Category: 103 milling machines
Latest update: 12.07.2023 add to watchlist
approved
dealer
item-No.: 6130511
New in: 1987

used

check Seller: FORMEX SK s.r.o.
Location: Land-sk
Price: 3.000 € add to watchlist

Main drive - spindle motor at 2450 RPM power - 4,5 kW spindle speed within four gears - infinitely variable speed range 20-4000, tool holder horizontal and vertical ISO 40 tool CLAMPING hydromechanisch 1200 daN, Quill stroke vertical fur 80 mm feed drive - single DC motors 1-2000 mm / min feed force in all axes each axis 5400 N, rapid traverse in all axes 5 m / mon workspace - along x axis 500 mm, cross y axis 360 mm, vertical z-axis 400 mm measurement - measurement of X, Y, Z - direct, resolution 0.001 mm, input gauge 0.001 mm, display step 0.005 mm, resolution 0.001 mm table AUFSPANNFLaeCHEN of rigid 4.Achse angle table 800 x 390 mm number and distance of T-grooves, wide T-slots 6/63/14 h7 NC rotary table 30 swivel 4.Achse - diameter. 380 mm control train control HEIDENHAIN TNC 115 / TNC 355 - screen screen - control SIEMENS 3 M4 810 M Kuhl installation - lubrication coolant - rinsing  ...

Category: 101 boring mills and machining centers
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 157047201

used

check Seller: Muller Machines SA
Location: Land-ch

add to watchlist

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Number of pallets: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN 407 / 415 Technical data Table length: 850 mm Table width: 440 mm Number of T-channels: 6 T-channel width: 14H7 mm Distance of the T-slots: 63 mm Longitudinal travel (X-axis): 600 mm Transversal travel (y axis): 450 mm Vertical travel (z axis): 400 mm c axis resolution max.: 0.001 ° Table load max.: 500 kg Taper in spindle: 40 ISO Spindle speeds: stepless from: 20 rpm up to: 4500 rpm Spindle nose SK: 40 Feeds (X, Y, Z): 1 - 10000 mm/min Feeds: stepless Rapid traverse:: 10 m/min Vertical quill travel: 75 mm Voltage 50 Hz 3x: 380 Volt Milling spindle motor: 8 kW Total power required: 15 kW Machine´s weight about: 2700 kg Overall dimensions machine: Length: 3100 mm Width: 2850 mm Height: 1930 mm Various  ...

Category: 101 boring mills and machining centers
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 157047208

used

check Seller: Muller Machines SA
Location: Land-ch

add to watchlist

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 430 Operating hours: 5751 Technical data Number of axis total: 3 Table length: 1000 mm Table width: 560 mm Longitudinal travel (X-axis): 800 mm Transversal travel (y axis): 600 mm Vertical travel (z axis): 500 mm W axis Dimension of the workpice: Length: 560 mm Width: 560 mm Height: 500 mm Diameter: 1000 mm Table load max.: 1000 kg Tool changer: Number of tools: 30 Tool lenght: 300 mm Max. tool-weight: 8 kg Average chip-to-chip time: 5.5 sec Spindle nose SK: 40 Distance spindle nose to table: 100 - 500 mm Spindle speeds: up to: 15000 rpm Feed range: 1 - 30000 mm/min Rapid traverse:: 35 m/min Air connect: 6 bar Voltage 50 Hz 3x: 400 Volt Spindle motor: 15 kW Total power required: 31 kVA Time under power: ...

Category: 101 boring mills and machining centers
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 157817257

used

check Seller: Muller Machines SA
Location: Land-ch

add to watchlist

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Positions APC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 430 Technical data Number of axis total: 5 Rotary table:diameter: 280 mm Table load max.: 200 kg Longitudinal travel (X-axis): 600 mm Transversal travel (y-axis): 450 mm Vertical travel (z axis): 450 mm Dimension of the workpice: Height: 215 mm Diameter: 280 mm B axis swivelling range: + / - 115 ° C axis Tool changer: Number of tools: 30 Average chip-to-chip time: 5.5 sec Spindle nose: HSK: 40 Spindle speeds: stepless from: 20 rpm up to: 36000 rpm Feed range: 1 - 30000 mm/min Rapid traverse:: 35 m/min Measurement system: Resolution: 0.1 µm Input resolution: 0.1 µm Display step: 0.1 µm Air connect: 6 bar Voltage 50 Hz 3x: 400 Volt Total power required: 22 kVA Noise level: 78 dB (A) Machine´s weight abo ...

Category: 103 milling machines
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 158218885

used

check Seller: Mach4metal
Location: Land-nl

add to watchlist

Table length: 1000 mm Table width: 500 mm Longitudinal X: 800 mm Cross Y: 500 mm Vertical Z: 400 mm CNC Brand: Siemens CNC Model: Sprint System 3 MAKE    Hermle TYPE      UWF 1000 YEAR     1987 ? SPECIFICATIONS X - Travel   800 mm Y - Travel   500 mm Z - Travel    400 mm bed / plano / portal / moving column Universal toolroom milling Controll       Siemens Sprint system  3 Table Length x Width       1000 x 500 mm Table load in kG      300 Kg Spindle Taper   ISO 40 kW power on spindle   6.9 kW Spindle speeds / ranges      3150 Rpm Number off controlled axis       3 + 1 = 4e axis DIMENSIONS Length    1890 mm Width      1750 mm Height  &nbs ...

Category: 101 boring mills and machining centers
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 158218894

used

check Seller: Mach4metal
Location: Land-nl

add to watchlist

Table length: 700 mm Table width: 700 mm Longitudinal X: 850 mm Cross Y: 700 mm Vertical Z: 500 mm Positions ATC: 75   Positions APC: 0   CNC Brand: Siemens CNC Model: 840 D MAKE   Hermle germany TYPE    C  40U + PW 160 YEAR   2004 SPECIFICATIONS X - Travel   850 mm Y - Travel   700 mm Z - Travel    500 mm Controll   Siemens 840D Table Length x Width   700m x 700 mm Table load in kG    800 Kg Spindle Taper    HSK 63 kW power on spindle    15 kW Spindle speeds / ranges    18000 Rpm ATC tool changer  75 ( 32 + 43) Coolant true spindle / Bar   40 Bar Number off controlled axis   5 DIMENSIONS Length    10000 mm Width      6000 mm Height     3400 mm

Category: 101 boring mills and machining centers
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 158218896

used

check Seller: Mach4metal
Location: Land-nl

add to watchlist

Table length: 630 mm Table width: 630 mm Longitudinal X: 650 mm Cross Y: 600 mm Vertical Z: 500 mm Positions ATC: 75   Positions APC: 0   CNC Brand: Siemens CNC Model: 840 D MAKE   Hermle Germany TYPE     C30U Dynamic YEAR    2008 SPECIFICATIONS X - Travel   650 mm Y - Travel   600 mm Z - Travel    500 mm Controll    Siemens 840D Table Length x Width   630 mm Table load in kG   800 Kg Spindle Taper   HSK 63 Spindle speeds / ranges  28000 Rpm ATC tool changer   75 ( 32 + 43) Coolant true spindle / Bar    40 Bar Number off controlled axis  5 DIMENSIONS Length   4100 mm Width     3000 mm Height    3200 mm

Category: 101 boring mills and machining centers
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 158218897

used

check Seller: Mach4metal
Location: Land-nl

add to watchlist

Table length: 630 mm Table width: 630 mm Longitudinal X: 650 mm Cross Y: 600 mm Vertical Z: 500 mm Positions ATC: 75   Positions APC: 0   CNC Brand: Siemens CNC Model: 840 D MAKE  Hermle Germany TYPE    C 30 U YEAR   2010 SPECIFICATIONS X - Travel   650 mm Y - Travel   600 mm Z - Travel   500 mm Controll    Siemens 840D Table Length x Width   630 mm Table load in kG   800 Kg Spindle Taper   HSK 63 Spindle speeds / ranges   18000 Rpm ATC tool changer   75 ( 32 + 43) Coolant true spindle / Bar   40 Bar Number off controlled axis   5 DIMENSIONS Length   4100 mm Width    3000 mm Height    3200 mm

Category: 101 boring mills and machining centers
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 158218898

used

check Seller: Mach4metal
Location: Land-nl

add to watchlist

Table length: 630 mm Table width: 630 mm Longitudinal X: 650 mm Cross Y: 600 mm Vertical Z: 500 mm Positions ATC: 75   Positions APC: 0   CNC Brand: Siemens CNC Model: 840 D MAKE   Hermle Germany TYPE    C 30 U Dynamic YEAR    2011 SPECIFICATIONS X - Travel   650 mm Y - Travel   600 mm Z - Travel   500 mm Controll  Siemens 840D Table Length x Width   630 mm Table load in kG   800 Kg Spindle Taper   HSK 63 Spindle speeds / ranges   28000 Rpm ATC tool changer   75 ( 32 + 43) Coolant true spindle / Bar   40 Bar Number off controlled axis   5 DIMENSIONS Length   4200 mm Width    3000 mm Height   3200 mm

Category: 101 boring mills and machining centers
Latest update: 10.01.2023 add to watchlist
approved
dealer
item-No.: 159158790

used

check Seller: Mach4metal
Location: Land-nl

add to watchlist

Table length: 1000 mm Table width: 560 mm Longitudinal X: 800 mm Cross Y: 600 mm Vertical Z: 500 mm Positions ATC: 30   Positions APC: 0   CNC Brand: Siemens CNC Model: SIEMENS 840D X - Travel:               800mm Y - Travel:               600mm Z - Travel:               500mm Table Length:             1000mm Table Width:              560mm Table load:               1500 Feed rate X-Axis:         30000mm/min. Feed rate Y-Axis:         30000mm/min. Feed rate Z-Axis:         30000mm/min. Spindle Taper:            Sk40ISO/Bt/Mk Power on spindle:&nbs ...

Category: 103 milling machines / CNC Milling Machines
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 160095356
New in: 1990

used

check Seller: Hans-Jürgen Geiger Maschinen-Vertrieb GmbH
Location: Metzingen Land-de

add to watchlist

x-travel: 400 mm y-travel: 330 mm z-travel: 350 mm total power requirement: 6,3 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 736 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Category: 101 boring mills and machining centers
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 161146141

used

Location: Land-nl

add to watchlist

Table length: 1000 mm Table width: 560 mm Longitudinal X: 800 mm Cross Y: 600 mm Vertical Z: 500 mm Positions ATC: 30   Positions APC: 0   CNC Brand: Siemens CNC Model: SIEMENS 840D X - Travel:               800mm Y - Travel:               600mm Z - Travel:               500mm Table Length:             1000mm Table Width:              560mm Table load:               1500 Feed rate X-Axis:         30000mm/min. Feed rate Y-Axis:         30000mm/min. Feed rate Z-Axis:         30000mm/min. Spindle Taper:            Sk40ISO/Bt/Mk Power on spindle:&nbs ...

Category: 101 boring mills and machining centers
Latest update: 15.07.2024 add to watchlist
approved
dealer
item-No.: 125936662
New in: 1989

used

check Seller: Schweizer Service
Location: Land-de

add to watchlist

With CNC control, HEIDENHAIN, Type: TNC 155, measuring taster Separate control cabinet: 1260 x 500 x 1700 mm Travel distances 700 x 550 x 550mm Table area 1000 x 490 mm Accessories: Treatment / Cooling system / tool shots The machine stored since 2013. At the time of storage, the machine was fully functional.; ready for use

Category: 103 milling machines / CNC Milling Machines
Latest update: 20.02.2024 add to watchlist
approved
dealer
item-No.: 131250799
New in: 1985

used

check Seller: Alfred Feldmann Werkzeugmaschinen
Location: Land-de
Price: 6.900 € add to watchlist

X: 500 mm Y: 360 mm Z: 400 mm Speed range: 40-2000 RPM Spindle retainer: SK 40 DIN2079 Control: HEIDENHAIN TNC 155 Total power: 6 kW Machine weight: 2000 kg Dimensions (W x D x H): 2.8 x 2.9 x 1.9 m Condition: good, ready to use

Category: 103 milling machines / CNC Universal Milling Machines
Latest update: 25.03.2024 add to watchlist
approved
dealer
item-No.: 138845387
New in: 1988

used

check Seller: SOCIETE FIMOTEC
Location: 67500 HAGUENAU, 20 RUE AMPERE Land-fr
Price: 8.000 € add to watchlist

Bearing number 1105-02690 Machine type Milling machine - Universal Make HERMLE Type UWF 1000 Built in 1988 Control type CNC Storage location FRANCE Country of origin Germany Delivery time SOFORT Freight base EXW Technical details x-way 700 mm y-way 630 mm z-way 500 mm Control heidenhain 355 Tool holder SK 40 (DIN 69871) Table clamping area: 1000 x 490 mm Spindle speed Gear stage 1 25 - 400 rpm. Spindle speed Gear stage 2 401 - 1260 rpm Spindle speed Gear stage 3 1261 - 4200 rpm Feed 5 m/min Rapid speed 10 m/min Swivel of the milling head + / - 90 ° Pinole diameter 110 mm Pinole stroke 95 mm Total power requirement 18 kW Machine weight approx. 5 t Information with full cabin coolant device Sale takes place without clamping equipment approx. 8500h switch-on hours

Category: 103 milling machines / CNC Milling Machines
Latest update: 16.01.2024 add to watchlist
approved
dealer
item-No.: 142002418
New in: 1993

used

check Seller: Jaschek Industrieservice GmbH
Location: 14656 Brieselang, Gewerbering 27 Land-de

add to watchlist

x-400,y-330,z-350,angle table 630x335,SK 40, 40-6,000 rpm,measuring probe

Category: 103 milling machines / CNC Milling Machines
Latest update: 09.07.2024 add to watchlist
approved
dealer
item-No.: 151402870
New in: 1990

used

check Seller: Maschinenhandel-Reuss GmbH & Co. KG
Location: Land-de

add to watchlist

DATA ON THE MACHINE Machine type: CNC milling machine Manufacturer: HERMLE Model: UWF1001H Built: 1991 Condition: used Location Warstein , Germany Reference M-HER-0221 Description We offer you a used CNC milling machine from manufacturer Hermle. Control Heidenhain TNC 407/415 Monitor new x-path 700 mm y-path 550 mm z-way 500 mm Table clamping area 650 x 395 mm Spindle speeds - infinitely 20- 4200 rpm Spindle holder ISO 40 DIN 2079 Pinole stroke vertical 95 mm Drive spindle motor 12 kw Machine weight approx. 3.8 t Space requirements approx. 5 x 4.6 x 2.5 m Electrics 400 Volt Coolant device Fixed angle table 1000 x 490 mm Vertical milling head swivel. +/- Full-protection cabin Separate control cabinet (absolutely clean and uncrafted) electronic handwheel Our offer is aimed at professionals who are covered in accordance with the Trade Code in accor ...

Category: 103 milling machines / CNC Milling Machines
Latest update: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158794346

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

CNC universal milling machine make HERMLE type PF 1000Machine -No: 5235 Year 1981Table size: 1000 x 315 mmLongitudinal movement X: 620/650 mmTransverse movement Y: 430/490 mmVertical movement Z: 400/420 mmSpindle mount DIN 2079: ISA 40Quill extendable: 80 mmminute / Max. Distance spindle / clamping surface: 80 - 500 mmminute / Max. Distance spindle / vertical Guide: 8 - 458 mmPivoting of the spindle head: 360 °12 spindle speeds: 45 - 2000 rpm.stepless feed rates all axes: 4 - 4500 mm / min.Drive power: 4.0 kWWeight approx: 1300 kgExternal dimensions approx. 1500 x 1200 x 2000 mmWith- CNC control Heidenhain TNC 145- Cooling device- side swing-away vertical milling headused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our o ...

Category: 101 boring mills and machining centers
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 164607635
New in: 2000

used

check Seller: Innovac GmbH
Location: Deutschland Land-de

add to watchlist

Travel X/Y/Z: 800mm/500mm/500mm, table dimensions X/Y: 1000mm/800mm, max. table load: 800kg, speed: 8000/min, tool positions: 30, tool holder: SK40, feed: 30m/min, positioning accuracy: +/-0.005mm, control: Heidenhain TNC 430, dimensions X/Y/Z: approx. 2700mm/2200mm/3000mm, weight: approx. 8000kg.

Category: 103 milling machines
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 164607807
New in: 1983

used

check Seller: Innovac GmbH
Location: Deutschland Land-de

add to watchlist

Controls: Heidenhain TNC 150, length: 3600mm, width: 3000mm, height: 1900mm, with documentation, the machine is not functional, the control has fire damage, an on-site inspection is possible.

Category: 103 milling machines
Latest update: 25.07.2024 add to watchlist
approved
dealer
item-No.: 164607810
New in: 1988

used

check Seller: Innovac GmbH
Location: Deutschland Land-de

add to watchlist

Travel X/Y/Z: 500mm/430mm/400mm, speed: 2000rpm, tool holder: SK40, quill stroke: 80mm, table dimensions X/Y: 800mm/380mm. Dimensions X/Y/Z: approx. 2000mm/2000mm/2000mm, weight: approx. 1500kg, control: Heidenhain TNC 114, documentation available. On-site inspection is possible.

Category: 103 milling machines / CNC Universal Milling Machines
Latest update: 25.03.2024 add to watchlist
approved
dealer
ankerimg
item-No.: 159722878
New in: 1988

used

check Seller: MARC
Location: 67500 HAGUENAU Land-fr

add to watchlist

Machine Details Warehouse number 1105-03692 Machine type Milling machine - Universal HERMLE brand Type fp 1000 Year of construction 1988 Control type CNC Control heidenhain 355 Storage location HAGUENAU Country of origin Germany Delivery time IMMEDIATELY Freight base EXW Technical details x-travel 700 mm y-travel 630 mm z-travel 500 mm Control heidenhain 355 Tool holder SK 40 (DIN 69871) Table clamping surface: 1000 x 490 mm Spindle speed gear stage 1 25 - 400 1/min. Spindle speed gear stage 2 401 - 1260 1/min. Spindle speed gear stage 3 1261 - 4200 1/min. Feed 5 m/min Rapid traverse 10 m/min Swivel of the milling head + / - 90 ° Pinole diameter 110 mm Pinole stroke 95 mm Total power requirement 18 kW Machine weight approx. 5 t Information with coolant device Sale without clamping devices

Category: 103 milling machines / CNC Milling Centers
Latest update: 09.10.2023 add to watchlist
approved
dealer
item-No.: 161046598
New in: 2002

used

check Seller: Industrialbay
Location: 23801 Calolziocorte Land-it

add to watchlist

:::SPECIFICATIONS::: CNC Model: Siemens Tool connection: SK 40 Spindle power: 9Kw Number of spindle revolutions: 12000 Number of tools: 30 X Shaft Stroke: 600mm Y-axis stroke: 450mm Z-axis stroke: 450mm Rapid feeds linear axes X Y Z: 35m/min Guides: roller Tilting rotary table: yes Round table type: continuous Tilting rotary table grades: + - 110° Table size: diameter 280mm Load allowed on the table: 200Kg Chip evacuator: carpet Other technical data: maximum tool diameter 80 (125) mm Chip/chip time change 5.5 sec Working feed speed 1 - 30.000 mm/min Resolution 0.001 mm :::D IMENSIONS AND WEIGHT::: Length: 3500mm Width: 3500mm Height: 2800mm Weight: 6500Kg

Category: 103 milling machines / CNC Milling Machines
Latest update: 20.03.2024 add to watchlist
approved
dealer
item-No.: 161060575
New in: 1996

used

check Seller: Kaiser- Werkzeugmaschinen
Location: 76646 Bruchsal Land-de

add to watchlist

CNC - TOOL MILLING MACHINE HERMLE UWF 902-S Control : Heidenhain 426 Travel X - axis approx. 600mm Travel Y - axis approx. 450mm Travel Z - axis approx. 500mm Speed range approx. 20 - 6300 rpm Tool holder : SK 40 Feed range approx. 1 - 10000mm/MIN Verikal /horizontal milling device Coolant device Drill quill Machine housing Soqllvbn Angle table Documentation Dimensions: L x W x H approx. 4000x2800x2400mm Weight approx. 4000kg

Category: 103 milling machines / CNC Milling Centers
Latest update: 04.01.2024 add to watchlist
approved
dealer
item-No.: 161756711
New in: 2006

used

check Seller: GINDUMAC GmbH
Location: 67663 Kaiserslautern Land-de

add to watchlist

BRAND: HERMLE YEAR: 2006 MODEL: C30U APPLICATION TYPE: MILLING LOCATION: ITALY MACHINE TYPE: MACHINING CENTERS (VERTICAL) AVAILABILITY: 01 10 2023 CONTROL UNIT BRAND: HEIDENHAIN GINDUMAC ID: IT-MIL-HER-2006-00001 Technical Information CONTROL UNIT BRAND: HEIDENHAIN MODEL: TC 530 MAIN DRIVE SPINDLE MOTOR POWER: 15 KW SPINDLE BORE: 18000 NUMBER OF AXIS: 5 MOVEMENT X-AXIS MOVEMENT: 650 MM Y-AXIS MOVEMENT: 600 MM Z-AXIS MOVEMENT: 500 MM C-AXIS MOVEMENT: 360º TABLE ROTATION MM MEDIA CHIP CONVEYOR: YES Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - MAXIMUM TOOL CAPACITY 32 - SPINDLE CONNECTION (SPINDLE) DIN 69871 - RENISHAW SYSTEM PREDISPOSITION - AIR BLOW THROUGH DRY MACHINING SPINDLE: YES - 5 AXIS CONTINUOUS PACKAGE: YES
