Cnc portal freze makineleri

Key data: 4000 mm, 2000 mm, 1200 mm

CNC gantry machining center AWEA LG4020 with Heidenhain 640I control and interchangeable universal head. Machine is immediately free and available. Dismantling and loading onto suitable trucks is possible at a reasonable price. Installation and commissioning on request.

Key data: 3000 mm, 1600 mm, 730 mm

CNC gantry machining center AWEA LP3016YF with Fanuc control very good condition immediately available. Dismantling and loading onto suitable trucks is cost-effective. Installation and commissioning on request.

Key data: 3000 mm, 1600 mm, 900 mm

CNC gantry machining center AWEA SP3016 with Fanuc control. Table load 10000 kg very good condition immediately free. Dismantling and loading of suitable trucks can be carried out cost-effectively. Installation and commissioning on request.

Brige Type Milling Machine Manufacturer AWEA Model VP 2012 Year 1998 CNC SIEMENS 810D Table Surface 2.200 x 1.100 mm Max weight allowed on table 3.500 kg. Longitudinal travel (X Axis) 2.000 mm Cross travel (Y Axis 1.200 mm Vertical travel (Z Axis) 760 mm Distance between columns 1.300 mm. Rapid Traverse (X Axis) 15 m/min. Rapid Traverse (Y, Z Axis) 12 m/min. Taper BT-50 Main spindle speed 5.000 r.p.m. Main spindle power 37 kVA Speed ranges 2 Automatic tool changer (ATC) INCLUDED Positions in tool magazine 30 Internal coolant 20 BAR INCLUDED Coolant deposit capacity 1000 l Portable handwheel INCLUDED 2 longitudinal chip conveyor INCLUDED Cross chip conveyor INCLUDED Rigid taper INCLUDED Total power 40 kVA Machine Weight 16.000 kg. Large amount of tools and accessories INCLUDED

x-travel: 2400 mmy-travel: 1500 mmz-travel: 810 mmControl: Heidenhain iTNC530 total power requirement: kWweight of the machine ca.: 7.8 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

First commissioned: 2006 Control: Fidia C20 incl. handwheel X-axis: approx. 7,000 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,751 mm A-axis: + 125° / - 95° C-axis: ± 275° Clamping table Clamping surface: approx. 6,000 x 2,000 x 400 mm Head Spindle power: 20 kW Spindle speed: max. 20,000 min-1 Tool holder: HSK 63A Tool tensioning: hydraulic Drives Linear axes Feed speed X-, Y-, Z-axis: 65 m/min Axle acceleration X-, Y-, Z-axis: 5 m/s2 Connection data Connected load: approx. 150 KW Dimensions, weights Space required Machine with protective cabin Dimensions: approx. 12,200 x 6,300 x 5,800 mm Total weight: approx. 105,000 kg Auxiliary - 20-fold tool changer - Engine room surveillance (camera) Options at extra cost: - Renishaw RMP60 probe - Fidia HMS System Condition of the machine Fully functional, very good condition

x-travel: 6000 mmy-travel: 2500 mmz-travel: 950 mmdistance between columns: 2400 mmHeight of spindle: 1200 mmbed width: 2115 mmbed length: 6000 mmtable load: 4 t/m2rapid travel x/y/z: 10000 mm/minfeeds infinitely variable: 1-3000 mm/minRated capacity of drive motor: 20 kWCross cut of slide: 320x340 mmPositioning increment: 2.5 °Turning speeds stepless: 10-3200 U/minTool tapers: ISO 50 tool piece magazine with: 20 Control: NUM 1060 total power requirement: 60 kVAdimensions of the machine ca.: - mweight of the machine ca.: - tequipped with:- CNC - Control NUM 1060- ATC with 20 tools(ISO 50)- 2-Axis Milling Head 2,5° x 2,5°- Covering- Cooling through Spindle 15bar- Chip ConveyorThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 3000 mm, 2000 , 900

CNC gantry machining center Hartdford HB 3190 A with Fanuc control year of manufacture 2005, table load 10000 kg. Dismantling and loading onto suitable trucks is cost-effective. Installation and commissioning on request.

Key data: 3000 mm, 2000 mm, 900 mm

CNC gantry machining center Hartdford HB 3190 A with Fanuc control Year of manufacture 2005 Table load 10000 kg. Dismantling and loading onto suitable trucks is cost-effective. Installation and commissioning on request.

x-travel: 3000 mmy-travel: 4000 mmz-travel: 1500 mmControl: Heidenhain TNC 430 M total power requirement: 120 kVAweight of the machine ca.: tdimensions of the machine ca.: m3/5 axes CNC portal milling machine with integrated C-axisand changeable milling heads.The machine had a purchase price of € 1.4 million in 2002.An inspection in the sellers plant under power is possible afterprevious appointment.Condition:The machine was overhauled in 2018, costs of over € 100.000,-.- Drives of the X-axis renewed- New hydraulic power unit- Complete electrical wiring renewed- Spindle cooling unit new- 2 pieces longitudinal conveyors new- Coolant pump new- Cover complete X-axis new- Bellows Y-axis new- Exchange measuring ruler X-axis- Fork head spindle bearing newBelleville spring assembly newDrive motor A-axis newSpindle cone ground- Overhaul milling gear (2020)Working rangeTravelsX-axis 3000 mm ...

Inv. Num. : 7187 Type: Varimat VD 2000 Producer: KOLB Created: 1995 Parameters: Operating system: SIEMENS Sinumerik Axis X: 6000 mm Axis Y: 2400 mm Z axis: 1100 mm Weight: 83000 kg

x-travel: 6200 mmy-travel: 1500 mmz-travel: 508 mmControl: Mazatrol type: M 32 workpiece height: 708 mmTool changer: 60 spindle taper ISO: 50 table surface area: 6200x750 mmtotal power requirement: kWweight of the machine ca.: tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3200 mmy-travel: 1400 mmz-travel: 508 mmtable surface area: 3000x1250 mmcolumn daylight: 1500 mmturning speeds: 35-5000 U/minspindle taper ISO: 50 control: Mazatron M PlusTable load: 5000 kgTool changer: 30 chip conveyor: The tech. Data are manufacturer or operator information and therefore for usnot binding. We reserve the right to prior sale, it applyonly our businessand conditions of sale.About Usmore than 400 own machines in stockover 12000 m² storage area, crane capacity 70 tmore than 10000 articles accessories for your workshopYou want to sell machines, production lines or your company,Then contact us.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 5000 mmy-travel: 3600 mmz-travel: 710 mmw-axis: 1250 mmMain spindle:: turning speed range - main spindle: 12000 min/-1power capacity - main spindel: 45 kWtool taper: HSK work table:: table surface area: 2100 x 4000 mmmax. workpiece weight: 43 tcolumn daylight: 2750 mmdistance table - lower edge spindle: 1880 mmTool-Presetter:: number of toolpositions: 60 pos.tool taper: HSK feeds:: 8000 mm/minrapid traverse ( X / Y / Z ): 30/30/30 m/minrapid traverse: W: 3 m/mincontrol: Mazatrol SmoothX ram head dimension: 450 x 450 mmb-axis: -100 / +100 °c-axis: +/- 180 °total power requirement: 105 kVAweight of the machine ca.: 65 tdimensions of the machine ca.: 7,6 x 12,6 x 6,65 mDouble-column, 5-Axis simultaneous Machining Center equipped with:- CNC-Control Mazatrol SmoothX- simultaneous 5 Axis Control Function- Relocation Detectro- Chip Conveyor- Hi-Pressure Coolant / Coolant through  ...

X-axis: 13,000 mm Y-axis: 4,500 mm Z-axis: 1,000 mm Distance between stand: 6,500 mm C-axis: 190º A-axis: 110º Rapid speed XYZ: 15,000 mm/min. Rapid response AC: 10 tpm CNC control: Siemens 840D Spindle mounting: HSK A63 Spindle speeds: 30,000 rpm. Spindle power: 20 kW Tool changer: 20 positions Torrestool tables: 16 pieces X-axis: 11,500 mm Y-axis: 3,500 mm Z-axis: 750 mm Country of origin Spain Machine dimensions LxWxH: 19,000 x 11,000 x 6770 mm Machine weight: 70,000 kg

x-travel: 31000 mmy-travel: 4310 mmz-travel: 1500 mmcolumn daylight: 4000 mmMain spindle:: turning speed range - main spindle: 16000 U/minpower capacity - main spindel: 34 / 44 kWtool taper: HSK A63 c-axis: +/- 360 °A-Axis: +/- 110 °Distance table surface - crossbeam bottom: 2570 mmwork table:: table surface area: 30000 x 3000 mmmax. workpiece weight: 16 tTool-Presetter:: number of toolpositions: 120 pos.tool taper: HSK A63 rapid traverse ( X / Y / Z ): 20 / 20 / 16 m/mincontrol: Heidenhain iTNC 530 total power requirement: - kVAweight of the machine ca.: 100 tdimensions of the machine ca.: 32 x 7,3 x 6,5 munused 5 Axis Gantry Machining Center with moving Portal.The direct driving method using a torque motor eliminates precision problemscaused by wear over time and by installing encoders on the torque motor side ofthe A and C axes, the actual turning angle can be accurately controll ...

Brige Type Milling Machine Manufacturer NICOLÁS CORREA Model FP 30/30 ATC Year 2000 CNC HEIDENHAIN TNC-426 Table surface 3.000 X 1.250 mm Max weight allowed on table 10.000 kg. Longitudinal Traverse (X Axis) 2.500 mm Transversal Traverse (Y Axis 2.000 mm Vertical Traverse (Z Axis) 800 mm Distance Between Columns 1.740 mm. Rapid Traverse X Axis 15.000 mm/min Rapid Traverse Y , Z Axis 12.000 mm/min Max. Working Feed 7.500 mm/min Taper ISO-50 Direct Output Head Speed 5.000 r.p.m. Main Motor Power 22 kW Speed Ranges 2 Internal coolant (12 Bar) INCLUDED Automatic tool changer INCLUDED Positions at tool magazine 30 Soluble Oil Lubricant Tank With Filter Paper + Magnetic INCLUDED External Electrospindle 18.000 rpm + Coolant INCLUDED 90º angle head MIMATIC INCLUDED Double rear chip conveyor INCLUDED Portable handwheel HEIDENHAIN HR-410 Machine Weight 25.500 kg. Large ...

Table Surface 3.000 X 1.250 mm Longitudinal Traverse (X Axis) 2.500 mm Cross Traverse (Y Axis) 2.500 mm Vertical Traverse (Z Axis) 1.000 mm Distance Between Columns 2.000 mm. Rapid Traverse (X Axis ) 15 m/min. Rapid Traverse (Y ,Z Axis) 12 m/min. Max. Working Feed 5 m/min. Head Type ORTOGONAL UDG-40 Orthogonal Milling Head indexing every C Axis Indexing 2.5º B Axis Indexing 2.5º Taper ISO-50 / DIN 69871 A Spindle Speed 50- 2.000 r.p.m. Range Speeds 2 Ranges ATC INCLUDED Nº Positions ATC 10 TOOLS Coolant Through Tools 15 BAR INCLUDED Spindle Motor 30 KW. Total Power Requirement 44 kW Year 1997 CNC Heidenhain TNC 426 Carrying Load Table 10.000 Kg. Machine Weight 24.000 Kg. Portable Handwheel HEIDENHAIN HR 410

Manufacturer NICOLAS CORREA Model FP 40/40 Year 1997 CNC HEIDENHAIN TNC 426M Table Surface 4.000 x 1.250 mm T slots 8 x 22 mm. Distance between T slots 150 mm. Max weight allowed on table 10.000 kg. Longitudinal Traverse (X Axis) 3.500 mm Cross Traverse (Y Axis) 2.500 mm Vertical Traverse (Z axis) 1.000 mm Distance Between Columns 2.300 mm Rapid Feed (X Axis) 15.000 mm/min Rapid Feed (Y,Z Axis) 12.000 mm/min Max. Working Feed 5.000 mm/min Taper ISO-50 Direct Output Head Speed 5.000 r.p.m. Speed Head 45º 3.000 r.p.m. Main Engine Power 22 kW Speed Ranges 2 Manual Support Hidden at the Right Side for Head 45º INCLUDED Chip conveyor INCLUDED Portable Handwheel INCLUDED Total power 37 kW Machine Weight 23.700 kg

Manufacturer NICOLÁS CORREA Model FP50/80 New in Year 2010 CNC HEIDENHAIN iTNC-530 5 ejes Table Surface 8.500 x 2.500 mm Max weight allowed on table 35.000 kg. Travels (X/Y/Z) 8.000/3.800/1.250 mm Distance between columns 3.100 mm Max distance table to under bridge 2.100 mm Min/max distance table to spindle 500-1.750 mm Rapid feed (X Axis) 10.000 mm/min Rapid feed (Y,Z Axis) 12.000 mm/min Max. Working Feed 7.000 mm/min Automatic head C5 E INCLUDED Number of continuous axis 2 B-Axis head swivel ± 190º C Axis head rotation ± 360º Spindle taper ISO 50 Spindle speed 4.000 r.p.m. Spindle motor 37 Kw Spindle Torque 718 Nm Speed Range 2 Automatic tool changer INCLUDED ATC positions 30 Portable Handwheel INCLUDED Thermal growth compensation system INCLUDED Machine dimensions 19.370 x 5.850 x 5.970 mm. Machine Weight 93.000 g.

CONTROLLER : FAGOR WIDTH: 6046 MM DEPTH: 2700 MM HEIGHT: 5490 MM WEIGHT: 40000 KG TABLE SIZE : 2500X2000 MM SPINDLE SPEED: 24000 1/MIN NUMBER OF AXIS: 5 X-AXIS MOVEMENT: 4000 MM Y-AXIS MOVEMENT: 2500MM Z-AXIS MOVEMENT: 850 MM

5 axis CNC – portal profile machining center for all materials - aluminum - steel - stainless steel - plastics - non-ferrous metals. Drilling + tapping, flow drilling, milling + thread milling, as well as sawing at free angles – for example, steel profile saws up to 6 mm wall thickness Largest saw blade diameter 500 mm Largest machining length 7,000 mm Largest workpiece cross-section 650 x H 300 mm Working range in five-axis operation 6,400 mm x 480 x H 300 mm Spindle drive power 17 kW at 100% ED Milling spindle speeds up to 24,000 rpm Moving tool magazine for 12 tools Tool holder HSK 63 Rapid speeds up to 100 m/min / acceleration 2.5 G Space requirement (including control cabinet and control panel) approx. 9 m x 2.5 m x H 2.6 m Weight approx. 5,000 kg. equipment: - OSAI® CNC control - YASKAWA® feed drives and feed controllers - HITECO® milling spindle wit ...

x-travel: 13500 mmy-travel: 6500 mmz-travel: 1500 mmw-axis: 6000 mmtable-size: 18000 x 4500 mmdistance between columns: 5200 mmworkpiece weight: 300 tspindle turning speed range: 4 - 600 U/minspindle taper ISO: ISO 60 spindle motor: 62,5 (x2) kWfeeds x/y/z -stepless: 1- 10000 / 3000 mm/minControl: Siemens 840D PL ram diameter: 700 x 700 mmtotal power requirement: - KVAweight of the machine ca.: - tdimensions of the machine ca.: - mModernization in 11/2014- CNC control Siemens 840 D pl- Coolant system- 5 headsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Warehouse number: 3686 PROCESSING Manufacturer: Takumi , Type: B8 Machine NO.: P0127, Year of construction: 2002 Specifications: Table size 1320 x 800 mm Longitudinal movement (X) 1200 mm Transverse movement (Y) 800 mm Vertical movement (Z) 500 mm Spindle speeds 20,000 rpm Spindle motor 15 Kw Tool changer 20 places Tool holder HSK-60A Rapid traverse XYZ 30 m/min Control Siemens 840D Fabr. Controlled in axes 3 Portal Type Accessories: Cooling water system. Length: 3550 mm, Høhe: 2770 mm, Width: 2260 mm, Weight: 6.850 kg

x-travel: 3.000 mmy-travel: 1.600 mmz-travel: 1.200 mmcontrol: HEIDENHAIN iTNC530 HSCI B-axis (swivelling head): +/- 100 °C-axis (milling head rotation axis): +/- 240 °feed and rapid traverse: : rapid feed Y,X,Z: 40.000 m/minRapid traverse B- and C-Axis: 50 rpmAccelerations (X, Y and Z): 4 m/s²Machine table:: : Clamping surface: 3.500 x 1.750 mmT-slots: 27 x 22 mm H12 T-slot - distance: 125 mmmax. workpiece load: 7.000 kg/m2Max. distance table to spindle nose: 1.356 mm2-Axis Fork Milling Head T21C: turning speed range:: 10- 24.000 min-1Drive power (S1/S6):: 42/50 KWTorque (S1/S6):: 67/84 NmTool bore: HSK-A 63 tool magazin:: : number of tools: 50 tool holder: DIN 69873 HSK A63 Max. Ø tool: 115 mmmax. tool-Ø adjacent slots free : 125 mmmax. tool length: 300 mmmax. tool weight: 12 kgcoolant equipment: : tank capacity: 1.400 lconnected load: voltage: 3x 40 V 50 Hz power requirement:  ...

Inv. Num. : 7015 Type: 17-10 FP NC/5 Producer: Waldrich Coburg Created: 1985 GO 2011 Parameters: 3D control system: Siemens Sinumerik 840 Table length: 5000 mm Table width: 2500 mm Max. workpiece weight: 60 t Weight: 125 t GO: 1997 2008 2011

travel -x axis: 7.200 mmtravel -y axis: 4.200 mmtravel -z axis: 1.750 mmControl: 840D sl daylight: 2300 mmdistance between columns: 3500 mmsize of pallet: 5000 x 3000 mmtable load: 65 tmilling drive: 50 kWspindle taper: ISO 60 c-axis: 7500 Nmspindle diameter: 150 mmturning speed range - milling: 10 - 4000 U/minfeed - rapid adjustment: 10 - 15000 mm/minb-axis: +/- 90 °total power requirement: 92 kWweight of the machine ca.: 380 tPlaner-Type Milling M/C - Double Column | WALDRICH COBURG - 15S - 10 FPF 300 NC- heavy-duty double-column milling machine (molds and dies)- 2 pallet stations with 2 pallets (load 65to each)- 2009 retrofit to SIEMENS 840Dsl (including complete electric wiring and new switch cabinet)- in 2011 change of all servo drives- 50kW NC universal milling head (2.5deg Hirth)(WALDRICH USP300C450F15S)- 40kW NC-forkhead (2-axis)(WALDRICH UFN00SZ500) - various (angular) milling ...

x-travel: 6600 mmy-travel: 3200 mmz-travel: 1000 mmw-axis: 1750 mmControl: Siemens 840 D column daylight: 2650 mmdistance spindle nose and table: 2500 mmtable surface area: 6400 x 2250 mmtable load: 50 ttool taper: ISO 60 spindle turning speed range: 5 - 2000 U/mintable feed: 10 - 15000 mm/minfeeds crossrail-slide horizontal: 10 - 10000 mm/minfeed: (W) 10 - 2000 mm/minspindle motor: 55 kWtotal power requirement: 85 kWweight of the machine ca.: 125 tdimensions of the machine ca.: 18 x 9,5 x 6,5 mMachine general overhauled and equipped with SIEMENS 840 D control in 2003- new digital motors, drive controllers, measuring systems and switch cabinet- tool changer for 60 tools (45 ISO 50, 15 ISO 60)- 3 angular milling heads (HSD 175, WFD 800) with service device 4 x 90 deg.indexing- hydrostatic table guideways- adjustable crossrail- 2 tables coupled- chip conveyor- coolant deviceMachine can be  ...

x-travel: 22000 mmy-travel: 7500 mmz-travel: 1750 mmw-axis: 4400 mmdistance between columns: mmtable load: 500 tmilling slide: 105 kWspindle turning speed range: 2000 U/minmax. torque on the spindle: 13 kNmtool taper: feed in x - axis: 10000 mm/minfeed in y - axis: 10000 mm/minfeed range Z-direction: 10000 mm/mintable-size: 22000 x ? mmcontrol: Siemens 840C ram head dimension: 600 x 600 mmworkpiece height max.: 5300 mmtotal power requirement: - kVAweight of the machine ca.: - tdimensions of the machine ca.: - mPortal milling machine equipped with:- CNC control Siemens 840C- tool magazine- Head changing station with X-stations- Coolant system with paper belt filterThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 12200 mmy-travel: 4400 mmz-travel: 1000 mmw-axis: 2320 mmdistance between columns: 3700 mmtable load: 200 tmilling slide: 120 kWspindle turning speed range: 6 - 750 U/minmax. torque on the spindle: kNmtool taper: ISO 50 / 60 feed in x - axis: mm/minfeed in y - axis: mm/minfeed range Z-direction: mm/mintable-size: 11000 x 3200 mmcontrol: Siemens 840C ram head dimension: 600 x 600 mmworkpiece height max.: mmtotal power requirement: - kVAweight of the machine ca.: - tdimensions of the machine ca.: 33 x 12 x 7,1 mPortal milling machine equipped with:- CNC control Siemens 840CThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 15300 mmy-travel: 4950 mmz-travel: 1000 mmw-axis: 3682 mmdistance between columns: 5100 mmtable load: 400 tmilling slide: 120 kWspindle turning speed range: 5 - 600 U/minmax. torque on the spindle: kNmtool taper: ISO 50 / 60 feed in x - axis: mm/minfeed in y - axis: mm/minfeed range Z-direction: mm/mintable-size: 15000 x 4500 mmcontrol: Siemens 840C ram head dimension: 600 x 600 mmworkpiece height max.: mmtotal power requirement: - kVAweight of the machine ca.: - tdimensions of the machine ca.: 41 x 13,7 mPortal milling machine equipped with:- CNC control Siemens 840C- Head changing station with X-stations- Coolant systemThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 19000 mmy-travel: 7600 mmz-travel: 2000 mmw-axis: 5000 mmtable surface area: 18500 x 5000 mmtable load: max. 500 tdistance between columns: 5500 mmpower capacity - milling spindle: 110 kWtool taper: CAT #60 Control: FANUC 15i MB total power requirement: - kWweight of the machine ca.: 650 tdimensions of the machine ca.: - mOverhauled & modernized in 2007equipped with:- CNC control FANUC 15i MB- 5 headsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 11200 mmy-travel: 3130 mmz-travel: 1000 mmControl: NUM 1060 W A-axis: +- 120 °c-axis: +215/-210 °spindle motor: 15 kWspindle taper: HSK-F63 turning speeds: 24000 U/mintable width: 1500 mmtable length: 9400 oder 2x3000 mmtotal power requirement: kWweight of the machine ca.: 20 tdimensions of the machine ca.: 14,6x5,0x4,225 mUse:e.g. for processing aluminum panels, drilling profiles, advertising (signsmilling, etc.), mold construction (prototypes) and processing of light steel frames / -beams using HSC millingThe vertically arranged high-frequency milling spindle for automaticTool change is mounted in a fork head on the Z-axis plate. TheSpindle can be moved with the fork head in 2 NC axes, in the A axisand the C-axis. The vertical movement is carried out via the Z-axis.Liquid cooling via a cooling unit.Tool magazine: moving plate changer in the potal, outside theWork areaMinim ...

Manufacturer ZAYER Model TEBAS-5000 Year 2013 CNC HEIDENHAIN iTNC-530 HSCI Table Table Surface 5.200 x 2.200 mm. Max. weight allowed on table 25.000 kg. Max distance from 45º head nose to table in vertical position 1.410 mm. Max distance from 45º head nose to table in horizontal position 1.465 mm. Max distance from direct exit head nose to table in vertical position 1.420 mm. Travels and feeds Longitudinal Traverse (X Axis) 5.000 mm. Transversal Traverse (Y Axis) 3.750 mm. Vertical Traverse (Z Axis) 1.250 mm. Distance between columns 3.000 mm. Rapid Traverse 50.000 mm/min Max. Working Feed 30.000 mm/min Headstocks Universal Auto Indexing Head 45º 0.001º/0.001º Taper DIN 69871 AD 50 Spud ISO 7388-2 B 50 Spindle speed 6.000 rpm Speed ranges 3 Main spindle power 43 kW Direct output head reduction 1-2,29 INCLUDED Taper DIN 69871 AD 50 Spud ISO 7388-2 B 50 S ...

First commissioning: 2016 Control: Heidenhain iTNC 530 incl. handwheel HR 520 X-axis: approx. 2,500 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,250 mm A-axis: ± 110° C-axis: ± 300° Clamping table Clamping surface: approx. 2,500 x 3,250 x 400 mm 2-axis milling head VH30 Spindle power: 60 kW Spindle speed: max. 22,000 min-1 Torque: 95 Nm Tool holder: HSK 63A Tool tensioning: hydraulic Coolant supply: outside and inside Blowing air: Outdoor Drives Linear axes Feed speed X-, Y-, Z-axis: up to 60 m/min Axle acceleration X-, Y-, Z-axis: up to 5 m/s2 Connection data Connected load: 190 kVa Fuse: 315 A Dimensions, weights Space requirement machine with peripherals: approx. 10,000 x 9,000 x 5,650 mm Total weight: approx. 55,000 kg Colour Housing, portal, control cabinet: RAL 7035 light grey Milling head and applications: RAL 6038 luminous green  ...
