STUDER macchina utilizzata in vendita

Macchina n. 2037.04 Guarda le foto !

Coperture telescopiche per assi X e Z per molte rettificatrici CNC Studer S21, S31, S33, S40 ecc. E per molti altri produttori di macchine su richiesta.

Studer S31 Spw.: 1000mm/ Sph.: 175mm Controllo Fanuc 16i-TB Messa in servizio 2004 Corse asse X 285 mm / asse Z 1150 mm Rettificatrice cilindrica universale 2x rettifica esterna e 1x rettifica interna

Key data: 180 mm, 800 mm

Comando Fanuc 31 i - A Diametro massimo di lavorazione 180 mm Lunghezza max. di lavorazione 800 mm Mandrino principale con mandrino autocentrante 30 kN Contromandrino con mandrino pneumatico Due teste di macinazione Torretta portautensili con 12 stazioni utensili motorizzate

DIAMETRO MASSIMO 450 . LUNGHEZZA MASSIMA 1600

Key data: 1000 mm, 285 mm, 1000 mm

Studer S33 CNC Smerigliatrice cilindrica universale Novità 2018 Controllo CNC: sì Tipo di controllo CNC: FANUC OI-TD Capacità e caratteristiche: 350mm x 1000mm Dimensioni della mola OD: 500 x 63 x 203,2 mm Corsa asse X: 285 mm Corsa asse Z: 1000 mm Risolutezza: 0,0001 mm Peso max. del pezzo tra le punte: 80 kg Tavolo girevole: -15 - +225 Indicizzazione: asse B Accoppiamento automatico 1 Hirth Dimensioni max. della mola: 500 x 63 x 203,2 mm Velocità periferica max.: 50 m/sec Capacità di alimentazione del motore: 14.47HP / 11kW Testa mandrino del pezzo: Vedere le specifiche di seguito: Vedere le specifiche di seguito Numero giri: 1 - 1.500 giri/min Capacità motore testa: 1,6 / 3 kW Passaggio mandrino: 30 mm Cono di montaggio: MK 5 Altezza punte: 175 mm Carico di lavoro: 80 kg Scheda tecnica della macchina - Complessivo: VEDI SOTTO Asse C: ...

Rettifica Studer S21 Lean CNC :::SPECIFICHE TECNICHE::: Modello CNC: Fanuc Versione del CNC: 21i-T Corsa Asse X: 254mm Corsa Asse Z: 483mm Fascia mola: 40mm Diametro mola: 400mm Altri dati tecnici: Testa portamola orientabile (B) -15°/+195° 1° 2 mole da esterno 1 mola da interno Mola rettifica esterno 400 mm x 40 mm x 127 mm 4 kW Testa portapezzo CM 4 :::DIMENSIONI E PESO::: Lunghezza: 2300mm Larghezza: 2000mm Altezza: 2100mm Peso: 4300Kg

Rettificatrice cilindrica esterna CNC, marca Studer, tipo S40-4, Bi 1987, I documenti sono disponibili. Il prezzo è netto

Diametro di rettifica 250 mm Lunghezza di rettifica 650 mm Larghezza centrale 700 mm Altezza punta 125 mm Diametro mola 400/450 mm Larghezza mola 50/80 mm Velocità mandrino del pezzo fino a 675 1/min Paletta del pezzo girevole +/- 45 ° Camerino Dispositivo di misurazione Sistema di raffreddamento Mola

Lunghezza di rettifica

- Mandrino di macinazione interno - Display digitale Heidenhain Altezza di picco 100 mm Larghezza punta 450 mm Ruote di macinazione da 300 mm Dimensioni del tavolo 950x200 mm Percorso longitudinale 450 mm Cono di mandrino MK 5 Velocità del mandrino continuamente 40 - 650 rpm Tavolo girevole - 10 gradi Peso circa 1700 kg Dimensioni 1570x1100x1400 mm

CONTROLS   CNC controls FANUC WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 350 mm   grinding length: 650 mm TAILSTOCK   distance betw. centers (max): 650 mm   sleeve stroke: 35 mm   sleeve diameter: 80 mm   taper: MK 3 SPINDLESTOCK GRINDING SPINDLE   tilting range (B-direction) min: 0 °   rotating range B-axis up to: 8.5 °   - mode of operation: manual GRINDING TOOL   type of grinding tool: wheel   diameter (max): 500 mm   width: 63 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2670 mm   space requirements -front/back-: 2100 mm   total height: 1800 mm ATTACHMENTS (GRINDING)   internal grin ...

CONTROLS   digital read out WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 200 mm   workpiece weight between centers (max): 400 kg   workpiece weight flying (max): 20 kg WORKPIECE SPINDLESTOCK   spindle revolutions (min): 80 /min   spindle revolutions (max): 800 /min   tool fixture: MK 4 TAILSTOCK   distance betw. centers (max): 400 mm   sleeve stroke: 20 mm   taper: MK 2 SPINDLESTOCK GRINDING SPINDLE   spindle revolutions (min): 1600 /min   spindle revolutions (max): 2200 /min   drive power: 3 kW GRINDING TOOL   diameter (max): 350 mm   borehole: diameter: 127 mm   width: 30 mm

CONTROLS   CNC controls FANUC 0I-TFP WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 350 mm   workpiece weight between centers (max): 80 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 350 mm   grinding length: 500 mm WORKPIECE SPINDLESTOCK   spindle revolutions (max): 1500 /min   drive power: 3 kW   spindle bore diameter: 30 mm   tool fixture: MK 5   c-axis: yes   - positioning/indexing: 0.5 ° TAILSTOCK   distance betw. centers (max): 400 mm   sleeve stroke: 60 mm   taper: MK 4 SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 370 mm   Z-axis travel: 500 mm   tilting range (B-direction) min: 60 °   drive power: 9 kW GRINDING TOOL   diameter (max): 500 mm    ...

CONTROLS   CNC controls GE FANUC SERIES 16 GC WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 350 mm   workpiece weight between centers (max): 130 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 350 mm   grinding length: 1000 mm WORKPIECE SPINDLESTOCK   spindle revolutions (min): 30 /min   spindle revolutions (max): 1000 /min   continuous speed variation: yes   c-axis: yes TAILSTOCK   distance betw. centers (max): 1000 mm SPINDLESTOCK GRINDING SPINDLE   Z-axis travel: 1000 mm   tilting range (B-direction) min: 0 °   rotating range B-axis up to: 210 °   drive power: 7.5 kW GRINDING TOOL   type of grinding tool: wheel   diameter (max): 500 mm SPINDLESTOCK INTERNAL GRINDING   tilting ran ...

CONTROLS   CNC controls FANUC 310I-A WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 180 mm   workpiece weight between centers (max): 25 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 400 mm   grinding length: 1000 mm TAILSTOCK   distance betw. centers (max): 1000 mm   taper: MK 4   Z-axis travel: 1600 mm SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 220 mm   Z-axis travel: 1600 mm   tilting range (B-direction) min: 0 °   rotating range B-axis up to: 25 °   drive power: 6.8 kW GRINDING TOOL   type of grinding tool: wheel   diameter (max): 400 mm   borehole: diameter: 127 mm ELECTRICAL SPECIFICATIONS   mains power supply: 45 kVA   mains voltage: 400 V   mains frequ ...

grinding diameter: 0,2 - 190 mm grinding length:400 mm centre height:100 mm weight of the machine ca.:1,6 t dimensions of the machine ca.:2 x 1,5 x 1,8 m

internal diameter: mm grinding depth: mm centre height:175 mm grinding length:120 mm longitudinal and cross slide:300 grinding wheel diameter:10 mm grinding wheel speeds:90.000 U/min Z-axis:300 mm Incl. automatic feeding B-Axis

grinding diameter:300 mm grinding length:540 mm centre height:175 mm total power requirement:20 kVA centre distance:1000 mm

grinding diameter:50 mm grinding length:100 mm centre height:100 mm centre distance:200 mm

Description: Serial Number: 020.0658.90.079 grinding diameter: 300 mm, grinding length: 500 mm, table slide longitudinal travel max.: 267 mm, control: GE Fanuc Series 16-T, weight approx.: 3,800 kg, Approx. Onsite Dimension. (l x w x h): 2,000 x 2,500 x 2,000 mm

grinding diameter:400 mm grinding length:650 mm centre height:125 mm total power requirement:5/8,25 kW weight of the machine ca.:3,4/3,5 t

Description: FANUC control system Two external and one internal grinding spindle Machine must be collected in mid-June 2024 Machine no.: 022.0102.90.017, max. travel of longitudinal slide: 1050 mm, max. speed of longitudinal slide: 10,000 mm/min, max. inclination of table: 8.5 degrees, max. travel of cross slide: 275 mm, max. speed of cross slide: 10,000 mm/min, max. workpiece weight between centres: 130 kg, max. quill travel 35 mm Attention: Clamping device and measuring system are not included in the scope of delivery Approx. Onsite Dimension. (l x w x h): 2,500 x 4,000 x 2,000 mm, weight approx.: 4,000 kg

Description: Serial number 046, control FANUC 16 I-T, ,Machine number: 202552, max. sanding length: 200 mm, max. Z-axis travel: 500 mm, max. speed: 10,000 mm/min, max. X-axis travel: 120 mm, max. speed: 5,000 mm/min, fixed sanding spindle bore 120 mm, speed range: 0-1500 min, spindle clearance: 50 mm, spindle torque: 30 Nm Attention: Clamping device and measuring system are not included in the scope of delivery Approx. Onsite Dimension. (l x w x h): 3,100 x 2,000 x 2,100 mm, weight approx.: 6,000 kg

Machine in good technical condition, after agreement possibility of testing. Grinding diameter Ø 250 mm Grinding length 750 mm Size of grinding wheel 400 x 50 mm. Length 2400 mm Width 1300 mm Height 1500 mm.

- - -: - - -: - - - -: - Rettificatrice cilindrica | STUDER - S 35 La macchina è in buone condizioni e può essere ispezionata sotto tensione in qualsiasi momento nello stabilimento svizzero. I dati tecnici della macchina seguiranno presto. - - - - - #Tags- Visualizzazione del materiale S-35

Description: Center height 175 mm, center width 1000 mm, maximum longitudinal slide travel 1050 mm, longitudinal slide speed 0.0001 to 10000 mm per minute, maximum table inclination 8.5 degrees, maximum cross slide travel 275 mm, maximum cross slide speed 0,0001 to 10000 mm per minute, quill travel of tailstock 35 mm, maximum workpiece weight between centers 130 kg, speed range of workpiece spindle 30 to 750 rpm, including manual operation and existing documentation, machine number 011.0126.60.021 control: GE FANUC SERIES 16-GC, weight approx.: 6,000 kg, Approx. Onsite Dimension. (l x w x h): 4,400 x 2,300 x 2,600 mm

Altezza del centro: 100 mm Interasse: 650 mm Diametro x larghezza della mola: 350x32 mm Diametro del foro della mola: 127 mm Peso della macchina ca.: 2,3 t Dimensioni della macchina ca.: 2 x 1,6 x 1,8 m

Distance between centers : 1000 mm Centers height : 175 mm Grinding wheel holder headstock orientation : 0 - 180 ° Grinding wheel holder headstock indexing precision : 5 ° Grinding wheel dimensions : 500 x 63 x 203 mm Cutting speed : 35 m/sec Headstock power : 7.5 kW Maximum workpiece weight : 130 kg Table orientation : 10 ° headstock rotation speed : 35-520 rpm EQUIPMENT : Sensitron 6 : Internal grinding spindle : 1 Measuring head MOVOMATIC ES124 for the diameter : 1 Tailstock : 1 Diamond grinding device for external wheel : 1 Radius grinding devic : 1 Display 2 axes HEIDENHAIN : 1 Lubricating tank with paper filtration : 1 Set of grinding wheel holders and grinding wheels : 1

Used Studer s 31 Cylindrical external / internal grinding machine Visible under power in Italy Year: 2003
