x-travel: 8000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 355 taper ISO: 50 spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 27,6 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 4.700 mm y-travel: 1.250 mm z-travel: 1.500 mm control: HEIDENHAIN iTNC 530 clamping table: - surface area: 5.000 x 1.000 mm max. workpiece weight: 10.000 kg T-slot number x size: 7 x 22 Abstand 140 mm Universal Milling Head: _ Swiveling area front/back level: automatisch Indexing: 0,001 x 0,001° stepless Constant Power at 100 % ED: 37 kW Speed range, stepless: 35 - 4.500 min-1 max. torque: 880 Nm tool taper: SK 50 – DIN 69871 internal coolant system feed: durch das Spindelzentrum automatic tool changer ATC: - Tool places: 60 Plätze diameter of tools max.: 125/240 mm workpiece length: 300 mm weight of tools max.: 25 kg feeds: - X-, Y- and Z-axis, stepless: 6 - 15.000 mm/min rapid in X/Y/Z: 25.000 m/min max. feed force X-Y-Z-axis: 10.000 N total power requirement: kW weight of the machine ca.: 35 t dimensions of the machine ca.: 12,7 x 5,6 x 4,2 m Equipment / Accessories:Hea ...
x-travel: 10000 mm y-travel: 1500 mm z-travel: 3000 mm Control: Heidenhain TNC 430 tool taper: ISO 50 spindle turning speed - stepless: 10 - 3000 U/min feed range: 10000 mm/min rapid traverse: 15 m/min main drive motor: 37 kW total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC-control HEIDENHAIN TNC 430 40-station ATC NC-Universal Milling head, automatic positioning (A/B axis 0.001 / 0.001 deg) Chip conveyor Optional (price upon request): CNC rotary table Juaristi 3000 x 3000 mm - Table load 30 to - Longitudinal movement 2000mm - Separate CNC-control FAGOR The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 7000 mm y-travel: 2000 mm z-travel: 1250 mm control: Heidenhain iTNC 530 plate size: 7000 x 1500 mm tool change unit: 60 Pos turning speeds: 35 - 4500 U/min spindle motor: 37 kW rapid traverse: 20 / 10 m/min total power requirement: - kW weight of the machine ca.: - t required space: - m equipped with: - Heidenhain iTNC 530 CNC control - Tool changer for 60 tools (ISO 50) - autom. Milling head (0,001 °) - Spindle cooling 15bar with paper band filter - Chip conveyor - Renishaw RMP 60 - Extra Miling Head (Spare Part) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 10000 mm y-travel: 3000 mm z-travel: 1500 mm Control: Heidenhain TNC 430CA milling head -swivable: 360.000 pos spindle turning speed range: 10 - 3000 U/min Tools changer: 40 pos. feed: 5000 mm/min Rapid Travel X / Y / Z-Achse: 10 / 15 / 15 m/min spindle motor: 37 kW total power requirement: 80 kVA weight of the machine ca.: 40 t dimensions of the machine ca.: m Traveling column milling and boring machine - Control Heidenhain TNC 430CA & HR 410 - autom. Tool changer with 40 places (SK 50) - Huron Universal milling head, automatic Positioning (A-/B-Axis each 0,001°) - Chip conveyor - OPTIONAL: Rotary Table 3000x3000mm - 30t (W-Axes: 2000mm), with independent FAGOR CNC Control The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 5005 mm, 3586 mm, 1106 mm
Üretim yılı: 2007 Otomatik alet değişimi Çalışma alanları [mm]: 5000x2500 Oluk mesafesi [mm]: 200 Seyahat menzili [mm]: 5005x3586x1106 İş beslemesi [bk/daq]: 35m/daq Hızlı besleme [b/min]: 40 Mil hızı [rpm]: 35 - 6000 Mil torku [kW]: 37kW Maksimum tork [Nm/rpm]: 670/525 Takım sıkıştırma: HSK-A 100 Tool magazin [pcs.]: 100k Makine kontrol sistemi: iTNC 530 2x univerzální úhlová hlava 45 Doğrudan çıkış başlığı Güç kaynağ
Env. Sayı : 7770 Türü: KFU 3000 Yapımcı: Zayer Oluşturuldu: 1990 Parametre: İşletim sistemi: HEIDENHAIN TNC 415 B Tabla uzunluğu: 3000 mm Tabla genişliği: 1000 mm Maksimum masa yükü: 10000 kg Hız: 3000 1 / dak Eksen X: 2700 mm Eksen Y: 1000 mm Eksen Z: 1000 mm Makine boyutları: 4000 x 2500 x 2800 mm Ağırlık: 18600 kg Ekipman: Zımba teli (yaklaşık 40 adet) Mengene (2 adet) Açı (2 adet) Sıkıştırma Blokları (2 adet)
Zayer 30KCU700AR (2003), Heidenhain iTNC 530 ile. - x, y, z = 7000, 2000, 1250 - CTS 15 çubuğu - Kontrollü freze kafası (konum doğruluğu 0,001) - 60 araç - 37 kW iş mili motoru - Hızlı travers 20/10 m/dak - 4500 dev/dak - ISO50 Standardı - Renishaw RPM60 Serisi -Konveyör - Ek freze kafası (yedek)
x-travel: 10000 mm y-travel: 1500 mm z-travel: 3000 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m - CNC control Heidenhain TNC 415B - controlled 2-axes NC-milling head 2,5° - coolant device The machine will be sold without the plate field Accessories: ca. 20 pieces tool tapers DIN 2080 with bolts DIN 69872 some spare parts like bevel gears for the milling head and ball screw for X-axis. Technische Daten / technical details: Verfahrweg X längs / X-travel longitudinal 10000 mm Verfahrweg Y quer / Y-travel cross 1500 mm Verfahrweg Z vertikal / Z-travel vertical 3000 mm Werkzeugschaft / spindle taper SK50 Drehzahlbereich (2-stufig) / spindle speed (2-steps) 35-3000 UpM /rpm Vorschub / infeed 6-10000 mm/min Eilgang X,Y,Z / rapid feed X,Y,Z 10, 15, 10 m/min Antriebsleistung Hauptmotor 100%ED / drive capacity main motor 100%ED 37 ...
x-travel: 10000 mm y-travel: 1500 mm z-travel: 2700 mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 7.000 mm y-travel: 2.000 mm z-travel: 1.250 mm Control: Heidenhain iTNC 530 Internal cooling system: 15 bar milling head: Automatisch 0,001 spindle turning speed range: 4.500 U/min spindle drive: 37 kW taper ISO: 50 tool change unit: 60 Chip coveyor: Inkl. rapid traverse: 20/10 m/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m -CTS 15 bars -Controlled milling head (pos. Accuracy 0,001) -60 tools -37 kw spindle motor -rapid 20/10 m min -4500 rpm -iso50 -Renishaw RPM60 -chip conveyor -extra milling head (spare) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1700 mm y-travel: 800 mm z-travel: 890 mm table surface area: 2000 x 630 mm spindle taper: SK 50 spindle turning speed range: 35 - 3000 U/min spindle drive: 26 kW feeds longditudinal/cross/vertical: 6 - 5000 mm/min rapid traverse: 15 m/min table load: max. 6000 kg control: HEIDENHAIN control: TNC 360 total power requirement: 45 kVA weight of the machine ca.: 13 t dimensions of machine L x W x H: 5,2 x 2,78 x 2,95 m Accessories: vertical head swivelling in 2 planes with hydr. tool clamping, various tool fixtures, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 12000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 415 taper ISO: 50 P.D.B. spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 37 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 4700 mm y-travel: 1000 mm z-travel: 1000 mm control: HEIDENHAIN TNC355 table-size: 5000x1000 mm T-slots: 7x mm turning speed range: 2800 U/min feed: 6-5000 mm/min rapid traverse: 15000 mm/min spindle motor: 30,00 kW spindle taper: SK 50 Table load: 10.000 kg Main drive: 40 PS weight of the machine ca.: 27,00 t dimensions of the machine ca.: m With HEIDENHAIN TNC 355 control. Machine can be inspected under power. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 10000 mm y-travel: 1100 mm z-travel: 1700 mm Control: Heidenhain type: TNC 155 Tool changer: 30 table surface area: 10000x1000 mm chip conveyor: universal head: table height over floor: 800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 3.400 mm y-travel: 1.250 mm z-travel: 2.000 mm Control: TNC-430PA table-size: 4.700 X 1.200 mm V- travel: 500 tool taper: ISO 50 milling head -swivable: 0.001º/0.001º Grad main drive: 37 kW Chip coveyor: inkl handwheel: HR-410 Tools changer: 60 pos. milling head: Automatic Head 45º weight of the machine ca.: 35 t - Automatic Head 45º INCLUDED - Automatic Head 45º 0.001º/0.001º - Head 45º Max. Speed 3.000 rpm - 45º Head Taper ISO-50 - Twist Head Contiuous INCLUDED - Twist Head Max Speed 3.000 rpm - Twist Head Taper ISO-50 - Ram with Quill - Quill Diameter 150 mm. - Quill Taper ISO-50 - Pick up station AITEK for 45º and Twist Heads - Rotary Table ZEATZ Ø 1200 INCLUDED - RENISHAW MP 16+SP2/1 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 22.000 mm y-travel: 1.500 mm z-travel: 3.000 mm Control: SIEMENS 840 D milling head -swivable: 0,001/0,001 Grad milling head: Universalfräskopf 45° Internal cooling system: 20 bar Chip coveyor: ja Tools changer: 30 pos. coolant: 1.100 l Tool taper: DIN 69871A ISO 50 total power requirement: 45 kW weight of the machine ca.: 68 t The round table shown in the pictures as well as the plate field are not sold with ! urning Speeds 6.000 r.p.m. AutoIndex Head 45 º Head 360.000 Pos. Elbow 360.000 Pos. Main Motor Power 37 Kw. Nº Change Range 2 Ranges Automatic Tool Charger INCLUDED Tools at ATC 30 Coolant Through Tool 20 Bar INCLUDED Soluble Oil Tank with filter paper INCLUDED Head Coolant System + CF Box INCLUDED Longitudinal Chip Conveyor INCLUDED Operator?s Platformd with 2000 mm Vertical movement. INCLUDED Ready for Rotor Translating Table (Regulator + Wires) /IN ...
Üretici ZAYER Model 30 KMU-5000 1999 Yılı CNC HEIDENHAIN TNC-430PA Masa yüzeyi 4.700 x 1.200 mm. Stroklar (X/Y/Z) 3.400/1.250/2.000 mm. Şaft Çıkışı (Batı Ekseni) 500 mm. ISO-50 Baş Konisi Ana Motor Gücü 37 kW 45º Otomatik Kapak DAHILDIR Baş Dönüşü 45º Otomatik Dönüş 0.001º/0.001º Baş devirleri 45º 3.000 rpm 45º ISO-50 Baş Konisi Sürekli Bükme Başlığı DAHILDİR Twist head devirleri 3.000 rpm'de Twist Head Konisi ISO-50 Bastonlu ram DAHILDİR Şaft çapı 150 mm. ISO-50 Çubuk Konisi İç ve dış soğutma başlığı 45º ve çubuk DAHILDİR Dış soğutma burma başlığı DAHILDIR Yarı otomatik kafa manyetiği DAHIL Otomatik Yükleme Araçları DAHIL Yükleyici Pozisyonları Htas 60 45º kafa depolama için AITEK Pickup Station ve Twist Head DAHILDİR Çip tahliyesi DAHILDİR HEIDENHAIN HR-410 Taşınabilir Direksiyon RENIS ...
Bu 3 eksenli Zayer KF 4000 1989 yılında üretilmiştir. 4.000 Ü1.000 mm büyüklüğünde bir masa sahiptir ve 10.000 kg'a kadar yükleri kaldırabiliyor. 3.000 rpm'ye kadar mil hızı ve 30â37 kW güç aralığı ile sağlam işleme yetenekleri sağlar. Bu Zayer KF 4000 evrensel işleme merkezini satın alma fırsatını değerlendirin. Bu makine hakkında daha fazla bilgi için bizimle iletişime geçin.
Sabit yataklı freze makinesi Zayer 2000BF. Tablo: 2500x700mm. Boyuna hareket: 2000mm. Çapraz seyahat: 1000mm. Dikey hareket: 1000mm. ISO50. Hızlar: 18. (28-1800rpm). Güç: 15cv. Ağırlık: 13000Kgs. DRO Fagor ile donatılmıştır.
Otomatik hareket koçlu üniversal freze makinesi. Tablo: 1700x700. Boyuna hareket: 1320mm. Çapraz seyahat: 1016mm. Dikey hareket: 560mm. ISO50. 18 hız (28-1800rpm) 18,75 Hp. Ağırlık: 6200Kg.
Bu 3 eksenli Zayer 30KF 3000 dikey işleme merkezi 1997 yılında üretilmiştir. Karmaşık işleme işleri için sağlam yapı ve hassasiyet sunar. İkinci el bir makinede güvenilir performans arayanlar için idealdir. Daha fazla bilgi için bizimle iletişime geçin.
Key data: 6000 mm, 2000 mm, 3000 mm
Makina tipi: CNC Hareketli Kolon Freze Makinesi ZAYER yapın KCU6000 yazın Yapım yılı 1992 Kontrol tipi: Heidenhain TNC 415 X yolu (mm) 6.000 Y-kapalı (mm) 2.000 Z-kapalı (mm) 3.000 (rpm) 20 - 1.800 arası hızlar Takım tutucu BT50 Boyuna besleme (mm/dev) 5 - 5000 mm/dak Enine besleme (mm/U) 5- 5000 mm/dak. Dikey ilerleme hızı (mm/dev): 5- 5000 mm/dak. Hızlı travers 10.000 mm/dak. Toplam güç (KW) 34 Uzunluk (mm) 11.000 Genişlik (mm) 2.500 Yükseklik (mm) 7.000 Ağırlık 31.000 kg Bilgi 'Juaristi MG6' döner tabla: 1500 x 1200 mm Soğutma sıvısı pompası ile Soğutma sistemi: 2,5 bar Takım soğutma: 15 bar
x-travel: 6000 mm y-travel: 2000 mm z-travel: 3000 mm Control: heidenhain TNC 415 total power requirement: 34 kW weight of the machine ca.: 31 t dimensions of the machine ca.: 7000 mm m Stocknumber 1110055 Type of machine CNC Floortype milling machine Make ZAYER Type KCU6000 Build in 1992 Type of control Heidenhain TNC 415 X-stroke (mm) 6.000 Y-stroke (mm) 2.000 Z-stroke (mm) 3.000 Speeds (Rpm) 20 - 1.800 Admission in spindlehead BT50 Feeds X (mm/R) 5 - 5000 mm/min Feeds Y (mm/R) 5- 5000 mm/min. Feeds Z (mm/R) 5- 5000 mm/min. Rapid feeds 10.000 mm/min. Total Power (KW) 34 Lenght (mm) 11.000 Width (mm) 2.500 Height (mm) 7.000 Weight 31.000 Kg Additional information Juaristi MG6 turntable: 1500 x 1200 mm Cooling system: 2.5 Bar Tool cooling: 15 Bar The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 4700 mm y-travel: 1000 mm z-travel: 1000 mm control: HEIDENHAIN TNC355 table-size: 5000x1000 mm T-slots: 7x mm turning speed range: 2800 U/min feed: 6-5000 mm/min rapid traverse: 15000 mm/min spindle motor: 30,00 kW spindle taper: SK 50 Table load: 10.000 kg Main drive: 40 PS weight of the machine ca.: 27,00 t dimensions of the machine ca.: m With HEIDENHAIN TNC 355 control. Machine can be inspected under power. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Kod 8529 Açıklama CNC Yatak freze makinesi Zayer Yap Tip 2200 BF 3 Makine nmb 52248 Yıl 1986 Kontrol Fagor 8020 Masa boyutu 2200 x 800 mm Hareket tablası (X) 1830 mm Çapraz çapraz travers koçu (Y) 1016 mm Dikey travers freze kafası (Z) 1016 mm İş mili konik ISO 50 Masadaki ağırlık 4000 kg Hayır. iş mili hızı 18 adım İş mili hızları 28 – 1800 rpm Besler dir. Progr. X-Y-Z 3 – 5000 mm/dak Rapids Boyuna 5 m/dak Çapraz 5 m/dak Dikey 5 m/dak Toplam Ağırlık 10.000 kg Ana motor 11 kW Güç bağlantısı 38 KVA Gerilim 380 Volt Aksesuarlar Freze kafası Horiz./Vert. ISO-50 ile Hidr. takım sıkma cihazı Kondisyon Makinesi iyi durumda
