used
This HELLER MCP-H 250 Horizontal Machining Centre was manufactured in 1999 in Germany. It is equipped with a HELLER Unipro 90 control unit and a tool taper SK50. The pallet size is 630 x 500 mm and the spindle speed range 45-6000 rpm. It has a NC rotary table, a pallet changing device and a tool magazin (chain) with 52 places. As additional equipment it comes with measuring device for BLUM TC 50, linear scales Heidenhain, BKW cooling unit for spindle cooling, Knoll coolant system with vacuum rotary filter and sludge discharge, Knoll chip conveyor, BKW cooling unit for cooling lubricant system, work area flushing and 2 pallets. The machine is in good condition for its age. Annual maintenance has been carried out over the entire service life. In 2018, the machine was retrofitted with the latest interface/receiver for the Blum TC 50. It is still under production and can be inspected at any ...
used
This 4-axis Heller MCi16 horizontal machining center, constructed in 2006, integrates advanced features for precision and efficiency. It boasts an HSK63 tool holder with 80 places, a high spindle speed of 10000, and a Siemens 840D control system that provides exacting operational command. The addition of an IKZ system at 63bar and a 2 compartment pallet changer significantly enhances productivity and reduces setup times. Consider the Heller MC16 machine we have for sale. For more information about this horizontal machining center, please reach out to us.
used
Manufacturer: HELLER Type MCA- U 150 Year of construction 1996/2008 Control UniPro 90 Machine weight approx. 10,000 kg Tool holder SK 40 x-travel 600 mm y-travel 500 mm z-travel 600 mm Speed range 8000 1/min Chip conveyor: yes Table size 500x400 mm Number of tools in the magazine 60 pl.
used
HELLER MC16 4-axis horizontal milling center YOM 2000 4-Axis SIEMENS CNC Path Control, Model SINUMERIC 840 D Longitudinal X-axis 630 mm Vertical Y-axis 630 mm Cross Z-axis 630 mm NC rotary table Tilting B axis 360.000 x 0,001 ° Pallet size 400 x 500 mm Max. workpiece size Ø x height 720 x 800 mm Max. workpiece weight 500 kg Pallet exchange time 9 sec. Turning Speed B axis 40 rpm/min Tool holder cone HSK 63 Tool size Ø x lg. x weight 150 x 227 x 12 mm/kg Spindle speeds, infinitely variable 45 – 24,000 rpm Feeds / quick feeds XYZ: 1 – 60,000 mm/min Feed force 10.000 nm Spindel torque 48/72 nm Spindle drive 30 kW Total electrical load, approx. 60 kW - 400 V - 50 Hz Total weight 12.5 tons Accessories / Special Features : -Separate standing 80 position Rack-Type tool Magazine with tool placement door and double Swivel gripper, own SIEMENS PC-Control with screen To ...
used
Key data: 630 mm, 630 mm, 630 mm
Heller MCI 16 Horizontal Machining Center, Built in 2006, Control Siemens 840 D, Travel X/Y/Z 630/630/630 mm, Tool changer 80 times, Tool holder HSK 63, Spindle speed up to 10,000 rpm, 2-fold pallet 400 x 500 mm, Rotary table 0.001°, IKZ 63 bar, Conveyor Machine weight 11,000 kg,
used
This HELLER MC25 Uni-Pro Horizontal Machining center was manufactured in the year 1998 in Germany. It is equipped with an UniPro CNC 90 control unit.
used
This 4-axis HELLER MCH 350 was manufactured in 2006, featuring a Siemens 840D PL control system and a robust spindle capable of 7,000 rpm. It includes a HSK 100 tool clamping system and a large magazine with 234 slots. The machine offers a substantial working area of 1250 x 1000 x 1000 mm and a pallet size of 800 x 800 mm. For more information about this machining centre, please reach out to us.
used
2007 Heller MCH250 Horizontal machining center available in CW20 2025 Machine center Control Siemens 840D Powerline Voltage 400V Frequency 50Hz Rated current 123 A Gear spindle with 2 stages Speed max. 6,000 min-1 Power max. 40 kW (100% ED) / 60 kW (40% ED) Torque max. 1146 Nm (100% ED) / 764 Nm (40% ED) Travel 800 / 800 / 800mm XYZ - B-axis pitch 1° Rapid traverse 50 m/min XYZ HSK A100 tool holder Tool magazine 405 places Tool dimensions ø280 / ø420 (bridge tool) / max. 25 kg / max. length 600 mm Pallet size 630 x 630mm Find more here - / Contact us at -
used
2004 Heller MCi 16 Construction year: 09.2004 steering: Siemens 840D Tool management: MTV Motor spindle power 40% ED: 30 kW Spider: 45 – 10,000 1/min (Replaced May 2015) Tool holder: HSK-A 63 DIN 69893 my IKZ Magazine places: 80 chain Travel X, Y, Z: 630 x 630 x 630mm Workpiece interference circuit: Ø 720mm Tension: 400 V / 50Hz/100A (fuse 100A) coolant tank: 1200 Liter Tool breakage control: Yes (SBBK) High pressure system: 70 Bar (Knoll) Scraper belt conveyor: Yes (Knoll) Tool changer : Not like. 2014 Tool code chip: AND (Balluff) Tool breakage control: Yes (SBBK) Z-KGT + Z-guides: Repair 2018+2020 Find more here - / Contact us at -
used
Well maintained CNC machine. No maintenance backlog. needed CNC machining center, horizontal needed Manufacturer: HELLER Type: MC 25 Year of construction: 2002 Control: CNC - path control including color flat screen SIEMENS SINUMERIK 840 D Switch-on time: 1 – 1 ½ shift, exclusively aluminum processing TECHNICAL SPECIFICATIONS Working area x-axis (longitudinal) 800 mm y-axis (vertical) 800 mm z-axis (transverse) 800 mm rotary table Pitch (B axis) 360,000 x 0.001° Indexing accuracy Tp (VDI/DGQ 3441) 10 angle s Clamping weight max. 800 daN Tangential moment (clamped) max. 3500 N, Tilting moment max. 8000 Nm Swiveling time 180° 2.2 s Round milling torque max. 800 Nm pallet changing device Number of pallets 2 Pallet size 500 x 630 mm Pallet change time (at 500/800 daN) 13/15 sec. Pallet load max. 800 daN Workpiece dimensions ...
used
X-travel: 630mm, y-travel: 630mm, z-travel: 630mm, B-travel: NC + 2 pallet changers, controls: Heller uni-Pro CNC 90, the machine needs to be overhauled, a power module is defective, therefore Z-axis does not move, reference point approach not possible, with documentation.
used
Control uni-Pro CNC 90 Travel X/Y/Z 800/800/710 mm Speed 4500 1/min Tool magazine for 52+120 tools SK 50 Indexing table 1° 4-fold pallet changer 500x630 mm Conveyor
used
x-travel:1000 mm y-travel:800 mm z-travel:1100 mm weight of the machine ca.:15,2 t Tool bore:SK50 Tool taper:HSK-A 100 turning speed range:45-6.000 U/min size of pallet:630x800 mm change time of pallets:21 sec Mechanical processing of cylinder heads and cylinder crankcases Machines have been in single-shift operation since 2013 Service and maintenance intervals were adhered to
used
x-travel:450 mm y-travel:450 mm z-travel:450 mm weight of the machine ca.:14 t size of pallet:320 x 320 mm Double spindle 4-axis machining center Horizontal 4 machine plates Renishaw probe Control Siemens Sinumerik 840D Working space (X / Y / Z): 450x450x450 mm Load pallet / table max .: 300 kg Acceleration: 10 m / s² Rapid traverse: 60 m / min Pallet size: 320 x 320 mm Chip-to-chip time: 2.6 s Workpiece height max .: 700 mm Tool holder: HSK 63 Tool places: 2x 60 Tool spindle: 10,000 rpm, 95 Nm Speed ??increase to 18,000 rpm Infrared receiver for probe, Make Renishaw Vaf72a0p Tool magazine with 60 places Control panel on the workstation Control panel on the tool installation site Workpiece positioning stations can be rotated manually with hydraulic workpiece clamping 60 bar Pneumatic support control on the workstation Automatic swing gate Extended coolant layer 70 bar / 1500I / VF 250 C ...
used
CONTROLS CNC controls SIEMENS 840 D WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 630 mm Y-axis travel: 630 mm Z-axis travel: 630 mm SPINDLE / HEAD spindle revolutions (min): 45 /min spindle revolutions (max): 10000 /min tool fixture: HSK A63 drive power S6 40%: 30 kW TOOL MAGAZINE magazin type: chain magazine number of positions: 80 AUTOMATIC WORKLOAD EQUIPMENT store type: table changer number of store positions: 2 number of pallets: 2 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 6200 mm space requirements -front/back-: 3400 mm total height ...
used
Travel X/Y/Z: 1600mm/1500mm/1250mm, table dimensions X/Y: 800mm/1000mm, round pallet storage: 4+1 with clamping hydraulics, speed: 6000rpm, feed X/Y/Z: 40000mm/min, rapid traverse X/Y/Z: 40000mm/min, max. workpiece weight: 2500kg, tool magazine: 405 places/SK50/set-up station. Including 70bar high-pressure coolant system, emulsion mist extraction system. On-site inspection is possible. Available from January 2025.
Qty. 1 Second-hand rail hard metal saw with drilling unit Mfc.: Heller Type: TEK001-73-37 Saw carriage: 610 ? 710 mm Cutting speed ? 6 stages: 63-200 m/min. Cutting area: rail height up to: 200 mm rail width up to: 200 mm Feeding speed: 50 ? 1250 mm/min. Power: 50 kW Drilling unit Qty. 3 Drilling spindles Drill diameter: 12 ? 40 mm z-stroke: 630 mm z-drill stroke (adj.): 250 mm Tool changing stroke (adj.): 380 mm Drill spindle diameter: 60 mm Min. distance from the end of the rail: 33 mm Drill spindle distance - spindle 1-3: min. 228 mm max. 600 mm Drill spindle distance ? spindle 1-2: min. 114 mm max. 486 mm Drill feeding speed: 40 ? 200 mm/min. Motor power: 30 kW, 1420 RPM Revolution range: Qty. 9 225 ? 280 ? 350 ? 450 ? 560 ? 710 ? 900 ? 1120 ? 1400 RPM
used
Radial drilling machine make HELLER type RB 50/1250Serial -No: 29551 built in 1961Technical specifications:Drilling capacity in steel: 50 mmDrilling capacity in GG: 60 mm12 spindle speeds: 33 - 1500 rpm.Spindle mount: MK 512 automatic feeds: 0.08 - 1.5 mm/revQuill stroke: 301 mmProjection: 1250 mmColumn diameter: 380 mmDrive power: 4 kWDimensions approx.: 2200 x 2300 x 2780/3110 mmWeight approx.: 4250 kgused, in real good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
We offer several machine pallets for Steinel and Heller machines!
used
BRAND: HELLER YEAR: 2002 MODEL: MC 16 APPLICATION TYPE: MILLING LOCATION: SLOVENIA MACHINE TYPE: MACHINING CENTERS (HORIZONTAL) AVAILABILITY: IMMEDIATELY Technical Information CONTROL UNIT BRAND: SIEMENS MODEL: 840 PL (POWER LINE) MAIN DRIVE SPINDLE SPEED RANGE: 45 – 12000 1/MIN SPINDLE MOTOR POWER: 40 KW NUMBER OF AXIS: 4 MOVEMENT X-AXIS MOVEMENT: 630 MM Y-AXIS MOVEMENT: 630 MM Z-AXIS MOVEMENT: 630 MM WORKPIECE WORKPIECE DRM OVER BED: 720 MM WORKPIECE DRM OVER SUPPORT: 800 MM WORKPIECE WEIGHT: 500 KG TABLE OUTER LENGTH: 400 MM OUTER WIDTH: 500 MM TOOLS MAX TOOL DIAMETER: 72/140 MM MAX TOOL LENGTH: 320 X 12 MM TYPE OF TOOL HOLDER: HSK 63 MEDIA MAIN ELECTRONIC CONNECTION: 400 V/ 50 HZ CHIP CONVEYOR: YES Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - PALLET CHANGING TIME 8 SEC. - PALLET CHANGER WITH DIVIDER S ...
used
BRAND: HELLER YEAR: 1999 MODEL: MC 16 APPLICATION TYPE: MILLING LOCATION: AUSTRIA MACHINE TYPE: MACHINING CENTERS (HORIZONTAL) AVAILABILITY: IMMEDIATELY Technical Information CONTROL UNIT BRAND: UNIPRO MODEL: CNC 90 MAIN DRIVE SPINDLE SPEED RANGE: 16000 1/MIN Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - HSK 63 TOOL CLAMPING SYSTEM - (OPTIONS) CHAIN / 80 - (CONTROL PANEL AT TOOL LOADING STATION) - ROTARY TABLE 360,000° X 0. 001° - COOLANT SYSTEM KNOLL,VRF 250, IKZ 80 BAR - WORKING AREA XYZ (MM) 630 / 630 / 630 - PALLET SIZE (MM) 400 X 500 - MECHANICAL WORKPIECE CLAMPING - ADDITIONAL OPTIONS, SPECIAL FEATURES DRILL BREAKAGE CONTROL (SBBK);
used
BRAND: HELLER YEAR: 1998 MODEL: MC 16 APPLICATION TYPE: MILLING LOCATION: AUSTRIA MACHINE TYPE: MACHINING CENTERS (HORIZONTAL) AVAILABILITY: IMMEDIATELY Technical Information CONTROL UNIT BRAND: UNIPRO MODEL: CNC 90 MAIN DRIVE NUMBER OF AXIS: 16000 MOVEMENT X-AXIS MOVEMENT: 630 MM Y-AXIS MOVEMENT: 630 MM Z-AXIS MOVEMENT: 630 MM TOOLS TYPE OF TOOL HOLDER: HSK 63 Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - MAGAZINE / PLACES - CHAIN / 160 - (CONTROL PANEL AT TOOL LOADING STATION) - ROTARY TABLE 360,000° X 0. 001° - COOLANT SYSTEM KNOLL,VRF 250, IKZ 80 BAR - PALLET SIZE (MM) 400 X 500 - MECHANICAL WORKPIECE CLAMPING - ADDITIONAL OPTIONS, SPECIAL FEATURES DRILL BREAKAGE CONTROL (SBBK)
used
Inv. Num. : 7288 Type: FTC 1000 Producer: Heller Generated:- Parameters: In good technical condition.
used
This 4-axis HELLER H2000 horizontal machining center was manufactured in 2014. Equipped with a Siemens 840D solution line control, it features a robust spindle capable of 10,000 rpm and 38 kW power. It includes an NC rotary table and a tool magazine with 80 slots for HSK 63 holders. Additional features include an infrared receiver with a Renishaw measuring probe and a scraper belt conveyor. For more information about this horizontal machining center, please reach out to us.
SAW CARRIAGE DISTANCE: 610-710 MM, RANGE OF CUTTING: HEIGHT: 200 MM, WIDTH: 200 MM, DRILL DIA.: 12 - 40 MM; STROKE: 630 MM;
