Modello
(Fabbricante: TRAUB)
CNC swiss type lathe Traub TNL 32-7, - Model TNL32/TNL32K, - Controller TX8i-s, - Main spindle max. diameter 32 mm, with C-axis, - Counter spindle including parts discharge, - Top revolver X/Y/Z/H-axis: 10 tools dual drive, - Bottom revolver X/Y/Z/H-axis: 9 tools same drive; counter spindle independent drive, - Conveyor belt for finished parts with gripper, - Coolant pump 3 bar, - Coolant pump 8 bar, - Swarf conveyor, hinged belt type H=1000 mm, - Linear encoder X-axis for revolver top/bottom, - Fabric filtration for coolant: grade of filtration ca. 30-40 µm, - High pressure coolant pump 20 bar, - CO2 fire fight system Kraft & Bauer, - Auto bar loader FMB LSK 38, max. bar length 3,2 m, Machine worked only with cutting oil, Country of origin: Germany, Control: TX8i-s, Operating hours: 55.000 | 36.000, Max bar dia. [mm]: 32, Spindle speed [rpm]: 8.000, Spindle stock stroke [mm]: 305, Weig ...
Tornio automatico CNC Traub TNL 32-7 • Versione TNL32/TNL32K modalità alternata • Controllo TX8i-s • Passaggio mandrino principale 32 mm, con asse C • Contromandrino con sollecitazione cava parziale • Braccio di massima dell'asse X/Y/Z/H: 10 colpi a doppia unità • Revolver inferiore asse X/Y/Z/H: 9 colpi di guida totale; Contatore mandrino sep. Guida • RAPP 8 volte; Unità totale 3 utensili IK • Unità di deflessione del pezzo con pinza lineare • Alimentazione refrigerante 3 bar • Alimentazione refrigerante 8 bar • Nastro trasportatore a cerniera, altezza di scarico 1000mm • Scala in vetro Torretta asse X superiore/inferiore • Filtro a nastro compatto per lubrificante di raffreddamento: finezza del filtro circa 30-40 μm • Sistema di estinzione a CO2 di Kraft & Bauer • Caricatore a barre FMB LSK 38, per aste 3,2 m • La macchina è stata a ...
Diametro di lavorazione max: 36 mm Velocità massima mandrino: 6300 rpm N° mandrini: 2 Controllo: Traub TX8i Toolchanger 1: N° utensili: 12 posizioni Corsa asse X: 50 mm Corsa asse Z: 50 mm Cambio utensile fronside: N° utensili: 7 posizioni Velocità: 150 - 3000 giri/min 300 - 6000 giri/min Diametro massimo: 40 mm Corsa asse X: 370 mm Corsa asse Z: 250 mm Lato posteriore del cambio utensile: Numero di utensili: 5 Velocità: 150 - 3000 giri/min 300 - 6000 giri/min Diametro massimo: 40 mm Corsa asse X: 73 mm Caricatore: FMB Turbo 5-42 Lunghezza barra: 3200 mm Diametro barra: 5 - 42 mm Paese di origine: Germania Macchina LxWxH: 3400 x 1300 x 1700 mm Peso macchina: 4000 kg
Key data: 140 mm, 220 mm
Sistema CNC Control Traub TX 8D Asse C/ Utensili azionati Alimentatore a barre Stamag DN42 Collezionista delle parti finite Nizzolo trasportatore a trucioli Raffreddamento a liquido interno Condizioni molto buone Diametro massimo della barra 42 mm Lunghezza di rotazione 220 mm Mandrino idraulico Chuck- max. Girando il dia. 140 mm Diametro massimo di rotazione 140 mm Diametro massimo di rotazione sul piano 390 mm Perforazione del mandrino 42 mm Numero di teste di torretta: 3 -1ª torretta 12 strumenti -2ª torretta 12 strumenti -3ª torretta 4 strumento Portautensili VDI 30 Spostamento dell'asse X 200 mm Scorrimento dell'asse Z 300 mm Velocità del mandrino 5600 giri/min Lunghezza massima della barra 4200 mm Max. Bar funzionanti in Dia. 42- 7 Potenza totale richiesta 34 kW Coperchio interbloccato Dimensioni totali: 7400x1900x2400 mm Peso 4500 kg
Traub TNA500 SN 253 Anno di costruzione 1997 Mandrino 2800 1/min torretta a 12 utensili Ha strumenti alimentati Potenza 46kVA
turning diameter: 275 mm turning length: 900 mm control: TRAUB TX8i-s spindle passage: 65 mm spindle turning speed - stepless: 1 - 5.000 U/min spindle diameter in front bearing: 110 mm C-axis: 1 - 500 U/min x-axis: 175 mm z-axis: 650/975 mm y-axis: +/- 40 mm rapid traverse X/Y/Z: 20 / 40 / 20 m/min feed capacity X/Y/Z: 5,5 / 5,5 / 10 kN tool turret - number of stations: 10 number of driven tools: 10 mm toolpiece turning speed range: 1 - 6.000 U/min power capacity at 25 % load: 5,50 kW max. torque at 25% load: 17,50 Nm tool taper DIN 69880: Ø30x55 spindle diameter in front bearing: 110 mm total power requirement: 95,00 kW weight of the machine ca.: 16,00 t dimensions of the machine ca.: 10,00 x 3,50 x H3,00 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter:275 mm turning length:900 mm spindle passage:65 mm power capacity at 100 % load:25/20 kW spindle turning speed range:1 - 5000 U/min spindle diameter in front bearing:110 mm c-axis:1 - 500 U/min. number of workpiece supports:4 tool turret:1 x-axis:290 mm y-axis:165 mm z-axis:360 mm b-axis:360 ° rapid speed:18/30 m/min number of tools:2x2 + 2x2 number of driven tools:2x2 + 2x2 mm toolpiece turning speed range:8000 / 2000 U/min power capacity:25% ED 5,8 kW tool taper:TRAUB 60 tool turret:2/3/4 x-axis:170 mm z-axis:600/950 mm y-axis:+/- 60 mm rapid speed:18/15/30 m/min number of driven tools:10 mm toolpiece turning speed range:1 - 6000 U/min power capacity:25% ED 5,8 kW tool taper:DIN 69880 40 x 63 total power requirement:95 kW weight of the machine ca.:16 t dimensions of the machine ca.:10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and ...
turning diameter:480 mm turning length:800 mm total power requirement:30 kW turning diameter over bed slide:240 spindle bore:65 mm disc turret:12 fach rapid travel range:20 / 10 m/min weight of the machine ca.:4,5 t dimensions of the machine ca.:4 x 2,2 x 2,1 m with CNC TRAUB TX 8 H C-axis driven tooling, 6 positions 3,5 kW / 4000 rpm power chuck coolant attachment, chip conveyor diverse toolholders
turning diameter:500 mm turning length:1000 mm weight of the machine ca.:7,3 t dimensions of the machine ca.:6,5 x 4,45 x 2,21 m
turning diameter: mm turning length: mm control: 0 total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bar material dia.: max. 85 mm bar length: 3000 / 3500 mm No. 0703 1 used bar feeder TRAUB 3D / E85 / 3000 Z Bar diameter : max. 85 mm Bar length: max. 3000 mm UNPROOFED / As Spare Part The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 480 mm turning length: 800 mm control: System TX8F turning diameter over slide: 240 mm spindle passage: 65 mm chuck diameter: 200 mm turning speeds: 4000 U/min power capacity: 30 kW total power requirement: kW weight of the machine ca.: 4,3 t dimensions of the machine ca.: m powered tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 12,7 mm turning length: 50 mm control: Traub System TX 8i turning speeds: 12000 U/min c-axis: 0,001° gripping station: 12,7 mm c-axis: 0,001 ° speeds: 12000 U/min rapid traverse: 15 m/min turret (x-stations): 6 worktool system: 5+3 worktool system: 3 Werkzeugsysteme total power requirement: 2,5/4 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2,4 x 1,1 x 1,7 m driven tools: 6+4+4 Rev+S7+S8 CNC turning machine Traub TNL 12K with barloader LNS Tryton 112 Motor drive S8 (rear working with driven tools possible) Motor drive S7 (front working with driven tools possible) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 250 mm turning length: 450 mm control: TX8D bore: 80 mm spindle speed:: 3150 U/min. CNC Lathe with Bar Feed and 3 Turrets Very large spindle bore, with bar loading device Please ask for further details. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Manufacturer: Traub Year of Manufacture: 2002, factory overhaul completed 2018 Model: TNK 36 Type of Machine: CNC automatic lathe Operating Hours: approximately 147,007 hours, as of June 2026 CONTROL SYSTEM - Control: TX8i (64 bit), 14 inch flat screen - Additional V24 RS232 interface in the control cabinet - MDE interface in control cabinet, machine running and piece counter - Thread cutting without compensating chuck - Polyform function for C-axis - Tool monitoring MAIN SPINDLE - Spindle bore: 36 mm - Maximum speed: 6,300 rpm - Drive power: AC 6.7 / 10.7 kW - C-axis - Change parts: Hainbuch - Mounting aid base body - Manual Hainbuch change device COUNTER SPINDLE - Counter spindle as motor spindle - Spindle bore: 32 mm - Maximum speed: 6,300 rpm - Travel Z4: 250 mm - Rapid traverse Z4: 30 m/min - C-axis - Device for counter clamping pressure - Workpiece ejector device - Increa ...
Manufacturer: Traub Model: TNK 36 Year of Manufacture: 2003 Operating Hours: approx. 124,705 h (as of May 2026) Total Connected Power: 33 kW Voltage: 400 V / 50 Hz Condition: No known defects. Available for live demonstration. CNC Control - Control: TX8i (64-bit) - Screen: 10.4 inch flat panel display - Interface: V24 RS232 in control cabinet - MDE Interface: Machine running / piece counter - Tool monitoring included - Thread cutting without compensation chuck - Programming: At machine control or via WinFlex IPS software on PC Main Spindle - Spindle Bar Capacity: 36 mm - Max. Speed: 6,300 rpm - Drive Power: AC 6.7 / 10.7 kW - C-axis included - Hainbuch collet chuck system (manual change device included) Counter Spindle - Motor spindle with C-axis - Counter-clamping pressure device - Workpiece ejector - Hainbuch Axfix collet chuck - Upper tool carrier with driven tools and ele ...
Passaggio del fuso: 80 mm. diametro di rotazione: 395 mm max. Lunghezza di rotazione: 750 mm, controllo: System TX 8H max. Velocità del mandrino: 3,150 U/min. Tornio CNC | TRAUB - TNA 400La macchina è in condizioni ben mantenute.- - - - - - #Tags:TNA400 | TNA-400I dati per questo annuncio sono stati creati con ModulMWS - la soluzione software di LogoTech oHG.
spindle passage: 80 mm max. turning diameter: 460 mm Max. Turning length: 1.000 mm control: System TX 8F max. Spindle speed: 2.800 U/min. CNC lathe | TRAUB - TNA 500 The machine is in a well-maintained condition. The machine videos from the production plant will be shared on request. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags:TNA500 | TNA-500 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 275 mm turning length: 900 mm control: TRAUB TX8i Main- opposite spindle: spindle passage: 65 mm power capacity at 100 % load: 25,20 kW power capacity at 40 % load: 30,20 KW max. torque at 40% / 100% load: 180 / 135 Nm spindle turning speed - stepless: 1 - 5.000 U/min spindle diameter in front bearing: 110 mm C-axis: 1 - 500 U/min worktool support: No. 1 x-axis: 290 mm y-axis: 165 mm z-axis: 600/950 mm B - axis: 360 ° rapid traverse X/Y/Z: 18 / 18 / 30 m/min feed capacity X/Y/Z: 10 / 10 / 7 kN number of tools: 2x2 + 2x2 number of driven tools: 2x2 + 2x2 mm toolpiece turning speed range: 8.000 / 2.000 U/min power capacity at 25 % load: 5,80 kW max. torque at 25% load: 4x18,6 / 4x74 Nm tool taper: TRAUB Ø60 worktool support: No.2 / No.3 / No.4 x-axis: 170 mm z-axis: 600/950 mm y-axis: +/- 60 mm rapid traverse X/Y/Z: 18 / 15 / 30 m/min feed capacity X/Y/Z: 10 / 10 / 7 k ...
Tornio Traub TNL 12 K in vendita anno di costruzione 2005 Smontaggio e carico su camion a spese dell'acquirente Consegna franco fabbrica esclusa l'assicurazione di trasporto Scopri di più qui - / Contattaci all'indirizzo -
CNC Control Traub System TX 8D Assi C/ Strumenti guidati Alimentatore a barre Stamag DN42 Collettore delle parti finite Trasportatore a truciolo Raffreddamento interno a liquido Ottime condizioni Diametro massimo barra 42 mm Lunghezza di tornitura 220 mm Mandrino idraulico Chuck- max. Diametro massimo di tornitura 140 mm Diametro massimo di rotazione sul letto 390 mm Alesatura mandrino 42 mm Numero di teste di torretta- 3 -1a torretta 12 utensili -2a torretta 12 utensili -3° torretta 4 Porta utensili VDI 30 Corsa asse X 200 mm Corsa asse Z 300 mm Velocità del mandrino 5600 giri/min Lunghezza massima barra 4200 mm Max. barre di lavoro in dia. Fabbisogno energetico totale 34 kW Copertura ad incastro Dimensioni totali: 7400x1900x2400 mm Peso 4500 kg
TRAUB TNL 18P ist eine CNC Langdrehautomat, gebaut für Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazitäten: Drehlänge 180 mm, Stangendurchmesser max. 20 mm; FMB minimag 20 Lademagazin für 2–23 mm bis 4200 mm. Hauptdaten: 7 Achsen, 2 Spindeln; Längsweg Z 205 mm (Z-Achse 250 mm), X 120 mm, Y -20/+40 mm; Hauptspindel bis 8000 min-1, Gegenspindel bis 6400 min-1; Spindelleistungen 2.2/3.7 kW und 1.5/2.5 kW; Gesamtbedarf 24 kVA; Gewicht ~4000 kg; Abmessungen 2500×1460×2250 mm. Zubehör: Hochdruck-Kühlmittel 30 bar, Wasserkühler, Papierfiltration, Reduzierhülsen, Führungsbuchse, Fräsapparat, Werkzeugvoreinstellung, Lampe, Löschsystem. Ermöglicht enge Toleranzen; geeignet für Automotive, Uhrenindustrie, Werkzeugbau, Luftfahrt und Medizintechnik. Technische Daten ohne Gewähr
TRAUB A 15 ist ein Drehautomat, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit in Serienfertigung. Arbeitsvermögen: Werkstück-Ø max 15 mm, Drehlänge 70 mm, Spindelbohrung 15 mm, größter Gewindedurchmesser 8 M, Kapazität 28–2100 p/h. Technische Daten: 12 Drehzahlen von 900–6500 t/min; Anschluss 50 Hz 3x380 V; Leistung 1,5 CV; Gewicht ca. 650 kg; Maße L1200×B800×H1500 mm. Zubehör: Stangenlademagazin TRAUB B3000 (max 3200 mm), Transportapparat, Greifereinrichtung, Senkrechtsupport, Schlitzapparat, Bohrreitstock, Werkstückzähler, Schutzhaube. Erreicht enge Toleranzen; geeignet für Automotive, Uhrentechnik, Werkzeugmaschinenbau, Luftfahrt und Medizintechnik Technische Daten ohne Gewähr
Numero Inv. : 8535 Tipo: TNL 18P Produttore: TRAUB Creato: 2013 Parametri: Sistema di controllo: TRAUB SYSTEM TX 8i-p Diametro massimo dell'asta: 20 mm Lunghezza massima di tornitura: 180 mm Numero di mandrini: 2 pezzi Velocità massima del mandrino: 8000 1/min Lunghezza: 2500 mm Larghezza: 1460 mm Altezza: 2250 mm Peso: 4000 kg Attrezzatura: Caricatore di barre
Article: Programme-controlled automatic lathe Manufacturer: Traub Type: TF60 / 140 Yob: 1978 Bar automat Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com
Control voltage: 24V DC, rated current: 85A, connected load: 39kVA, rated power: 49kW, control-on operating hours: 32,779h, automatic operation 1: 5,040h, automatic operation 2 operating hours: 1,844h, production time: 33,731h, length: 3231mm, width: 2076mm, height: 1917mm, weight: 4.8t, with documentation, chip conveyor and FMB turbo 8-80 bar feeder. An on-site inspection is possible.
Rated current: 60A, control voltage: 24V, connected load: 33kW, length: 2290mm, width: 1350mm, height: 1630mm, weight: 4.65t, operating hours: 78,439h, with documentation, chip conveyor and bar feeder. An on-site inspection is possible.
Traub TNX 65Year of manuf. : 2011 Control : Mitsubishi TX8i-s ____________Description:Mainspindle:Technology:MotorspindleSpeed:5.000 rpmPower:22,6 kWTorque:180 NmBarcapacity:65 mmWorkpiececlamping:Collet chuck, Hainbuch Spanntop Kombi Axfix Gr. 65Subspindle:Technology:MotorspindleSpeed:5.000 rpmPower:22,6 kWTorque:180 NmWorkpiececlamping:Collet chuck, Hainbuch Spanntop Kombi Axfix Gr. 65Ejector:Hydraulic with flushToolcarrier I (X/Y/Z):Technology:Turret with 10 stationsTaper:VDI30Tooldrive:6.000 rpm, 5,5 kW, 17,5 NmMovement in X/Y/Z:175/80/650 mmRapid travers in X/Y/Z:20/20/40 m/minToolcarrier II (X/Y/Z):Technology:Turret with 10 stationsTaper:VDI30Tooldrive:6.000 rpm, 5,5 kW, 17,5 NmMovement in X/Y/Z:175/80/650 mmRapid travers in X/Y/Z:20/20/40 m/minToolcarrier III (X/Y/Z):Technology:Turret with 10 stationsTaper:VDI30Tooldrive:6.000 rpm, 5,5 kW, 17,5 NmMovement in X/Y/Z:175/80/650 ...
Key data: 110 mm, 450 mm, 5600 1/min
Anno di fabbricazione 1996 Controllo: TX8 F inclusi il sistema di alimentazione Simag da 42,1 barre Anno di costruzione: 2003 Il distributore di barra è massimo di circa 3,2 m per 3 m di barra. con tanti accessori La macchina è ancora in fase di alimentazione ed è disponibile con poco preavviso
This 10-axis TRAUB TNK 36 horizontal turning machine was manufactured in 2002. It features a main spindle speed of 6,300 rpm and a counter spindle speed of 6,300 rpm. The machine includes a maximum workpiece diameter of 32 mm and a coolant tank capacity of approximately 360 liters. If you are looking to get high-quality turning capabilities, consider the TRAUB TNK 36 machine we have for sale. Contact us for further details.
