Transnorm Pneumatic Pusher 900-600-500 90° RA2092 Technical Specifications: External Dimensions of Mounting Frame: LxWxH=980x700x825 mm Maximum Product Width: 900 mm Maximum product height: 640 mm Maximum conveyor belt-frame width (NB): 600 mm Maximum conveyor belt-frame height (BH): 90 mm Support feet: available as an option Drive: Pneumatic cylinder Optionally available : Control system Prices net plus VAT from the central warehouse of Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns in Verbindung. Kontaktieren Sie uns einfach telefonisch oder per Mail. Wir helfen Ihnen gerne bei der Planung und Umsetzung Ihrer Projekte. Wir freuen uns darauf von Ihnen zu hören. Mit freundlichen Grüßen Ihr Team der Dr. Sonntag GmbH & Co. KG Ihr Spezialist und Ansprechpartner für Intralogistik
Transnorm conveyor belt GF 5650-600-500 RA2450 Technical data: Conveyor length (NL): 5650 mm frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed. Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0,75 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 41 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: condition: good (used) Conveying length in mm: 5650 Nominal / outside width in mm: 600 Belt width in mm: 500 Driven: YES Engine type: SEW Eurodrive Zentralantrieb mit Spannstation KW: 0,75/S1 ...
Transnorm Rising falling Incline belt conveyor with leading belt GF 800+1275+1005-700-600 RA2499 Technical data: Conveyor length (NL): 2980 mm ( 830 +150 mm arch + 1200 mm riser segment + 800 mm leading ) frame width (NB): 700 mm, 900 mm with motor belt width (GuB): 600 mm Overall height (BH): 80 mm, 430 mm with motor Angle: freely adjustable between 0 and 15° Supporting feet: optionally available Conveying speed (v m/s): contact us Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0,37 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: condition: good (used) Conveying length in mm: 2980 ( 800 + 1275 + 1005 ) Nominal / outside ...
Transnorm belt conveyor GF 4365-600-500 RA2493 Technical data: Conveyor length (NL): 4365 mm frame width (NB): 600 mm, 800 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 300 mm with motor support feet: optional Conveying speed (v m/s): contact us Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0,37 S1 drive drum: Ø = 81 mm belt return roller: Ø = 45 mm Year of manufacture: 2014 Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Customize length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Construction year: 2014 condition: good (used) Conveying length in mm: 4365 Nominal / outside width in mm: 600 Belt width in mm: 500 Driven: YES Engine type: SEW Eurodrive Zentralantrieb mit Spannstation KW: 0,37/S1 Ampere: 1,30 Co ...
Transnorm Rising falling Incline belt conveyor with leading belt GF 800+4650+560-600-500 RA2494 Technical data: Conveyor length (NL): 6100 mm ( 560 mm arch + 4650 mm riser segment + 800 mm leading ) frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 430 mm with motor Angle: freely adjustable between 0 and 15° Supporting feet: optionally available Conveying speed (v m/s): contact us Drive: SEW gear motor, R17DT71D4/BMG/TH Electrical data: 50Hz V380-500, kW 0,37 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Construction year: 2008 condition: good (used) Conveying length in mm: 6100 ( 8 ...
Transnorm accumulation roller conveyor 19000-600-550 RA2491 Make: Transnorm Roller width (RB): 550 mm Nominal/outer width (NB): 600 mm Length: 19000 mm Roller diameter: 50 mm Roller distance: 76 mm Drive motor: SEW Drive Eletrical Data: 380 V, 0,37 kW Accumulating space size: 700 mm Height frame: 140 mm including Motor: 300 mm Conveyor speed: please contact us Optionally available: Supports Sideguidesfrequency converter for stepples speed controlling Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: scope of delivery: without supports and side guides Driven: YES Engine type: SEW Eurodrive Zentralantrieb mit Spannstation Nominal / outside width in mm: 600 Roll width in mm: 550 condition: gut Jam detection: Lichtschranke nominal voltage: 380-480 V Conveyor speed m / s: bitte Kontaktieren Roll division in mm: 76 Conveying length in mm: ...
Transnorm roller conveyor 3620-600-555 RA2492 Make: Transnorm Roller width (RB): 550 mm Nominal/outer width (NB): 600 mm Length: 3620 mm Roller diameter: 50 mm Roller distance: 76 mm Drive motor: SEW Gear Motor Eletrical Data: 380 V, 0,37 kW Height frame: 140 mm including Motor: 300 mm Conveyor speed: please contact us Optionally available: Supports Sideguidesfrequency converter for stepples speed controlling Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: condition: good (used) Construction year: 1995 nominal voltage: 380-480 V Conveying length in mm: 3620 Nominal / outside width in mm: 600 Roll width in mm: 550 Roll division in mm: 76 Driven: YES Engine type: SEW Eurodrive KW: 0,37/S1 Conveyor speed m / s: bitte Kontaktieren scope of delivery: including side guides without supports For individual, expert advice, simply get in to ...
Transnorm conveyor belt with leading belt GF 4050+4890-600-500 RA2051 Technical data: Conveyor length (NL): 8940 mm (4050 mm + 4890 mm) frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed. Drive: SEW gear motor and overdrive from belt one to belt two Electrical data: 50Hz V380-500, kW 0,75 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: condition: good (used) Conveying length in mm: 8940 ( 4050 + 4890 ) Nominal / outside width in mm: 600 Belt ...
Transnorm conveyor belt with leading belt GF 4070+4430 -600-500 RA2052 Technical data: Conveyor length (NL): 8500 mm (4070 mm + 4430 mm) frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed. Drive: SEW gear motor and overdrive from belt one to belt two Electrical data: 50Hz V380-500, kW 0,75 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: condition: good (used) Conveying length in mm: 8500 ( 4070 + 4430 ) Nominal / outside width in mm: 600 Belt ...
Transnorm conveyor belt GF 1500-600-500 RA2070 Technical data: Conveyor length (NL): 1500 mm frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed. Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0,37 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Construction year: 1998 condition: good (used) Conveying length in mm: 1500 Nominal / outside width in mm: 600 Belt width in mm: 500 Driven: YES Engine type: SEW Eurodrive Zentralantrieb mit ...
Transnorm conveyor belt GF 15000-600-500 RA2067 Technical data: Conveyor length (NL): 15000 mm frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed. Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 1,1 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Construction year: 1998 condition: good (used) Conveying length in mm: 15000 Nominal / outside width in mm: 600 Belt width in mm: 500 Driven: YES Engine type: SEW Eurodrive Zentralantrieb mi ...
Transnorm conveyor belt GF 1250-600-500 RA2096 Technical data: Conveyor length (NL): 1250mm frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed. Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0,37 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Construction year: 1998 condition: good (used) Conveying length in mm: 1250 Nominal / outside width in mm: 600 Belt width in mm: 500 Driven: YES Engine type: SEW Eurodrive Zentralantrieb mit S ...
Transnorm belt conveyor GF 3250-700-600 RA2470 Technical data: Conveyor length (NL): 3250 mm frame width (NB): 700 mm, 800 mm with motor belt width (GuB): 600 mm Overall height (BH): 80 mm, 300 mm with motor support feet: optional Conveying speed (v m/s): 0.5 Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0,37 S1 drive drum: Ø = 81 mm belt return roller: Ø = 81 mm Year of manufacture: 1994 Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Customize length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: condition: good (used) Conveying length in mm: 3250 Nominal / outside width in mm: 700 Belt width in mm: 600 Driven: YES Engine type: SEW Eurodrive Zentralantrieb mit Spannstation KW: 0,37/S1 Ampere: 1,30 scope of delivery: without support ...
180 Derece Kuşak Eğri Konveyörü, Transnorm, TS 1500 -100 – kullanılmıştır - Fiyat ve konum: sadece 2.500.-€ (net) söküldü, paketlendi ve yüklendi! Üretici: Transnorm Tip: TS 1500 -100 Yapım Yılı: 1997 Nominal genişlik: 700mm İç yarıçap: 500mm Konveyör vinci: 180 derece Kemer Tipi: KT 94 Boyutlar: Ayak dahil Daha fazla boyut için bkz. eskiz (motor olmadan ölçülmüş) Durum: iyi Hemen müsait Konum: Frankenberg deposu alanı
Transnorm roller curve conveyor 90°-770-700 IR800 Make: Transnorm Type: TS 2712 Year of construction: 1996 Conveying speed V= 0,58 m/sec Conveying angle: 90° Roller width: 600 mm Outer width/nominal width (NB): 680 mm Inner radius: 800 mm Drive chain drive Rollers: plain bearings with conical plastic molded part Transport weight: 130 kg on Euro pallet Transport mast: L x W x H = 1800 x 900 x 450 mm Scope of delivery: without supports (please enquire if required) Optionally available supports Side guides Frequency converter for infinitely variable speed control Price plus VAT ex central warehouse Dr. Sonntag GmbH & Co. KG 97076 Würzburg Features: Antrieb: SEW Getriebemotor Running direction: links/ rechts nominal voltage: 380-500V Construction year: 1994 Drive type: Kette condition: very good (used) Nominal / inner radius in mm: 800 Nominal / outside width in mm: 770 Roll width in mm: ...
Transnorm conveyor belt GF 1050-600-500 RA2475 Technical data: Conveyor length (NL): 1050 mm frame width (NB): 600 mm, 800 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 300 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0,37 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm welded again before sale Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Construction year: 1999 condition: good (used) Conveying length in mm: 1050 Nominal / outside width in mm: 600 Belt width in mm: 500 Driven: YES Engine type: SEW Eurodrive Zentralantrieb mit Spannstation KW: 0,37/S1 scope of delivery ...
Transnorm conveyor belt GF 950-600-500 RA2474 Technical data: Conveyor length (NL): 950 mm frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 330 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0,37 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Construction year: 1999 condition: good (used) Conveying length in mm: 950 Nominal / outside width in mm: 600 Belt width in mm: 500 Driven: YES Engine type: SEW Getriebemotor KW: 0,37/S1 scope of delivery: without supports and side guides Für eine individuel ...
Transnorm conveyor belt GF 1020-600-500 RA2473 Technical data: Conveyor length (NL): 1020 mm frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 330 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Drive: SEW gear motor Electrical data: 50Hz V380-500, kW 0,37 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Construction year: 1999 condition: good (used) Conveying length in mm: 1020 Nominal / outside width in mm: 600 Belt width in mm: 500 Driven: YES Engine type: SEW Getriebemotor KW: 0,37/S1 scope of delivery: without supports and side guides Für eine individ ...
Conveyor belt, belt conveyor, conveyor belt, belt conveyor, belt conveyor -Manufacturer: Transnorm, belt conveyor type 1100 -Speed: frequency controlled, up to 58.7 m/min -Drive: SEW-Eurodrive 1.1/0.11 kW, see photo nameplate -Brake: 10 Nm -Belt width: 600 mm -Conveyor length: approx. 7700 mm / approx. 800 mm height adjustable -Set-up dimensions: 7720/860/H340 mm -Transport dimension: 3940/860/H490 mm -Total weight: 392 kg
Conveyor belt, belt conveyor, transport belt, belt conveyor, belt conveyor -Manufacturer: Transnorm, belt conveyor type 1100 -Speed: frequency-controlled, up to 83.5 m/min -Drive: SEW-Eurodrive 1.1/0.11 kW, see photo of nameplate -Brake: 10 Nm -Belt width: 600 mm -Conveyor length: approx. 7290 mm / approx. 780 mm height adjustable -Installation dimensions: 7290/860/H340 mm -Transport dimensions: 4230/860/H570 mm -Total weight: 358 kg
Conveyor belt, belt conveyor, conveyor belt, belt conveyor, belt conveyor -Manufacturer: Transnorm, belt conveyor type 1100 -Speed: frequency controlled, up to 83.5 m/min -Drive: SEW-Eurodrive 1.1/0.11 kW, see photo nameplate -Belt width: 600 mm, up to 800 mm possible -Conveyor length: approx. 13400 mm -Set-up dimension: 13495/940//H340 mm -Transport dimension: 4150/940/H670 mm -Total weight: 422 kg
Roller conveyor, conveyor belt, roller track -Roller width: 400 mm -Conveyor length: 2000 mm -Roller diameter: 50 mm -Central spacing: 100 mm -Height: 300 mm -driven: via flat belt -without: flat belts -Dimensions: 2000/520/H300 mm -Weight: 90 kg
Conveyor belt, belt conveyor, transport belt, belt conveyor, belt conveyor -Manufacturer: Transnorm, belt conveyor type 1100 -Speed: frequency-controlled, up to 83.5 m/min -Drive: SEW-Eurodrive 1.1/0.11 kW, see photo of nameplate -Belt width: 600 mm -Conveyor length: approx. 6000 mm -Installation dimensions: 6010/950/H340 mm -Transport dimensions: 4140/950/H430 mm Total weight: 300 kg
Conveyor belt, belt conveyor, transport belt, belt conveyor, belt conveyor -Manufacturer: Transnorm, belt conveyor type 1100 -Speed: frequency-controlled, up to 83.5 m/min -Drive: SEW-Eurodrive 1.1/0.11 kW, see photo of nameplate -Belt width: 600 mm -Conveyor length: approx. 6000 mm -Installation dimensions: 6000/940/H340 mm -Transport dimensions: 4200/940/H490 mm -Total weight: 269 kg
Curved roller conveyor, curved track, curved roller conveyor, curved roller conveyor, curved roller conveyor, roller curve, curved conveyor with drive, roller conveyor, roller curve conveyor -Manufacturer: Transnorm, roller curve conveyor 90° with drive -Type: TS 2712 -Rolls: Ø 54-84 x 500 mm -Speed: 24 m/min -Drive: SEW-Eurodrive 0.37 kW, see photo nameplate -Conveyor width: approx. 500 mm -Transport dimensions: 2260/1030/H410 mm -Weight: 99 kg
Conveyor belt, belt conveyor, transport belt, belt conveyor, belt conveyor -Conveyor belt: Belt conveyor -Speed: 23.45 m/min -Drive: SEW-Eurodrive 0.25 kW, see photo of nameplate -Belt width: 815 mm -Conveyor length: 7200 mm -Quantity: 4 pieces available -Price: per piece -Transport dimensions: 7255/1050/H270 mm -Weight: 202 kg/unit
Transnorm conveyor belt GF 15600-900-800 RA2217 Technical data: Conveyor length (NL): 15600mm frame width (NB): 900 mm, 1000 mm with motor belt width (GuB): 800 mm Overall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally available Conveying speed (v m/s): contact us Drive: SEW gear motor, SA47/T DT80 N4 Electrical data: 50Hz V380-500, kW 0,75 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: Construction year: 2014 condition: good (used) Conveying length in mm: 15600 Nominal / outside width in mm: 900 Belt width in mm: 800 Driven: YES Engine type: SEW Eurodrive Zentralantrieb mit Spannstation KW: 0,75/S1 Conveyor spe ...
Conveyor belt, belt conveyor belt, conveyor belt, belt conveyor, belt conveyor, flat belt conveyor -Manufacturer: Transnorm, belt conveyor type TS 1200 -Speed: frequency controlled, up to approx. 160 m/min -Drive: SEW-Eurodrive 0.055/0.55 kW i= 3.83, see photo of nameplate -Voltage: 380-500V -Brake: 5 Nm -Strap width: 500 mm -Conveying length: 848 mm -Quantity: 3x conveyor belt available -Price per piece -Transport dimension: 860/700/H415 mm -Weight: 62 kg/pc.
Conveyor belt, belt conveyor belt, conveyor belt, belt conveyor, belt conveyor, flat belt conveyor -Manufacturer: Transnorm, belt conveyor type TS 1200 -Speed: frequency controlled, up to approx. 205 m/min -Drive: SEW-Eurodrive 0.055/0.55 kW, see photo of nameplate -Voltage: 380-500V -Brake: 5 Nm -Strap width: 500 mm -Conveying length: 848 mm -Quantity: 2x conveyor belt available -Price per piece -Transport dimension: 875/700/H345 mm -Weight: 64 kg/St.
Conveyor belt, belt conveyor, transport belt, belt conveyor, belt conveyor -Manufacturer: Transnorm, belt conveyor with central drive -Type: 1100 -Drive: SEW-Eurodrive 1.1/0.11 kW, see photo of nameplate -Belt width: 600 mm -Conveyor length: approx. 13800 mm / height adjustable by approx. 1000 mm -Installation dimensions: 13880/970/H370 mm -Transport dimensions: 4770/970/H1580 mm -Total weight: 478 kg
