,5 kW - Ingombro ca. L 1750 x A 2100 x P 850 mm - Peso ca. 600 kg
pressure: 60 tthroat: 280 mmstroke: 10-140 mmno. of strokes: 110 Hub/minram - range of adjustment: 60 mmtable surface area: 740x560 mmram surface: 380x195 mmhole in the table: 300x200 mmtable height: 760 mmtool hole in ram: Ø 40 mmweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 35 tthroat: 220 mmstroke: 8-96 mmno. of strokes: 120 Hub/minram - range of adjustment: 50 mmtable surface area: 580x440 mmram surface: 305x170 mmhole in the table: 215x175 mmtable height: 870 mmtool hole in ram: Ø 40 mmweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
