usado
Key data: 3550 mm
Ref.-No.00804 Descripción Plegadora hidráulica Herramientas incluidas Fabricante: EHT Tipo EHT VarioPress 320 Año de construcción 1997 1997 Presión regulable de forma continua: 3200 kN 320 toneladas Anchura máxima de trabajo: 3550 mm 3550mm Anchura de trabajo entre montantes: 3050 mm Proyección del soporte: 350 mm Altura de la mesa: 900 mm Carrera del émbolo: 270 mm Ajuste del bisel del émbolo: 15 mm Con dispositivo de bombeo y dispositivo de sujeción rápida para herramientas superiores Velocidad de elevación: vacío 100 mm/s, bajo carga: 10 mm/s, retracción: 100 mm/s Control: DNC 80 PC ( DNC 84 PS= 4 ejes
usado
Key data: 250 t, 6050 mm
Fabricante: EHT Werkzeugmaschinen GmbH Tipo: 250 - 60 Año de construcción: 1998 Longitud de trabajo: 6050 mm Fuerza de prensado: 250 toneladas Cantidad de aceite: 400 l Corriente nominal: 52 A Corriente nominal del fusible principal: 80 A Potencia del motor principal: 22 kW Tipo de control: DNC 74 PSG
usado
Key data: 80 t, 3050 mm
Fuerza de prensado 800 kN Longitud de plegado 3050 mm Carrera del émbolo aprox. 160 mm Altura de montaje de hasta 340 mm Dimensiones largo x ancho x alto: 3750 x 1600 x 2850 mm Peso aprox. 7500 kg Incluyendo herramientas (ver fotos)
usado
Plegadora CNC Fabricante EHT Tipo EHPS 20-35 Año de construcción 1995 Control DNC800 Longitud de plegado 3550mm presión de prensado 200t Las matrices de bloques y segmentos también están disponibles Documentación e instrucciones de funcionamiento disponibles La máquina fue revisada hace 3 años y dejada de lado. Ya no está energizado.
Datos técnicos: - Ancho de corte máximo 3050 mm - Potencia máxima de corte a 45 Kp/mm2 4 mm - hydr.. Ajuste del ángulo de corte - Número de titulares 18 stk - Número de trazo hasta 24 /min - Tope de ángulo delantero 1100 mm - 3 piezas brazos de soporte frontal 750 mm - mot. Tope trasero con control de posicionamiento 5 - 1000 mm - Estan de alto mantenimiento - Iluminación de línea de corte - E - Botón de pie - Protección de la habitación con barrera de luz - Unidad 400 V / 9.5 kW - Requerimiento de espacio aprox. W 3900 x H 1850 x D 2100 mm - Peso aprox. 5,7 t
usado
Datos técnicos: - Longitud máxima de trabajo 1250 mm - Paso del soporte 1050 mm - Fuerza máxima de prensado 80 t - Trazo 250 mm - Extensión del soporte 300 mm - altura máxima de la instalación entre Mesa - Vigas de prensa 560 mm - Velocidades de elevación - Velocidad de inactividad máxima 100 mm/seg - Velocidad ascendente 100 mm/seg - Velocidad de prensa hacia abajo máx. 12 mm/seg - Potencia total de accionamiento 15 kW - Requerimiento de espacio aprox. W 1750 x H 3400 x D 2000 mm - Peso aprox. 8500 kg - con: - CNC - Control CYBELEC DNC 7400 PSGY - X controlado - eje trasero 5 - 1000 mm - Z - eje en tres etapas pneum. Ajustable - Dedos de parada móviles y plegables manualmente - desplazamiento neumático controlado de troquel - hydr. Sujeción de herramientas - bombardeo manual - 2 piezas apoyan brazos - Herramie ...
usado
Presión: 250 t Ancho de trabajo: 3550 mm ancho del soporte ligero: 3050 mm Extensión del soporte: 300 mm Golpe de espalda: sí electr. Conexión: 400 V, aprox. 26 kW Peso: 20 t Requisito de espacio: 2100 x 3800 x 3100 mm
usado
Presión: 150 t Ancho de trabajo: 4500 mm ancho del soporte ligero: 3050 mm Extensión del soporte: 300 mm Parada trasera: 1000 mm electr. Conexión: 380 V, 18,5 kW Peso: 14,8 t Requisito de espacio: 4200 x 2000 x 3000/3150 mm
usado
Pressing force: 1250kN, bending length: 2550mm, oil volume: 250l, control: DNC 806 PS/K.
usado
Working length: 3050mm, sheet thickness: 10mm.
usado
sheet width:3050 mm plate thickness:4 mm total power requirement:9 kW weight of the machine ca.:6 t dimensions of the machine ca.:3900 x H 1850 x T 2100 mm
usado
usado
pressure: 225 t chamfer lenght: 3050 mm distance between columns: 2550 mm column arm: 300 mm ajustment speed: 110 mm/sec work speed: 9.0 mm/sec return speed: 130 mm/sec work stroke: 240 mm dayligth: 320 - 560 mm table height: 1000 mm table width: 200 mm oil volume: 350 ltr. operating pressure: max. 296 bar air pressure: 4.5 - 6.0 bar voltage: 400 Volt total power requirement: 18.5 kW weight: 14900 kg range L-W-H: 5180 x 2400 x 3100 mm Furnishing: - electro-hydraulic CNC die bending/press brake - CYBELEC CNC control ModEva 12S, swiveling at the front right High-resolution graphic color screen 14 inches Representation as a line, area or volume drawing of the product Clear, concise menus in the operators language Large tools and products library - CNC-controlled back gauge adjustment (X-axis) Stop range X axis of bending line .. 5.0 - 1.000 mm Adjustment speed .. max. 250 mm/sec. - CN ...
usado
pressure: 150 t chamfer lenght: 4050 mm distance between columns: 3050 mm column arm: 350 mm dayligth: 430 mm piston stroke: 220 mm table width: 300 mm oil volume: 390 ltr. pressure: 265 bar total power requirement: 18,5 kW weight of the machine ca.: 13.000 kg range L-W-H: 4900 x 2740(1890) x 3310 mm from a maintenance workshop Furnishing: - CYBELEC CNC control, model DNC 30 - Swivel control, right front - controlled axes Y1 + Y2 + X + R - CNC motorized table crowning - hydraulic upper tool clamping - Pneumatic lower tool clamping - 2x front pneumatic bending aids - 2x free-moving 2 hand controls/foot controls - lateral protective device (protective grille) - rear protective device (protective grille) - Operation manual The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usado
Description: Year of construction 1989 Pressure 150 t Bending length 4050 mm Stand width 3050 mm Stand projection 350 mm Installation height 430 mm Piston stroke 220 mm Table width 300 mm Oil content 390 liters Pressure output 265 bar Total power requirement 18.5 kW weight approx.: 13,000 kg, Approx. Onsite Dimension. (l x w x h): 4,900 x 2,740 x 3,310 mm
usado
N.º de tejido: 202 395 Longitud de trabajo: 2550 mm Salida: 2000 KN Recorrido de seguimiento: 13 mm Distancia de seguridad: 176 mm
usado
pressure: 125 t chamfer lenght: 3050 mm distance between columns: 2550 mm throat: 300 mm stroke: 240 mm dayligth: 640 mm quantity of oil: 250 l : total power requirement: kW weight of the machine ca.: 15,00 t dimensions of the machine ca.: m • Cybelec ModEva PAC touch screen control, retrofitted • Pilz safety barrier retrofitted • controlled axes: Y1, Y2, X, R • 6 stop fingers can be moved laterally • Pneumatic die displacement • Upper and lower tool clamping automatically • 2 support arms on linear guides • CNC controlled crowning • Tool package consisting of: • Lower tool V6, segmented • Punch straight H 192, length = 3050mm Replacement blades are not included. Can be ordered in different radii. • Stamp offset H 220, length = 6x250mm Dimensions: approx. L 4.05 x W 1.80 (plus support arms) x H 2.90 m The data for this ad was created with ModulMWS - the softwar ...
usado
pressure: 125 t chamfer lenght: 3550 mm distance between columns: 2250 mm throat: 300 mm stroke: 240 mm dayligth: 640 mm quantity of oil: 250 l Control: total power requirement: kW weight of the machine ca.: 12,00 t dimensions of the machine ca.: 3,90 x 1,80 x 3,00 m • Control: Cybelec DNC 80 2D graphics • Upper tool clamping automatic • Lower tool clamping 90mm and 13mm • controlled axes: Y1, Y2, X1, X2, R, Z1, Z2 • motorized crowning • 6 x V block die length 3,500, segmented: with V12/30°, V40/80°, V24/80°, V10/30°, V24/30°, V16/30° • Straight punch, H 350mm / approx. 70°, length 3060 mm, segmented The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usado
Ancho de la hoja: 3000 mm Espesor de la placa: 10 mm
usado
pressure: 175 t chamfer lenght: 3050 mm voltage: 3x400 V control voltage: 24 kW : 80 A frequency: 50 Hz : DNC 1200PS PressCad : 18,5 kW quantity of oil: 350 l height of the machine: 3360 mm weight of the machine ca.: 12700 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usado
Presión: 175 t Longitud del chaflán: 4050 mm Control: DNC 1200 PS peso de la máquina aprox.: kg
usado
This EHT VarioPress 225-30 Bending machine was manufactured in the year 1997 in the Netherlands.
usado
This EHT EHPS 25-30 Bending machine was manufactured in the year 1991. The machine has a pressing force of 2500 kN.
usado
pressure: 135 t chamfer lenght: 3050 mm distance between columns: 2550 mm stroke: 250 mm quantity of oil: 300 l frequency: 50 Hz : 63 A voltage: 3 x 400 V total power requirement: 21,5 kW weight of the machine ca.: 11260 Kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usado
Presión: 125 t Longitud del chaflán: 5050 mm Control: Cybelec ModEva Y-carrera rápida: 100 mm/s: 10 mm/s : 100 mm /s Volumen de aceite: 250 l
usado
sheet width: 3200 mm plate thickness: 4,0 mm distance between columns: 3300 mm daylight opening: OW 400 mm adjustment: UW 80 mm pivoting angle: 180 Grad clamping capacity max.: 200 KN air pressure - required: 4.5 - 6.0 bar total power requirement: 9,8 kW oil volume: 160 l weight: 8500 kg range L-W-H: 4550 x 2530 x 2275 mm well-maintained machine with lots of special accessories () last maintenance/test in JUNE 2023 Furnishing: - CNC screen control CYBELEC model DNC-884-PP32 Swivel control panel, front right - CNC controlled / electro-motorized back gauge pneumatic / lowerable material stop fingers Adjustment speed max. 250 mm/sec. Drive power 0.5 kw Sheet metal support table at the back - motorized lower beam adjustment (S axis) Adjustment range max. 80.0 mm - hydraulic swivel movement of the lower beam - hydraulic movement of the upper beam Adjustment range max. 400 mm Lifting ...
usado
Presión: 125 t Longitud del chaflán: 3550 mm Distancia entre columnas: 3050 mm Brazo de columna: 300 mm Carrera del ariete: 240 mm Cantidad de aceite: 200 L Potencia total requerida: 11 kW Peso de la máquina aprox.: 14000 kg
usado
Presión: 300 t Chaflán Longitud: 3050 mm Cantidad de aceite: 400 l Dimensiones: 4550x3000x3700 mm Peso: 19000 kg
usado
Hydraulic cylinders, support cylinders, hydraulic rams, pressure rams, hydraulic buffers, pressure boosting cylinders -Hydraulic cylinder: from press brake EHT type EHP 11-40 -Piston rod: Ø 155 mm -Stroke: 250 mm -Number: 2x cylinders available, 1x left / 1x right -Price per piece -Dimensions .: 855/285/380 mm -Weight: 311 kg / pc.
usado
Stop for press brake, edging bench, guillotine shears, drive shaft -Drive shafts: for stop, from press brake EHT type EHP 11-40 2 pieces -Length: 515 mm -Socket: Ø 25 mm -Price: complete -Dimension: Ø 50 x 515 mm -Weight 5.1 kg / pc.
