usato
Key data: 530 mm, 3000 mm
Lunghezza tornibile: 3000 mm Diametro di rotazione: 530 mm sopra il letto / 315 mm sopra la slitta trasversale Controllo: Fagor 8055 Velocità di rotazione: 2.000 giri/min min. max. Foro mandrino: 105 mm Torretta portautensili: 8 posizioni Dotate: - 2 cornici fisse - 1 lunetta mobile Paese di origine: Spagna Potenza del motore: 11 kW Peso della macchina: 4000 kg Macchina LxPxH: 4000 x 1700 x 1800 mm
usato
Num. Inv. : 6889 Tipo: Taurus 260 Produttore: Pinacho Creato: 2000 Parametri: Sistema di controllo: FAGOR Lunghezza massima tornibile: 1500 mm Diametro massimo tornibile: 520 mm Potenza massima mandrino principale: 11 kW Velocità minima del mandrino principale: 40 1/min Velocità massima del mandrino: 2500 1/min Numero di utensili: 8 pezzi Foro mandrino: 80 mm Lunghezza: 4000 mm Larghezza: 1800 mm Altezza: 1850 mm Peso: 3500 kg Attrezzatura: Lunette (2 pezzi)
usato
Key data: 450 mm, 1500 mm
Dettagli della macchina Codice articolo. 1105-03977 Tipo di macchina Tornio - a ciclo controllato Fabbricare PINACHO Tipo Smart turn 8 225 Anno di costruzione 2013 Tipo di controllo CNC Luogo di stoccaggio HAGUENAU Paese d'origine: Spagna Tempi di consegna immediatamente Base di trasporto franco fabbrica Dettagli tecnici diametro tornibile 450 mm lunghezza di tornitura 1500 mm controllo FAGOR TC 8055 potenza totale richiesta 15 kW Peso della macchina circa 3 t dimensioni della macchina circa 2,29X1 X 1,2 m Informazioni aggiuntive INSEGNA AL TORNIO CNC Pinacho offre il tornio piano CNC ST-225. Si tratta di un metodo veloce e preciso macchina fino a 450 mm in oscillazione sul bancale, 1500 mm in interasse e 65 mm nel foro del mandrino. Torni paralleli a 2 o 3 assi abbinati a Fagor controL. La potenza disponibile fino a 15 kW oltre all'elevata velocità di rotazione ...
usato
Tornio Pinacho S90-310. Distanza tra i centri: 1.625mm. Oscillazione: 620mm. Oscillazione sul carrello: 425 mm. Oscillazione nella fessura: 880 mm. Alesaggio: 80mm. 12 velocità: 30-1500 giri/min. Potenza motore: 7,5cv. Dotato di mandrino. Dotato di DRO Heidenhain. Dopo Cristo.
usato
Stato Ottimo Tipo di controllo Siemens Sinumerik Lunghezza max. lavorabile 1.500 mm Diametro tornibile su carro Ø 500 mm Max passaggio barra Ø 78 mm Diametro mandrino Ø 250 mm Velocità mandrino 2.000 giri/min Potenza mandrino 22 Kw Tipo mandrino ASA 8 Stazione portautensili Duplomatic 8 posizioni Accessori Evacuatore trucioli
usato
- Prima proprietà: da uso proprio e di prima mano - Altezza punte: 180 mm - Larghezza punte: 1000 mm - Diametro sopra il letto: 360 mm - Larghezza letto: 250 mm - Diametro del mandrino principale: 42 mm - Controllo: Fagor 8055 TC - Velocità di taglio costante: 100-4000 rpm - Avanzamento di lavoro Z.X: 0-7000 mm/min - Traslazione rapida Z.X: 10 m/min - Motore principale 5,5 kW
usato
N° 5197: 1 Gebr. Tornio per cicli Fabr. PINACHO, tipo Mustang 200, Bauj. 2001
usato
turning diameter:360 mm turning length:1000 mm control:Fanuc Oi-TF turning diameter over bed slide:300 mm max. swing over slide:190 mm bed width:250 mm spindle taper:A2-5 spindle speeds:0-4000 1/min. spindle bore:42 mm tailstock quill diameter:58 mm tailstock quill stroke:180 mm taper of tailstock quill:4 MK max. length of work piece:1000 mm rapid traverse x/z:15/12 m/min power requirement:7,5 kW weight of the machine ca.:1200 kg dimensions of the machine ca.:2250x1115x1630 mm automatic tool changer:8-fach CNC controller:Fanuc Oi-TF tools:1 Satz foundation bolts:1 Satz New CNC lathe KRAFT ST 285/1000 with Fanuc Oi Mate TD Made in Europe For more information please see the attached documents
nuova
turning diameter:1010 mm turning length:4000 mm control:FANUC OI TF max. swing over slide:718 mm bed width:500 mm spindle taper:A2-15 spindle speeds:0-1400 1/min. spindle bore:130 mm transmission ratio:2 tailstock quill diameter:120 mm tailstock quill stroke:300 mm taper of tailstock quill:6 MK max. length of work piece:4000 mm rapid traverse x/z:10/10 m/min power requirement:22 kW weight of the machine ca.:9500 kg dimensions of the machine ca.:6557x2202x2487 mm max. workpiece weight between centers:8600 kg automatic tool changer:8-fach CNC controller:FANUC OI TF tools:1 Satz coolant system:6 bar New CNC lathe KRAFT ST 500/3000 with FANUC OI TF Made in Europe For more information please see the attached documents
nuova
turning diameter:402 mm turning length:750 mm control:FAGOR 8037 turning dia. over face-slide:245 mm turning diameter over bed slide:380 mm bed width:250 mm spindle taper:A2-5 spindle speeds:40~2800 (3 Stufen) 1/min. spindle bore:42 mm tailstock quill diameter:58 mm tailstock quill stroke:180 mm taper of tailstock quill:4 MK max. length of work piece:750 mm power requirement:4 kW weight of the machine ca.:1050 kg dimensions of the machine ca.:2000x1115x1670 (LxBxH) mm turret:8 fach CNC controller:FAGOR 8037 electronic hand wheel:für X- und Z-Achse New CNC lathe KRAFT ST 285/1000 with Fanuc Oi Mate TD Made in Europe For more information please see the attached documents
nuova
turning diameter:402 mm turning length:1000 mm control: 8055 turning dia. over face-slide:245 mm turning diameter over bed slide:380 mm bed width:250 mm spindle taper:A2-5 spindle speeds:40~2800 (3 Stufen) 1/min. spindle bore:42 mm tailstock quill diameter:58 mm tailstock quill stroke:180 mm taper of tailstock quill:4 MK max. length of work piece:750 mm power requirement:4 kW weight of the machine ca.:1050 kg dimensions of the machine ca.:2250x1115x1670 (LxBxH) mm turret:Multifix CNC controller:FAGOR 8055 electronic hand wheel:für X- und Z-Achse New CNC lathe KRAFT ST 285/1000 with Fanuc Oi Mate TD Made in Europe For more information please see the attached documents
usato
turning diameter:450 mm turning length:1000 mm control:FANUC OI TF max. swing over slide:260 mm bed width:300 mm spindle taper:A2-6 spindle speeds:0-3000 1/min. spindle bore:65 mm transmission ratio:1 tailstock quill diameter:68 mm tailstock quill stroke:200 mm taper of tailstock quill:4 MK max. length of work piece:1000 mm rapid traverse x/z:12/15 m/min power requirement:9 kW weight of the machine ca.:1400 kg dimensions of the machine ca.:2800x1215x1750 mm automatic tool changer:8-fach CNC controller:FANUC OI TF tools:1 Satz 3 jaw chuck Ø:200 mm live center:4 MK :aus Guss New CNC lathe KRAFT ST 225/1000 with FANUC 0i mate TD Made in Europe For more information please see the attached documents
usato
turning diameter:620 mm turning length:2.000 mm turret (x-stations):8 tool taper:VDI 40 turning diameter over bed slide:415 mm control:8055 TC FAGOR spindle bore:80 mm rapid power traverse in X-and Z direction:10 m/min speeds:0-650 / 650-2.500 1/min total power requirement:28 kVA weight of the machine ca.:3,6 t dimensions of the machine ca.:4,6 x 2 x 1,8 m teach-in lathe with tailstock MT 5, 8-hole turret, 3 jaw-chuck
usato
Distance between centers: 1625 mm Max swing over bed: 520 mm Bed length: 350 mm Swing over longitudinal carriage: 470 mm Swing over cross carriage: 320 mm Swing in the gap: 770 mm Spindle hole diameter: 68 mm Main motor power: 7.5 CV Equipped with: 3-jaw universal chuck: Ø 310 mm Turret: Yes
usato
Description: PINACHO Mustang CNC Lathe machine number: 41101 control unit: Steuerung Fagor 8055 TC tecnical details: center height: 200 mm distance between centers: 1000 mm permitted diamter over guide travel: 400 mm permitted diameter over longitudinal slide: 370 mm permitted diameter over cross slide: 210 mm bed width: 300 mm headstock bore hole main spindle: 65 mm main spindle Nase Camlock no. 6 DIN 55027 morse taper of main spindle: 5 spindle speed 2 constant cutting speed 1st step 0 - 700 rpm, 2nd step 700 - 3000 rpm feeds working range Z, X: 0 - 7000 mm/min. rapid traverse Z, X: 10 m/Min. tailstock shaft diameter: 58 mm tailstock shaft path 155 mm morse taper tailstock: 4 motors: power main motor: 7.5 kW power direct current motor Z-axis in Nm: 12 Nm power direct current X-axis: 4 Nm power of motor pump: 0.57 kW further details: without clamping jaw chuck, with foot switch seri ...
usato
: gebraucht : 1999 : 1676 : prompt, Zwischenverkauf v : Spanien : 10500 € : 1 : 335 mm : 750 mm : 165 mm : 42 mm : 175 mm : 250 mm : DIN55022-5 Nr. 4 : 60-2000 (9) 1/min : 0.05 - 0.75 mm/U : 0.025 - 0.375 mm/U : 0.5 - 7.5 mm : 60 : 245 mm : 120 mm : 48 mm : 3 MK : 140 mm : 2.2 kW : 1900 mm : 850 mm : 1485 mm : 880 kg 3-Jaw chucks Röhm Dm. 300 mm 4-fold steel holder with 4 inserts Chuck protection Cranking length 120 mm Sliding rotary guard with integrated machine lamp Rear chip splashboard Cooling equipment Lead screw and draw screw cover Foot brake User Manual in English COMPLIES WITH GERMAN UVV &, AUSTRIAN AMVO The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
usato
FAGOR 8055TM CNC Description: - Distance between points: 1,000mm - Point height: 260mm - Diameter over bench: 530mm - Diameter admitted on longitudinal carriage: 475mm - Diameter admitted over cross slide: 315mm - Bench width: 350mm - 2 spindle speed ranges: from 0-625 rpm and from 625 to 2500 rpm - Work advances Z and X axes in mm/min.: 0-7000 - Rod pitch: 72mm - DUPLOMATIC turret with 8 tools It has all the manuals for both the lathe and the Fagor cnc. All tool holders and chuck jaws seen in the photographs are included. In 2021 a retrofitting was carried out. - Bench grinding - Preset spindles and axis nuts + change of axis balls - Change bearings axles + belts
usato
Distance between centers: 1650 mm Centers height: 225 mm Max swing over bed: 440 mm Swing over cross slide: 260 mm Swing over gap: 640 mm Spindle hole diameter: 52 mm Gap length: 160 mm Spindle speeds: 12, 32-1800 rpm Motor power: 5.5 CV Equipped with: 3-jaw universal chuck: Ø 250 mm Set of jaws: 1
usato
- Distance between points: 1,000mm - Point height: 260mm - Diameter over bench: 530mm - Diameter admitted on longitudinal carriage: 475mm - Diameter admitted over cross slide: 315mm - Bench width: 350mm - 2 spindle speed ranges: from 0-625 rpm and from 625 to 2500 rpm - Work advances Z and X axes in mm/min.: 0-7000 - Rod pitch: 72mm - DUPLOMATIC turret with 8 tools It has all the manuals for both the lathe and the Fagor cnc. All tool holders and chuck jaws seen in the photographs are included. - Bench grinding - Preset spindles and axis nuts + change of axis balls - Change bearings axles + belts
usato
Codice Prodotto: 10314 Produttore: PINACHO Anno di costruzione: 2005 Tipo di controllo: Konventionell Luogo di stoccaggio: Halberstadt Paese di origine: Spagna Penna da viaggio: 180 mm Diametro tornibile: 630 mm Lunghezza di tornitura: 3000 mm Diametro di tornitura sul letto: 620 mm Movimento trasversale. (X-Axis): 365 mm Diametro penna contropunta: 72 mm Diametro di tornitura su slitta trasversale: 880 mm
usato
Tipo: S90/285-155 tornio a doppio mandrino! Distanza tra i centri: 2000 mm Oscillazione sul letto: 830 mm Oscillazione su slitta trasversale: 525 mm Diametro del foro mandrino principale: 155 mm Potenza sul mandrino principale: 7,5 kW Numero di velocità: 12 > 750 rpm Schermo digitale: sì Lunghezza: 3100 mm Larghezza : 1000 mm Altezza: 1800 mm Peso: 3 tonnellata
usato
Dotato di SK-kit: - cambio utensile automatico 8 posizioni - Tipo VDI - mandrino idraulico - contrappunto idraulico - centro idraulicoSwing over bed: 620 mm Oscillazione su slitta trasversale: 580 mm Distanza centro tot centro: 2000 mm Diametro del foro mandrino: 80 mm Potenza sul mandrino: 11 kW Numero di velocità: 1 > 2500 rpm Comando: Fanuc Cambio utensile: sì Numero di utensili: 8 posizioni
usato
Tornio in metallo prodotto da PINACHO tipo L-1/165Masch. -No: 11782Specifiche tecniche:Altezza punta: 165 mmDistanza tra i centri: 750 mmDiametro di rotazione sul letto: 330 mmDiametro di rotazione nella manovella: 480 mmForo mandrino: 42 mmSupporto mandrino: DIN 55022/518 velocità mandrino: 30 - 2000 rpm.20 avanzamenti: 0,047 - 0,86 mm / rev20 traverse: 0,021 - 0,39 mm / rev20 filettature metriche: 0,5 - 916 Filettature WW: 56 - 4 Gg / 1 20 filettatura modulo: 0,25 - 4,5 MDrive potenza: 2 / 3,8 HPDimensioni: 1645 x 820 x 1260 mmPeso circa.: 800 kgWith- Mandrino a tre ganasce 200 mm- Supporto in acciaio multifisso con inserti multipli- centro mobile appuntito, in buone condizioniPrezzo su richiesta. Consegna: franco magazzino o camion di carico senza posizione. Pagamento: netto al momento dell'acquisizione o su appuntamento. I dati tecnici non sono vincolanti. Errori esclusi. Saremo lie ...
usato
Pinacho Rayo 180 360 x 1000 mm CNCSwing over bed: 360 mm Oscillazione su slitta trasversale: 198 mm Distanza centro tot centro: 1000 mm Diametro del foro mandrino: 42 mm Alimentazione mandrino: 5,5 HP Numero di velocità: 100 > 4000 rpm Comando: Heidenhain Lunghezza: 2870 mm Larghezza: 1510 mm Altezza: 1550 mm Peso: 1,5 ton
usato
Altezza centro: 165 mmDisposizione del centro: 750 mmEsatto mandrino: 58 mmCNC Marca: FanucCNC Modello: Oi Mate MACH-id 5214 MAKE Pinacho Spagna TIPO SMART 6 Anno precedente 2009 Indicazioni Max. diametro di tornitura 335 mm DBC Lunghezza di tornitura 750 mm Asse X 700 mm Asse Y 250 mm Alesaggio mandrino 58 mm Velocità mandrino principale 4000 rpm Controllo FANUC Oi MATE - TC Ore 700 H dimensioni Lunghezza 2100 mm Larghezza 1400 mm Altezza 1600 mm
usato
Altezza centro: 225 mmDispositore del centro: 1150 mmEsao mandrino: 65 mmCNC Marca: FagorCNC Modello: 8055 PINACHO - MUSTANG 225 Ciclo Teach-In tornio 450 x 1150 mm MACH - ID 6349 Marca: PINACHO Tipo: MUSTANG 225 Controllo: Fagor 8055 Anno di costruzione: 2004 Oscillazione sul letto 450 mm Oscillazione su slitta trasversale 260 mm Lunghezza di tornitura DBC 1.150 mm Alesaggio mandrino 65 mm Potenza mandrino 8 kW Larghezza letto 300 mm Mandrino contropunta 58 Corsa pinole 115 mm Cono mandrino 4 Mk Velocità / gamme 3000 Rpm Velocità di avanzamento Asse X 7.000 mm Velocità di avanzamento Asse ...
Tipo: Smart Turn 5/260 Swing over bed: 560 mm Oscillazione su slitta trasversale: 315 mm Distanza centro tot centro: 3000 mm Diametro del foro mandrino: 80 mm Potenza sul mandrino: 11 kW Numero di velocità: 1 > 2500 rpm
usato
diametro di tornitura: 520 mm copertura di rotazione: 1625 mm controllo: FAGOR 800 TG largo del mandrino: 530 mm diametria di rotazione su supporto scorrevole: 475 mm altezza del centro: 260 mm largia letto: 350 mm esabbia mandrino principale: 68 mm velocità di rotazione: 1500 U/min traversa a rotaia: 5 m/min Drive: 10 kW potesse potenza totale: kW peso della macchina ca.: 1,87 t dimensioni della macchina ca.: 2,8x1,4x1,8 m
