Modello
(Fabbricante: HERMLE)
fresatrice, anno 2002, CNC TNC 430. Macchina usata in buone condizioni. Maggiori informazioni e prezzi su IndustrialBuyer.
Controllo: iTNC 530 Max.travel gamma: X 850 mm Y 700 mm Z 500 mm A +/- 115? C nx 360? Velocità del mandrino ? 18000 giri/min Rastremare? HSK 63 Cambio utensile ? 38+44 posizione Serbatoio del liquido di raffreddamento: 900l la macchina è dotata di raffreddamento del mandrino, è disponibile il sistema di bloccaggio Erowa,
Questo centro di lavorazione verticale Hermle C 800 V a 3 assi è stato prodotto nel 1996. Offre una costruzione robusta e precisione per compiti di lavorazione meccanica complessi. Se desideri ottenere capacità di fresatura di alta qualità, considera la macchina Hermle C 800 V che abbiamo in vendita. Contattaci per maggiori informazioni su questa macchina.
Questo centro di lavorazione verticale a 3 assi HERMLE C 1200 V è stato prodotto nel 2003. Dispone di un robusto tavolo di serraggio di 1400 x 900 mm e di un mandrino di fresatura ad alte prestazioni con una potenza massima di 10 kW, coppia fino a 87 Nm e velocità fino a 16.000 giri/min. Ideale per lavori di lavorazione complessi, la macchina HERMLE C 1200 V che abbiamo in vendita offre precisione e durata. Contattaci per maggiori informazioni.
x-travel:850 mm y-travel:630 mm z-travel:500 mm spindle taper ISO:40 milling head speed:25 - 4200 U/min table surface area:560 x 1200 mm total power requirement:15 kW weight of the machine ca.:4 t dimensions of the machine ca.:4,3 x 4,4 x 2,3 m with CNC HEIDENHAIN TNC 415
x-travel: 510 mm y-travel: 450 mm z-travel: 410 mm taper in main spindle: MAS BT 45° (SK40) table surface area: 800 x 395 mm T-slots: 6 Stk. turning speeds: 50 - 2500 U/min feed stepless: 4-1600/4-1000 mm/min voltage: 400 V total power requirement: 5.0 kW weight of the machine ca.: 1400 kg range L-W-H: 2300 x 2300 x 1800 mm from a training workshop maintained condition () - in checked conditions - machinevideo - https://www.youtube.com/watch?v=iSTVEdv2fO8 Furnishing : - robust universal milling machine - swiveling control panel, right front - rotatable universal milling head (re/li = 90°) with hydraulic tool clamping - manual milling spindle feed, with locking - swiveling milling spindle protection - Stable T-slot clamping/angle table - Axis feeds with rapid traverse - Central lubrication unit - Control cabinet, installed on the left Digital display - without function The data fo ...
x-travel: 600 mm y-travel: 450 mm z-travel: 450 mm total power requirement: kW weight of the machine ca.: 6.5 t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
travel: 600 mm length: 450 mm width: 400 mm spindle turning speed range: 20 4500 U/min Control: Heidenhain TNC 425 weight: 3300 kg dimensions of the machine ca.: 4,0 x 3,8 x 2,1 m total power requirement: 15 kW tool taper: HSK A 63 table-size: 850 x 440 mm 3-axis machining centre X-axis travel: 600 mm Y-axis travel: 450 mm Z-axis travel: 400 mm Table size: 850 × 440 mm Tool holder: HSK-A63 Spindle speed: 20 – 4,500 rpm Control system: Heidenhain TNC 425 Total power requirement: 15 kW Machine weight: approx. 3,300 kg Space requirement (L × W × H): approx. 4.0 × 3.8 × 2.1 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 500 mm y-travel: 430 mm z-travel: 400 mm total power requirement: 4 kW weight of the machine ca.: 1,4 t dimensions of the machine ca.: 2 x 2 x 2 m No. 3999 Universal tool milling machine HERMLE UWF 801 Working area: 500 x 430 x 400 Drive: 3 Control: Heidenhain TNC 135 Fixed table 800 x 390 mm chip tray documentation Spindle SK 40 Speed range 50 - 2500 min-1 Space requirement approx. 3 x 3 x 2 m Weight approx. 1400 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm total power requirement: 3 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2 x 2 x 2 m No. 2392 Universal tool milling machine HERMLE UWF 801 Working area: 500 x 430 x 400 mm Drive: 3 kW Control: TNC 135 With manual control: Working area 520 x 450 x 410 mm, fixed table 800 x 400 mm Tool holder SK 40 18 spindle speeds from 40 - 2000 1/min Feed stepless x,y 4 - 1600 mm/min z 4 - 1000 mm/min Dimensions 2.3 x 2.3 x 1.7 m Weight 1350 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 630 mm y-travel: 500 mm z-travel: 500 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control Heidenhain TNC 426 electronical hand wheel manual swivel head quill coolant device measuring feeler Technische Daten: /technical details X Weg / x travel 630 mm Y Weg / y travel 500 mm Z Weg / z travel 500 mm Drehzahlbereich 2-stufig / spindle speed range (2-steps) 20 - 7000 UpM / rpm Eilgang / rapid feed 15 m/min. Spindelaufnahme / spindle taper SK 40 Gewicht der Maschine ca. / weight 4500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 700 mm y-travel: 550 mm z-travel: 500 mm spindle taper ISO: 40 control: Heidenhain type: TNC 155 milling-head swivable +/-: boring spindle: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG ...
x-travel: 500 mm y-travel: 360 mm z-travel: 400 mm Control: Siemens 810 tool taper: SK 40 table surface area: 800x390 mm T-slot - width: 14H7 mm number of T-slots: 6 T-slot - distance: 63 mm turning speeds: 20-4000 U/min transmission ratio: 4 Feed: 1-2000 mm/min rapid traverse: 5 m/min total power requirement: 9 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2,5x2,9x1,9 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appoint ...
x-travel: 530 mm y-travel: 430 mm z-travel: 400 mm spindle taper ISO: 40 milling-head swivable +/-: boring spindle: : 650x440 mm table - swivable: Grad turning speeds: 45-2000 U/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m HS 570 4953 Automatic clamping spindle mount The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data ...
x-travel: 850 mm y-travel: 700 mm z-travel: 500 mm Control: Siemens 840 D rotary table: 800 mm c-axis: 0.001º ( ±360º) 0 B-axis (table): +25 / -110 º mm number of spindle speeds: 18.000 U/min/rpm tool taper: HSK 63 Tools changer: 38 fach/tools Internal cooling system: 80 bar handwheel: total power requirement: 43 kVA weight of the machine ca.: 10,6 t dimensions of the machine ca.: m Equipment- Paper belt filter – 200 l tank- Active control cabinet cooling- Infrared probe M&H (Heidenhain)- Laser tool measuring system Blum- Chip conveyor- Cleaning pistol with pump 2 bar / 40 l min- 3D Quick Set- Electronic handwheel The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
number of spindle speeds: 10.000 U/min NC rotary indexing table Ø: 630 mm control: HEIDENHAIN - iTNC 530 numbers of positions in the tool changer: 32 tool taper: SK 40 5-axis simultaneous machining center | HERMLE - C 30 U equipped with ITC (80 bar), NC swivel rotary table, tool changer & chip conveyor. The Z-axis motor was replaced in 2025, and the spindle was already replaced in 2015 at 7,100 operating hours. The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: C30U | C-30U | C-30 U The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 630 (875) mm y-travel: 500 mm z-travel: 500 mm Control: Heidenhain TNC 430 turning speeds: 20-7.000 U/min feed: 0-15.000 mm/min tool change unit: 16-fach rapid power traverse in X-and Z direction: 15 m/min tool taper: SK 40 table surface area: 900 x 528 mm max. table load: 400 kg spindle diameter in front bearing: 55 mm swivellable: 0-90 ° quill stroke: 75 mm spindle hours: 9.546 h total power requirement: 12/7,5 kW weight of the machine ca.: 4,8 t dimensions of the machine ca.: 4 x 3,6 x 2,2 m HERMLE U 630T 3-axis machining centre, built in 1999 The X-axis, with a stroke of 630 mm, can be extended to 875 mm by swivelling the tool changer out of the way. Accessories: Tool holders, see pictures The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Centro di lavorazione a 5 assi Tipo: U 1130 Produttore: Hermle Anno: 2005 Controllo: Heidenhain TNC 530 X: 1130 mm Y: 720 mm Z: 630 Rastre del mandrino: HSK63 Rivista utensile: 28 posizioni IKZ 40bar Rilevamento della rottura degli utensili laser Peso della macchina: 8500 kg Nizzolo trasportatore a trucioli Macchina in buone condizioni, completamente funzionante, sotto alimentazione Trova di più qui - / Contattaci a -
x-travel: 600 mm y-travel: 450 mm z-travel: 400 mm table-size: 850 x 440 mm spindle taper: SK 40 control: HEIDENHAIN TNC 355 ATC: 32 Pos spindle turning speed range: 20 - 4000 U/min spindle drive: 5,9 kW quill stroke: 80 mm feeds longditudinal/cross/vertical: 1 - 2000 mm/min power feed x/y/z: 7200 N rapid traverse longitudinal and cross: 10 m/min rapid traverse vertical: 10 m/min total power requirement: 12 kW weight of the machine ca.: 3 t Acc.: NC-dividing unit (=4th axis) make WALTER with 3-jaw chuck 160 mmø, vertical head with hydr. tool clamping and quill retraction, solid table, various tool fixtures, electron. hand wheel, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
travel -x axis: - mm travel -y axis: - mm travel -z axis: - mm control: HEIDENHAIN - iTNC 530 number of spindle speeds: 18.000 U/min tool taper: HSK-A63 5-axis simultaneous machining center | HERMLE - C 20 U equipped with ITC & pallet changer. The machine is in a well-maintained condition, works in Switzerland. The machine and can be inspected at any time under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: C 22 | C22 | C-22 | C22U The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Centro di lavorazione verticale CNC Tipo: U 630 T Produttore: Hermle Anno: 2001 Controllo: Heidenhain TNC 426 X: 630 mm Y: 500 mm Z: 500 mm Velocità massima del mandrino: 7000 giri/min Motore a mandrino: 7,5 kW Rastre del mandrino: ISO 40 Tabella: 900 x 528 mm Carico massimo del tavolo: 400 kg Peso della macchina: 4800 kg Sonda strumentale: Heidenhain TS 220 Documentazione Macchina in buone condizioni, completamente funzionante, sotto alimentazione. Trova di più qui - / Contattaci a -
Viaggio: 800 mmy-Viaggio: 600 mmZ-Viaggio: 500 mm: Potenza totale richiesta: kWpeso della macchina ca.: tDimensioni della macchina ca.: mI dati per questo annuncio sono stati creati con ModulMWS - la soluzione software di LogoTech oHG.
x-travel: 410 mm y-travel: 310 mm z-travel: 400 mm table-size: 700 x 280 mm control: Heidenhain TNC 145 tool adaptor: SK40 turning speed range: 40- 2.000 U/min rapid speed: 1,5 m/min feed speeds: 1500 mm/min power requirement: 2.2 kW quill stroke: 63 mm weight: 1,3 t total power requirement: 2,2 kW weight of the machine ca.: 1,5 t dimensions: 1,4 x 2,1 x 2,0 m Features: - New TFT screen - Coolant system - Hydraulic tool clamping - Milling head with spindle sleeve - Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x/y/z - 500/360/400 mm, massimo 4000 rpm, 4 angolo di serraggio, 1 pulsante, vari colpi, armadio Lista
HERMLE C 42 U ist ein 2 x 5-Achsen Zentrum mit Laderoboter, ausgelegt auf hohe Präzision und Zuverlässigkeit. Tisch 400×400 mm, 450 kg, Wege X800 Y800 Z550 mm, A ±130°. Spindel HSK-A63 0–18.000 rpm, 42 kW, 148 Nm; Eilgänge 45/45/40 m/min. Magazin 42+160, 54 Paletten, KUKA Roboter, IKZ 80 bar, Renishaw/BLUM. Einsatz: Automotive, Luftfahrt, Uhrmacherei, Medizintechnik Technische Daten ohne Gewähr
HERMLE C 600 V ist ein 3-Achsen Bearbeitungszenter, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Tisch 800×465 mm, Verfahrwege X 600 / Y 450 / Z 450 mm, Max. Werkstückgewicht 200 kg; Werkzeugwechsler 30 Plätze, Aufnahme HSK-A63. Spindel 20–16.000 min-¹, Leistung 15 / 10 kW; Vorschub 1–30.000 mm/min, Eilgang 35 m/min, Vorschubkraft 6000 N. Anschluss 3×400 V 50 Hz, Gesamtbedarf 35 kVA, Gewicht ~6800 kg, Abmessungen 2500×2020×2750 mm, 78 dB(A). IKZ 40 bar. Erreicht enge Toleranzen; Anwendungen: Automotive, Luftfahrt, Medizintechnik, Uhrenindustrie, Werkzeugbau. Technische Daten ohne Gewähr
HERMLE C 42 U ist ein 5-Achsen-Bearbeitungszentrum, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazitäten: Tisch Ø440 mm, 5 T-Nuten 14H7, max. Werkstückgewicht 450 kg; Verfahrwege X800 × Y800 × Z550 mm, A ±130°, Tischdrehzahl 30 t/min; Hauptdaten: Spindel HSK-A63 0–18.000 rpm, Leistung 42 kW, Drehmoment 148 Nm, Eilgang 45/45/40 m/min, Netz 3x400 V 50 Hz, Druckluft 6 bar, Gesamtleistung 37 kVA, Gewicht ~13.500 kg, Abmessungen 5000×2450×3200 mm; Zubehör: Werkzeugwechsler 42 Plätze, Zusatzmagazin 160 Plätze, IKZ 80 bar, Schnittstellen RS232/Ethernet/USB, Schaltschrank-Klimagerät; geeignet für enge Toleranzen in Automotive, Luftfahrt, Medizintechnik, Uhrenbau, Werkzeugbau Technische Daten ohne Gewähr
HERMLE UWF 802 M ist eine CNC-Fräsmaschine, die Präzision, hohe Genauigkeit und Zuverlässigkeit bietet. Längsweg X 800 mm, Querweg Y 500 mm, Vertikalweg Z 500 mm; Tisch 800×390 mm; max. Werkstückgewicht 500 kg. Spindelaufnahme ISO 40; Drehzahl bis 6300 t/min; Anschluss 3×400 V 50 Hz; Maschinengewicht ca. 1750 kg; Abmessungen 3000×2200×2000 mm; Pinolenhub 75 mm. Ermöglicht enge Toleranzen; typische Einsatzbereiche: Automotive, Uhrenindustrie, Maschinenbau, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr
