GeneralCNC Turning Centre with C axis and tool drive; Control: CNC control SIEMENS 840D ERGOLine Working areaSwing diameter over guide ways700 mmTurning diameter410 mmTransverse stroke300 mmLongitudinal stroke800 mmMax. Turning Length800 mmClamping chuck diameter max.250 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWSpeed range25 - 5000 rpmTorque (100% DC)280 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)225 NmAccuracy at point stopping0,01 degreeTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-4000 rpmPower max. (40% DC)11,3 kWFloor space/WeightDimensions (L x W x H)4,17 x 2,69 x 1,99 mWeight approx.6500 KgChuck rinsing device, outsidechuck rinsing device, outside (m ...

GeneralUniversal turning-/milling center; Control: SLIMline® Control SIEMENS 840D sl, w/o CELOS Working areaSwing diameter over guide ways500 mmTurning diameter400 mmMax. Turning Length1100 mmBar diameter max.65 mmWork spindle (left)Spindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)14 kWDrive power (40% DC)17 kWSpeed range- 5000 rpmBench speed485 rpmTorque (100% DC)275 NmMax. torque (40% DC)345 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% DC)8,8 kWDrive power (40% DC)10,5 kWTorque (100% DC)73 NmTorque (40% DC)90 Nmlocking moment850 NmSwivelling range+/- 120 degreeTool magazineType of magazineChain Number of tools60 Max. tool diameter78 mmMax. tool-Ø with free adjacent pockets125 mmFloor space/WeightDimensions (L x W x H)5,19 x 2,11 x 2,47 mWeight approx.11200 KgBASICBasic, consisting of: - Basi ...

General2-axes universal turning center with driven tools and C-axis; Control: Control Fanuc 0i-F Plus with iHMI and Manual Guide i Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways520 mmMax machining diameter460 mmClamping chuck Ø254 mmX travel300 mmZ travel730 mmMain drive 1Type of main driveAC Drive power (100% DC)15 kWDrive power (40% DC)19,5 kWSpeed range-3500 rpmTorque (100% DC)246 NmMax. torque (40% DC)319 NmWork spindleSpindle noseA2-8 Spindle diametre on front bearing140 mmSpindle bore91 mmBar diameter max.80 mmTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)5,44 kWTropical PackageTropenpaket für Maschine Option beinhaltet: - aktives Kühlaggregat für Schaltschrank - zusätzlicher Ventilator im Bedienpult Empfohlen ab 35°C bis max. 40°C Umgebungstemper ...

General2-axes universal turning center with driven tools and C-axis; Control: Control Fanuc 0i-F Plus with iHMI and Manual Guide i Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways520 mmMax machining diameter460 mmClamping chuck Ø254 mmX travel300 mmZ travel730 mmMain drive 1Type of main driveAC Drive power (100% DC)15 kWDrive power (40% DC)19,5 kWSpeed range-3500 rpmTorque (100% DC)246 NmMax. torque (40% DC)319 NmWork spindleSpindle noseA2-8 Spindle diametre on front bearing140 mmSpindle bore91 mmBar diameter max.80 mmTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)5,44 kWDouble cartridge filter for coolantDouble Cartridge Filter for Coolant Options includes two filters placed on the coolant distributor. When one filter is stocked, operator can manually switche ...

General2-axes universal turning center with fixed tools; Control: Control Fanuc 0i-F Plus with iHMI and Manual Guide i Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways520 mmMax machining diameter460 mmClamping chuck Ø254 mmX travel300 mmZ travel730 mmMain drive 1Type of main driveAC Drive power (100% DC)15 kWDrive power (40% DC)19,5 kWSpeed range-3500 rpmTorque (100% DC)246 NmMax. torque (40% DC)319 NmWork spindleSpindle noseA2-8 Spindle diametre on front bearing140 mmSpindle bore91 mmBar diameter max.80 mmTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmSignal lamp with 4 colours standardSignal lamp with 4 colours Red: general error Yellow: intervention necessary Green: automatic mode Blue: setup mode Alternative Speed TurningTechnology cycle Alternate Spindle Speed (Turning) for the application of an alternate speed for  ...

General2-axes universal turning center with fixed tools; Control: Control SIEMENS SINUMERIK ONE Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways520 mmMax machining diameter460 mmClamping chuck Ø254 mmX travel300 mmZ travel730 mmMain drive 1Type of main driveAC Drive power (100% DC)15 kWDrive power (40% DC)19,5 kWSpeed range-3500 rpmTorque (100% DC)246 NmMax. torque (40% DC)319 NmWork spindleSpindle noseA2-8 Spindle diametre on front bearing140 mmSpindle bore91 mmBar diameter max.80 mmTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mm

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools90 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12400 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring system Table surface 800 x 650 (Ø 650) mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 9 Distance between T-Slots 63 mmRotation speed max.4. Axis 40 rpm4. Axes (swivelling range) 360 x 0,001 degree5. Axes (swivelli ...

GeneralUniversal Machining Centre in monoBLOCK construction - MPC Machine Protection Control; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal750 mmCross650 mmVertical560 mmTechnical DataDrive power (100% DC)25 kWDrive power (40% DC)35 kWTorque (100% DC)86 NmTorque (40% DC)130 NmSpeed range- 20000 rpmSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmMiscellaneousClamping SystemHSK-A 63 Floor space/WeightWeight approx.12300 KgNC swivel rotary tableTable surface 800 x 650 (Ø 650) mmCentre bore 50h6 mmMaximum load (table centre) 600 KgSlot width 14 mm4. Axes ( ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle) Tool magazine, chain vert., 60 pocketsTool magazine Vertical chain magazine basic with 60 magazine pockets SK 40 or optionally chosen spindle ta ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring system Table surface 800 x 650 (Ø 650) mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 9 Distance between T-Slots 63 mmRotation speed max.4. Axis 40 rpm4. Axes (swivelling range) 360 x 0,001 degree5. Axes (swivelli ...

GeneralUniversal Milling Centre; Control: DMG MORI SLIMline® Multi-Touch control Working area 1Longitudinal750 mmCross600 mmVertical520 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightWeight approx.8000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only! Type of Measuring system Direct measuring system Table surface Ø 800 x 620 mmMaximum load (table centre) 350 KgSlot width 14 mmNumber of Slots 9 Distance between T-Slots 63 mm4. Axes (swivelling range) 360 x 0,001 degree5. Axes (swivelling range) -10/+95 x 0,001 degreeMode for positioning only Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Pur ...

GeneralUniversal Milling Centre; Control: DMG MORI SLIMline® Multi-Touch control Working area 1Longitudinal750 mmCross600 mmVertical520 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightWeight approx.8000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only! Type of Measuring system Direct measuring system Table surface Ø 800 x 620 mmMaximum load (table centre) 350 KgSlot width 14 mmNumber of Slots 9 Distance between T-Slots 63 mm4. Axes (swivelling range) 360 x 0,001 degree5. Axes (swivelling range) -10/+95 x 0,001 degreeMode for positioning only Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Pur ...

GeneralUniversal milling machine, with compound Guideway construction; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal500 mmCross450 mmVertical400 mmTechnical DataType of main driveAC Drive power (100% DC)14,5 kWDrive power (40% DC)20,3 kWSpeed range20 - 14000 rpmSpindle taperBT 40 Clamping SystemDIN ISO 7388-3-A, AD Feed rate longitudinal/transverse/vertical-30000/-30000/-30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)4,15 x 3,98 x 2,75 mWeight approx.4500 KgSwivel Rotary Table, simultaneousSwivel Rotary Table for simultaneous machining swivel range -5 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformation Not available with NC-Divider EA 410! Table surface 630 x 500 mmCentre bore 30H6 mmMaximum load (table centre) 300 KgSlot width 14 mmNum ...

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring system Spindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle) NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +1 ...

GeneralUniversal Milling Machine; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)25 kWDrive power (40% DC)35 kWSpeed range20 - 20000 rpmSpindle taperSK40 Tool holder DIN ISO 7388-1-A Clamping SystemDIN ISO 7388-3-A, AD Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring system Spindle speed 20,000 rpmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 20,000 min-1 At speed 18.000-20.000 min-1 SK40 – BIG-PLUS® stipulated Output 35 kW / 25 kW (47 hp / 33.5 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63.5 ft lbs) (40 / 100 % duty cycle) NC swivel rotary tableSwivel Rotary Table for simu ...

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperSK40 Tool holder DIN ISO 7388-1-A Clamping SystemDIN ISO 7388-3-A, AD Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring system Toolchangertoolchanger Type of magazine Chain Type of gripper Double gripper Number of tools 30 Max. tool weight 8 KgMax. tool length 300 mmMax. tool diameter with occupied adjacent pockets 80 mmMax. tool dia. with free neighbouring pockets 130 mmNC swivel rotary tableSwivel Rotary Table for simultaneous  ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS X with Siemens SINUMERIK ONE Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgNC swivel rotary tableTable surface Ø650 mmCentre bore 32 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 9 Distance between T-Slots 63 mmRotation speed max.4. Axis 40 rpm4. Axes (swivelling range) 360 x 0,001 degree5. Axes (swivelling range) +/- 120 degreeRotation Speed 5. Axis 20 rpmIntegrated motor spindle speedMASTE ...

GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 63 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machining Prod. package 40 bar/23 l/minProduction package 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) tank 900 l, rotating clear-view window, scraper flight conveyor coolant through spindle centre form AD NC rotary table with pallet changerType of Measuring system Direct measuring system Table surface 1000 x 800 mmCentre bore 50H6 mmMaximu ...

GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 100 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machining Prod. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pump NC rotary table with pallet changerType of Measuring system Direct meas ...

GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 63 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machining Prod. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pump NC rotary table with pallet changerType of Measuring system Direct measu ...

GeneralUniversal machining centre; Control: 3D Control Siemens 840D powerline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 100 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machining Prod. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pump NC rotary table with pallet changerType of Measuring system Direct measuring  ...

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.18300 KgDirect measuring systemDirect path measuring system CabineFull protection cabin NC swivel rotary table with pallet carrierTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 500 KgSlot width 14 mmNumber of Slots 5 Distance between T-Slots 100 mm4. Axes (swivel ...

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.17800 KgDirect measuring systemDirect path measuring system CabineFull protection cabin Package Mill / Turn HSK-A 63Package Milling / Turning: Upgrade NC-swivel rotary table to Milling - Turning / direct drive Pallet C-axis d 630 mm / 24.9 in Speed C-axis 1.000 rpm Integrated balancing ...

GeneralTraveling column machine DMG MORI Design; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal1800 mmCross700 mmVertical700 mmTool changerType of magazineChain Number of tools30 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,75 x 3,45 x 2,75 mWeight approx.14320 KgMiscellaneousClamping SystemDIN 69872 NC-swivel head (B-axis)Controlled NC-swivel milling head (B-axis) with clamping in position. Continuously positioning NC swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel range: +/- 90° Swivel speed: 40 rpm Fixed tableFixed Table ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal400 mmCross400 mmVertical375 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mWeight approx.7200 KgDie and Mold Package linearDie and Mold Package linear Dynamic package V-type Eagle timing belt for Z axis Package Mill / TurnPackage Mill / Turn (only available for Siemens 840D solutionline) NC-Mill-turn table 450x450 mm / 17.7x17.7 in rounded down to d460 mm / 18.1  ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with HEIDENHAIN TNC7 Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® tools Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63 Clamping System HSK-A 63 Toolchanger with set up station for tool loadingNumber of tools 30 IoTconnectorIoTconnector The IoTconnector allows the use of online services of DMG MORI (e.g. NETservice) NETserviceNETservice Qualified support by Internet-based remote diagnostics Messenger V4Messenger V4 Clear presentation of the machine live status. Service AgentService Agen ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63 Clamping System HSK-A 63 Tool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine) NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformation Tool mag ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal400 mmCross400 mmVertical375 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mWeight approx.7200 KgPackage Mill / TurnPackage Mill / Turn NC-Mill-turn table 450x450 mm / 17.7x17.7 in rounded down to d460 mm / 18.1 in C-axis direct drive, speed max.1,200 rpm Integrated balancing system Motorspindle 20-20,000 rpm power 35/25 kW (40/100% ED) tool taper HSK-A63 according  ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with Siemens SINUMERIK ONE Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® tools Drive power (100% DC) 16 kWDrive power (40% DC) 21 kWTorque (100% DC) 85 NmTorque (40% DC) 111 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63 Clamping System HSK-A 63 Toolchanger with set up station for tool loadingNumber of tools 60 Tool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine) NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 36 ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® tools Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper SK40 Tool holder DIN ISO 7388-1-A Clamping System DIN ISO 7388-3-A, AD Toolchanger with set up station for tool loadingNumber of tools 30 NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transf ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® tools Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63 Clamping System HSK-A 63 Tool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine) NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and wor ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinPackage Mill / Turn HSK-A 63Package Milling / Turning: Upgrade NC-swivel rotary table to Milling - Turning / direct drive Table plate C-axis d 680 mm / 26.8 in Speed C-axis 1.000 min-1 Integrated balancing sensor Motor spindle speedMASTER® HSK-A63 Spindle speed 20 - ...

GeneralUniversal Milling Machines; Control: DMG MORI SLIMline® Multi-Touch control Working area 1Longitudinal500 mmCross450 mmVertical400 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)3,15 x 2,86 x 2,71 (4,82 x 4,16 x 2,71) mWeight approx.5000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only!Type of Measuring system Direct measuring systemMode for positioning only5. Axes (swivelling range) -5/+110 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeDistance between T-Slots 63 mmNumber of Slots 7Slot width 14 mmMaximum load (table centre) 200 KgTable surface Ø 630 x 500 mmDirect measuring syste ...

GeneralUniversal Milling Machines; Control: 3D-control Heidenhain TNC 620 Working area 1Longitudinal500 mmCross450 mmVertical400 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)3,15 x 2,86 x 2,71 (4,14 x 4,16 x 2,71) mWeight approx.5000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only!Type of Measuring system Direct measuring systemMode for positioning only5. Axes (swivelling range) -5/+110 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeDistance between T-Slots 63 mmNumber of Slots 7Slot width 14 mmMaximum load (table centre) 200 KgTable surface Ø 630 x 500 mmDirect measuring system X,Y,ZDir ...

GeneralUniversal Milling Machines; Control: 3D-control Heidenhain TNC 620 Working area 1Longitudinal500 mmCross450 mmVertical400 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)3,15 x 2,86 x 2,71 (4,14 x 3,56 x 2,71) mWeight approx.5000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only!Type of Measuring system Direct measuring systemMode for positioning only5. Axes (swivelling range) -5/+110 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeDistance between T-Slots 63 mmNumber of Slots 7Slot width 14 mmMaximum load (table centre) 200 KgTable surface Ø 630 x 500 mmDirect measuring system X,Y,ZDir ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with Siemens SINUMERIK ONE Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minNC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformationTool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine)Tool magazine 60 pocketsTool magazine 60 places HSK-A63 Vertical chain with double gripper incl. set up station for tool loadingChip removal package with cabin roofSwarf removal package chip conveyor Coolant - air-blast changeover Swarf con ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinChip removalChip removal: manual, from the chip troughCoolant supplyCoolant supply: Multi-jet strip at spindle head, switchable from coolant to air (max. 6 bar / 90 psi, 6 water jets, 6 air jets) Pump capacity: 70 l/min / 18 gallon/min (theoretical pump perform ...

GeneralUniversal milling and turning machining centre with duoBLOCK construction; Control: CELOS X with HEIDENHAIN TNC7 Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal800 mmCross1050 mmVertical850 mmTool changerApplicationUniversal Type of magazineWheel Tool changer planehorizontal Type of gripperDouble gripper Number of tools123 NC mill-turn table with palletNC mill-turn table with pallet number of T-slots: - 1x cross slot 14 H7 / 0.55 H7 - 12x star slots 14 H11 / 0.55 H11 / 22.5° max. table speed milling operation: 30 rpm turning operation: 780 rpm integrated balancing sensor Pallet changer for 2 palletsType of Measuring system Direct measuring systemTable surface Ø 800 x 630 mmCentre bore 50 mmMaximum load (table centre) 1400 Kg4. Axes (swivelling range) 360 x 0,0 ...

Working areaTurning diameter500 mmDistance between spindles1435 mmMax. Turning Length1100 mmGeneralTurning/milling center with turning length 1100 mm - mounting HSK-A 63 DIN 69893 - B-axis ±120 - Y-axis ±100 mm - 60-fold chain magazine - Absolute, direct path measuring systems in X-, Y- and Z-axis - Hydraulically movable tailstock with foot pedal - Double switch filter - Electric handwheel - DMG MORI IoT connector - Clamping pressure adjustment on the control - 5-axis simultaneous machining; Control: CELOS X with Siemens SINUMERIK ONE Main drive 1Drive power (100% DC)14 kWDrive power (40% DC)17 kWSpeed range- 5000 rpmTorque (100% DC)275 NmMax. torque (40% DC)345 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-15000 rpmDrive power (40% DC)22,5 kWDrive power (100% DC)19 kWTorque (100% DC)85 NmTorque (40% DC)120 NmFloor space/WeightDimensions (L x W x H)5,77 x 2,3 ...

GeneralUniversal Milling Machines; Control: DMG MORI SLIMline® Multi-Touch control Working area 1Longitudinal500 mmCross450 mmVertical400 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)3,15 x 2,86 x 2,71 (4,14 x 2,91 x 2,71) mWeight approx.5000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only!Mode for positioning only5. Axes (swivelling range) -5/+110 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeDistance between T-Slots 63 mmNumber of Slots 7Slot width 14 mmMaximum load (table centre) 200 KgTable surface Ø 630 x 500 mmType of Measuring system Direct measuring systemDirect measuring syste ...
