Katlama makineleri

sheet width: 1050 mmplate thickness: 1,5 mmdaylight opening: 100 mmbending angle max.: 135 °height: OW 100 mmtotal power requirement: manuell dimensions of the machine ca.: 1600 x 900 x 1450 mmweight of the machine ca.: 330 kg.Furnishing:- Split upper, lower and rear tool- Height of the upper tool = 100 mm Division 100/100/100/100/100/100/100/70/60/50/40/30/100 left + right with horn tool- Upper tool with quick change system- Quick foot clamp- Angle stop - lockable- manual back gauge 500 mm- mobile The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 1250 mmplate thickness: 1,25 mm STplate width at 30 kg/mm: 2,0 mm ALUthickness at Niro-steel: 0,8 mm VAdaylight opening: 100 mmbending angle max.: 135 °height: OW 100 mmtotal power requirement: manuell weight of the machine ca.: 350 kg.dimensions of the machine ca.: 1715 x 750 x 1400 mmFurnishing:- Split upper, lower and rear tool- Height of the upper tool = 100 mm Division 100/100/100/100/100/100/100/100/100/70/60/50/40/30/100 left + right with horn tool- Upper tool with quick change system- Quick foot clamp- Angle stop - lockable- manual back gauge 500 mm- mobileThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

AYEL-TECH MAGNETIC FOLDING MACHINE TYPE 1000E -Capaciteit 1000 x 1.6 mm -Voetbediening -Measure 4 sets -Documentatie -230V DUTCHMACH Metal working machinery ENSCHEDE - NETHERLANDS (3 km from the German border)

AYEL-TECH SCHWENKBIEGEMASCHINE TYPE CKL-H 1260 x 2 - Capaciteit 1260 x 2 mm - Bovenmes in segments - Hydraulic buigen - Voetklemming - Afstandbediening - Noodstop - Documentatie - 400V DUTCHMACH Metalworking machines ENSCHEDE - NETHERLANDS (3 km from the German border)

AYEL-TECH SWIVEL BENDING MACHINE TYPE VZB 1260 x 2 -Capaciteit 1260 x 2 mm -Bovenmes in segments -Max buighoek 135 ° DUTCHMACH Metal working machinery ENSCHEDE - NETHERLANDS (3 km from the German border)

Working length: 1020 mm Maximum sheet thickness: 2.5 mm Maximum opening width: 48 mm Bending angle: 0-135 ° Width: 1350 mm Overall width: 820 mm Height: 1140 mm Approximate weight: 285 kg FEATURES -Universal bending machine for sheet metal working and repairers -Sturdy construction in modern design -Easy adjustment of the upper beam by means of foot pedal, hands are free for the workpiece - manual bending machine for standard bending tasks -Segmented clamping beam for a large number of bending possibilities -Optimum price-performance ratio -Faster and easier bending operation via handle -Non-slip rubber coating on the foot pedal for safe working -Easy adjustment of the lower beam on the corresponding thickness -High upper beam for the manufacture of highly bent profiles Action price, including free home delivery to 1 address Germany (Mainland)

sheet width: 2065 mmplate thickness: 1,20 mmdaylight opening: 30,0 mmbending angle max.: 0 - 135 °total power requirement: manuell weight of the machine ca.: 500 kg.dimensions of the machine ca.: 2400 x 1115 x 1150 mm- Universally applicable bending machine for plumbing and repair shops- Robust construction in a modern design- easy adjustment of the upper beam by means of a foot pedal, Hands are free for the workpiece- manual bending machine for standard bending tasks- segmented upper beam for a large number of bending options- An auxiliary cylinder supports the bending process when folding- faster and easier bending process using a bow handle- easy adjustment of the lower beam to the respective sheet thickness- high upper beam for the production of high-edged profilesFurnishing :- Segmented upper cheek- back gauge- bending segments 38 | 38 | 38 | 50 | 50 | 50 | 50 | 76 | 76 | 101 | 12 ...

sheet width: 2065 mmplate thickness: 1,20 mmdaylight opening: mit WZ 35,0 mmdaylight opening: ohne WZ 60,0 mmbending angle max.: 0 - 135 °total power requirement: manuell weight of the machine ca.: 520 kg.dimensions of the machine ca.: 2400 x 1115 x 1150 mm- Segmented upper beam for a large number of bending options- Universally applicable bending machine for plumbing and repair shops- High upper beam for producing high-edged profiles- Quick and easy bending process using a bow handle- Easy adjustment of the upper beam for efficient work- The bending angle is set using a scale- Individually removable segments for bending boxes- Robust construction in a modern designFurnishing :- segmented upper beam- Foot clamp- Fixed stop for angle adjustmentThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2000 mmsheet thickness - max.: 6 mmconnected load: 7,5 kW: . with crowbar: . The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

-Exhibition Machine- State-of-the-art fully hydraulic folding machine. Extensive standard equipment: · hydraulic drive for upper and bending beam · Pointed rail 45 degrees · Rails in upper, lower and bending beam · Oil filling · Control panel with: Digital display of bending angle infinitely variable specification of the bending angle Push button for controlling the upper and bending beam Switch for automatic operation · Control: PLC - Siemens · Foot switch for manual and automatic operation · CE certification · Safety stop at approx. 25 mm upper beam height Hydraulic dynamic crowning Motorized backgauge (1000 mm) Electr./hydr. adjustment of the bending wing, Touch screen: Input for backgauge values and Bending angle of the folding machine Pressure regulation of the upper beam Automatic tool clamping Round bending function with bending Half-shells 180 ...

Hydraulic swivel bending machine - ordering machine (delivery time approx. 10-14 weeks), incl. hydraulic dynamic crowning, touch screen, Pressure regulation of the upper cheek, backgauge (1000mm), goat feet with automatic tool clamping, electr./hydr. Adjustment of the bending cheek -Illustrations similar-

Hydraulic folding machine - ordering machine (delivery time approx. 10-14 weeks), incl. hydraulic dynamic crowning, touch screen, Pressure regulation of the upper beam, back gauge (1000mm), goat's feet with automatic tool clamping, electr./hydr. Adjustment of the bending beam -Illustrations similar- hydraulic CNC bending machine - order machine (delivery time approx. 10-14 weeks), incl. hydraulically dynamic camber, touchscreen, pressure regulation of the upper beam, backgauge (1000mm), goat feet with automatic tool clamping, electric/hydraulic adjustment of the bending beam -images similar-

Hydraulic swivel bending machine - ordering machine (delivery time approx. 10-14 weeks), incl. hydraulic dynamic crowning, touch screen, Pressure regulation of the upper cheek, backgauge (1000mm), goat feet with automatic tool clamping, electr./hydr. Adjustment of the bending cheek -Illustrations similar- hydraulic CNC bending machine - order machine (delivery time approx. 10-14 weeks), incl. hydraulically dynamic camber, touchscreen, pressure regulation of the upper beam, backgauge (1000mm), goat feet with automatic tool clamping, electric/hydraulic adjustment of the bending beam -images similar-

Hydraulic swivel bending machine - storage machine, incl. hydraulic dynamic crowning, touch screen, Pressure regulation of the upper cheek, backgauge (1000mm), goat feet with automatic tool clamping, electr./hydr. Adjustment of the bending cheek -Illustrations similar- hydraulic CNC bending machine - storage machine, incl. hydraulically dynamic camber, touchscreen, pressure regulation of the upper beam, backgauge (1000mm), goat feet with automatic tool clamping, electric/hydraulic adjustment of the bending beam -images similar-

Hydraulic swivel bending machine - ordering machine (delivery time approx. 10-14 weeks), incl. hydraulic dynamic crowning, touch screen, Pressure regulation of the upper cheek, backgauge (1000mm), goat feet with automatic tool clamping, electr./hydr. Adjustment of the bending cheek -Illustrations similar-

sheet width: 3050 mmplate thickness: 8 mmtotal power requirement: 7,5 kWdistance between columns: mmweight of the machine ca.: tdimensions of the machine ca.: mSPS controlFoot switchTechnische Daten / technical details:Arbeitslänge / working lenght 3050 mmBlechdicke / plate thickness 8 mmÖffnungsweite der Oberwange / opening widths of the upper flange 300 MmMotorleistung / drive capacity 7,5 kWGewicht ca. / weight ca. 9000 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description of the machine are not binding.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Hydraulic swivel bending machine - ordering machine (delivery time approx. 10-14 weeks), incl. hydraulic dynamic crowning, touch screen, Pressure regulation of the upper cheek, backgauge (1000mm), goat feet with automatic tool clamping, electr./hydr. Adjustment of the bending cheek -Similar images- hydraulic CNC bending machine - order machine (delivery time approx. 10-14 weeks), incl. hydraulically dynamic camber, touchscreen, pressure regulation of the upper beam, backgauge (1000mm), goat feet with automatic tool clamping, electric/hydraulic adjustment of the bending beam -images similar-

Hydraulic swivel bending machine - ordering machine (delivery time approx. 10-14 weeks), incl. hydraulic dynamic crowning, touch screen, Pressure regulation of the upper cheek, backgauge (1000mm), goat feet with automatic tool clamping, electr./hydr. Adjustment of the bending cheek -Illustrations similar- hydraulic CNC bending machine - order machine (delivery time approx. 10-14 weeks), incl. hydraulically dynamic camber, touchscreen, pressure regulation of the upper beam, backgauge (1000mm), goat feet with automatic tool clamping, electric/hydraulic adjustment of the bending beam -images similar-

large working width: 2520 mm for sheets up to: 1.5 mm Upper beam opening width: 180 mm Adjustability bending beam: 40 mm Bending angle adjustment: 135° Weight: 1970 kg Dimensions: 1970 x 750 x 1250 mm

functioning Working width: 2500 mm sheet thickness: 3 mm Functional Working length: 2500 mm thickness: 3 mm

sheet width: 1050 mmplate thickness: 1,5 mmdistance between columns: mmdaylight opening: 100 mmweight of the machine ca.: 330 kgdimensions of the machine ca.: 1,6 x 0,9 x 1,45 m- Split upper, lower and rear tool- Upper tool with quick change system- Quick foot clamp- Angle stop - lockable- manual backgauge 500 mm- mobile The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 2040 , 2

Motorized swivel bending machine Manufacturer Fasti Type 2095-20-2 Sheet power 2040 x 2 mm at 400 N/mm2 Digital display of the bending angle Foot pedal Notaus Power connection 400V

sheet width: 1270 mmplate thickness: 1,75 mm STplate thickness: 2,00 mm ALUplate thickness: 2,50 mm KUthickness at Niro-steel: 0,80 mmdistance between columns: 1300 mmdaylight opening: OW ~ 380 mmwork height max.: 900 mmadjustment: UW 60,0 mmbending angle max.: 180 °weight: ca. 200 kg kgrange L-W-H: 2000 x 520 x 1500 mm good condition () Bending splint e.g. regroundFurnishing:- robust, manual folding machine- manual lifting by hand lever (incl. gas pressure damper)- manual clamping of the upper beam by means of a handwheel on the side- manual lower beam adjustment- Bending angle fixed stop, with analogue angle display- Upper beam with large opening width- Instructions / description Machine link :http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno=100 8-9355182The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2040 mmplate thickness: 2,0 mmdaylight opening: mmdistance between columns: 2100 mmwork height max.: mm: max. 135 Gradtotal power requirement: 1,5 kWweight of the machine ca.: 1,7 trange L-W-H: 2,9 x 1,0 x 1,7 mFurnishing:- Bending angle preselection- Segmented tool- additional bending set- manual backgauge- DokumentationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2040 mmplate thickness: 3,0 mmdaylight opening: mmdistance between columns: 2100 mmwork height max.: mm: max. 135 Gradtotal power requirement: 4,0 kWweight of the machine ca.: 2,2 trange L-W-H: 23,1 x 1,0 x 1,7 mFurnishing:- Bending angle preselection- Segmented tool- additional bending set- manual backgauge- DokumentationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

working width 2040 mm sheet thickness at 40 kp/mm² 4 mm Manual backgauge up to 600 mm Connected load 7.6 kW Machine weight approx. 3 t Dimensions L/W/H approx. 3.3 m / 1.4 m / 1.8 m Accessories: Bending tool with radii 3 mm, 6 mm, 7.5 mm, 10 mm

1500 x 1.5 mm bending capacity (sheet iron 400 N/mm2) with new angle control ELGO (new in 2023) (without hindling)

sheet width: 1020 mmplate thickness: 2,00 mmdistance between columns: mmtotal power requirement: kWweight of the machine ca.: 0,500 tdimensions of the machine ca.: mUpper beam can be swung outBending rail groundThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 1020 mmplate thickness: 2,00 mmdistance between columns: mmtotal power requirement: kWweight of the machine ca.: 0,65 tdimensions of the machine ca.: mUpper beam can be swung outBending angle adjustable via potentiometerLifting height can be preselected via scaleManual and automatic bending mode possibleThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 1020 mm, 2 mm

Max. bending length: 1020 mm Max. sheet thickness: 2 mm steel Upper beam can be swung out Bending angle adjustable via potentiometer Lifting height can be pre-selected via scale Manual and automatic bending mode possible Weight: approx. 650 kg

sheet width: 2040 mmplate thickness: 2,00 mmdistance between columns: mmtotal power requirement: kWweight of the machine ca.: 1,50 tdimensions of the machine ca.: mMotorized upper beam adjustment via foot switchGoatfoot billsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2040 mmplate thickness: 2,00 mmdistance between columns: mmtotal power requirement: kWweight of the machine ca.: 1,50 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 2040 mm, 2 mm

Max. bending length: 2040 mm Max. sheet thickness: 2 mm steel Upper beam adjustment motorized via foot switch Honeysuckle Notes Weight: approx. 1500 kg

sheet width: 2040 mmplate thickness: 3 mmdaylight upper clamping: 350 mmbending angle max.: 0-135 °adjustment of lower and bend clamping: 80 mmcontrol: Fastimatic M200 power requirement: 2,2/1,5 kWweight of the machine ca.: 2460 kgdimensions of the machine ca.: 3,2 x 2,8 x 2,1 mCondition: ready for operation: Condition: very good: CE signed: Electric 400 Volt: CNC-control with screen: Mot. back gauge: 1000 mmFoot switch: Motorized machine with motorized bending beam adjustment for setting the sheet thickness, screen control Fastimatic M200 (DELEM FM 200 B) for controlling the top cheek stroke, the bending angle and the back gauge with max. 30 working steps, emergency stop switch with magnetic holder, back gauge with ball screw spindles, CE mark. The bending performance refers to sheets of strength of 400 N / mm². Please notice that the price of a new CNC-machine in this dimension ...

sheet width: 3000 mmplate thickness: 2,0 mmdistance between columns: 3240 mmDaylight opening: 350 mmbending angle max.: 0 - 135 °adjustment of lower beam: 80 mmpower capacity: 2,2 / 1,5 kWtotal power requirement: 3,7 kWweight of the machine ca.: 3,4 tdimensions of the machine ca.: 4,3 x 1,1 x 1,6 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2040 mmplate thickness: 2,00 mmdistance between columns: mmtotal power requirement: kWweight of the machine ca.: 1,80 tdimensions of the machine ca.: mManual and automatic bending process possibleBending angle adjustable via potentiometerStroke height of the upper beam and material thickness can be preselected via DIP switchesPolished bending railThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Max. bending length: 2040 mm Max. sheet thickness: 2 mm steel Manual and automatic bending sequence possible Bending angle adjustable via potentiometer Lifting height of the upper beam and material thickness can be preselected via dip switch Bending rail ground Weight: approx. 1800 kg

Bending capacity at 45 kg/mm2: 2540 x 2 mm 6 angles pre-adjustable Automatic or manual operation Double foot switch 1 additional edge rail 1 additional bending rail wide

sheet width: 2540 mmplate thickness: 2.50 mmdistance between columns: 2600 mmdaylight opening: OW 300 mmadjustment: UW 115 mmpivoting angle: 180 Gradwork height max.: 910 mmback stop - adjustable: bis 690 mmvoltage: 400 Vtotal power requirement: 3.8 kWweight: 2250 kgrange L-W-H: 3640 x 1750 x 1600 mm maintained condition ()Furnishing:- robust electro-motive folding machine- Bending angle adjustment via electric potentiometer infinitely adjustable with digital value display- manual % automatic mode selectable- Electrical adjustment of the travel paths of the upper beam- manual lower beam adjustment up to 115 mm- 1x set of bending tools (installed / used condition)- freely movable double foot switch- manual material back gauge, adjustable at the back Adjustment range up to max. ~ 690 mm- User manual (PDF) Machine link:http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno =1008- ...

Offer 23336 Specifications: - Max. working width 2040 mm - max. material thickness at 40 kg / mm², strength 3 mm - Bending angle adjustment electronically pre-selectable 0 - 135 ° - Automatic sequential control for a complete workflow - Coding switch - Upper beam stroke up + down adjustment - Maximum opening width / stroke of the upper beam 350 mm - Height adjustability - the bending beam 80 mm - the lower beam 80 mm - Upper beam drive 400 V / 1.5 kW - Bending beam drive 400 V / 2.2 kW - with - E.- foot button - Flat rail + pointed rail - Space requirement approx. W 3200 x H 1600 x D 900 mm - Weight approx. 2800 kg

sheet width: 2540 mmplate thickness: 3,0 mmdistance between columns: 2500 mmback stop - adjustable: 1000 mmupper clamping bar adjustment: 350 mmtotal power requirement: 4,62 kWdimensions: 3800 x 2300 x 1750 mmweight of the machine ca.: 3050 kg- lateral protective wall- 1x dual free-moving footswitch- 1x free moving footswitch- Electrically controlled back gauge with rear sheet metal support surface - with ball rollers- incl. new hydraulic pump (value approx. 4000€)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Max. bending length: 3040 mm Max. sheet thickness: 4 mm steel Manual and automatic bending sequence possible Bending angle adjustable via potentiometer Lifting height of the upper beam variable Central lubrication Bending rail ground Operating instructions Other bending rails and backgauge on request Weight: approx. 6,000 kg

large working width: 3240 mm for sheets up to: 4 mm Opening width upper wall: 350 mm Adjustability bending pliers: approx. 80 mm Bending angle adjustment: up to approx. 180° Top cheek drive: 4.8 kW Unterwangen drive: 7.5 kW electr. Connection: 400 V kW Weight: 6800 kg Space requirement: 4520 x 1400 x 2080 mm

sheet width: 2540 mmplate thickness: 5,00 mmdistance between columns: mmupper beam stroke: 350 mmstroke bending beam: 80 mmtotal power requirement: kWweight of the machine ca.: 7,50 tdimensions of the machine ca.: 4,20 x 2,90 x 2,30 mFurnishing- Upper beam stroke: 350mm- Motorized folding beam adjustment- controlled backgauge 1000mm (1500mm with repositioning)- Control Fm100- Geissfusssatz divided height approx. 130mm- Sharp rail 45 °- Bending bar: 15mm, 20mm + reinforcement bar 35mm- Radius rail R16mm, length 2000mm- Radius rail R30mm, length 1000mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2040 mmplate thickness: 3,00 mmdistance between columns: mmbending angle: 135 °upper beam stroke: 350 mmengine output: 4 kWtotal power requirement: kWweight of the machine ca.: 2,50 tdimensions of the machine ca.: 3,20 X 1,60 X 0,90 m- with different OW rails, especially segmented tools- Footswitch- Manual operationMachine is repaired, checked, cleaned by a specialist and is then completefunctioning. Test run is carried out.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

No. 5120: 1 gebr. Swivel bending machine Fabr. FASTI, type 212, Arb.-Ber.: 2500 x 3 mm,

Folding machine HELMUT LOTZE 3100×9 CNC (A3709) Max worklength 3100 mm Max tickness 9 mm Distance between clampblock — ram 300 mm Eletric motor (power) 15 kW Length 5050 mm Depth 1875 mm Hight 2040 mm Weight 15 ton ACCESORIES yes Additional info Type 116 Mechanical drive Cybelec CNC control Cap: 2500 x 10 mm / 2000 x 12 mm

sheet width: 2500 mmplate thickness: 6,00 mmdistance between columns: mmupper beam stroke: 600 mmadjustment lower beam: max. 100 mmbending beam adjustment: max. 100 mmconnected load: OW 5,5 / BW 7,5 kWvoltage: 50 Hz, 400 Vtotal power requirement: kWweight of the machine ca.: 7,00 tdimensions of the machine ca.: m• Bending angle adjustment via potentiometer• Sharpening rail 45°• Bending rail• Operation manualDimensions: approx. L 3.55 x W 1.1 (plus yellow warning plates) x H 2.0 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 1050 mmplate thickness: 8,0 mmdistance between columns: 1250 mmangle adjustable from - to: 0 - 180 Gradupper clamping bar adjustment: 350 mmtraversing speed: OW 4,4 mm/sekControl: ELGO TYP 86 back stop - adjustable: max. 1000 mmengine output: 5,5 kWweight of the machine ca.: 3200 kgrange L-W-H: 1900 x 2600 x 1600 mm maintained condition with a lot of bending tools () Pointed rails, radius rails, bending rails, divided goats foot rails etc.Furnishing:- heavy duty heavy duty folding machine, easy to operate- Angle adjustment via electric potentiometer- ELGO NC control unit TYPE 86 for electric backgauge- NC electric backgauge, with rear sheet metal support surface- electric/motorized bending beam- Electric/motorized upper beam .. max. 350 mm- manual lower beam adjustment .. max. 125 mm- manual bending beam adjustment .. max. 125 mm- Upper beam with 2x guide spindles- 1x free m ...

sheet width: 3000 mmplate thickness: 6,00 mmdistance between columns: mmopening of the upper cheek: 450 mmopening of the down cheek: 125 mmOpening of the bending cheek: 125 mmtotal power requirement: kWweight of the machine ca.: 7,00 tdimensions of the machine ca.: m- Renewed control cabinet with Siemens control- controlled back gauge 1000 mm- Crowning adjustment- Support table with wheels- various bending rails including sharp rail- segmented goats foot- Operation manualThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
