used
3-D coordinate measuring machine ZEISS NUMEREX Granite measuring plate, granite measuring plate, measuring table Model No. 3648-18, Serial. No. X-1019, year of construction approx. 1986 Measuring range X = approx. 1250 mm, Y = approx. 900 mm, Z = approx. 400 mm Measuring plate L x W 1525 x 1435 mm Usable area 1525 x 1100 mm Measuring plate thickness 305 mm Passage width in the portal 1100 mm Probe holder 9.5 mm Compressed air connection 6 bar Mains connection 230 Volt, 50 Hz. - Granite plate with steel inserts with internal thread - Axis adjustment with pneumatic sliding guide for X, Y and Z-axis - Plate on base frame with 5 pieces of adjustable feet, 3 pieces support plate for the adjustable feet - Computer and software missing (not available and not included) Space requirement of the measuring machine L x W x H 1600 x 1850 x 2200 mm Weight of the machine approx. 2.8 ton. Plate damage ...
used
3-D coordinate measuring machine ZEISS NUMEREX Granite measuring plate, granite measuring plate, measuring table Model No. 3648-18, Serial. No. X-1019, year of construction approx. 1986 Measuring range X = approx. 1250 mm, Y = approx. 900 mm, Z = approx. 400 mm Measuring plate L x W 1525 x 1435 mm Usable area 1525 x 1100 mm Measuring plate thickness 305 mm Passage width in the portal 1100 mm Probe holder 9.5 mm Compressed air connection 6 bar Mains connection 230 Volt, 50 Hz. - Granite plate with steel inserts with internal thread - Axis adjustment with pneumatic sliding guide for X, Y and Z-axis - Plate on base frame with 5 pieces of adjustable feet, 3 pieces support plate for the adjustable feet - Computer and software missing (not available and not included) Space requirement of the measuring machine L x W x H 1600 x 1850 x 2200 mm Weight of the machine approx. 2.8 ton. Plate damage& ...
used
Table size 2500x1500 mm X Travel 1200 mm Y Travel 1800 mm Z Travel 1000 mm Measuring head VAST XT
used
Control UMess-300 / Software version 5.10 Travel X/Y/Z 850/1200/600mm switching probe / autom. Button change Accessories: Pushbutton frame with 5 button positions
used
X-travel: 380mm, y-travel: 450mm, z-travel: 280mm, max. load: 410kg, probe: Renishaw PH1, length: 890mm, width: 840mm, height: 1370mm, weight: 360kg, with documentation, an inspection is possible.
used
Without software, documentation available.
used
Y-travel: 500mm, z-travel: 450mm, including measuring probes and documentation, software is faulty, machine cannot be started properly.
used
X-travel: 400mm, y-travel: 500mm, z-travel: 300mm, max. workpiece weight: 50kg, resolution: u1=(3.4+L/200)µm, touch probe: PH6/TP2, software: U-Soft 9.04, operational hours: unknown, with documentation, without accessories, has been regularly maintained and calibrated.
used
Ref. -No.: 10157 Manufacturer: CARL ZEISS Year of construction: 1997 Type of control: HP 9000 Serie 700 Control: Betriebsystem HP-UX.9.05 Storage location: Halberstadt Country of origin: Deutschland Turntable: 1000x2100 mm Machine weight: 4.800 kg Machine Height: 3050 mm Table height above the floor: 850 mm X-Axis: 850 mm Y-Axis: 1800 mm Z-Axis: 600 mm Further information: Three coordinate measuring machine Microcomputer control X-axis as a longitudinally movable portal Y-axis cross slide in the portal Z-axis as measuring head quill (vertical) Passage between the portal approx. 1,000 / 1080 mm Passage in height approx. 750 mm
used
Description: Including measuring probes, operation, calculator z-motion: 700 mm, x-motion: 1,000 mm, y-motion: 700 mm, weight approx.: 3,000 kg, Approx. Onsite Dimension. (l x w x h): 1,400 x 1,400 x 2,700 mm
used
Description: Composed of: - Machine body dimensions 2015x1700x2843 mm - Desk with pc, monitor, HP printer , - External unit ZEISS ACCURA MASS/B, 1600 VA - ZEISS control console - ZEISS calibration sphere - Exchange magazine with Contact Probing System heads and 1 Optical Probing System head - Complete with user and installation manuals , - Complete with instruction manual for CALYPSO software - Various boxes and packaging for component storage  , NOT INCLUDED, EXCLUDED FROM SALE, VISUAL MICROSCOPE z-motion: 700 mm, x-motion: 900 mm, y-motion: 1,200 mm, control: PC, software: CALYPSO, table surface area l x w : 1500x1150 mm, daylight: 1,100 mm, weight approx.: 3,500 kg, Approx. Onsite Dimension. (l x w x h): 1,700 x 2,015 x 2,843 mm
used
Stand unit with steel plate with C99 control Measuring ranges: x=5000 mm, y=2600 mm, z=2100 mm Measuring plate: 6000 mm x 3000 mm Rotary swivel head RDS for TP Control panel Dynalog Travelling control unit on the stand, opto-coupler, screen, keyboard, mouse Active vibration damping Without software and hardware. We reserve the right to make changes and errors in the technical data as well as to make the interim sale. Price plus transport and installation.
used
ZEISS MC 850 X-AXIS STROKE: 850 MM Y-AXIS STROKE: 1200 MM Z-AXIS STROKE: 600 MM WEIGHT APPROSS. 3800 KG DIMENSIONS (W X H X D): 1.6 X 1.56 X 2.95 MM
used
RACING X/Y/Z AXES 900/900/700 MM MEASURING PRECISION 2.2 + L/300 ?M WORKPIECE WEIGHT (MAX.) 1,200 KG CONTROL SYSTEM VAST MEASURING HEAD POINT/POINT CONTROL MODE CONTINUOUS SCAN MACHINE DIMENSIONS WIDTH 1,640 MM LENGTH 1,740 MM HEIGHT 2,700 MM WEIGHT (APPROX.) 2,000 KG
used
This ZEISS ScanMax Measuring machines machine was manufactured in 2019 in Germany. It has 3 axis.
used
This CARL ZEISS ScanMax G32001-9906-000 measuring machine was built in the year 2007 in Germany.
used
Antique Universal Measuring Microscope Fabr. CARL ZEISS JENAbuilt around 1939Craft No. 1191used, in good and functional conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
This Zeiss Eclipse CNC 07/07/06 Measuring machine was made in 2002 in Germany. It is equipped with a ZEISS U-SOFT Plus, Version 9.05, control.
used
Machine Product: Universal length measuring instruments with a direct measuring range over the entire length of the device. Comparator with horizontal base bed (hard rock with high homogeneity and rigidity) X-axis measuring system: Incremental, high-precision Heidenhain length measuring system, 100 mm long in the measuring element incremental Heidenhain incident light measurement systems over the entire length of the base bed to the left and right of the stage in the base bed Z-axis measuring system: INCREMENTAL, high-accuracy RENISHAW length measuring system, 80 mm long Product: • Standard software 828 WIN ULM "Free Measuring" • PC evaluation unit (without monitor) • Pair of measuring brackets, immersion depth 14mm (0.55 inch) • 2 parallel clamping claws 60/20 • 2 quick-release claws • 2 measuring attachments with spherical zone • Setting gauge 2 • W ...
used
Connected load: 460VA.
used
x-travel: 850 mm y-travel: 1200 mm z-travel: 600 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Universal 3D measuring center, double-column, modern software, many accessories The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 9200 mm y-travel: 1600 mm z-travel: 2400 mm dia. of test piece: mm working area: mm dist. between centers: mm control: ZEISS C 99 total power requirement: kW weight of the machine ca.: 30 t dimensions of the machine ca.: 10 x 3,6 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Precision measuring device, tripod with micrometer CARL ZEISS JENA 0 - 25 mm Scale size: 0.01 mm DIN 863/1 Dimensions: 155 x 115 x 70 mm
used
Universal measuring device, probe CARL ZEISS JENA 40 - 160 mm (similar to Multimar) Accuracy dial indicator: 0.01 mm used, tested ! Dimensions: 320 x 70 x 40 mm
used
Length measuring system with display unit CARL ZEISS JENA display unit AE80 electronic unit ZE10A length measuring rod IALK measuring space: 1200 mm measuring bar: 1240 x 56 x 42 mm approx. 4,5 m connection cable 220 V 50 Hz used, tested ! Dimensions: 1300 x 360 x 100 mm
