HITACHI SEIKI macchina utilizzata in vendita

Fresatrice CNC Hitachi Seiki VK 55 II Numero macchina: 56008 Anno di costruzione: 1995 Picchiettando senza compensare il mandrino Tavola di serraggio: 1400 x 560 mm Max. distanza percorsa asse X, Y, Z: 1000 x 600 x 600 mm Gamma di velocità 60 – 8000 giri / min. Precisione di posizione: +-0,005 mm

Rettificatrice di tipo Gantry A cosa: Hiatachi Seiki Modello: 9GA-NRAA Tabella: 2500 x 1200 mm Max. Corsa al tavolo: 2000 mm Capacità: 1500 x 900 x 500 mm Controllo: Fanuc 15 MA Anno: 1995

A 3-axis horizontal machining center with approx. 150 additional tools. Tool magazine SK40: 61 places. Travel X/Y/Z: 600mm/580mm/580mm, max. tool size: 400mm x 400mm, max. tool weight: 400kg. Power: 35-12000rpm, rapid traverse X/Y/Z: 50m/min, feed speed: 1-50000mm/min. Dimensions X/Y/Z: approx. 4000mm/3700mm/2900mm, weight: approx. 400kg. Operating time: 73,974h, machining time: 25,714h, machining cutting hours: 21,591h. Cabinets for tools can also be handed in. Documentation available.

x-travel:900 mm y-travel:800 mm z-travel:710 mm control:Fanuc 16M spindle drive:18,5 kW turning speed range - stepless:20-4.500 1/min tool magazin::60 x SK 50 tool diameter:110 mm tool length - max.:400 mm max. tool weight:20 kg Table Indexing:360 x 1° ° size of pallet:630 x 630 mm type of pallet-changer:2-fach shuttle rapid traverse:20 m/min internal coolant system feed:50 bar total power requirement:54 kVA weight of the machine ca.:14 t dimensions of the machine ca.:2,65 x 4,43 x 2,95 m Reliable horizontal machining center will be sold with two additional pallets and fixtures

x-travel:560 mm y-travel:450 mm z-travel:450 mm table surface area:760 x 410 mm turning speed range:8.000 U/min Vertical Processing Centre

This Hitachi Seiki VS60 Vertical Machining center was manufactured in the year 2007. It is equipped with a Fanuc 16 M control unit. The machine has a spindle speed of 20000 rpm.

This HITACHI SEIKI 254Y Erosion machine was manufactured in the year 2003 in Japan. The machine has a wire feed rate of 20 to 300 mm/s.

Rotation diameter max. 360mm Turning length max. 500mm Seiki Seicos A 10L control maximum rotation diameter 450 mm main spindle: Speed range - main spindle 30 - 4,000 min/-1 Drive power - main spindle 11 / 15 kW Spindle assembly A2-8 maximum usable bar diameter 65 mm maximum spindle diameter 255 mm Distance spindle center - plane 1.015 mm racing: x-axis 265mm z axis 530mm C axis 360 Tool turret: Number of tool positions 10 pos. Outer diameter 25mm Inner diameter 32mm Type QCT / KV 40mm Tool holder no. 40 QCT Tool magazine: Number of tool places 12 pos. Maximum tool size 50 x 80/200 mm Maximum tool weight 6.0 kg Driven tool stations: Number of motorized tool stations 5 stations. Speed range - driven tool stations 100 - 3,000 min -1 Drive power - driven tool stations 5.5 / 2.2 kW Counter spindle equipped with C axis. Excellent supply of driven tool holders.

Axis control, electronic handwheel, control unit -The electronic handwheel was removed from a CNC machining center make: Hitachi Seiki type: HC400. Other spare parts available. -electronic handwheel for Hitachi Seiki type: HC400 -Dimensions: 170/120/H80 mm -Weight: 0.6 kg

Tool changer chain, chain magazine, tool changing system, tool magazine -The tool changer was removed from a CNC machining center make: Hitachi Seiki type: HC400. Other spare parts available. -Tool changer for: Hitachi Seiki type HC400 -complete with: gripper arm and drive -Tool change positions: 80 -Admission: SK -Dimensions: 2270/630/H1725 mm -Own weight: 860 kg

PLC, control panel, operator panel, control machine -The front of the control panel comes from: a Hitachi Seiki type HC400 machining center -Manufacturer: Hitachi Seiki -Control: FANUC -Dimensions: 400/310/H100 mm -Weight: 3.8 kg

Hitachi horizontal spindle machine tools, FANUC cabinet, type 16M, travels: X axis 820mm, Y axis 800 mm, Z axis 800mm, with 4th additional axis: B axis circular table 360 ​​degrees. Automatic tool changer with 90 tool locations, BT50 tool cone, 2-compartment pallet changing system, pallet dimensions 630 mm x 630 mm, max. 500 mm, tool weight max. 25 kg, spindle power 40 KW, max. speed. spindle rotation speed 10000 rpm, cooling system, central coolant supply.

HITACHI SEIKI VM 50 X-axis - 760mm Y-axis - 510mm Z-axis - 510mm Table size 1120x510mm CNC control - Seicos A10M

X: 300 mm Z : 620 mm Chuck : 10 inches Part conveyor Part catcher

HITACHI SEIKI TF25-1100 CNC 2 AXIS Seicos control (Fanuc based) Turning diameter 400 Turning length 1000 Self-centering chuck diameter 250 Turret 10 positions Tailstock in cycle Presetting Chip conveyor RS232 port Year 1999 Machine in production

turning diameter: 254 mm turning length: 380 mm control: Seicos total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Seicos CNC control C-axis driven tools 16-fold turret head Tool Eye tailstock chip conveyor coolant device Technische Daten / technical details: Umlaufdurchmesser über Bett / max rotary diameter over bed 450 mm max. Drehdurchmesser / max. turning diameter 254 mm max. Drehlänge / max. turning lenght 380 mm Planweg (x) / cross way (x) 230 mm Längsweg (z) / longitudinal way (z) 600 mm Drehzahlbereich / spindle speed 30-5000 UpM /rpm Werkzeugrevolver / turret head 16 fach /holes Eilgang x,z / rapid feed x,z 30/30 m/min Antriebsleistung Spindel / drive capacity spindle 11/7,5 kW Gewicht der Maschine ca. / weight 4800 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, acces ...
