66 TRAUB satılık ikinci el makine

turning diameter:500 mm turning length:1000 mm weight of the machine ca.:7,3 t dimensions of the machine ca.:6,5 x 4,45 x 2,21 m

turning diameter:275 mm turning length:900 mm spindle passage:65 mm power capacity at 100 % load:25/20 kW spindle turning speed range:1 - 5000 U/min spindle diameter in front bearing:110 mm c-axis:1 - 500 U/min. number of workpiece supports:4 tool turret:1 x-axis:290 mm y-axis:165 mm z-axis:360 mm b-axis:360 ° rapid speed:18/30 m/min number of tools:2x2 + 2x2 number of driven tools:2x2 + 2x2 mm toolpiece turning speed range:8000 / 2000 U/min power capacity:25% ED 5,8 kW tool taper:TRAUB 60 tool turret:2/3/4 x-axis:170 mm z-axis:600/950 mm y-axis:+/- 60 mm rapid speed:18/15/30 m/min number of driven tools:10 mm toolpiece turning speed range:1 - 6000 U/min power capacity:25% ED 5,8 kW tool taper:DIN 69880 40 x 63 total power requirement:95 kW weight of the machine ca.:16 t dimensions of the machine ca.:10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and  ...

turning diameter:445 mm turning length:2000 mm turning diameter over bed slide:660 spindle bore:65 mm spindle speeds::16 - 3150 U/min. rapid motion - x-axis:10 mm/min rapid traverse Z-axis:15 m/min total power requirement:34 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:6 x 2,5 x 2,2 m with CNC Control TX 8 D C-axis driven tooling 14 station turret head 3 jaw chuck dia. 315 mm tailstock, steady as NC-axis diverse driven toolholders diverse turning toolholders chip conveyor and coolant attachment

Manufacturer:TRAUB Model: TNX 80/65 Year of Manufacture: 2008 Type of Machine : CNC Lathe Total Power Requirement: 95 kW Voltage: 400 V, 50 Hz Machine Weight: approx. 14,000 kg Machine Dimensions (L x W x H): approx. 5.5 m x 7.8 m x 2.52 m Floor Space Required: approx. 5.5 m x 7.8 m Spindle Specifications - Spindle head DIN 55026: HSP A8 / GSP A6 - Spindle bore diameter: 65 mm - Maximum spindle speed: 4,300 min-1 (HSP) / 5,000 min-1 (GSP) - Main spindle motor output: 25.2 / 30.2 kW - Counter spindle motor output: 17 / 21.5 kW Turret System - Turret positions: 4 turrets (positions 1, 2, 3 and 4) - Turret stroke X-axis: 170 mm - Turret stroke Y-axis: plus/minus 60 mm - Turret stroke Z-axis: 600 / 500 / 950 mm - Number of driven tools per turret: up to 10 - Vertical tool holders DIN 69880: 40 x 63 mm Linear Tool Carrier - B-axis: swivelling - Number of driven tools: 2x2 / 2x2( ...

Manufacturer: TRAUB Model: TNX 80/65 Year of Manufacture: 2005 Type of Machine : CNC Lathe Total Power Requirement: 95 kW Voltage: 400 V, 50 Hz Machine Weight: approx. 14,000 kg Machine Dimensions (L x W x H): approx. 5.5 m x 7.8 m x 2.52 m Floor Space Required: approx. 5.5 m x 7.8 m Spindle Specifications - Spindle head DIN 55026: HSP A8 / GSP A6 - Spindle bore diameter: 65 mm - Maximum spindle speed HSP: 5,000 min-1 - Maximum spindle speed GSP: 5,000 min-1 - Main spindle motor output: 25.2 / 30.2 kW - Counter spindle motor output: 17 / 21.5 kW Turret System - Turret positions: 4 turrets (positions 1, 2, 3 and 4) - Turret stroke X-axis: 170 mm - Turret stroke Y-axis: plus/minus 60 mm - Turret stroke Z-axis: 600 / 500 / 950 mm - Number of driven tools per turret: up to 10 - Vertical tool holders DIN 69880: 40 x 63 mm Linear Tool Carrier - B-axis: swivelling - Number of driv ...

Torna çapı: 5-42 mm dönüş uzunluğu: 3200 mmkontrol: Traub TX8i x ekseni: 50 mmz ekseni: 50 mm toplam güç gereksinimi: kW makinenin ağırlığı ca.: 4000 kgmakinenin boyutları ca.: mBu reklamın verileri, LogoTech oHG'nin yazılım çözümü ModulMWS ile oluşturulmuştur.

Mil geçişi: 80 mmmax. Turlama çapı: Max. 395 mm. Vida uzunluğu: 750 mmKontrol: System TX 8H max. Mil hızı: 3.150 U/d. CNC torna makinesi | TRAUB - TNA 400Makine iyi bakımlı bir durumda. - - - - - -#Tags:TNA400 | TNA-400Bu reklam için veri, LogoTech oHG'nin yazılım çözümü olan ModulMWS ile oluşturuldu.

spindle passage: 80 mm max. turning diameter: 460 mm Max. Turning length: 1.000 mm control: System TX 8F max. Spindle speed: 2.800 U/min. CNC lathe | TRAUB - TNA 500 The machine is in a well-maintained condition. The machine videos from the production plant will be shared on request. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags:TNA500 | TNA-500 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Torna çapı: 480 mm Torna uzunluğu: 800 mm kontrol: Sistem TX8F sürgü üzerinden dönme çapı: 240 mm mil geçişi: 65 mm çap: 200 mm dönüş hızı: 4000 U/min. güç kapasitesi: 30 kWToplam güç gereksinimi: makinenin kW ağırlığı ca.: 4,3 makinenin boyutu ca.: güçlendirilmiş araçlarBu reklamın verileri, LogoTech oHG'nin yazılım çözümü ModulMWS ile oluşturulmuştur.

turning diameter: 12,7 mm turning length: 50 mm control: Traub System TX 8i turning speeds: 12000 U/min c-axis: 0,001° c-axis: 0,001 ° gripping station: 12,7 mm speeds: 12000 U/min rapid traverse: 15 m/min turret (x-stations): 6 worktool system: 5+3 worktool system: 3 Werkzeugsysteme total power requirement: 2,5/4 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2,4 x 1,1 x 1,7 m driven tools: 6+4+4 Rev+S7+S8 CNC turning machine Traub TNL 12K with barloader LNS Tryton 112 Motor drive S8 (rear working with driven tools possible) Motor drive S7 (front working with driven tools possible) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 275 mm turning length: 900 mm control: TRAUB TX8i Main- opposite spindle: spindle passage: 65 mm power capacity at 100 % load: 25,20 kW power capacity at 40 % load: 30,20 KW max. torque at 40% / 100% load: 180 / 135 Nm spindle turning speed - stepless: 1 - 5.000 U/min spindle diameter in front bearing: 110 mm C-axis: 1 - 500 U/min worktool support: No. 1 x-axis: 290 mm y-axis: 165 mm z-axis: 600/950 mm B - axis: 360 ° rapid traverse X/Y/Z: 18 / 18 / 30 m/min feed capacity X/Y/Z: 10 / 10 / 7 kN number of tools: 2x2 + 2x2 number of driven tools: 2x2 + 2x2 mm toolpiece turning speed range: 8.000 / 2.000 U/min power capacity at 25 % load: 5,80 kW max. torque at 25% load: 4x18,6 / 4x74 Nm tool taper: TRAUB Ø60 worktool support: No.2 / No.3 / No.4 x-axis: 170 mm z-axis: 600/950 mm y-axis: +/- 60 mm rapid traverse X/Y/Z: 18 / 15 / 30 m/min feed capacity X/Y/Z: 10 / 10 / 7 k ...

max. bar material dia.: 65 mm max. swing diameter: 175 mm max. bar length: 3.000 mm control: System TX 8F travel -x axis: 140 mm travel -z axis: 520 mm CNC lathe | TRAUB - TNC 42/65 DG equipped with bar loader. The machine is in a well-maintained condition and can be inspected at any time under power. The machine videos from the production plant will be shared on request. Technical data of the machine will follow soon. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TNC65 | TNC-65 |TNC 42-65 DG | TNC 42/65DG The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Satılık Traub TNL 12 K torna tezgahı Yapım Yılı 2005 Masrafları alıcıya ait olmak üzere kamyonun çıkarılması ve yüklenmesi Nakliye sigortası hariç fabrika teslimi teslimat Daha fazlasını burada bulabilirsiniz - / Bize ulaşın -

CNC Kontrol Traub Sistemi TX 8D C ekseni/Tahrikli aletler Çubuk besleyici Stamag DN42 Bitmiş parçaların toplayıcısı Talaş konveyörü Dahili sıvı soğutma Çok iyi durumda çubuk çapı 42 mm Dönüş uzunluğu 220 mm Hidrolik ayna Chuck- max. tornalama çapı 140 mm tornalama çapı 140 mm yatak üzerinde tornalama çapı 390 mm İş mili delik işleme 42 mm Taret kafası sayısı- 3 -1. taret 12 alet -2. taret 12 alet -3. taret 4 alet Takım tutucular VDI 30 X ekseni hareketi 200 mm Z ekseni hareketi 300 mm İş mili hızı 5600 rpm çubuk uzunluğu 4200 mm 42-7 arasındaki çalışma çubukları Toplam güç gereksinimi 34 kW Kilitlemeli kapak Toplam boyutlar: 7400x1900x2400 mm Ağırlık 4500 kg

BASIC FUNCTIONS   number of spindles: 1   number of turrets: 1   live positions: yes WORKING RANGE TURNING   swing diameter (max): 560 mm   turning diameter (max): 275 mm   bar diameter (max): 42 mm   worpiece length max.: 450 mm MAIN SPINDLE   spindle revolutions (min): 5600 /min   drive power: 11 kW X/Z SLIDE   number of tool positions (total): 11   number of live positions: 11   - rotation speeds (max): 4500 /min TAILSTOCK   sleeve stroke: 60 mm   sleeve diameter: 70 mm   holding force (max.): 8600 kN ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2700 mm   space requirements -front/back-: 1600 mm   total height: 1800 mm   total weight approx.: 3500 kg ATTACHMENTS (TURNING)   chip conveyor: yes   European CE standards: yes

CONTROLS   CNC controls TRAUB TX 8 BASIC FUNCTIONS   number of spindles: 1   number machining units (turrets): 1   number of turrets: 1   live positions: yes   number of c-axes: 1 WORKING RANGE TURNING   swing diameter (max): 450 mm   turning diameter (max): 350 mm   bar diameter (max): 60 mm   worpiece length max.: 490 mm MAIN SPINDLE   spindle revolutions (max): 4000 /min   c-axis: yes TOOL MAGAZINE   number of positions: 12 ELECTRICAL SPECIFICATIONS   total power consumption: 39 kW   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 3150 mm   space requirements -front/back-: 2100 mm   total height: 2100 mm   total weight approx.: 4000 kg ATTACHMENTS (TURNING)   tailstock: yes - Machine in good condition Features: - Complete tool holders (very comprehensive) - Includes driven tool hold ...

CONTROLS   CNC controls TRAUB TX8I-S BASIC FUNCTIONS   number of spindles: 2   live positions: yes   number of c-axes: 2 WORKING RANGE TURNING   turning diameter (max): 20 mm   bar diameter (max): 20 mm MAIN SPINDLE   spindle revolutions (max): 10000 /min   c-axis: yes COUNTER SPINDLE   spindle revolutions (max): 10000 /min   c-axis: yes ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz ATTACHMENTS (TURNING)   chip conveyor: yes   through spindle coolant attachment: yes   hydraulic system: yes   European CE standards: yes - Interchangeable operation: Can be used as a short- or long-turning lathe Equipment: Number of axes: 12 (15) - Main spindle C - Sub-spindle D20 with X/Z/C axes - Upper tool gantry with X/Y/Z/H/B axes and 8 tool holders - Lower tool gantry with X/Y/Z/H axes and 8 tool holders - Coolant system with 20 to 80 ba ...

Env. No. : 8535 Türü: TNL 18P Üretici: TRAUB Oluşturuldu: 2013 Parametre: Kontrol sistemi: TRAUB SYSTEM TX 8i-p çubuk çapı: 20 mm Maksimum dönüş uzunluğu: 180 mm İğ Sayısı: 2 adet Maksimum iş mili hızı: 8000 1 / dak Uzunluk: 2500 mm Genişlik: 1460 mm Yükseklik: 2250 mm Ağırlık: 4000 kg Ekipman: Çubuk Sürücü

Article: Programme-controlled automatic lathe Manufacturer: Traub Type: TF60 / 140 Yob: 1978 Bar automat Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

Key data: 800 mm, 600 mm, 500 1/min

CNC kontrolü Traub System TX8 I, bar geçişi 42 mm, maksimum dönüş uzunluğu 450 mm, maksimum hız 8000 rpm, her biri 10 alet pozisyonu olan 2 taret, tahrik edilmiş aletler, soğutma sistemi, KNOLL 240 S-1/50 yonga konveyörü, filtrasyon sistemi/kompakt kayış filtresi RESY

CNC kontrol Traub System TX8 I, bar geçişi 42 mm, maksimum dönüş uzunluğu 450 mm, maksimum hız 8000 rpm, her biri 10 alet pozisyonu olan 2 taret, tahrik edilmiş aletler, yonga konveyör KNOLL 240 S-1/50, filtrasyon sistemi/kompakt bant filtre RESY KBF 452/500

CNC kontrol Traub System TX8 F, 6 alet pozisyonu ile 1 taret ve 6 alet pozisyonu olan 1 taret, sürülen aletler, 30 mm bar geçiti, polar filtre sistemi, soğutma cihazı ve aut. Bar yükleme şarjörü

CNC kontrollü Traub System TX8 D, 1 taret, 12 alet pozisyonu, 60 mm bar geçişi, polar filtre sistemi ve yonga konveyörü ile

CNC kontrollü Traub System TX8 D, 1 taret ile 14 alet pozisyonu ve 1 taret ile 9 alet pozisyonu, sürülen aletler, maksimum torlama uzunluğu yaklaşık 1000 mm, bar geçişi 80 mm, güç 73 KW, polar filtre sistemi ve yonga konveyörü ile

This 3-axis TRAUB TNA 300 horizontal turning machine was manufactured in 2000. It features a spindle diameter of 65 mm and includes a high-pressure coolant system, driven tools with 4 kW power, and an automatic bar change system. The machine is equipped with a chip conveyor and tool monitoring systems for enhanced efficiency. If you are looking to get high-quality turning capabilities, consider the TRAUB TNA 300 machine we have for sale. Contact us for further details.

This 4-axis TRAUB TNC 65 DG was manufactured in 2009. It features a powerful tool drive turret with a speed of 4000 rpm and a high-pressure coolant system with programmable pressure stages. The machine is designed for machining metals and plastics, equipped with a C-axis for numerically controlled turning and positioning. If you are looking to get high-quality turning capabilities, consider the TRAUB TNC 65 DG horizontal turning machine we have for sale. Contact us for further details.

This 5-axis TRAUB TNC65 DG was manufactured in 1999. It features a robust control system with TRAUB TX8H technology, dual tool carriers with 10 stations each, and a maximum clamping diameter of 60 mm. The machine is equipped with a coolant cleaning system and a hinged belt conveyor for efficient chip removal. If you are looking to get high-quality turning capabilities, consider the TRAUB TNC65 DG horizontal turning machine we have for sale. Contact us for further details.

Genel CNC eğik yataklı torna Traub mevcuttur. Takım istasyonları: 12, alet tutucu: VDI40, turlama çapı: 180mm, maksimum salınım çapı: 450mm, maksimum dönüş uzunluğu: 490mm, bar kapasitesi: 60mm, hareket X/Z: 160mm/490mm, hızlı dönüş: 15m/dakika, besleme hızı: 10m/dakika, makine boyutları X/Y/Z: yaklaşık 3100mm/2000mm/1800mm, ağırlık: yaklaşık 4250kg, kontrol: Traub System TX-8. Sahada inceleme yapılabilir.

turning diameter over bed: 254 mm spindle passage: 20 mm turning length: 120 mm Control: TX8i-s total power requirement: 40 kW weight of the machine ca.: 5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
