usato
tube diameter: 60 mmwall strength: 3 mmbending radius min.: 2 x Rohr-Ø ÷ R200 mmbending angle: 0 - 180 °gas tube pipelines: 2 (60.,3mm) mmspeed: stufenlos 0,5 - 2,0 total power requirement: 1,5 kWweight of the machine ca.: 0,7 t- Powerful mandrel bending machine up to 2 gas pipe (60.3mm) in semi-automatic design (6000 mm pipe slide length)- Electromechanical drive of the bending axis- hydraulic clamping- mandrel feed / extract- 30 programs x 9 bending angle + correction angleThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
Produttore: Kottmann & Berger Tipo: BVA 3 Anno di costruzione: 2001 Potenza nominale: 5 kW Pressione: max. 6 bar Diametro di curvatura (acciaio): 32 mm Raggio di curvatura: 1,5 x D – 2,5 x D Peso macchina: 0,7 t
usato
Gamma tubi fino a: 48,3x3,25mm (E235mitRm =2xD) Raggio di curvatura fino a: 125 mm Controllo: elettronico ( + nota preselezione dell'angolo di flessione 4 volte ) Angolo massimo di curvatura: 180 Velocità di piegatura: 20 /s Dimensioni L/W/H: 2380 / 800 / 1250 mm Peso: circa 650 kg Elettr. Potenza: 2,4 kW unità di segatura con visualizzazione della posizione della sega tramite laser a linea Unità di sbavatura, unità di azionamento per attacchi di montaggio Posizionamento del tubo - lunghezza e torsione Indicatore di posizionamento a 2 assi, retrazione prematura del mandrino Automatico. Lubrificazione mandrino (quantità minime) Interfaccia per la connessione di rete e l'importazione dei dati
usato
tube diameter max.: 38 mmwall strength: 2 mmbar material dia. min.: 10 mmbending radius min.: 35 mmbending radius max.: 150 mmpull up length of tube: 4500 mmbending angle max.: 180 °accuracy of bending angle: ± 0,2 °total power requirement: 7,5 kWweight of the machine ca.: 1,2 t- with 8-pos. bending angle pre-selection- crawler gear control- positioning device by hand- tube twist deviceFollowing bending tools are with the machine:- ø 10 mm, radius 27,5 mm- ø 12 mm, radius 35 mm- ø 12 mm, radius 56 mm- ø 15 mm, radius 35 mm- ø 15 mm, radius 57,5 mm- ø 18 mm, radius 35 mm- ø 18 mm, radius 59 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
Piegatrice mandrino Tansfluid DB 628 Anno di costruzione: anno 1995 Potenza motrice Potenza motrice 1,5 kW Cilindro idraulico di azionamento e catena a rulli Tipo di curvatura della gamma di tubi 4-28 mm Angolo di curvatura angolo di curvatura 190° (senza tubo) Raggio di curvatura raggio di curvatura 1,5 x P – 2,0 x P Pressione nominale pressione nominale 250 bar Pressione di esercizio 3095 mm n. destra. Portata portata 4,5 l/min
usato
- Tubo campo di lavoro Ø 4 - 28 mm x 3 mm per acciaio - Tubo campo di lavoro Ø 4 - 35 mm x 2 mm per metalli non ferrosi - Lunghezza di scorrimento del tubo 3.000 mm - Controllo elettronico monoasse / ingresso angolare - Raggio di curvatura max. 90 mm - Quantità minime - Lubrificazione mandrino - utensili esistenti ( 17,2 x 2 / 21,3 x 2 / 25,0 x 2 / 26,9 x 3 mm ) - Peso circa 600 kg - L x L x H circa 3.800 x 600 x 1.100 mm - Incluse istruzioni per l'uso e lista dei pezzi di ricambio
usato
tube diameter: 6 - 28 mmwall strength: 2 mmbending radius min.: 2 x D Control: IPU 20 bending radius max.: 5,0 x D mmbending angle max.: 190 °arbor length: 3000 mmoperating pressure: 180 barhydraulic motor: 4 kWweight of the machine ca.: 900 kgdimensions of the machine ca.: 3,8 x 1,1 x 1,3 mCondition: ready for operation: Electric 400 Volt: Bending segments: diverse ZollBending mandrels: 4 Operation panel: 0,5 x 0,6 x 1,03 mDouble Foot pedal: Machine manual: Semi-automatic electro-hydr. mandrel tube bending machine with PLC control for 20 angles and display in the control panel for bending angle specification, angle detection and angle measurement via absolute value encoder, autom. tool plate reset, Turning device with digital display, hydr. quick chuck, aut.Mandrel lubrication, adjustable length stops.Operating modes: manual and semi-automatic.Control buttons: hydraulics on / off, ...
usato
Produttore: Tubobend Tipo: 80 S 108 V Anno di costruzione: 2000 Portata: max. Ø 76.1 mm
usato
tube diameter: 51 mmwall strength: 3 mmsemi-automatic operated: UZMA bending radius max.: 225 mmbending angle max.: 190 °bending speed: 35 ° / sec.mandrel length: 3.100 mmengine output: 5,5 kWvoltage: 380 Vtotal power requirement: 11,0 kWweight of the machine ca.: 1,36 tdimensions of the machine ca.: 4,20 x 1,60 x 1,20 m- Serial No.: 0144- semi-automatic mandrel bending machine- bending angle is program controlled- length + twisting angle manually adjustable- digital display for twisting angle, length and bending angle- the following bending sets are included: 1.) R75 mm / Ø 20 mm 2.) R60 mm / Ø 25 mm 3.) R75 mm / Ø 30 mm 4.) R75 mm / Ø 40 mm 5.) R170 mm / Ø 50 mm 6.) R35 / flat Material 40 x 10 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
