Il freno a pressa CNC EHT VarioPress 175-35 è stato costruito nel 2004 in Germania dalla EHT Werkzeugmaschinen GmbH (ora TRUMPF). La macchina è progettata per la lavorazione di precisione di pezzi con una lunghezza massima di 3550 mm. Il processo di lavorazione viene eseguito con una forza di compressione elevata di 175 tonnellate che, unita a un design estremamente stabile, garantisce eccellenti risultati di flessione, anche durante le sfide più intense. Tutto ciò è integrato dall'avanzato sistema di controllo CYBELEC, che facilita significativamente il funzionamento quotidiano della macchina. Il freno pressante EHT VarioPress pesa 14900 kg. Specifiche tecniche del freno a pressione EHT VarioPress 175-35 - Regolatore CNC: CYBELEC DNC 1200PS Eco/Col - Forza di stampa massima: 175 t - lunghezza massima della lamera: 3550 mm - supporti anteriori - potenza di connessione: 20,5 ...
sheet width:3050 mm plate thickness:4 mm total power requirement:9 kW weight of the machine ca.:6 t dimensions of the machine ca.:3900 x H 1850 x T 2100 mm
sheet width: 3200 mm plate thickness: 4.0 mm ST distance between columns: 3300 mm upper clamping bar adjustment: 400 mm Adjustment folding beam: 80.0 mm pivoting angle: 180 Grad clamping capacity max.: 200 KN rear stop: 10.0 - 1600 mm oil volume: 160 Liter total power requirement: 9.8 kW weight: 8500 kg range L-W-H: ~ 4900 x 2000 x 2300 mm from a maintenance workshop good / well-maintained condition () - inspected condition - machine video - https://www.youtube.com/watch?v=RY-amZooeX4 Equipment: - robust CNC folding machine - CNC control unit - CYBELEC DNC 80 PP swiveling control panel, front right 2D graphic display for visualization and multi-simulation 2D graphic programming easy operation - CNC motorized backgauge travel range 10.0 - 1,600 mm pneumatic / retractable gauge fingers adjustment speed max. 250 mm/sec. rear sheet support table with brushes - motorized lower beam ...
sheet width: 3100 mm plate thickness: 4.0 mm thickness at Niro-steel: 2.5 mm cutting angle adjustment: 1.0 ° back stop - adjustable: 10 - 1000 mm adjustment speed: 180 mm/s down holder: 21 Stück strokes per minute: 18 - 31 column arm: 200 mm Control: ELGO P8721 oil volume: 160 L 0: max. 300 bar voltage: 400 V main drive: 7.5 kW weight of the machine ca.: 4800 kg. dimensions of the machine ca.: 3660 x 2070 x 2140 mm from a maintenance workshop good condition () Features: - Electro-hydraulic sheet metal shear (swing cut) - Machine frame = all-steel welded construction - ELGO NC control system, Model P8721, control panel on the front left for positioning the electrically driven backgauge Target/actual position value input possible Adjustment via three-phase motor using a toothed belt - Support table with ball bearings Recessed handles between the table plates - Front finger guard - ...
pressure: 150 t chamfer lenght: 3550 mm distance between columns: 3050 mm Control: Cybelec DNC 880S stroke: 700 mm throat: 350 mm dimensions: 4400x2200x3940 mm weight of the machine ca.: 15.000 kg Accessories/equipment: - Bending aid in front of the machine - Parking space for bending aid - 3 stop fingers - Control conversion 2011 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 50 t chamfer lenght: 1550 mm distance between columns: 1150 mm Control: CYBELEC DNC 1200 PS Eco column arm: 405 mm table height: 900 mm stroke of ram: 400 mm distance between table / ram: 720 mm total power requirement: 9,5 kW weight of the machine ca.: 5.200 kg dimensions of the machine ca.: 2000x1900x2920 mm Accessories/Equipment: - CYBELEC DNC 1200 PS Eco controller - 2 support arms - 4 stop fingers - Lasersafe - Foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 135 t chamfer lenght: 3050 mm distance between columns: 2550 mm dayligth: 320 - 560 mm stroke: 240 mm working feed: 10.0 mm/sec return speed: 150 mm/sec column arm: 400 mm work height max.: 1050 mm control: DNC 1200 PS/B operating pressure: max. 297 bar compressed air: 4.5 - 6.0 bar connected load: 15.0 kW oil volume: 250 ltr. weight: 11500 kg range L-W-H: 5240 x 2400 x 2900 mm good/well-Maintained conditions used in Aluminum processing - in checked conditions - machine Video - https://www.youtube.com/watch?v=z-Bxibk_8uE Features: - CNC Electro-Hydraulic Press Brake - CYBELEC CNC Control Model DNC 1200 PS/B Swiveling Control Panel, Front Right Numerical Programming Tool & Program Library - CNC Controlled Axes: Y1 + Y2 + X + R + CNC Crowning - CNC Electro-Motorized Backgauge (X-Axis) with 3x Manually Adjustable Backgauge Fingers (Z-Axis) Maximum Travel Speed: 250 mm/sec - ...
sheet width: 4050 mm plate thickness: 8 mm distance between columns: mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 110 t chamfer lenght: 2550 mm Control: Cybelec DNC 70 weight: 9000 kg dimensions: 3000 x 2100 x 3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
sheet width: 3000 mm plate thickness: 4 mm distance between columns: 3050 mm total power requirement: 8 kW weight of the machine ca.: 4.8 t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 85.0 t chamfer lenght: 2050 mm distance between columns: 1650 mm column arm: 400 mm stroke: 240 mm dayligth: 320 - 560 mm ajustment speed: 150 mm/sec working feed: 15.0 mm/sec return speed: 150 mm/sec back stop - adjustable: 5.0 - 1000 mm table width: 110 mm work height max.: 1050 mm operating pressure: max. 297 bar compressed air: 4.5 - 6.0 bar oil volume: 200 l operating pressure: 340 bar total power requirement: 7.5 kW weight of the machine ca.: 5900 kg range L-W-H: 4100 x 2100 x 2750 mm with increased installation height / piston stroke well-maintained condition () - in checked condition - machine video - https://www.youtube.com/watch?v=ikl6RNZWeiU Equipment: - CNC electro-hydraulic press brake - including CYBELEC CNC control swiveling control panel at the front right external screen - CNC axis adjustment: Y1 - Y2 - X - R - Z1 - Z2 - I + CNC crowning - CNC electro-motor ...
pressure: 225 t chamfer lenght: 2050 mm distance between columns: 1550 mm control: CYBELEC DNC 1200 PS Eco stroke: 550 mm table height: 700 mm throat: 405 mm distance between table / ram: 320-870 mm column arm: 405 mm weight of the machine ca.: 14.000 kg Accessories / equipment: - controlled axes: Y1 - Y2 - X - R - Z1 and Z2 can be moved manually - Lasersafe angle measurement - Pneumatically adjustable support table - pneumatic upper and lower tool clamping - 2-hand foot control - manual crowning The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 150 t chamfer lenght: 4050 mm distance between columns: 3550 mm Control: CYBELEC ModEva Pac throat: 350 mm distance between table / ram: 430 mm table width: 250 mm stroke: 250 mm total power requirement: 18,5 kW weight of the machine ca.: 16500 kg dimensions of the machine ca.: 4400x2100x3200 mm Equipment/accessories: - Control conversion at the end of 2018 - Electric backgauge 1250 mm - 10-stage die displacement - crowning - EHT 26 mm tool holder - Axes controlled: Y1,Y2,X,R - Sheet metal holding table - 4x manually adjustable stop fingers - pneum. Upper tool clamping - Safety light curtain - 3x height-adjustable support arms - Oil cooler - 2-hand foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 230 t chamfer lenght: 4050 mm distance between columns: 3550 mm column arm: 420 mm oil volume: 400 l Control: ModEva 10S weight of the machine ca.: 19700 kg dimensions: 5100 x 2160 x 3420 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 225 t chamfer lenght: 4050 mm distance between columns: 3550 mm control: CYBELEC DNC 86 PS total power requirement: 18,5 kW weight of the machine ca.: 18.000 kg dimensions of the machine ca.: 5180x2400x3200 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 125 t chamfer lenght: 3550 mm distance between columns: 3050 mm column arm: 300 mm stroke of ram: 240 mm quantity of oil: 200 l control: CYBELEC Cybtouch 15 range L-W-H: 4500x2200x3000 mm Equipment/accessories: - manual crowning - 3 x manual stop fingers - die displacement - pneum. upper tool clamping - foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
sheet width: 3100 mm plate thickness: 4.0 mm thickness at Niro-steel: 2.5 mm cutting angle adjustment: 1.0 ° back stop - adjustable: 10 - 1000 mm adjustment speed: 180 mm/s down holder: 21 Stück strokes per minute: 18 - 31 oil volume: 160 L Control: ELGO P8511 column arm: 200 mm distance between columns: 3050 mm 0: max. 300 bar voltage: 400 V main drive: 9.0 kW weight of the machine ca.: 4800 kg. dimensions of the machine ca.: 3660 x 2070 x 2140 mm from a maintenance workshop Equipment: - electro-hydraulic sheet metal shear swing cut - machine frame = all-steel welded construction - ELGO NC control model P8511, control panel at the front left for positioning the electro-motoric rear stop target/actual position value input possible adjustment by three-phase motor via toothed belt - support table with ball rollers there are recessed grips between the table plates - front finger guar ...
200941,789 h864,086 strokes4,550 mm2,300 kN (230 t)Cybelec ModEva 10S23,400 kg400 l3 x 400 V / 50 Hz AC24 V37 kVA80 A06/2026Various punches and dies
sheet width: 6000 mm plate thickness: 6 mm distance between columns: 610 mm Control: Elgo 87 P2 total power requirement: 15 kW weight of the machine ca.: 22 t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Larghezza del foglio: 3050 mm Spessore della piastra: 10 mm controllo: Elgo 87 P2 : 11 - 31 Regolazione dell'angolo mozzo/mintaglio: 1 - 4 Numero di tenute tenute: 16 Stück: 900 kg: 11 kW Larghezza tabella: 700 mm Altezza tabella: 800 mmrange L-W-H: 4000 x 2220 x 1830 mm Peso: 6300 kg I dati per questo annuncio sono stati creati con ModulMWS - la soluzione software di LogoTech oHG.
pressure: 135 t chamfer lenght: 2550 mm distance between columns: 2050 mm control: CYBELEC ModEva 10 S total power requirement: 25 kW weight of the machine ca.: 11.000 kg dimensions of the machine ca.: m Machine: - Sturdy machine frame constructed as a fully welded all-steel structure - Pressure beam with high bending strength - Electrohydraulic top drive via proportional valves - Modern block hydraulic system Optional equipment: - Increase in installation height and stroke by 150 mm each - Backgauge system 2 - 2 axes, R-axis adjustment 150 mm - 2 x additional stop fingers 2/4-axes, however, offset by 20 mm - CNC holding device - Distance from the bending line to the holding device approx. 240 mm - EHT quick-clamping device for EHT upper tools, pneumatic, head width 26 mm, horizontally self-centering - EHT lower tool clamping, mounting width 55 mm, pneumatic - Hardened insert strip for E ...
Press force: 200t, working length: 3550mm, distance between columns: 3050mm, length: 4000mm, width: 2000mm, height: 3000mm, weight: 16t. The machine is fully functional and in good technical condition. Upper tools are included. The lower tool, consisting of the die block or prism, is missing. An on-site inspection is possible.
A hydraulic CNC press brake Eht. Press force: 230t, working length: 4550mm, distance between side frames: approx. 4050mm, max. stroke: approx. 300mm, max. installation height: approx. 500mm, max. throat depth: approx. 405mm, approach speed: approx. 100mm/s, working speed: approx. 10mm/s, return speed: approx. 100mm/s, control: Cybelec ModEva 10S, operating hours: 41789h. Including various punches and dies. Weight: approx. 23,5t, machine dimensions X/Y/Z: approx. 2400mm/5200mm/3100mm. Documentation available. An on-site inspection is possible.
Freno a pressione idraulico CNC EHT in vendita. Forza di pressione: 1100 kN, lunghezza di flessione: 3050 mm, distanza minima/massima tra il tavolo: 280 mm/600 mm, velocità di avvicinamento rapido: 100 mm/s, velocità di lavoro: 2 mm/s-8 mm/s, velocità di ritorno: 100 mm/s, intervallo di regolazione del retroscartamento: 5-1000 mm, velocità di regolazione del retroscartamento: 200 mm/s, regolazione verticale del retroscartamento: +/-10 mm, distanza di sicurezza tra utensili ed elementi di funzionamento: 120 mm, tempo di arresto: 75 ms, distanza di arresto: 11 mm, sistema di controllo: DAK 90. Peso della macchina: 8500kg. Documentazione disponibile. Ispezione su appuntamento possibile.
Sheet metal shears, tin scissors, sheet metal scissors, hydraulic shears -Sheet shear: hydraulic -Cutting width: 2000 mm -Max. cutting thickness: steel 6 mm -Features: Back gauge, cutting gap adjustment -Space requirement: 3280/2700/H2060 mm -Transport dimensions: 2280/2700/H2060 mm -Weight: 5980 kg
Hydraulic cylinders, support cylinders, hydraulic pistons, pressure pistons, hydraulic buffers, pressure boosting cylinders -Hydraulic cylinder: from press brake EHT type EHP 11-40 -Piston rod: Ø 155 mm -Stroke: 250 mm -Number: 2 cylinders available, 1 left / 1 right -Price: per piece -Dimensions: 855/285/380 mm -Weight: 311 kg/unit
Stop for press brake, bending machine, guillotine shear, drive shaft -Drive shafts: for stop, from press brake EHT type EHP 11-40, 2 pieces -Length: 515 mm -Hole: Ø 25 mm -Price: complete -Dimensions: Ø 50 x 515 mm -Weight 5.1 kg/pc.
Bending tool, die, upper knife, upper tool, straight tool, die tool, seam closing tool -Tool: from press brake EHT type EHP 11-40 -Measures: see drawing in the photos -Dimension: 4050/45 / H130 mm -Weight: 147 kg
pressure: 225 t chamfer lenght: 3050 mm distance between columns: 2550 mm column arm: 300 mm ajustment speed: 110 mm/sec work speed: 9.0 mm/sec return speed: 130 mm/sec work stroke: 240 mm dayligth: 320 - 560 mm table height: 1000 mm table width: 200 mm oil volume: 350 ltr. operating pressure: max. 296 bar air pressure: 4.5 - 6.0 bar voltage: 400 Volt total power requirement: 18.5 kW weight: 14900 kg range L-W-H: 5180 x 2400 x 3100 mm - in checked condition - machine video - https://www.youtube.com/watch?v=ebbbzSYMxKw Furnishing: - electro-hydraulic CNC die bending/press brake - CYBELEC CNC control ModEva 12S, swiveling at the front right High-resolution graphic color screen 14 inches Representation as a line, area or volume drawing of the product Clear, concise menus in the operators language Large tools and products library - CNC-controlled back gauge adjustment (X-axis) Stop rang ...
È disponibile una cesoia a ghigliottina idraulica EHT ricondizionata nel 2023. Lunghezza di taglio: 3000 mm, spessore massimo della lamiera acciaio/VA: 4 mm/2 mm, registro posteriore: 10 mm-1000 mm, velocità di regolazione: 180 mm/s, frequenza della corsa: 18-31 colpi/min, volume dell'olio: 160 l. Dimensioni della macchina X/Y/Z: circa 3700 mm/2100 mm/2150 mm, peso: circa 4800 kg, ore di funzionamento: 44024 ore. I cilindri, le pale e i tubi flessibili sono stati revisionati nel 2023. È possibile effettuare un'ispezione in loco.
