Mitre dairesel testereler

saw blade diameter: 350 mmcutting length: 430 mmcutting diameter: 135 mmturning speeds: 3.800 U/minDust suction hood: 100 mmdimensions of saw-blade: 350 x 3,0/2,4 x 40 mmtotal power requirement: 3,0 kWweight of the machine ca.: 100 kgdimensions of the machine ca.: 1,6 x 1,0 x 2,0 m- Cross-cut and miter saws for cross-cut cuts- Miter adjustment on both sides (60 ° / 45 °), with fixed stop- Shift cut on one side up to 45 °, with fixed stop- Stable cast iron construction- Precise linear bushing guide on the tool slide hardened and ground steel shafts- manual saw feed- Saw blade infinitely adjustable in height- nozzle for opt. SuctionCutting data:- Cutting length at 90 ° = 430 mm- Cutting height at 90 ° = 135 mm- Cutting length at 45 ° = 310 mm- Cutting height at 45 ° = 92 mm Special accessories included:- 1x HM circular saw blade 350 x 3.0 / 2.4 x 40 mm Z = 108 FTZ neg. For aluminu ...

saw blade diameter: 410 mmcutting diameter: 170 mmturning speeds: 3.500 U/minDust suction hood: 100 mmdimensions of saw-blade: 420x3,2/2,4x40 mmtotal power requirement: 3,0 kWweight of the machine ca.: 120 kgdimensions of the machine ca.: 1,6 x 1,0 x 2,0 m- Cross-cut and miter saws for cross-cut cuts- Miter adjustment on both sides (60 ° / 45 °), with fixed stop- Shifter cut on both sides 45 °, with fixed stop- Stable cast iron construction- Precise linear bushing guide on the tool slide hardened and ground steel shafts- manual saw feed- Saw blade infinitely adjustable in height- nozzle for opt. SuctionCutting data:- Cutting length at 90 ° = 410 mm- Cutting height at 90 ° = 170 mm- Cutting length at 45 ° = 290 mm- Cutting height at 45 ° = 115 mm Special accessories included:- Adjustment of shifter cut via hand crank, both. adjustable (45 ° / 45 °)- HM circular saw blade 420x3.2 ...

saw blade diameter: 420 mmcutting diameter: 200 mmCutting height at 45°: 140 mmhole of sawblade: 50 mmtotal power requirement: 5,0 kWDust suction hood: 100 mmweight of the machine ca.: 310 kg.range L-W-H: 1,6 x 1,0 x 2,0 m- Cross-cut and miter saws for cross-cut cuts- Miter adjustment on both sides (60 ° / 45 °), with fixed stops- Shifter cut on both sides (60 ° / 45 °), with fixed stops- Stable cast iron construction- Precise linear bushing guide on the tool slide hardened and ground steel shafts- manual saw feed- Saw blade infinitely adjustable in height- nozzle for opt. SuctionFurnishing :- 5 kW motor- Saw blade can be tilted via handwheel and worm gear (Schifters cut)- Saw blade diameter 520 mm- Saw blade mounting hole 50 mm- Saw blade speed 2,800 rpm- 400 volt / 5 kW (S6 / 40%) motor with brake and automat. Star-delta motor connection- Machine weight approx. 250 kgCutting dat ...

Graule ZS 200N Cutting and miter circular saws Motor 400 V / 3.0 kW Speed 2800 rpm Cutting length 420 mm (at 90°) Cutting height 200 mm (at 90°) Miter range: horizontal 45°-90°-20° Miter range: vertical 60° -90°-45° Saw blade s. 520 mm Suction nozzle 100 mm Weight 310 kg G&GA-ZS200N-3KW Underframe optional

Manufacturer: H&M HM-ZN 8000-R automatic miter and beam saw Type: ZN-8000 R Motor: 6 kW Saw blade: ø600 - ø700 mm Axle: ø30 Saw height: 250mm Angle adjustment: 0 dead 180° Tilt: 0 tot 45° Zenter line: 200mm Printer: 2 boven- en 2 zijdrukkers Feed table: 9500mm Export table: 6000mm Table castors: Incoming and outgoing conveyors are driven Feed: 55 m/min. Length stop rack with 0.4 m/s feed Repeatability: 0.1 - 1 mm (naar wens instelbaar)\ Noise: 81 dB Suction: ø200 mm weight 1350KG Powers: 380V, 3 Ph, 35A + 220 V, 16A

saw blade diameter: 350 mmcutting diameter: 120 mmcapacity 45 degrees: flat: 180 x 50 mmcapacity 45 degrees: round: 116 mmcapacity 90 degrees: flat: 200 x 80 mmcapacity 45 degrees: square: 100 x 100 mmcapacity 90 degrees: square: 105 x 105 mmcapacity 90 degrees: round: 120 mmweight of the machine ca.: 266 kgFurnishing:- Aluminum circular saw with manual clamping device- machine base- without saw bladeThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Double mitre saw OMS INVINCIBLE OK Maximum cutting length 3000mm Maximum cutting width 140mm Units adjustable at an angle of 45/-45° Motor power: 2×2.2kw Saws 320mm Pneumatic material clamping Net price

This machine was specially to the grooves and separation of Built in the front of the drawer. On these machines panels can generally be tongued and divided.

The U2PRW mitre and drill is designed for processing slats and furniture fronts made of solid wood or MDF. The machine tool operates in a semi-automatic cycle. During one cycle, the machine performs: cutting at a given angle (in the range of 45 - 90 degrees) and drilling in a jammed plane or edge of the element. – made in Poland TECHNICAL PARAMETERS: Max. height of the material to be cut: 60 mm Max. width of the material to be cut at an angle of 45° 70 mm Max. material width at 90° 150 mm Max. length of cut material 2200 mm Min. length of cut material at 45° 455 mm main saw diameter 250 or 300 mm scoring diameter 100 mm Max. bottom cutter diameter 35 mm Max. bottom milling depth 15 mm seating diameter of face drills and bottom milling cutter 10 mm Drill head (face drilling): 4 spindles spindle axial spacing 32 ; 32 ; 40 mm Linear spindle system Max. face d ...
