Fabricante:
(Categoría: 106)
Descripción del equipo Prensa de extrusión indirecta usada • Marca / Modelo: SMS Hasenclever 28 / 31.5 MN "McKechinstrang" • Tipo: Sistema de extrusión indirecta horizontal para palanquillas no ferrosas • Accionamiento: Unidad principal mecánica con auxiliares hidráulicos • País de origen: Alemania • Estado actual: Desmantelado y disponible para despacho • Nº de serie. / Año de fabricación: [Por confirmar] 2. Especificaciones técnicas clave Valor del parámetro Fuerza del pistón principal 25.07 MN Fuerza total de prensado con acoplamiento 31.23 MN Carrera máxima: 3.070 mm Carrera de trabajo 2.825 mm Velocidad del ariete a 28 MN 0–64 mm/seg Velocidad del ariete a 31,5 MN 0–57 mm/seg Rango de diámetro de palanquilla 230–355 mm Longitud de palanquilla (fría) 320–1.320 mm resistencia del sistema de calefacción del receptor; máx. 63 kW / ...
Prensa de forja de matriz abierta de 6500 toneladas HJ / Seonam (Corea) Diseño: Corporación de Europa del Este Instalación: 2006/2008 Tipo de prensa: Sistema hidráulico de aceite de empuje hacia abajo de cuatro columnas Fuerza nominal (presión estática de trabajo de 320 bar): 5.000 toneladas Fuerza de ajuste (presión de trabajo estática de 420 bar): 6500 toneladas Luz diurna: 5.200 mm Carrera de la cruceta móvil: 2.700 mm Diámetro del ariete principal (cilindro central): 1 juego - ¢950 mm Diámetro del ariete lateral (cilindro lateral): 2 juegos - ¢750 mm Diámetro del cilindro de retorno: 2 juegos - ¢300 mm Ancho de la mesa móvil: 2.600×Longitud 6.600 mm Carrera de la mesa móvil (centro a ambos lados 2.750 mm): 5.500 mm Velocidad de aproximación: 300 mm/seg Cilindro principal Velocidad de forja (2.200 toneladas/320 bar): 163 mm/seg Velocidad ...
VORONEZH K8544 Prensa de forja en caliente AÑO : 1980 / 2008 REVISIÓN E INSTALACIÓN FUERZA: 2500ton CARRERA DEL ARIETE : 350 mm TAMAÑO DE RAM : 1120X1070 mm TAMAÑO TOTAL DE LA MESA : 1400X1200 mm NÚMERO DE CARRERAS EN MODO CONTINUO : 60 NÚMERO DE CARRERAS EN MODO MANUAL : 26 ALTURA DE CIERRE : 890 mm CARRERA DEL KNOCK OUT SUPERIOR : 60 mm STOROKE DE KNOCK OUT INFERIOR : 70 mm MOTOR PRINCIPAL: 132KW (CAMBIADO A HYUDAI HEAVY Y2012) DIMENSIÓN TOTAL DE LA PRENSA : 5380X4680X6400 mm REFUERZO HIDRÁULICO NUEVO EN 2007 CONDICIÓN : MUY BUENAS CONDICIONES DE TRABAJO Prensa de recorte disponible
Línea de prensa de forja en caliente Sumitomo de 2000 toneladas Año 2006 Carrera 350 mm (13,78 pulgadas) Golpes por minuto 75 Altura de cierre 850 mm (33,47 pulgadas) SlideAdj. 7 mm (.27 pulgadas) Tamaño de carnero 1200 mm LR X 1300 mm FB Tamaño de la cama 1320 mm LR X 1300 mm FB Sistema de transferencia de 4 etapas Knockout deslizante Knockout inferior Sistema de chatarra Cambiador de troquel doble Zapatos Extra Die Calentador de palanquilla y sierra de palanquilla también disponibles Esta línea fue utilizada por HONDA para hacer engranajes de transmisión, toma una palanquilla, la corta a medida, la calienta a 1300 C y luego la prensa la golpea 4 veces. Puede determinar las partes buenas de las malas, las partes malas se envían a un tanque de enfriamiento, las partes buenas se envían a un transportador de enfriamiento que puede recoger las piezas a mano al final ...
(2) Prensa de forja horizontal Asahi THP500-6 (máquina de cabeza) Año: 2008 Primera carrera: 24 mm Segunda carrera: 50 mm Potencia de arranque: 150 kN Altura abierta: 625 mm Altura cerrada: 425 mm Troquel (WxL): 500x490 mm Punzonado (WxL): 250x350 mm Carrera del carnero: 200 mm Fuerza de forja: 5000 kN Tiempo de ciclismo: 6.5 seg Velocidad de la manivela: 60 RPM Peso de la máquina: 28 t
: neu : ca. 10 Wochen ab Auftrags : Türkei : 17700 €: 339.84 €: 100 to: fix : 300 mm: 680 mm: 1520 mm: 8 mm/s: 5 mm/s: 10 mm/s: 500x1520 mm: 100 mm: 190 mm: 2630 mm: 1000 mm: 2350 mm: 2500 kg2 guidingsupper plate with T-slotstable plate with T-Slotsmanometerrapid down move with automtic changeto working speedpiston stops in every position2 hand controltable height adjustableaccording to CE regulationsuser manual in GERMAN and ENGLISHThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: neu : ca. 10 Wochen ab Auftrags : Türkei : 21500 €: 412.8 €: 150 to: fix : 300 mm: 610 mm: 1520 mm: 9 mm/s: 5 mm/s: 10 mm/s: 600x1520 mm: 100 mm: 190 mm: 2630 mm: 1000 mm: 2470 mm: 3200 kg2 guidingsupper plate with T-slotstable plate with T-Slotsmanometerrapid down move with automtic changeto working speedpiston stops in every position2 hand controltable height adjustableaccording to CE regulationsuser manual in GERMAN and ENGLISHThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: neu : ca. 12 Wochen ab Auftrags : Türkei : 5500 €: 106.15 €: 30 to: fix : 775 mm: 5 mm/s: 10 mm/s: 1500 mm: 700 mm: 2015 mm: 400 kgsteel welded framestop at any positionpressure manometersafety valve against overloading2 V-blockstable height adjustabletable up-down movement attachmentcontrol by operating leveraccording to CE regulations user manual in GERMAN and ENGLISHThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure:250 tthroat:450 mmstroke:36 - 126 mmno. of strokes:40 /mindistance table/ram, max. stroke up, adjustment up:525 mmtable surface area:1000 x 750 mmhole in the table:400 x 360 mmtable height over floor:1000 mmram surface:600 x 500 mmram adjustment:111 mmpower requirement:19,0 kWweight:13,5 tDimensions (WxDxH):1,3 x 3,2 x 3,35 mclutch:pneumatic overload protection in ram:mechanical ram adjustment:motoric
pressure:100 tdistance between columns:1230 mmstroke:20 - 200 mmno. of strokes:20 - 60 /mindistance table/ram, max. stroke up, adjustment up:650 mmtable surface area:1050 x 750 mmtable height over floor:760 mmside window:540 mmram surface:1000 x 750 mmram adjustment:100 mmpower requirement:18,0 kWweight:20,5 tDimensions (WxDxH):2,8 x 1,9 x 4,3 minfinitely variable drive:PIV clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric
pressure:160 tdistance between columns:880 mmstroke:150 mmdistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:830 x 1000 mmhole in the table:265 x 365 mmtable height over floor:850 mmside window:610 mmram surface:860 x 1000 mmpower requirement:55,0 kWweight:14,7 tDimensions (WxDxH):2,2 x 2,0 x 4,3 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary
Pressure:250 tthroat:450 mmstroke:8 - 135 mmno. of strokes:50 /mindistance table/ram, max. stroke up, adjustment up:635 mmtable surface area:1250 x 850 mmhole in the table:355 mmtable height over floor:950 mmpassage to the back:660 mmram surface:790 x 610 mmram adjustment:120 mmpower requirement:18,5 kWweight:14,0 tDimensions (WxDxH):1,5 x 2,8 x 3,65 mGerman Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch
pressure:500 tdistance between columns:2400 mmstroke:400 fix mmno. of strokes:13 - 23 /minDistance table/ram, max. stroke up, adjustment up:1600 mmtable surface area:2300 x 1800 mmcolumn travel -side:1600 mmram surface:2170 x 1800 mmram adjustment:300 mmtotal power requirement:110,0 kWWeight:135,0 tDimensions (WxDxH):3,35 x 4,85 x 7,0 mclutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric
pressure:300 tdistance between columns:2500 mmstroke:350 mmdistance table/ram, max. stroke up, adjustment up:1280 mmtable surface area:2500 x 1500 mmtable height over floor:850 mmside window:900 mmram surface:2500 x 1500 mmspeed down:300 mm/sspeed up:240 - 450 mm/sworking speed:23 - 44 mm/soil volume:3000 lpower requirement:132,0 kWweight:54,0 tDimensions (WxDxH):3,25 x 3,2 x 4,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA
nominal force:100 tstroke:320 mmno. of strokes:35 /mindistance between columns:360 / 250 mmDistance table/ram, max. stroke up, adjustment up:500 mmtable surface area:320 x 450 mmtable height over floor:660 mmram surface:250 x 280 mmspindle diameter:125 mmpower capacity:3,0 kWweight:4,5 tDimensions (WxDxH):2,0 x 1,6 x 3,1 m
Pressure:100 tdistance between columns:910 mmstroke:600 mmdistance table/ram, stroke up:1000 mmtable surface area:1340x680 / 910x1085 mmhole in the table:700 x 510 mmtable height over floor:800 mmside window:680 mmram surface:1230x680 / 910x1000 mmcapacity of ejector:7,5 tejector stroke:150 mmpower requirement:15,0 kWweight:9,5 tDimensions (WxDxH):2,3 x 1,9 x 3,6 mlight guard:Sick blank holder / ejector in ram:hydraulisch
pressure:150 tthroat:450 mmstroke:115 fix mmno. of strokes:45 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:2250 x 1090 mmtable height over floor:900 mmpassage to the back:1900 mmram surface:1900 x 900 mmram adjustment:100 mmpower requirement:16,0 kWweight:19,5 tDimensions (WxDxH):3,0 x 2,3 x 3,9 m
pressure:200 tdistance between columns:1800 mmstroke:710 mmDistance table/ram, max. stroke up, adjustment up:1100 mmtable surface area:1600 x 1300 mmpressure of drawing cushion in table:80 tstroke of drawing cushion in table:250 mmdie cushion area:1400 x 1080 mmtable height over floor:800 mmside window:1300 mmram surface:1660 x 1300 mmspeed down:400 mm/sspeed up:410 mm/sworking speed:14,3 - 49,7 mm/spower requirement:46,0 kWweight:25,0 tDimensions (WxDxH):3,65 x 3,3 x 5,4 mheight over floor:5,05 mheight beneath floor:0,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical
pressure:50 tdistance between columns:1750 mmstroke:500 mmDistance table/ram, max. stroke up, adjustment up:800 mmtable surface area:1700 x 750 mmtable height over floor:800 mmside window:650 x 750 mmram surface:1700 x 750 mmpower requirement:11,0 kWweight:11,0 tDimensions (WxDxH):2,1 x 1,15 x 3,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary
pressure:015 tthroat:200 mmstroke:4 - 70 mmno. of strokes:140 /mindistance table/ram, max. stroke up, adjustment up:310 mmtable surface area:430 x 395 mmhole in the table:165 x 160 mmtable height over floor:560 - 735 mmtable adjustable:175 mmram surface:160 x 130 mmram adjustment:80 mmpower requirement:1,2 kWweight:0,9 tDimensions (WxDxH):1,0 x 1,25 x 1,8 mclutch:Drehkeil overload protection in ram:mechanical
pressure:030 tstroke:8 - 40 mmno. of strokes:100 - 600 /mindistance between columns:325 mmdistance table/ram, max. stroke up, adjustment up:250 mmtable surface area:540 x 300 / 325 x 395 mmhole in the table:315 x 110 mmtable height over floor:1000 mmcolumn travel -side:290 mmram surface:250 mmmaterial width of feeder:120 mmmaterial thickness of feeder:3,0 mmfeed length:60 mmpower requirement:5,5 kWweight:2,6 tDimensions (WxDxH):1,5 x 1,2 x 2,2 mclutch:pneumatic roll feed:mechanical, Bruderer BBV 120/60
pressure:100 tthroat:350 mmstroke:6 - 100 mmno. of strokes:60 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:850 x 700 mmhole in the table:470 x 150 mmtable height over floor:855 mmram surface:450 x 300 mmram adjustment:80 mmpower requirement:7,5 kWweight:5,0 tdimensions (WxDxH):1,5 x 2,3 x 2,6 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical
pressure:500 tdistance between columns:2240 mmstroke:1180 mmdistance table/ram, max. stroke up, adjustment up:1800 mmtable surface area:2050 x 1800 mmpressure of drawing cushion in table:250 tstroke of drawing cushion in table:380 mmdrawing cushion surface in table:1800 x 1200 mmpressure of drawing cushion in ram:122 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:1800 x 1200 mmram surface:2215 x 1800 mmtable height over floor:500 mmspeed down:400 mm/sspeed up:10 - 400 mm/sworking speed:10 - 100 mm/sdepth of the foundation:3,0 mpower requirement:122 + 75 + 64,5 kWweight:110,0 tDimensions (WxDxH):3,6 x 2,2 x 8,5 mheight over floor:6,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic
pressure:500 tdistance between columns:3200 mmstroke:1250 mmdistance table/ram, max. stroke up, adjustment up:1810 mmtable surface area:3000 x 1900 mmpressure of drawing cushion in ram:150 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:2400 x 1200 mmram surface:3160 x 1900 mmspeed down:400 mm/sspeed up:250 mm/sworking speed:18 - 58 mm/sheight over floor:6,5 mpower requirement:90,0 + 36,5 kWweight:110 tGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic
pressure:800 tdistance between columns:3010 mmstroke:300 mmdistance table/ram, max. stroke up, adjustment up:1350 mmtable surface area:3000 x 1800 mmtable height over floor:500 mmside window:1500 x 1400 mmram surface:3000 x 1800 mmspeed down:300 mm/soil volume:900 lheight over floor:5,4 mheight beneath floor:2,1 mpower requirement:200,0 kWweight:80,0 tDimensions (WxDxH):5,2 x 2,6 x 7,5 mram interlocking:in TDC depth stop:mechanical
nominal force:315 tstroke:300 mmno. of strokes:36 /mindistance between columns:540 mmdistance table/ram, max. stroke up, adjustment up:750 mmtable surface area:530 x 630 mmblow die to die:630 tAllowed max. force:500 tram surface:450 x 560 mmspindle diameter:180 mmpower capacity:18,0 kWweight:13,0 tDimensions (WxDxH):2,5 x 2,0 x 4,0 m
pressure:100 tdistance between columns:1060 mmstroke:700 mmdistance table/ram, max. stroke up, adjustment up:1250 mmtable surface area:1000 x 700 mmpressure of drawing cushion in table:40 tstroke of drawing cushion in table:200 mmdie cushion area:Ø 250 mmtable height over floor:950 mmside window:580 x 750 mmram surface:1000 x 700 mmoil volume:700 lpower requirement:47,0 kWweight:13,0 tDimensions (WxDxH):2,2 x 1,8 x 5,0 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical; motoric adjustable ram interlocking:SITEMA
pressure:160 tdistance between columns:2050/1900 mmstroke:15 - 170 mmno. of strokes:15 - 40 /mindistance table/ram, max. stroke up, adjustment up:690 mmtable surface area:1600 x 800 mmside window:800 mmram surface:1620 x 700 mmram adjustment:140 mmpower requirement:15,0 kWweight:24,0 tDimensions (WxDxH):3,3 x 2,3 x 5,3 mheight over floor:4,8 mheight beneath floor:0,5 mclutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic
pressure:500 tstroke:40 - 160 mmno. of strokes:32 / 48 /mindistance between columns:1620 mmdistance table/ram, max. stroke up, adjustment up:660 mmtable surface area:1600 x 1300 mmtable height over floor:750 mmcolumn travel -side:400 x 430 mmram surface:1400 x 1200 mmram adjustment:120 mmpressure of drawing cushion in table:60 tstroke of drawing cushion in table:100 mmdrawing cushion surface in table:1300 x 810 mmmaterial width of feeder:1000 mmmaterial thickness of feeder:- 6,0 mmfeed length:350 mmheight beneath floor:0,3 mpower requirement:44,0 / 66,0 kWweight:56,0 tDimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 mheight beneath floor without drawing cushion:0,3 mheight beneath floor with drawing cushion:1,0 mclutch-/ brake combination:pneumatic; Desch overload protection in ram:mechanical ram counterbalance:pneumatic ram adjustment:motoric drawing cushion in table:pneumatic Mechanical pincer ...
