KAISER maquina usada para la venta

Punzonadora automática, prensa de alta velocidad, prensa excéntrica, prensa de una sola columna, punzonadora, prensa excéntrica de una sola columna. Fabricante: Kaiser PO 10. Año de fabricación: 1982. Capacidad de presión: 10 [toneladas]. Carrera: ajustable de 2 a 40 [mm]. Velocidad: 120-600 [golpes/min]. Tamaño de la mesa: 460 x 250 [mm]. Pasador de sujeción: 32 [mm]; profundidad 50 [mm]. Sistema central de lubricación automática. Conexión: 380 [V]; 50 [Hz]. Ajuste manual de la velocidad en el motor. Motor: Stober; 1,1 [kW]; 1450 [1/min]. Embrague y freno de disco simple. Dimensiones: 1250/950/H1800 [mm]. Peso: 850 [kg]. El esquema incluido. Embalaje y carga incluidos. Dispositivo de alimentación no incluido, si es necesario póngase en contacto para obtener más información.

16 piezas SK 50 Precio para los 16 Envíos dentro de Alemania 65.- IVA no deducible.

Alimentación de rodillos KAISER ZR 12 Ancho de la correa: 120 mm Longitud de avance 100 mm Ángulo de avance - ajustable - 90 - 180 grados Tecnología. Estado - bueno, completo Con neumática. Recambios Btto 250 kg

Prensa mecánica KAISER 315 TON. Modelo: V 315 WR/2340 Estado: bueno, completo Técnicas: Fuerza: 315 T Piano Dimensioni: 2280x1250 mm Tamaño de la diapositiva: 2000x1200 mm Recorrido por diapositivas: 280 mm Ajuste deslizante: 150 mm Heigh de molde: 500 mm Número de accidentes cerebrovasculares: 20-60 por mimute

Prensa mecánica KAISER 250 TON. Modelo: V 250 WR/2340 Estado: bueno, completo Técnicas: Fuerza: 250 T Piano Dimensioni: 2000x1200 mm Dimensioni slitta: 2000x1200 mm Recorrido por diapositivas: 280 mm Ajuste deslizante: 150 mm Heigh de molde: 495 mm Número de accidentes cerebrovasculares: 15-60 por mimute

Press capacity: 40 ton Ram stroke adjustable: 8 - 50 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 310 mm Free frontal opening L-R: 820 mm Table surface area : 810 x 450 mm Slide area: 720 x 350 mm Hole in table: 600 x 110 mm Number of strokes: 100 - 1.000 s.p.m. Table height over floor: 1.030 mm Required power: 19,5 kW Weight of machine approx.: 6,8 ton

Pressure total: 315 ton Ram stroke: 160 mm Slide adjustment: 100 mm Shut height (stroke down, adjustment up): 1.050 mm Free frontal opening L-R: 2.740 mm Free lateral opening F-B: 1.500 mm Distance between oil tray: 2.400 mm Table surface area : 2.740 x 1.800 mm Slide area: 2.400 x 1.700 mm Number of strokes: 10 - 60 s.p.m. Required power: 75,5 kW kW Working hours machine: 77.341 h Height over floor approx.: 5.500 mm Dimensions L x W x H: 5.400 x 3.300 x 5.700 mm Weight of machine approx.: 80 ton Control: Siemens S5

Press capacity: 35 ton Ram stroke adjustable: 6 - 50 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 250 mm Free frontal opening L-R: 430 mm Table surface area : 410 x 410 mm Slide area: 307 x 187 mm Hole in table: 170 x 110 mm Number of strokes: 60 - 300 s.p.m. Weight of machine approx.: 2,4 ton

Punching force: 630kN, stroke adjustment: 10-80mm, ram adjustment: 80mm, stroke speed: 65-400/min, connected load: 11kW, length: 1590mm, width: 1650mm, height: 3000mm, weight: 9.5t, with documentation.

PRESS DESIGN   drive system: eccentric / crank   frame design: H-frame, tie rod   openings in uprights: yes   table cushion: yes   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 200 to PRESS TABLE   table surface (left-right): 1780 mm   table surface (front-back): 1300 mm   opening in bed (left-right): 1445 mm   opening in bed (front-back): 260 mm SLIDE   slide force: 200 to   table surface (left-right): 1500 mm   table surface (front-back): 1100 mm   stroke: 178 mm   stroke rate (max.): 120 /min SLIDE (MECHAN. PRESS)   slide adjustment: 150 mm   stroke rate (min.): 20 /min   stroke rate (max.): 120 /min DIE CUSHION (TABLE CUSHION)   number of cushions: 11  & ...

CONTROLS   conventional PRESS FORCES   total force (nominal): 60 to SLIDE (MECHAN. PRESS)   slide adjustment: 70 mm   stroke min.: 11 mm   stroke max.: 60 mm   variable speed: yes   stroke rate (min.): 60 /min   stroke rate (max.): 240 /min ATTACHMENTS (PRESSES)   strip feeder: yes

pressure:063 t stroke:70 fix mm no. of strokes:15 - 60 /min distance between columns:1340 mm width between oil collecting pans:1180 mm distance table/ram, max. stroke up, adjustment up:328 mm table surface area:1260 x 700 mm hole in the table:1000 x 100 mm table height over floor:1000 mm column travel -side:470 mm ram surface:1300 x 650 mm ram adjustment:100 mm power requirement:27,5 kW weight:13,7 t Dimensions (WxDxH):3,4 x 2,1 x 3,4 m clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

Press capacity: 40 ton Ram stroke adjustable: 8 - 50 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 290 mm Free frontal opening L-R: 680 mm Free lateral opening F-B: 250 mm Distance between oil tray: 560 mm Table surface area : 640 x 450 mm Slide area: 560 x 350 mm Hole in table: 450 x 110 mm Number of strokes: 85 - 500 s.p.m. Table height over floor: 875 mm Required power: 7,5 kW Height over floor approx.: 2.800 mm Weight of machine approx.: 5,8 ton

Press capacity: 125 ton Ram stroke adjustable: 30 - 120 mm Slide adjustment: 100 mm Shut height (stroke down, adjustment up): 450 mm Free frontal opening L-R: 1.290 mm Free lateral opening F-B: 450 mm Table surface area : 1.250 x 800 mm Slide area: 1.250 x 650 mm Hole in table: 1.050 x 260 mm Number of strokes: 30 - 220 s.p.m. Table height over floor: 1.200 mm Required power: 39 kW Height over floor approx.: 3.800 mm Dimensions L x W x H: 3.500 x 2.200 x 3.800 mm Weight of machine approx.: 21,5 ton

Press capacity: 40 ton Ram stroke adjustable: 8 - 50 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 290 mm Free frontal opening L-R: 600 mm Free lateral opening F-B: 190 mm Table surface area : 600 x 500 mm Slide area: 600 x 400 mm Hole in table: 500 x 110 mm Number of strokes: 65 - 400 s.p.m. Table height over floor: 1100 mm Required power: 32 kW Height over floor approx.: 2.800 mm Weight of machine approx.: 6,2 ton

Press capacity: 32 ton Ram stroke adjustable: 8 - 50 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 270 mm Free frontal opening L-R: 685 mm Free lateral opening F-B: 250 mm Table surface area : 680 x 530 mm Slide area: 565 x 350 mm Hole in table: 450 x 110 mm Number of strokes: 65 - 400 s.p.m. Table height over floor: 950 mm Required power: 7,5 kW Height over floor approx.: 2.800 mm Weight of machine approx.: 5,5 ton

Press capacity: 50 ton Ram stroke: 54 mm Slide adjustment: 80 mm Shut height (stroke down, adjustment up): 303 mm Table surface area : 810 x 550 mm Number of strokes: 65 - 400 s.p.m. Weight of machine approx.: 7,5 ton Main Motor: 11 kW

Press capacity: 100 ton Ram stroke: 300 mm Slide adjustment: 125 mm Shut height (stroke down, adjustment up): 600 mm Free frontal opening L-R: 2.020 mm Free lateral opening F-B: 620 mm Table surface area : 2.000 x 1.000 mm Slide area: 2.000 x 900 mm Hole in table: 1.700 x 300 mm Number of strokes: 10 - 50 s.p.m. Table height over floor: 1.200 mm Required power: 39 kW Height over floor approx.: 4.400 mm Dimensions L x W x H: 5.166 x 2.500 x 4.400 mm Weight of machine approx.: 38 ton

Description: Water/oil separator for compressors with condensed air. Approx. Onsite Dimension. (l x w x h): 900 x 900 x 1,400 mm, weight approx.: 100 kg

Description: Press force: 35 to Number of strokes: 80 - 300 Stroke: 6 - 50 Ram adjustment: 50 Table dimensions: 540 x 340 mm Hole diameter: approx. 125 mm weight approx.: 1,800 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 1,000 x 2,200 mm

Boring head, spindle head, drill head, grooving head, grooving head, spindle drilling head, boring head, spindle tool -Quantity: 2x spindle tools -Intake: SK50 -Spindle dimensions: 145-230/225-310 mm -Price: complete -Weight: 14 kg/pc

Tool holder, milling holder, milling tool -Number: 3x SK50 holders -different designs -Bore chucks, flat chucks, reducing sleeves, cutter heads, shell end mills, spindle tools -suitable for tool changers -Sale: only complete -Weight: 10 kg

Eccentric press, single column press, punching machine, single column eccentric press, eccentric press, single column press -Manufacturer: Kaiser, punching machine with gripper feed type PO 40 F -Pressure capacity: 55 tons -Stroke: adjustable from 9 to 60 mm -Stroke rate: 70-350 strokes/min -Table size: 590 x 410 mm -Table recess: 290 x 150 mm -Projection: 220 mm -Punching fixture: Ø 38 mm -Insertion height 335 mm -Dimensions: 1905/1540/H2940 mm -Weight: 3720 kg

Tool holder, milling holder, milling tool -Number: 8x SK50 mounts -different designs -Brill chucks: flat chucks, reducing sleeves, cutter head, shell end mill, spindle tool -suitable for tool changers -is only sold complete -Weight: 32 kg

Tool holder, milling holder, milling tool -Number: 14x SK50 mounts -Tool holder: Ø 36 mm -Brill chucks: flat chucks, reducing sleeves, cutter head, shell end mill, spindle tool -suitable for tool changers -is only sold complete -Dimensions: 800/315/H650 mm -Weight: 62 kg

Datos técnicosPresión : 32 toCalibra : (stepless) desde: 80 s/minup hasta: 400 s/minEjecución : 4 soportaSuperficie de mesa: Longitud: 420 mmNillo : 380 mmAltura de la herramienta: 300 mmCon potencia de prensado: upside downAjuste del deslizamiento: 50 mmAjuste de deslizamiento: desde: 6 mmhasta de golpe: 50 mmdiámetro del deslizamiento: 32 mmSuperficie de sujeción del deslizamiento: Longitud: 420 mm Ancho: 380 mmPaso entre los soportes: longitudinal: 420 mmLateral : 250 mmVoltaje 50 Hz 3x: 380 VoltioPeso de la máquina: 3000 kgTamañaduras totales: Longitud: 1400 mmVuelo : 900 mmAltura: 2700 mmAccesorios variados: Alimentación automática: número: 1 Ejecución: colletsAcerdo de roscadoIzquido neumáticoExtractor de la sumidera Carretes de stock con motor eléctrico

pressure: 63 t stroke: 10-80 mm no. of strokes: 65-400 Hub/min ram - range of adjustment: 80 mm table surface area: 1030x550 mm ram surface: 920x450 mm hole in the table: 700x200 mm : 420 mm weight of the machine ca.: 10 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Capacidad (x): 0 Aproceso aplicación: 0 Otra información: 0 Datos técnicos Taper en husillo: BT 50 Diámetro: 53 - 70 mm

pressure: 40 t dayligth: 250 mm stroke: 8 - 50 mm table clamping surface LxW: 620 x 450 mm table height over floor: 980 mm no. of strokes: 85 - 500 Hub/min distance between columns: 680 mm ram - range of adjustment: 50 mm number of T-slots: 4 ram surface: mm total power requirement: 8 kW dimensions of the machine ca.: 2,3 x 2,2 x 2,8 m weight of the machine ca.: 5,8 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 75 t throat: 260 mm stroke: 16-80 mm table surface area: 800 x 520 mm distance table/ram: 350 mm strokes - infinitely variable: 50 - 250 Hub/min ram surface: 400 x 300 mm ram adjustment: 70 mm total power requirement: 7,5 kW dimensions of the machine ca.: 2,7 x 1,7 x 2,6 m weight of the machine ca.: 4 t hole in the table: 260 x 180 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
