used HOMAG 83

The machine has been regularly serviced by HOMAG. edge banding machine Homag KR77 year 1999 edge banding machine with return HOMAG KR 77 /A3/S2 year 1999 glueing thickness max 3 mm thickness roll material max 3 mm zero joint hot air corner trimming unit corner copying unit 2 motors tool change places 8 universal trimming unit scraper unit profile scraper unit units clocked pneumatic machine length 8. 545 mm Control system HOMAG HOMATIC NC 21 Workpiece return Conveyor belt Gluing height max 65 mm Workpiece width min 55 mm Height adjustment motor-driven Belt top pressure Feed max 24 m/min Feed infinitely variable Changeover stations Roller magazine 2 Gluing system Granulate Pre-melting container Quick-change gluing tank glue tank spraying unit cross-cut saw unit 2 motors flush/radius/bevel stations 1 buffing unit design right-hand machine CE mark SCHUGOMA KANTENKING HOMAG A 3 gluing unit ...

Control cards -Replacement cards for: -Homag type: KFL 53 -Homag type: KFL 54 -Homag entrance cards -Homag control cards -Homag controller cards -Cabinet: is only sold complete -Weight: 200 kg

The machine has been regularly serviced by HOMAG. 3. Weeke/Homag BHT 500 year 2004 CNC automatic drilling machine WEEKE/Homag BHT 500 Profiline year of construction 2004 working range X 2.500 mm working range Y 1. 400 mm Number of separate aggregates 4 drills vertical 70 drills horizontal X 26 drills horizontal Y 8 grooving saw dowel driving throughfeed drilling unit Control Homag powerControl Software woodScan, woodWOP Working range Z 45 mm CNC axes 4 milling spindles Main motor 6 kW Dowel driving units 4 dowel diameters 8 mm Clamping system Vacuum clamp Safety device Light barrier Vacuum pump Capacity vacuum pump 100 m³/h Feeding automatic Roller conveyor Discharge automatic Belt conveyor CE mark Barcode reader Dxf interface Find more here - / Contact us at -

Homag Machining centers with flat table Machine type Optimat BOF41/45K Year of construction: 2001 We bought the machine used around 2012 through the Kaul company. The machine ran in single-shift operation for a maximum of one day a week. Two new vacuum pumps were purchased in 2022. But I need this for them Replacement machine which we will receive at the beginning of February. The machine must be delivered without accessories. In 2023 and 2022, three Indramats repaired by Homag were installed. The machine runs mechanically flawlessly. However, there are hardly any electronic replacement parts. Find more here - / For a video see /listings/5142348-used-2001-homag-optimat-bof41-45k Contact us at -

Homag saw unit Brand: Homag Type: 000W04206041 Year of construction: 2000 M-No.: 4-02078 000W04206041 Nmax: 9,900 rpm

Homag saw unit Brand: Homag Type: 000W04206041 Year of construction: 1998 SKU:4-060-24-0165 2.056.10.3021 Saw blade: ø180 mm Nmax: 10,000 rpm

Manufacturer: Homag, Type: Profi BAZ/20/40/14/3/KA, Year: 2003, Control: Woodwop, Maschinensteuerung: Homag, Programming station office: möglich, Work piece width min-max mm: 1400, Min.-max. workpiece length in mm: 5200, Min.-max. workpiece height in mm: 10-60, C axis: yes, Number of milling spindles vertical: 2, Anzahl Frässpindeln horizontal: no, Milling engine 1 hours power: ca.12, U/min 1) Vertikal: 1500-24000, Milling engine 2 hours power: ca.12, U/min 2) Vertikal: 1500-24000, Number of tool changers: 2 (1 defekt), Tellerwechseler: yes, Number of tools per tool-magazine: 12, Mitfahrender Werkzeugwechsler: yes, Belt conveyor: Rollentransport, Traverse table: yes, Stops in the table front: yes, Automatische Beladung: yes, Automatschische Entladung : yes, Vacuum pumps m³/h: 100, Tool clamping system: HSK 63, Saw unit: yes, Radial arm machine: yes, Laser positioning: no, incl. to ...

Manufacturer: Homag Getriebe Verstellung Oberdruck/Maschinenhalter Bett, Type: auf KF Homag, FREETEXT1: 3 Verstellgetriebe, FREETEXT2: 4 Winkelhalter Bett,

Manufacturer: Homag aus Homag KF 20, Type: Ein und Ausgangskarten Streckensteuerung,

Manufacturer: KEB Homag Umrichter, Serial number: 07.F0.R01-1228, was installed in machine: Homag Maschine, Production number: 95150305/129518, Frequency converter: yes, Power Output: 750, FREE TEXT: 750 W 2/4 50/60 Hz,

Manufacturer: Homag, Type: NFL 26/6/10/PW/L, Year: 2002, Control: Homag, Work piece width min-max mm: 136-250, Min.-max. workpiece length in mm: 2500, Min.-max. workpiece height in mm: 10-25, Working width min-max mm: 136 - 250, Feeding speed min-max m/min: 15 - 60, 1st milling unit kW / rpm: Ritzen 4,5 kW/6000 U/min, 2nd milling unit kW / rpm: Ritzen 4,5 kW/6000 U/min, 3rd milling unit kW / rpm: 6,6 kW Profilfräsen 6000 U/min, Free space for units: 2x 460 mm, Machine overhauled: no, System dismantled: yes, Year :2002

Manufacturer: Homag , Type: Power FR 20/09/15/L/Q1, Year: 2007, Control: Powercontrol Homag, Conveyor: Nockenkette, Work piece width min-max mm: 350, Min.-max. workpiece length in mm: 220-1500, Min.-max. workpiece height in mm: 10-30, Machine with controlled dogs: yes, Cam distance mm: ca.500, Feeding speed min-max m/min: ca.60, Feed stepless: yes, verängerte Kette mm: yes, Overall milling units: 5, Moulding units swivel-mounted: 5, gesteuerte Fräsaggregate: keine, 1st milling unit kW / rpm: 6,6/5850, 1. swivelling controllable: yes, 2nd milling unit kW / rpm: 6,6/5850, 2. swivelling controllable: yes, 3rd milling unit kW / rpm: 6,6/5850, 3. swivelling controllable: yes, 4th milling unit kW / rpm: 6,6/5850, 4. swivelling controllable: yes, 5th milling unit kW / rpm: 6,6/5850, 5. swivelling controllable: yes, Year :2007

Manufacturer: Homag PU und EVA, Type: KAL 310 310/6/A3/S2, Year: 2008, Control: NC 22, Software: Homag, Min-max edge material mm: 0,5-3,0, Work piece width min-max mm: 65, Min.-max. workpiece length in mm: 250, Min.-max. workpiece height in mm: 12-60, Min-max feed m/min: 10-25, Premilling: yes, Fine milling: yes, Application of separation agent: yes, IR zone: yes, Coil magazine: 2-fach, Mitre stations: HL 81, Bevel milling: yes, Corner tracing type: FF 12, 4 motors: Ja, Radius scraper: yes, Type of scraper: PN 10, Flat scraper: FA 11, 4 motors: Ja, Ersatzverleimteil : PU, Bonding part EVA: EVA, Buffing unit: yes, Separation agent setup: yes, Year :2008

Manufacturer: 2 StückPerske, Type: Ritzmotor Homag FPL 526, Motor with gear: KNS 51.14-2 D, From machine: Homag Maschine, Spindle length mm: ca.60, Diameter of the spindle mm: 30, Power kW: 1,0/2,0, Volt/Hz: 50-60-120, pm: 2750/5700/3380/6920, Motor with gear: KNS 51.14-2 D, Price per unit Euro: 600, FREE TEXT: Spindeldurchmesser 30/Länge mm ca. 55 mm,

Manufacturer: Homag, Type: Ritzsäge Nachschwenkeibrichtung für links und rechts, From machine: Homag FPL, Shaft dimensions L x D mm: 1200,

Manufacturer: Homag, Type: Motorhalterplatte mit pnematischen ein und Ausrücken, From machine: Homag FÜL 526,

Manufacturer: Homag, Spare part from machine: Homag Kf, for left machine side: links, Number of motors: 1, Motor : Perske, kW-Leistung : 4,4, Volt/Hz : 100, Drehzahlen U/min : 5860, Pneumatically controlled: yes, Shaft dimensions L x D mm: 30, Slewable horizontally: yes, pneumatisch gesteuert : yes,

Manufacturer: Homag Doppelzerspaner mit Schutzfräsen, Spare part from machine: Homag, for left machine side: yes, Number of motors: 3, Motor : Perske, kW-Leistung : 3/4,4, Volt/Hz : 50/100, Drehzahlen U/min : 2880/5860, Siko Anzeige : yes, Pneumatically controlled: yes/mit Revolver, Slewable horizontal 3: yes, FREE TEXT: Nur Ständer ohne Motore,

Manufacturer: Homag, Type: KAL 310, Year: 2004, Control: NC 21, Software: Homag, Min-max edge material mm: 0,5-3, Min.-max. workpiece length in mm: 150-3000, Min.-max. workpiece height in mm: 10-55, Min-max feed m/min: 24, Axis control: yes, Premilling: yes, Fine milling: yes, Application of separation agent: yes, IR zone: yes, Power per lamp: 400 Watt, Coil magazine: einfach, Strip magazin: yes, Min.-max. batten magazine mm: yes, Mitre stations: yes, Bevel milling: yes, Radius milling axis adjustment: lyes, Corner tracing type: FK 11, 2 motors: 2, Radius scraper: yes , Scraper with axis adjustment: yes, Flat scraper: yes, Spraying system 2: yes, Cleaning nozzles: yes, Bonding part EVA: yes, Pre-smelting Kg/Hr: yes, Buffing unit: yes, Top pressure belt/roller: Band, Separation agent setup: yes, Workpiece support: yes, Machine lenght mm: ca.9,5, Noise enclosure: yes, Return type: Bargsted ...

Manufacturer: Homag, Spare part from machine: Homag Fräsständer ohne Motore, for left machine side: Linke und rechte Seite, Pneumatically controlled: yes, FREE TEXT: Nur Ständer ohne Motore/mit seitlichen Schwalbeschwanzführungen,

Manufacturer: Kraft-Homag-Viet, Beabeitung: Rohlinge Kaliberieren-Formatieren-<CRLF>Fälzen und Kaliberieren, Herstellung von: Innentüren, Work piece width min-max mm: 1300 X 2200, Min.-max. workpiece height in mm: 10-60, Min.-max. workpiece length in mm: 50-2200, Manufacturer1: Bargstedt, Machine type1: Beschickungsanlage doppelseitig, Year of manufacture1: ca 2000, Manufacturer2: Viet Kalibrieranlage, Machine type2: 4 Aggregate Walze/Schuh, Year of manufacture2: ca.1998, Manufacturer3: Homag Doppelendprofiler, Machine type3: Längsprofilerer, Year of manufacture3: Überholt 2004,

Manufacturer: Homag, Type: Schwabbelaggregate, Year: 1996, Ersatzteil aus Maschine: Homag KF, für Maschinenseite links: yes, für Maschinenseite rechts: yes, Polieraggregat: yes, Oszilierend : yes, Motorenanzahl: 2, Bürstendurchmesser mm: 150, Bürstenbreite mm: 30, Kw output: 0,25, Volt/Hz: 30/50, Drehzahlen U/min: 2850, pneumatisch ansteuerbar: yes, Bürstendurchmesser mm: 150, Bürstenbreite mm: 30, Kw output: 0,25, Volt/Hz: 30/50, Drehzahlen U/min: 2850, pneumatisch ansteuerbar: yes, Year :1996

Manufacturer: Homag Postforming, Type: VFR10/22, Year: 1997, Control: Homatic/NC 16, Software: Homag, Finished product: Türzargen/Verkleidungen, Indirekt Postforming: yes, Work piece width min-max mm: 60-1000, Min.-max. workpiece length in mm: 800-2500, Min.-max. workpiece height in mm: 16-28, Workpiece protrusion mm: 55-30, Profilarten : L-Profil/U-Profil, Postformig Fräsaggregate Stück/kW: 2 X 1 kw, Universalfräsaggregat Stück/kW: 2 X 4 kw, Leimauftrag für Profile mm: U-105, Düsensystem: yes, Furnierbefeuchtung: yes, Heiz und Ablüftstation: yes, Profildruckstrecke: yes, Fräsaggregat : yes, Fräsaggregat U-Profil/Nuten: yes, Year :1997

Manufacturer: Homag Zerspaneraggregat, Ersatzteil aus Maschine: Homag KF 62, für Maschinenseite rechts: yes, Motorenanzahl: 2, kW-Leistung : 3,0/4,4, Volt/Hz : 380/100, Drehzahlen U/min : 2880/4400,

Manufacturer: Homag Kantenfräsgerät, Ersatzteil aus Maschine: Homag KF 62, für Maschinenseite rechts: yes, Motorenanzahl: 2, kW-Leistung : 0,55, Volt/Hz : 380/165, Drehzahlen U/min : 12000, Siko Anzeige : no, Horizontal Rollentastung : yes, Vertikale Rollentastung: yes, pneumatisch ansteuerbar: no, Schwenkbar vertikal: yes,
