usato
Potenza laser: 6 kW Oscillatore: AF 6000 Velocità di posizionamento: 120 m / min Area di lavoro: 3070 x 1550 mm Il principio del laser: ottica volante Velocità di taglio: 0 - 60 m / min. Spessore di taglio: acciaio fino a 25 mm, acciaio inox fino a 20 mm. Lunghezza - 9845 mm Larghezza - 4245 mm Altezza - 2015 mm Peso - 11.000 kg.
usato
table length: 3000 mmtable width: 1500 mmtotal power requirement: 51 kWburner heads: weight of the machine ca.: tdimensions of the machine ca.: mwith changing table (without automtic storage)ByVision Touchscreen and manual control unitTechnische Daten / technical details:Laserleistung / laser capacity 6 kWMaterialdicke Stahl / thickness of the material steel 25 mmMaterialdicke Edelstahl / thickness of the stainless steel 20 MmMaterialdicke Alu / thickness of the material Aluminium 12 mmBlechgröße x,y / sheet size x,y 3000, 1500 mmSchneidbereich x,y,z, / cutting area x,y,z 3048, 1524, 80 mmAntriebsleistung / drive capacity 51 kWGewicht ca. / weight ca. 15000 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description of the machine are not binding.The data for this ad was cr ...
usato
-potenza risonatore: 6 kW -campo di lavorazione: 3000x1500 mm -spessore massimo di taglio, acciaio neroj: 18 mm -spessore massimo di taglio, acciaio inox: 8 mm -spessore massimo di taglio, alluminio: 6 mm
usato
originates from lasercutting machine
usato
-moc rezonatora: 6 kW -zakres obróbki: 3000x1500 mm -maksymalna grubość cięcia, stal czarnaj:18 mm -maksymalna grubość cięcia, stal nierdzewna: 8 mm -Maksymalna Grubość Cięcia, alluminio: 6 mm
nuova
Macchina da taglio laser fibra 1500x3000 mm Sorgente laser Raycus da 12000W Base macchina ad alte prestazioni. Servomotori ad alte prestazioni. Sistema di controllo del taglio intelligente, funzionamento facile; Avvio rapido, supportato dalla tecnologia di segmento e steppiecing; Il condotto dell'aria specializzato con calibro sovradimensionato, rende fluido lo scarico del fumo. Design completamente chiuso; Protezione laser standard CE europea. Due tavoli navetta offrono un elevato livello di sicurezza e comfort Parametri tecnici: Area di lavoro 3000x1500 mm Corsa asse X 1520 mm Corsa asse Y 3020 mm Corsa asse Z 300 mm Precisione di posizionamento X,Y ±0,05 mm Precisione di posizionamento ripetuta X,Y ±0,03. mm Accelerazione 1.3 m/s² Max. Velocità di posizionamento simultaneo 120 m/min Carico della tavola 3000 kg Dimensioni macchina 8100×2812×2640 mm Pote ...
usato
Ermaksan LASERMAK 6000 6X2 laser cutter è stato prodotto nel 2014. Parametri tecnici: – sorgente laser: 6000 W CO2-laser GE Fanuc C6000i-Model C – Eccitazione RF: 2 MHz – stabilità di potenza: ± 2% (monitor di alimentazione) – lunghezza dell'onda laser: 10,6 μM – modalità fascio: modalità Fanuc Low Order – otturatore laser: otturatore meccanico di sicurezza – composizione laser gas: CO2 / He / N2 – consumo di gas via laser: 20 l / h – portata dell'acqua di raffreddamento: 250 l / min – capacità massima di taglio: acciaio dolce 25 mm (durante le prove il massimo raggiunto: 30 mm), acciaio inossidabile 15 mm, alluminio 12 mm – fabbisogno energetico totale: 100-120 kW – lunghezza focale della testa di taglio: 5 "-7" -10 "pollici" – dimensioni massime del foglio di lavoro: 6150 x 2000 mm – capacità massima di carico: 4000 kg – assi macc ...
usato
Fanuc Laser-model C3000 Type A04B-0811-B311 44 kVa - 130 amp Type A04B-0811-B511
usato
Type: Vario T 1.0 L originates from LVD lasercutting machine power: 2,2 kW
usato
Originated from LVD lasercutting machine
usato
Options fitted: - automatic nozzlechanger - scrapconveyor Workpiece dimensions: 6160 x 2035 mm Type of Laser: LVD Power: 10 kW Control: Touch-L Longitudinal travel X-axis: 6280 mm Cross travel Y-axis: 2070 mm Hight travel Z-axis: 130 mm Travel speed: 140 m/min Max cuttingthickness in steel: 25 mm Max cuttingthickness in Inox: 30 mm Motor Power: 75 kW Length: 17 200 mm Depth: 6300 mm Hight: 3360 mm Weight: 21,5 ton Shuttle table: yes
usato
CO2 2d laser Model MAZAK NTX48 Champion Year 1999 Hours worked 53052 Power 1500 watts Hybrid type axis movement (X axis table movement, Y and Z axis head movement) X-axis longitudinal travel 2650 mm Y-axis transverse travel 1270mm Z-axis travel 100mm Machinable dimensions 2500x1250mm Head with capacitive sensor Mazatrol L-32B CNC Control Maximum machinable thicknesses with 5-inch head now supplied --6.0mm iron -3.0mm stainless steel -2.5 mm aluminum (with 7.5 inch head Iron 12.0mm Stainless 6.0mm theoretical) External dimensions: Length 5563mm
usato
lunghezza del tavolo: 6000 mm larghezza del tavolo: 4300 mm teste dei bruciatori: 1 Controllo: Omnicom 160iLB altezza del tavolo: 700 mm velocità di lavoro: max. 20.000 mm/min precisione di posizionamento: 60.000 mm/minpeso della macchina ca.: circa 8 t
nuova
Molte delle nostre macchine sono disponibili a magazzino. Chiamaci per saperne di più. Taglierina laser a fibra FLV-3015-OE 3kW / VF1530-3000W Parametri tecnici - Formato massimo del foglio: 3000 x 1500 mm - Precisione di posizionamento degli assi X e Y: ±0,05 mm/m - Precisione di posizionamento ripetibile degli assi X e Y: ±0,03 mm - Velocità massima: 60000 mm/min - Accelerazione massima: 0,7 G - Carico massimo: 1200 kg - Potenza: 3,0 kW - Potenza richiesta: 24,0 kW - Marchio di origine: MAX Photonics - Alimentazione: ~3x400 V 50 Hz - Classe di protezione: IP54 Spessore di taglio - Acciaio nero: spessore consigliato 20,0 mm, spessore massimo 22,0 mm - Acciaio inox: spessore consigliato 8,0 mm, spessore massimo 10,0 mm - Alluminio: spessore consigliato 6,0 mm, spessore massimo 8,0 mm - Ottone: spessore consigliato 5,0 mm, spessore massimo 6,0 mm Costruzione ...
nuova
Molte delle nostre macchine sono disponibili a magazzino. Chiamaci per saperne di più. Taglierina laser a fibra FLV-3015-OE 4kW / VF1530-4000W Parametri tecnici - Formato massimo del foglio: 3000 x 1500 mm - Precisione di posizionamento degli assi X e Y: ±0,05 mm/m - Precisione di posizionamento ripetibile degli assi X e Y: ±0,03 mm - Velocità massima: 60000 mm/min - Accelerazione massima: 0,7 G - Carico massimo: 1200 kg - Potenza: 4,0 kW - Potenza richiesta: 27,0 kW - Marchio di origine: MAX Photonics - Alimentazione: ~3x400 V 50 Hz - Classe di protezione: IP54 Spessore di taglio - Acciaio nero: spessore consigliato 22,0 mm, spessore massimo 25,0 mm - Acciaio inox: spessore consigliato 10,0 mm, spessore massimo 12,0 mm - Alluminio: spessore consigliato 8,0 mm, spessore massimo 10,0 mm - Ottone: spessore consigliato 6,0 mm, spessore massimo 8,0 mm Costruzione ...
usato
ROFIN SCx30 Laser X30-1133 Data di costruzione 10/2001
usato
Trotec Speedy 300 Co2 Laser 120 Watt raffreddato ad acqua Questo sistema è sempre stato mantenuto dalla Trotec. • Immediatamente pronto all'uso • Completamente funzionale • Ottime condizioni • + Protezione antipolvere estesa all'interno del laser Vantaggi della macchina per incisione laser Speedy Software intuitivo Le macchine per incisione laser Speedy vengono fornite con il software JobControl®. Questo è facile da imparare: un tutorial di 15 minuti è sufficiente per iniziare il tuo lavoro di incisione. Dotato di una varietà di opzioni, il software è ideale sia per i principianti che per gli incisori affermati. Macchina per incisione laser veloce Speedy è la scelta perfetta per la tua macchina per incisione laser, sia che tu stia appena iniziando la tua attività o stia cercando di aumentare la tua capacità produttiva. I componenti di prima classe gar ...
usato
working area: 3000x1500 mm: 20 mm: 15 mm: 10 mmmax. workpiece weight: 900 kg: 4000 W Machine comes WITHOUT LIFTMASTER!Standard equipmentMachine:- Closed machine frame with integrated laser unit- Motion unit for high-precision machining- Torque drive in combination with linear direct drives- Closed beam guidance- Single cutting head strategy- Cooling unit- Automatic pallet changer in longitudinal direction- 19 touch colour screen- Longitudinal conveyor belt- Work area lighting- Position laser diode- Spraying device- PierceLine- FocusLine- NitroLine- PlasmaLineCutting head:- Lens cutting head with 250mm focal length- Universal quick-change device (UTI)- LensLine with condition check- ControlLine: Height control and sheet outer edge detection- Lens with RFID chipControl system:- SINUMERIK 840D SL control system- Simple workshop programming- Fast post-production- Integrated technology data- ...
usato
table length: 3000 mmtable width: 1500 mmburner heads: 1 Control: Trumpf total power requirement: 73 kWLaser cutting machine Trumpf TruLaser 3030 Lean EditionLaser power 3200WType L 20Year of construction 2012Net 400V/50HzTotal power requirement 73 kVAControl voltage 24VFuse 3 x 125 AAir connection 7-10 barNitrogen connection 30 barOxygen connection 20 barBeam one hour 7755Laser one hour 25263Machine is in very good conditionand optimized by Trumpf in 12/2022.Documentation: Completely availableThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usato
Macchina da taglio laser TRUMPF TRUMATIC L3030
usato
x-axis: 2000 mmy-axis: 1500 mmz-axis: 750 mmburner heads: 1 3 Dlaser capacity in Watt: 2700 3D laser cutting and welding systemTruLaser Cell 7020Machine no. A0421A0099 Type: L13standard equipment- X = 2000, Z = 750mm, B = +/- 135°, C = n x 360°- Laser TruFlow 2700- Position laser diode- Stationary, rotatable pendant control panel- Teach panel- Teach software- Magnetic clutch, head detection- Laser power control- Power Cycles- Logbook function- focus line- Nitrogen jet aeration- Network connection including installation via teleservice- Analog modem for teleservice- Lighting boom- Documentation twiceDeviating from this standard equipment or in additionthe machine TruLaser Cell 7020 is equipped with:With the following configuration:Frequency 50HzVoltage 400 V0Electrical regulation IECLanguage operating instructions GermanNumber of operating instructions 2 pcColor standard RAL9002/5010Tru ...
