turning diameter:480 mm turning length:1250 mm control:H 645 weight of the machine ca.:8 t dimensions of the machine ca.:5 x 2 x 2 m centre distance:1580 mm swing over bed:495 mm swing diameter:üb.Querschlitten ca.350 mm working area:1600 mm control:H645 connected load:50 kW
centre distance: 5000 mm turning diameter over bed: 4000 mm turning dia. in gap: 5000 mm spindle bore: 104 mm turning speeds: 1,4 - 71 (18x) U/min total power requirement: 30 kW weight of the machine ca.: t dimensions of the machine ca.: m 4-jaw face plate Ø 3.150 mm modular lathe! The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
max. width of grinding wheel: 50 mm ratio: 0 max. dia. of grinding wheel: 400 mm total power requirement: 3 kW weight of the machine ca.: 1000 kg dimensions of the machine ca.: m Pre-Dressing Device for Gear Grinding Wheels The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter over bed: 500 mm turning diameter over slide rest: 330 mm turning diameter in the gap: 600 mm turning length: 3000 mm bed width: 505 mm spindle bore: 72 mm spindle head: DIN 55022 Gr. 8 taper in tailstock: MK 5 turning speed range: 22,4- 1120 U/min power requirement: 18,5 kW dimensions: 5,3 x 1,75 x 1,53 m weight of the machine ca.: 5,2 t used lathe in nice condition with digital scale - 2 axis digital scale - 4 jaw chuck Ø 250 mm - 3 jaw chuck Ø 260 mm - Multifix C toolholder system - some toolholders - steady The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Mandrino a 3 ganasce WMW NILES DHK 200x3 Ø esterno: 200 mm Flangia: 155 mm Foro Ø: 60 mm Cerchio bulloni: 175 mm Altezza con ganasce: 125 mm Numero mandrino: 507 Dimensioni: 200 x 200 x 125 mm
Mandrino a 3 griffe, mandrino a tre griffe WMW DH-B 200x3x6 ( DH-B200x3x6 ) TGL 30-2332 Ø esterno: 200 mm Ø cerchio bullone : 133.133.BR 5 mm Bore Ø: 54 mm Altezza con ganasce: 140 mm usato, testato ! Dimensioni: 200 x 200 x 121 mm
Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -DH: 200x3-III -TGL: 30-2332 -Chuck size: Ø 200 mm -Weight: 16.7 kg
Four-jaw chuck, four-jaw lathe chuck, 4 jaw chuck -Type: DH250x4/TGL30-2332 -Chuck size: Ø 250 mm -Throughout: Ø 80 mm -Rezess: Ø 210 mm -Hole circle: Ø 230 mm -Number: 3x available -Price: per piece -Weight: 18 kg
Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Mouth size: Ø 250 mm -Recess inlet: Ø 210 mm -Through hole: Ø 80 mm -Weight: 18 kg
Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -DH: B200x3x6 -TGL: 30-2332 -Chuck size: Ø 200 mm -Cone: Ø 104 mm -Hole circle: Ø 132 mm -Through hole: Ø 54 mm -Weight: 15 kg
Three-jaw chuck, three-jaw lathe chuck -Chuck size: Ø 200 mm -Weight: 18 kg
Three-jaw chuck, three-jaw lathe chuck -DH200x3-III -TGL: 30-2332 -Mouth size: Ø 200 mm -Recess: Ø 155 mm -Bolt circle: Ø 174 mm -Through hole: Ø 57 mm -Weight: 12 kg
Three-jaw chuck, 3-jaw chuck -Type: DHB 200x3x5 TGL 30 2332 -Mouth size: Ø 200 mm -Passage: Ø 54 mm -max.: 3000 rpm -Short taper mount: Ø 105 mm -Weight: 24 kg
Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Mouth size: Ø 200 mm -threaded mounting -Through hole: Ø 53 mm -Weight: 19.7 kg
Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Feed size: Ø 200 m -Through hole: Ø 54 mm -Short cones: 5 -Bolt circle: 105 mm -Weight: 16.2 kg
three-jaw chuck, three-jaw lathe chuck -Handover: in current condition as viewed -Short cone: has been shortened -Chuck size: Ø 200 mm -Through hole: Ø 54 mm -Hole: cone Ø 104.5 mm -as per pictures, without additional accessories -Weight 14.4 kg
Wedge rod feed, swivel feed, swivel swivel feed, power clamp feed -Feed size: Ø 250 mm -Weight: 35.5 kg
Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Feed size: Ø 200 m -Through hole: Ø 54 mm -Weight: 12 kg
Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 160 mm -TGL: 30-2312 -Weight: 11.2 kg
three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 250 mm -Cone: Short cone 8 Ø 139 mm -Bolt circle: Ø 170 mm -Through hole: Ø 80 mm -Weight: 24 kg
Three-jaw chuck, three-jaw lathe chuck, 3-jaw chuck -Mouth size: Ø 200 mm -Short cone mount for: bayonet disc attachment -Cone size: 6 -Cone: Ø 106 mm -Bolt circle: Ø 133.4 mm -Through hole: Ø 54 mm -Weight: 15 kg
Three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -Chuck size: Ø 160 mm -DKRD Ø: 160 mm -Weight: 15.5 kg
three-jaw chuck, three-jaw lathe chuck, 3 jaw chuck -DH250x3-III -TGL 30-2332 -Chuck size: Ø 250 mm -Cone: Short cone 8 Ø 140 mm -Bolt circle: Ø 172 mm -Through hole: Ø 80 mm -Weight: 28 kg
