usato
Superficie di serraggio del tavolo: corsa x: 400 mm corsa a: 175 mm corsa z: 450 mm Supporto mandrino: ISO 30 Velocità mandrino: 50-2000/50-3400 rpm Tensione di funzionamento: 380 V Potenza totale richiesta: circa 2,5 kVA kW Spazio richiesto: 1200 x 1000 x 1600 mm Peso: circa 1100 kg
usato
Viaggio XYZ: 300-135-270 Porta mandrino: Iso 30 Velocità del mandrino: 100-2000 Dimensioni tabella: 600x195 Avanzamento automatico all'asse X Velocità manuale sull'asse X Rotazione fraeskop a 360° Inclinare il tavolo li e ruotare di 30° Pompa Cowlmittel Con vizio Con porta utensili ER25 con alcune pinza Marcatura
usato
Fresatrice Aciera F3 Viaggio XYZ: 300-135-270 Porta mandrino: Iso 30 Velocità del mandrino: 100-2000 Dimensioni tabella: 600x195 Alimentazione automatica sull'asse X Ingranaggio manuale sull'asse X L'avanzamento dell'asse Y può essere facoltativamente tra mandrino filettato o rack e pignolo Fraeskop 360° drehbahr Tavolo basculante li e re 30° ruotare Freno motore Kuhlmittelpumpe Con la morsa Con porta utensili con pinza Marcatura
usato
x-travel: 620 mmy-travel: 420 mmz-travel: 400 mmspindle taper ISO: 40 DIN 69871Aspindle turning speed range: 50 - 4000 U/mintable-size: 800 x 400 mmtable load: 400 kgfeeds -stepless-: max. 2000 mm/minrapid traverse: 5 / 4 m/minpower capacity - milling spindle: (S1) 10,5 kWquill stroke: 80 mmcoolant: voltage: 400 Vtotal power requirement: 17,5 kWweight of the machine ca.: 1,9 tdimensions of the machine ca.: 2,00 x 2,76 x 2,05 m- Fabr.No.: 90082- perfect condition from educational institution- Digital Read Out System Heidenhain ND780- electronic hand wheel- mechanical hand wheels- cont. variable spindle speeds- cont. variable feed rates- horizontal milling spindle- drilling quill- Coolant equipmentThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
x-travel: 290/300 mmy-travel: 160 mmz-travel: 330/340 mmengine output: 1,5/1,9 kWweight of the machine ca.: 0,7 tOptical condition: very good: Mechanic: very good: The machine can be viewed under current.: Heidenhain digital readout, axes:: 3 Aktiv vertical milling head Sk 40: Sk 40 S 20x2 operating instruction: operating key: ATTENTION:We would be happy to provide you with a free offer. However, please haveUnderstand that we only have inquiries with a complete addressto edit.2102-2047380 V, 50 Hz, with CEE plug and cableColor greenCompliance with the Machinery Directive on request at extra cost (see list below) # milling protection device electr. secured, integrated in the emergency stop chain!° already available:° Engine brake° Safety handwheels° 2 x emergency stop switches° Mandatory and prohibition signs according to the latest standard° Electrical acceptance according t ...
usato
Tipo di macchina: Fresatrice per utensili Produttore: DECKEL Modello: FP 1 Active 3-Axis Anno di costruzione: 1984 Condizione: molto buona Tipo di offerta: macchina usata Indicazioni: Tavola: 600 x 210 mm Gamma di velocità: 40 - 2000 rpm. Montaggio mandrino: SK 40 Gamma di viaggio: x = 300 mm y = 160 mm z = 340 mm Propulsione: 1.6 / 2.0 kW Osservazione: Heidenhain TNC 113, Display digitale attivo a 3 assi, Cabina di sicurezza con spegnimento elettrico, dispositivo di raffreddamento, Morsa della macchina con piattaforma girevole larghezza ganasce 110 mm, Mandrino SK 40 con 13 pinze 5 - 25 mm, 5 portautensili SK 40, Controllo dell'avanzamento a variazione continua e traslazione rapida in x, y, z Peso: 850 kg La macchina è in ottime condizioni e immediatamente pronta e può essere vista e dimostrata con noi. Saremo lieti se siete interessati alla nostra offerta. Soggetto a errori, modif ...
usato
Tipo di macchina: Fresatrice per utensili Produttore: DECKEL Modello: FP 1 Active 3-Axis Anno di costruzione: 1989 Condizione: molto buone Tipo di offerta: Macchina usata Indicazioni: Tavola: 600 x 210 mm Gamma di velocità: 40 – 2000 giri/min. Attacco mandrino: SK 40 Gamma di corsa: x = 300 mm y = 160 mm z = 340 mm Propulsione: 1.6/2.0 kW Osservazione: Heidenhain TNC 113 Display digitale attivo a 3 assi, Avanzamento e traslazione rapida infinitamente variabili in x, y, z dispositivo di raffreddamento, Lubrificazione centralizzata luce della macchina, 5 portautensili SK40, Portapinze con 10 pinze da 2 a 20 mm Peso: 800 kg La macchina è in ottime condizioni e pronta per l'uso immediato e può essere visionata e dimostrata da noi. Saremmo lieti se foste interessati alla nostra offerta. Sono fatti salvi errori, modifiche e vendita anticipata.
usato
x-travel: 390/400 mmy-travel: 210/220 mmz-travel: 390/400 mmturning speeds: 25-2500 U/minfeed: 8-400 mm/minrapid traverse: 1500 mm/minquill stroke: 100 mmtool taper: Sk 40 x S 20 x 2 drive motor: 2,0/3,0 kWtotal power requirement: kWweight of the machine ca.: 1,2 tdimensions of the machine ca.: mOptical condition: good: Mechanic: good: The machine can be viewed under current.: 2202 11050380 V, 50 Hz, with CEE plug and cableColor greenEquipment: 3 Axis Active Digital Display (HH) TNC 113 Vertical head Sk 40 Coolant device Centralized lubrication pump Free-running safety wheels Stepless feed Emergency stop switch Engine brake New scrapers New bellows Great maintenance done Lockable main switch 10 tool holders fixed angle table (planed) Chip tray 4 machine shoes Cold light lamp Instruction manual, spare parts list, circuit diagram Control key u. driver ringMachine is workshop tested an ...
usato
x-travel: 390/400 mmy-travel: 210/220 mmz-travel: 390/400 mmturning speeds: 25-2500 U/minfeed: 8-400 mm/minrapid traverse: 1500 mm/minquill stroke: 100 mmtool taper: Sk 40 x S 20 x 2 drive motor: 2,0/3,0 kWtotal power requirement: kWweight of the machine ca.: 1,2 tdimensions of the machine ca.: mOptical condition: good: Mechanic: good: The machine can be viewed under current.: 2202 11050380 V, 50 Hz, with CEE plug and cableColor greenEquipment: 3 Axis Active Digital Display (HH) TNC 113 Vertical head Sk 40 Coolant device Centralized lubrication pump Free-running safety wheels Stepless feed Emergency stop switch Engine brake New scrapers New bellows Great maintenance done Lockable main switch 10 tool holders fixed angle table (planed) Chip tray 4 machine shoes Cold light lamp Instruction manual, spare parts list, circuit diagram Control key u. driver ringMachine is workshop tested an ...
usato
Description: Machine number 2313-0568, grooving table approx. 1000 x 440 mm, HOLEX vice, jaw width 160 mmweight approx.: 2,200 kg, Approx. Onsite Dimension. (l x w x h): 1,800 x 1,700 x 1,900 mm
usato
Description: max. 6300 rpm, SK 40 holder, quill stroke 80 mm, feed rate 2 to 3600 mm/min, rapid traverse 4000 mm/min, travel X Y Z 400 mm, clamping table 700 x 460 mm, head swivelling 180°, without machine vice, CNC path control DIALOG 4weight approx.: 2,000 kg, Approx. Onsite Dimension. (l x w x h): 3,100 x 1,400 x 1,900 mm
usato
Description: max. 6300 rpm, SK 40 tool holder, quill stroke 80 mm, feed rate 2 to 3600 mm/min, rapid traverse 4000 mm/min, travel X Y Z 400 mm, clamping table 700 x 460 mm, head swivelling 180°, without machine vice, CNC path control DIALOG 4weight approx.: 2,000 kg, Approx. Onsite Dimension. (l x w x h): 3,100 x 1,400 x 1,900 mm
usato
Produttore: Lid Tipo: FP 4 MA Anno di costruzione:1987 Controllo: Controllo Contour 2 Area di lavoro: 485 x 385 x 380 mm Velocità di avanzamento: 1-3000 mm/min Corsa Pinole: 80 mm Azionamento principale: 4 kW Numero di perni rotanti: 18 Velocità mandrino: 63...3150 min Portautensili: SK 40 Carico da tavola: 600 kg Peso: circa 1850 kg Dimensioni senza pannello di controllo: 2000 x 2400 x 2000 mm Saremo lieti di inviarvi ulteriori informazioni e foto su richiesta.
usato
La macchina è in condizioni TOP ! X/Y/Z: 400/220/400 mm Velocità: 40 - 2500 rpm Avanzamento: 0 - 500 mm/min Corsa rapida: 1200 mm/min Corsa penna: 80 mm Tavola: 700 x 320 mm Portautensili: ISO 40 Motore motore: 2,2 kW Dimensioni macchina (LxPxA) 120 x 150 x 175 cm Dimensioni quadro elettrico (LxPxA) 64 x 32 x 90 cm Peso macchina 1200 kg Armadio comando peso 80 kg
usato
Viaggio XYZ: 300-150-340mm Porta mandrino: Iso 40 S20x2 Velocità del mandrino: 40-2000 Dimensioni del tavolo: 260x600mm Tavolo angolare flottante Heidenhein digitale su 3 assi Alcuni porta utensili Freno motore Tensione 3×380 Volt Potenza 1,1 - 1,3 kW Con i CE
usato
Coperchio FP1 Revisionato geometricamente Nuovi soffietti, raschietti, catene. Ingranaggio conico impostato nella testa Nuovo display digitale a 3 assi Motore con freno Interruttore di arresto di emergenza X- 300 mm, Y 150 mm, Z- 340 mm
usato
x-travel: 700 mmy-travel: 400 mmz-travel: 450 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: m3-axis digital read outhorizontal and vertical milling spindlequillTechnische Daten / technical details:Längsweg X / X-travel longitudinal 700 mmQuerweg Y / Y-travel cross 400 mmSenkrechtweg Z / Z-travel vertical 450 mmTischgröße / table size 1000x470 mmSpindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 31,5-1600 UpM /rpmVorschubbereich X und Y-Achse / feed range X and Y axis 10-500 mm/min.Vorschubbereich Z-Achse / infeed Z-axis 5-250 mm/minAntriebsleistung/ power capacity 5 kWGewicht der Maschine / weight 2400 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description of the machine are not binding.The data f ...
usato
Description: MALFUNCTION x-travel 600 mm y-travel 500 mm z-travel 450 mm Control dialog 11 Speed range 20 - 5000 rpm Tool holder SK 40 Table surface 900 x 520 mm Feed continuously 2 - 4000 mmweight approx.: 4,100 kg, Approx. Onsite Dimension. (l x w x h): 3,500 x 3,200 x 2,500 mm
usato
x-travel: 500 mmy-travel: 400 mmz-travel: 400 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: m3-axis digital read outhorizontal and vertical milling spindlequillTechnische Daten / technical details:Längsweg X / X-travel longitudinal 500 mmQuerweg Y / Y-travel cross 400 mmSenkrechtweg Z / Z-travel vertical 400 mmTischgröße / table size 800x460 mmSpindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 50-2500 UpM /rpmVorschubbereich / feed range 8-630 mm/min.Antriebsleistung Frässpindel / power capacity milling spindle 4,4 kWGewicht der Maschine / weight 1500 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description of the machine are not binding.The data for this ad was created with ModulMWS - the software solu ...
usato
x-travel: 500 mmy-travel: 400 mmz-travel: 400 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: m3-axes digital read outhorizontal and vertical milling spindlequillTechnische Daten / technical details:Längsweg X / X-travel longitudinal 500 mmQuerweg Y / Y-travel cross 400 mmSenkrechtweg Z / Z-travel vertical 400 mmTischgröße / table size 800x460 mmSpindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 50-2500 UpM /rpmVorschubbereich / feed range 8-630 mm/min.Antriebsleistung Frässpindel / power capacity milling spindle 4,4 kWGewicht der Maschine / weight 1500 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description of the machine are not binding.The data for this ad was created with ModulMWS - the software solu ...
usato
x-travel: 500 mmy-travel: 400 mmz-travel: 400 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: m3-axes digital read outhorizontal and vertical milling spindlequillTechnische Daten / technical details:Längsweg X / X-travel longitudinal 500 mmQuerweg Y / Y-travel cross 400 mmSenkrechtweg Z / Z-travel vertical 400 mmTischgröße / table size 800x460 mmSpindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 50-2500 UpM /rpmVorschubbereich / feed range 8-630 mm/min.Antriebsleistung Frässpindel / power capacity milling spindle 4,4 kWGewicht der Maschine / weight 1500 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description of the machine are not binding.The data for this ad was created with ModulMWS - the software solu ...
usato
Description: Motor 2800 rpm, including grinding discs and colletsweight approx.: 150 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 1,500 mm
usato
N° 5152: 1 gebr. Fresatrice per utensili Fabr. COPERCHIO , Tipo FP - 4 M,
usato
Articolo n. 5032: 1 gebr. Fresatrice universale per utensili Fabr. DECKEL, tipo FP 2 attivo, Bauj. 1981 con display digitale attivo a 3 assi Heidenhain Arb.-Ber.: 400 x 220 x 400 mm, potenza motrice: 2 kW Accessoristica: Tavolo rigido 700 x 330 mm Coperchio paraspruzzi pieghevole con vassoio trappola per trucioli Piedini macchina, Documentazione Altro: Portamandrino SK 40 / M 16 Gamma di velocità 25 - 2.500 min-1 Spazio richiesto circa 2,5 x 1,8 x 1,8 m Peso da circa 1,5 a Per ulteriori dati si rimanda alle schede tecniche allegate
usato
x-travel: 2.200 mmy-travel: 560 mmz-travel: 720 mmcontrol: iTNC 530 Heidenhainturning speed range - milling: 20 ~ 12.000 U/minpower capacity - milling spindle: 35 / 25 kWtool taper: SK 40 tool piece magazine with: 100 pos.table surface area: 2.600 x 600 mmrapid traverse X-axis: 100 m/minrapid traverse Y-axis: 50 m/minrapid traverse Z-axis: 50 m/minmax. tool diameter: 80 mmmax. tool-dia with free toolbox: 130 mmmax. tool length: 300 mmmax. tool weight: 6 kgmax. table load: 2.200 kgtotal power requirement: kWweight of the machine ca.: 12 tdimensions of the machine ca.: 7,0 x 4,2 x 2,7 mChip conveyor: Coolantsystem: interface 4. axis: 4. axis: 560 mmSeperating wall: oil mist extraction: test probe: TS 631 Tailstock: 350 mm / MK 5 elektr. hand wheel: through spindle coolant: 40 barTravelling column milling machineDECKEL MAHO - DMF 220 Linear - incl. 4th Axis ...
usato
Ref. -No.: 10164Manufacturer: DECKEL MAHOYear of construction: 1986Type of control: CNCControl: CNC 432Storage location: HalberstadtCountry of origin: DeutschlandTotal connected load: 40 kVAX-Travel: 800 mmY-Travel: 450 mmZ-Travel: 500 mmFeed force (X, Y, Z): X 800, Y 24000, Z 8000 NQuill Stroke: 100 mmSpeed work spindle: 20-4000 RPMFeeds X/Y/Z: 1-3000 m / minRapid Traverse X/Y/Z: 8 m / minTool Taper: ISO 40 Space requirements: 3680 x 3780 x 2720 LxWxH (mm)Further information:Additional information:- with controlled rotary table Ø800 (B axis)- simultaneously controlled axes: 3- axes controlled one after the other: 4
usato
x-travel: 350 mmy-travel: 240 mmz-travel: 340 mmturning speed range: 20 - 6.300 U/minfeed speeds: 1 - 5.000 mm/minrapid traverse: 5 m/mintool taper: SK 40 power capacity: 6,3 / 10 kWcontrol: Sinumeric 810 D tool change unit: pneumatisch manuelltotal power requirement: kWweight of the machine ca.: 1,6 tdimensions of the machine ca.: ca. 2 x 2 m110653528345-sided universal milling machineRotary table with swivel axis (clamping surface 400 x 290 mm)Rotation range C-axis displayed 360 ° on the screenB-axis swivel range +105 / -15 ° shown on the screenTable load capacity 100 kg,Operating modes 2 and 3, prepared for Net service, programming instructionsincluded, RS 232 C interfaceOperating mode 4 (extended manual intervention)Accessories: coolant device, electronic handwheelMachine is workshop tested and with electricalAcceptance reportThe data for this ad was created with ModulMWS - the so ...
usato
Mandrino: ISO 30 Viaggi (X/Y/z): 300 / 200 / 350 mm Velocità: (8) 80 - 2200 rpm Corsa del mandrino: 45 mm Alimentazione: 20 - 200 mm/min Dimensioni tabella: 600 x 200 Estensione: 110 mm Gireggiatura della testa: s/- 90 Potenza del motore: 1.1 / 1.4 kW Collegamento: 380 V / 16 A Dimensioni, approssimativamente: 1280 x 1120 x 1750 mm Peso circa: 450 kg Strutture: - Testa di fresatura gireante - 90 gradi - Display digitale a 3 assi - Piede refrigerante con pompa - Pulsante di emergenza - Luce della macchina - Fresatrice Vice RB 133 con giradischi, R'hm - 4 portautensili
usato
adattatore utensile: 50 mmutensili: 5 Stück: 4 Stück:
usato
Description: Rotation speed range: 45 - 2000 rpm With swiveling milling head Table dimensions: approx. 1000 x 315 mm Attention: the hydraulic machine vice is not included in the scope of delivery and purchaseweight approx.: 1,800 kg, Approx. Onsite Dimension. (l x w x h): 2,300 x 2,000 x 2,000 mm
usato
Description: Machine number: 2199 Spindle speed: 50 - 900 rpm Feed rate: 10 - 370 mm/min Table dimensions: 600 x 180 mm With 3 grooves Travel distances: X: approx. 400 mm Y: approx. 300 mm Z: approx. 300 mm Incl. vertical milling head, collets and other various machine accessoriesweight approx.: 1,000 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 1,500 mm
usato
Description: Attention: Machine not functionalcontrol: HEIDENHAIN TNC 155, table surface area l x w : 990x490 mm, tool taper: SK 40, weight approx.: 2,000 kg, Approx. Onsite Dimension. (l x w x h): 2,600 x 2,300 x 2,200 mm
usato
Description: NC tool milling machine - Heidenhain TNC 114B - hydr. Tool clamping - Machine light - Coolant device x-travel 510 mm y-travel 450 mm z-travel 410 mm Table size 800 x 390 mm Spindle mount ISO 40 Speed range - vertical 50 - 2500 rpm Quill stroke 80 mm Spindle motor 3 KW Machine weight approx. 1.4 t Space requirement approx. 1.6 x 1.6 x 1.95 mweight approx.: 1,4 kg, Approx. Onsite Dimension. (l x w x h): 1,600 x 1,600 x 1,950 mm
usato
x-corsa: 850 mm Corsa Y: 440 mm Corsa z: / mmControllo: TNC 355C
usato
Description: Serial number: 9712 Control: SIEMENS SINUMERIK 820M Table dimensions: 800 x 390 mm With 6 slots and an attached machine vise (jaw width: 100 mm) and a three-jaw chuck (diameter: 110 mm) Tool holder: SK 40 Travel distances: X: approx. 400 mm Y: approx. 400 mm Z: approx. 400 mmweight approx.: 2,000 kg, Approx. Onsite Dimension. (l x w x h): 2,500 x 2,000 x 2,000 mm
usato
Description: Drilling capacity in steel 30 mm Tool holder MK 4 Drilling stroke 225 mm Projection 315 mm Table size 650 x 560 mm Feeds o.1 to 1.5 mm/rev Spindle speeds 40 - 1800 rpm Total power requirement 5.15 kW Machine weight approx. 1.0 t Space requirement approx. 1.2 x 0.8 x 2.5 mweight approx.: 1,000 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 2,500 mm
usato
x-travel: 600 mmy-travel: 400 mmz-travel: 400 mmtable surface area: 800 x 400 mmspindle taper: SK 40 control: HEIDENHAIN TNC 310 spindle turning speed range: 10 - 3150 U/minspindle drive: 5,5 kWfeed - longitudinal/cross: 1 - 5000 mm/minfeeds vertical: 0,5 - 2500 mm/minrapid traverse: 6 / 6 / 3 m/mintotal power requirement: 10 kVAweight of the machine ca.: 2,5 tdimensions of machine L x W x H: 2,16 x 1,70 x 2,0 mAccessories: solid table, vertical head with hydr. tool clamping and quill retraction, electron. handwheel, coolantThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
Indicazioni: Portautensili: SK 40 Max. distanza percorsa asse X/Y/Z: 700 / 500 / 500 mm Gamma di velocità: 63 - 3150 1/min Corsa mandrino: 100 mm Avanzamenti: asse X,Y 16 - 800 mm/giro; Asse Z 8 - 400 mm/giro Traslazione rapida: asse X,Y 3000 mm/giro; Asse Z 1500 mm/giro Dimensioni del piano angolare: 900 x 500 mm Potenza motore: 12 kVA Connessione: 400 V Peso, circa: 2550 kg Dimensioni (LxPxA), circa: 1770 x 1880 x 2158 mm Attrezzatura: - Display digitale a 3 assi, Fagor - Tavola angolare rigida - Lampada per macchine - Pulsante di arresto di emergenza - Strumento operativo - Scarpe per macchine
nuova
Tre assi - Display digitale Distanze x/a/z 800 mm / 350 mm / 400 mm alimentazione 10~500 (18) mm/min Traverse rapide X + Z – assi 1.200 mm/min Traversa rapida Y - asse 1.200 mm/min. Area di serraggio del tavolo 800x400 horiz. Millimetro Superficie di serraggio del tavolo 250x950 verti. Millimetro Carico da tavola 400 kg Motore principale 3 kW Peso della macchina ca.ca. 2,3 t Requisiti di spazio ca. 1 820x1 640x1 710 mm
usato
16 pezzi SK 50 Prezzo per tutti e 16 Spedizione in Germania 65.- IVA non detraibile.
nuova
x-travel: 600 mmy-travel: 300 mmz-travel: 440 mmtable-size: 1120 x 260 mmspindle taper ISO: 40 spindle turning speed range: 35 - 1600 U/mintotal power requirement: 2,2 kWweight of the machine ca.: 1,36 tdimensions of the machine ca.: 1,65 x 1,32 x 1,65 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
Fresatrice per utensili da un'officina di formazione in ottime condizioni Produttore Klopp Korradi Data di costruzione 1991 Digitale SK40 · alimentazione automatica su tre assi Pinole di foratura 50 mm Testa girevole Velocità mandrino fino a 45-1950 giri/min x-310 millimetri y-180 millimetri z-310 millimetri Tavolo 600 x 250 mm Alimentazione infinitamente variabile 10 - 470 mm/min. dimensioni della macchina circa 1,0 x 1,1 x 1,6 m Collegamento alimentazione 400Volt 10 Ampere Dispositivo digitale a 3 assi AXEsta Contro-tenuta per fresatura orizzontale Dispositivo refrigerante Vasca con chip Prezzo speciale
usato
x-travel: 300 mmy-travel: 200 mmz-travel: 350 mmtable surface area: 700 x 270 mmtaper in main spindle: ISO 40 turning speeds: 8: 150 - 1660 U/minturning speed range - horizontal: 8. 110 - 1230 U/minfeeds: 8: 25 - 285 mm/minweight: 900 kgquill stroke: 60 mmtotal power requirement: 3,7 kWrange L-W-H: 1,3 x 1,38 x 1,65 mCondition: ready for operation: Video available on our website.: CE signed: Electric 380 Volt: Cooloing pump: Digital readout 2 axis: x+y / Digidata KNT 7000 Fixed working table: Vertical milling head swivelling +quill adjustment: chip pan: Swiveling table: 600 x 250 mmSlotting head: Hub 80 mmUniversal tool milling machine with 2 axis digital display and swivelingvertical milling head with quill, fixed + swiveling table, slotting head, automatic feeds and rapid trverse in all three directions. Machine from a repair shop.The digital display shows 2 axes because the t ...
usato
Description: 'Serial number: 114596 Operating voltage: 400V Frequency: 50Hz Power: 5.8 kW Connection: 0.12 kW Speed: 2800 rpm Spindle speed: 63 - 3150 rpm Tool holder: SK 40 Table dimensions: 800 x 320 mm With 5 grooves Attention: the machine vice located on the clamping surface is not included in the scope of delivery Travel paths: X: approx. 500 mm Y: approx. 400 mm Z: approx. 500 mm Incl. three-axis digital display from the manufacturer ARBAH'weight approx.: 1,500 kg, Approx. Onsite Dimension. (l x w x h): 1,800 x 1,500 x 2,000 mm
usato
- Dimensioni tavola 460 mm x 800 mm - Corsa asse X 500 mm - Portamandrino ISO 40 - Gamma di velocità (18) 50 - 2.500 giri/min - Potenza motore azionamento principale 3,75 / 4,4 kW
usato
Corsa: X, Y, Z 595mm x 400 mm x 450 mm Gamma di velocità da 30 a 1.800 giri/min per orizzontale e verticale Testa di fresatura per girare a destra e a sinistra con penna d'oca 75 mm Portautensili SK 40 Numero macchina 80003 Accessoristica: Display digitale a 3 assi Heidenhain
usato
Description: Universal tool milling machine - Digital display - horizontally milling device - Coolant system - Vise - Operation manual x-travel 600 mm y-travel 410 mm z-travel 200 mm Speed range - horizontal 30 - 1280 rpm Speed range - vertical 50 - 2150 rpm Head swivels +/- 90° Spindle holder ISO SK40 Table surface 1000 x 315 mm Total power requirement 3.2 kW Machine weight approx. 1.44 t Space requirement approx. 1.6 x 1.7 x 2.1 mweight approx.: 1,450 kg, Approx. Onsite Dimension. (l x w x h): 1,600 x 1,700 x 2,100 mm
usato
x-travel: 400 mmy-travel: 320 mmz-travel: 400 mmControl: Heidenhain TNC 426/430 tool taper: SK 40 spindle turning speed range: 5000 U/mintotal power requirement: 5,5 kWweight of the machine ca.: 2 tdimensions of the machine ca.: 2,5 x 2,0 x 2,0 m1 used Universal tool milling machineMake KUNZMANNType WF 4 CNCBuilt in 2002with Heidenhain TNC 426/430Operating hours:Control on: 39893 hMachine on: 36335 hProgram run: 5705 hSpindle running time: 8287 hAutomatic tool suit, drilling quillMilling head swivels +/- 90°(without vice)A viewing is possible at any time by arrangement.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
Area di bloccaggio del tavolo: 350 x 700 mm percorso x: 500 mm A-way: 320 mm z-way: 400 mm Porta mandrino: SK 40 Velocità del mandrino: 30 - 2500 giri/min Tensione operativa: 380 V Fabbisogno energetico totale: 2,2 kW Fabbisogno di spazio: 1500 x 1500 x 1800 mm Peso: circa 1700 kg
usato
x-travel: 650 mmy-travel: 500 mmz-travel: 450 mmtable surface area: 1000 x 600 mmspindle taper: SK 40 spindle turning speed range: 5 - 6500 U/minquill stroke: 60 mmvertical head swivelling: +/- 90 table load: max. 400 kgfeeds longditudinal/cross/vertical: 0 - 4000 mm/minrapid traverse: 25 / 25 / 20 m/mindistance table / vertical spindle: 100 / 550 mmdistance table/horizontal spindle: 270 / 720 mmno. of tools in magazin: 20 tool diameter: 95 mmwotkpiece diameter with 2 vacant positions: 135 mmtool length - max.: 300 mmweight of tools max.: 7 kgcontrol: HEIDENHAIN, iTNC 530 spindle power: 13 kWtotal power requirement: 20 kVAweight of the machine ca.: 5,5 tdimensions of machine L x W x H: 3,45 x 2,38 x 2,25 mAccessories: vertical head with quill retraction and hydr. tool clamping, solid table, electron. hand wheel, probe HEIDENHAIN TS 640, coolantThe data for this ad ...
