Specifications BT 6 FREQUENCY Drilling capacity in E 335 0.5 - 6 mm Spindle B 12 Drilling depth 55 mm Radius 177 mm Spindle / Base Plate 135 to 404 mm Base plate 296 x 349 mm T-slot width 12 mm Column diameter 75 mm Total height 810 mm Weight 85 kg Motor frequency-controlled 0.55 kW Grid connection 230 V / 50 Hz Spindle speeds infinitely variable 1,000 - 9,000 rpm Standard packaging A - 89x52x127 cm
Drilling machine, column drilling machine, pillar drilling machine, pillar drilling machine, multi-spindle head, multi-spindle drilling head, drilling gear -with two-spindle drilling head Manufacturer Sigloch Schrieder Type: V602 -Drive power: 1.02/0.88 kW -Drill distance adjustable: 18-110 mm -Max. Drill: 2x Ø 6 mm -Table size: 275 mm -Spindle mount: MK3 -Projection: 220 mm -Speeds: 100-2900 rpm -Columns: Ø 100 mm -Spindle stroke: 75 mm -Transmission -Dimensions: 900/400/H1910 mm -Weight: 230kg
Computer cabinet, server cabinet, control cabinet, network server cabinet, computer housing-Manufacturer: RITTAL-Type: IT Solutions TE 7000-390-Field of view: 400 x 400 mm-Number: 1x cabinets available-Price: per piece-Dimensions: 600/600/H580 mm-Weight: 40 kg
Automatic drill, drill press, drill press, stand drill, pillar drill-Spindle mount: MK 3-Transmission-Automatic drill: with rapid traverse-Automatic drilling-Threading: automatic-Table size: 450 x 360 mm-Projection: 285 mm-Spindle stroke: 150 mm-Speed: 180-2000 rpm-Feed: 0.08-0.32 mm/rev-Dimensions: 900/1000/H2100 mm-Weight: 840 kg
bench drill, pillar drill, column drill -Recording: MK2 -Protrusion: 260 mm -Travel distance: 190 mm -Speeds: 435 - 4350 rpm -Column diameter: 80 mm -Spindle stroke: 70 mm -Motor power: 450 W -Base plate: Sheet metal plate -Dimensions: 645/635/H780 mm -Weight: 130 kg
Multi-spindle head, multi-spindle drill head, drilling gear- Joint multi-spindle head-max.: x drill-3x built-in drill collet: mm-min. Distance drill: mm-Weight: 11.3 kg-Articulated multi-spindle heads are variable tools: for various machining operations such as drilling, thread cutting, ountersinking, reaming, milling, turning, with which several holes can be machined at once.
Drill, column drill, column drill, pillar drill, box column drill, tapping machine, tapping machine -Manufacturer: HIW Helmerding, drill press -Motor: 1.0/1.6kw -Speeds: 95 - 1050 rpm, 8 levels -Feed: 0.08/0.16/0.28 1/rev. -Table size: 500 x 400 mm, travel 685 mm -Spindle mount: MK3 -Spindle stroke: 180 mm -Projection: 280 mm -Dimensions: 1100/650/H2340 mm -Weight: 690 kg
Multi-spindle head, multi-spindle drill head, drilling gear-Joint multi-spindle head-Max. x drill-7x drill built-in collet: mm-min. Distance drill: mm-Weight: 11.3 kgArticulated multi-spindle heads are: variable tools for various machining operations such as drilling, thread cutting, countersinking, reaming, milling, turning, with which several holes can be machined at once.
Magnetic drill, hand drill-Magnetic base: Magnetor type PS 32 L-Drilling machine: AEG type HBE-IV- Recording: MK2-Max. Drill: Ø 23 mm -Connection: 265V/200Hz-Dimensions: 700/300/H670 mm-Weight: 49 kg
Morse taper sleeve, tool holder, Morse taper, Morse cone, taper sleeve, adapter, extension sleeve, reducing sleeve, cone sleeve, adapter sleeve, spindle sleeve-Manufacturer: Artykuly Techniczne, adapter sleeve: Morse taper sleeve MK6/5-Type: PTPk-6/5-Dimensions: Ø 64/130 mm-Weight: 1.5 kg
Multi-spindle head, drill beam, multi-spindle drill head, articulated multi-spindle head, row drilling machine, dowel drill head, dowel drilling machine, drilling gearbox -Number: max. 3x drill bits -Recording: M8 -right/left: rotating alternately -Drill bit spacing: 32 mm -Number: 1x drill heads available -Price: per piece -Dimensions: 140/75/H95 mm -Weight: 3 kg
Drilling machine, drill press, pillar drill, column drill -Condition: Working -Note: Clamping table repair-welded, see pictures -Manufacturer: Flott, column drill type SB 15 -Spindle mount: MK2 -Motor: 0.525 kW -Speed adjustment: via V-belt -Speed speeds: 215 - 400 - 730 - 1250 - 2300 - 4300 rpm -Table size: 220 x 220 mm -Spindle holder: MK2 with drill chuck -Travel: 360 mm -Spindle stroke: 55 mm - Throat: 295 mm -Column Ø: 100 mm -Accessories: collecting tray for coolant -Dimensions: 930/700/H1805 mm -Weight: 190kg -Handover: in current condition as seen
Drill press, bench drill, column drill, pillar drill-Manufacturer: TOS, high-performance column drilling machine type 40 TF / C-Motor: MEZ 2.2 kW-Speeds: 56 - 2240 rpm-Table size: 400 x 315 mm, travel 600 mm-spindle taper: MK4-Spindle stroke: 165 mm-Projection: 290 mm-Pillar Ø: 140 mm-Dimensions: 1200/650 / H1990 mm-Weight: 602 kg
handheld terminal, handheld control device, operating unit, control panel, operating panel, operating unit, operating device, programming device-Manufacturer: Siemens, Simatic S5 operator panel-Type: OP 393 III 6ES5393-OUA 15-Protection class: IP 50-Number: 2x control unit available-Price: per piece-Dimensions: 148/320/H55 mm-Weight: 0.7 kg/piece
