usato
Dati tecnici: - max. premendo la forza 40 t - max. corsa 500 mm - Velocità di sollevamento 0 - 40 mm/s - Ritorno 0 - 200 m/min - Altezza di installazione 750 mm - Estensione al pestello medio 360 mm - Impatto che dura 440 x 360 mm - Perni di posa dell'impatto 40 mm - Dimensioni del tavolo 630 x 500 mm - Foro da tavolo / sfondamento 200 mm - Altezza del tavolo sopra corridoio 710 mm - Riempimento dell'olio circa. 300 ltr - Unità 400 V / 4 kW - Requisito di spazio circa. W 1200 x H 2800 x D 1600 mm - Peso circa. 2500 kg
usato
PRESS DESIGN drive system: hydraulic frame design: C-frame, single sided table cushion: yes PRESS FORCES total force (nominal): 160 to PRESS TABLE table surface (left-right): 1250 mm table surface (front-back): 600 mm thickness of bolster plate: 100 mm SLIDE table surface (left-right): 750 mm table surface (front-back): 450 mm stroke: 500 mm SLIDE (HYDR. PRESS) approximation velocity max.: 200 mm/s return velocity max.: 250 mm/s TOOL ASSEMBLY DIMENSIONS distance table - slide max.: 800 mm throat (C-frame): 360 mm ELECTRICAL SPECIFICATIONS total power consumption: 20.5 kW mains voltage: 380 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 1250 mm ...
usato
pressure:40 t throat:360 mm stroke:500 mm distance table/ram, max. stroke up, adjustment up:660 / 1000 mm table surface area:630 x 500 mm hole in the table:200 mm table height over floor:1060 / 720 mm ram surface:450 x 360 mm speed down:60 mm/s speed up:300 mm/s power requirement:7,5 kW weight:2,75 t dimensions (WxDxH):1,0 x 1,8 x 3,05 m additional plate in table:height approx. 340 mm
usato
pressure:25 t throat:355 mm stroke:500 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:500 x 500 mm hole in the table:180 mm table height over floor:700 mm ram surface:250 x 250 mm power requirement:7,5 kW weight:2,1 t dimensions (WxDxH):1,45 x 0,9 x 2,55 m
usato
pressure:100 t throat:360 mm stroke:500 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:900 x 560 mm table height over floor:710 mm ram surface:630 x 400 mm speed down:200 mm/s speed up:200 mm/s power requirement:17,0 kW weight:5,0 t Dimensions (WxDxH):1,2 x 1,9 x 3,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2
usato
table length:2000 mm table width:600 mm table height:300 mm mounting surface:700 x 600 mm centre distance:1200 mm centre height:160 mm Dimensions (WxDxH):2,0 x 0,6 x 0,3 m
usato
pressione: 63 t gola: 315 mm corsa: 16 - 125 mm max. distanza tavola - pistone: 417 mm regolazione del pistone: 70 mm numero di corse: 80 Hub/min superficie del tavolo: 800 x 630 mm superficie del pistone: 500 x 400 mm potenza totale richiesta: 6 kW peso della macchina ca.: 5 t dimensioni della macchina ca.: 1,5 x 2,2 x 2,75 m
usato
pressure: 63 t throat: 315 mm stroke: 8 - 120 mm table surface area: 630 x 800 mm dayligth: 560 mm ram adjustment: 70 mm no. of strokes: 56/90 Hub/min ram surface: 400 x 500 mm total power requirement: 6 kW weight of the machine ca.: 5,5 t dimensions of the machine ca.: 1,5 x 2,2 x 2,75 m The following work is/was carried out on the machine. partial overhaul: - Machine is completely disassembled, checked - Machine is repainted - new press safety valve - New separate control cabinet with touch panel and ABB safety control - new shaft bearing - A current UVV test and braking time measurement is carried out before delivery The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
pressione: 400 t corsa: 600 mm luce diurna: 900 mm superficie di serraggio (laterale): 2500x1000 mm superficie: 2000x1500 mm foro nella tavola: 1500x200 mm potenza totale richiesta: 45 kW peso della macchina ca.: 32 t area cuscino stampo: 100 mm area cuscino stampo: 150 mm
usato
pressure: 63 t throat: mm stroke: 8 - 120 mm no. of strokes: 135 Hub/min max. distance table - ram: 560 mm ram adjustment: 70 mm table surface area: 800 x 600 mm ram surface: 500 x 400 mm total power requirement: 12 kW weight of the machine ca.: 5,5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
pressure: 63 t throat: - mm stroke: 16 - 125 mm max. distance table - ram: 417 mm ram adjustment: 70 mm no. of strokes: im Dauerlauf 80 Hub/min table surface area: 800 x 630 mm ram surface: 500 x 400 mm clamping plate thickness: 70 mm total power requirement: 6 kW weight of the machine ca.: 5,5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
pressione: 160 t rotroat: 360 mm corsa: 500 mm superficie table: 1250x630 mm ram superficie: 1000x450 mm altazza: 1000 mm dayligth: 800 mm peso della macchina ca.: 8 t
usato
pressione: 10 t stroke: 400 mm feed down: 200 mm/sec feed up: 450 mm/sec max. distanza table - ram: 630 mm potesse di potenza complessiva: 8,5 kW peso della macchina ca.: 1,3 t dimensioni della macchina ca.: m
usato
pressione: 63 t roat: - mm stroke: 16 - 125 mm mometria tabella: 800 x 600 mm forza: 250 superfiso di taglio: 1600 mm² regolamento della tavola: 220 mm potenza totale: 6 kW peso della macchina ca.: 5 t distanza/ram: 562 mm
usato
pressure: 100 t throat: 355 mm stroke: 8 - 130 mm table surface area: 710 x 1200 mm T-slots at tabel: 3 clamping plate thickness: 75 mm no. of strokes: 50/80 Hub/min ram adjustment: 80 mm ram surface: 450 x 560 mm T-slots at ram: 2 tool shank hole (depth x diameter): 100 x 50 mm max. distance table - ram: 540 mm distance between columns: 400 mm connected load: 11,5 kW weight of the machine ca.: 9,0 t Overall size: 1,65 x 2,25 x 3,05 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
