Key data: 20 t

Punching Machine Manufacturer: Amada Type: Aries 245 Year of construction: 1989 CNC Control: Amada 04PA Operating hours: approx. 20,000 Punching force: 200 KN Sheet thickness (stainless steel) max.: 3 mm Sheet thickness (mild steel) max.: 4 mm Sheet thickness (aluminum) max.: 3 mm Travel: 1,270 x 1,000 mm Revolver: 20-fold (2x rotatable B-stations) Incl. complete set of tools ! Power: 11 KVA Dimensions: LxWxH = 2,700 x 3,784 x 1,950 mm Weight: 7,500 kg plus 2,500 kg foundation slab

Key data: 20 t, 600 mm, 600 mm

We offer our reliable Amada Aries-222 punching machine for sale here. The machine is fully functional. The associated tool kit is complete and the machine is fully equipped.

Key data: 25 t, 3000 mm, 500 mm

For cannibalization I offer a powerline 25-500, built in 1985, which works until the end Machine can no longer be tried; already partially dismantled. In 2017 both servo cards were new! Invoice available

Description: Working surface: approx. 200 x 200 mm With hand lever: approx. 500 mm lengthweight approx.: 30 kg, Approx. Onsite Dimension. (l x w x h): 660 x 400 x 400 mm

Description: sheet metal punching machine EDEL Stanzomat 410 - 20 with CNC technology serial number: 2811388 control: EF200S  , well preserved , possibility of manual and automatic operation (saved programs) include many tools, original instructions in German  , please also have a look at the PDF document of this machine weight approx.: 4,500 kg, Approx. Onsite Dimension. (l x w x h): 5,000 x 2,500 x 2,000 mm

Punching machine EDEL - Maximum power: 25to. - Extension 26 cm - Height: 170cm - Width: 65cm - Depth: 50cm Good condition fully functional can be visited and tried out on site. Shipping abroad. Visit: Basically, I would like to point out to you that in order to avoid misunderstandings, the article can be viewed before purchase and tested under electricity. Please ask questions before purchasing to avoid any ambiguity. If you have any general questions or make an appointment for a visit, I can be reached at any time, using the telephone number below or above. Errors in the description and intermediate sale reserved. The VAT is shown separately on my invoices. Shipping with forwarding.

serial number: 28043 weight: 3 tpressure: 30 tvolt: 380 Vfrequency: 50 HzThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 6731 Type: CX 1000/30 Producer: EUROMAC Created: 1999 Parameters: Compressive force: 30 t Maximum lifting speed: 200 mm/s Feed length X-axis: 2000 mm Feed length Y-axis: 1000 mm Stroke: 60 mm Machine height: 1800 mm Machine length: 4000 mm Machine width: 2800 mm Machine weight: 5250 kg

Key data: 30 t, 1250 mm, 1250 mm

Euromac punching and nibbling machine type: CX1250/30 with light barrier, multi-tool and individual tools with extensive tool. With tool cabinets. The machine is in top condition and can be viewed under power.

Technical data: -maximum cutting force 300 kN -maximum punching diameter up to 88.9 mm -Max that material thickness 6.35 mm -Work area without putting up 1000 x 2000 mm -Actual workspace 1145 x 2100 mm -Work area normally with putting 1000 x 4000 mm -Size work table 1000 x 3500 mm -maximum working speeds of the axes 50 m / min -Max stroke sequence. 320 strokes/min -2 collets min. / max. distance 160-1900 mm -Need for compressed air 6 bar -Power supply 400 V / 15 kW -Space B 4200 x T H 3800 x 2250 mm -Weight approx. 6500 kg -with:-tool station 360-degree rotatable programmable 0.01 ° -CNC control - div. accessories in the separate tool Cabinet

Punching machine X5 Manufacturer: FINNPOWER YEAR: 2006 Desktop... 2530x1270mm Nominal pressing force... 056 Axis X ... 2584mm Axis Y ... 1317mm thickness of the cut material ... 8mm Magazine slots ... 20 Control Fanuc ... Oi-PC Machine weight ... 10500kg L x W x H ... 7600x6980mm The machine is in good condition, possible to test under power.

weight approx.: 250 kg, Approx. Onsite Dimension. (l x w x h): 850 x 750 x 1,500 mm

Serial No.: 1704 Punching capacity: Ø 28 x 16 Available with special tools: Ø 100 x 4 Year of construction: 1997 Country of origin: Italy

Punching capacity: 25 tplate thickness: 10 mmno. of strokes: 120 Hub/minpunch diameter: 105 mmpositioning accuracy: 0,1 mmweight of the machine ca.: 1.800 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Press force: 35 to Number of strokes: 80 - 300 Stroke: 6 - 50 Ram adjustment: 50 Table dimensions: 540 x 340 mm Hole diameter: approx. 125 mmweight approx.: 1,800 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 1,000 x 2,200 mm

- Working pressure: min 6 - max. 7 bar - Machine weight: 170 kg - Space requirement (W x D x H): 0.55 x 0.55 x 1.4 m - Condition: very good Details for profile WICONA, system WICLINE 50E - 50EN, 60E, CODE:332.04.10 from vocational school, was hardly in use, as good as new

Description: • Dovetailer, dovetailing machine • Max. Workpiece width approx. 480 mm • Workpiece length from 200 mm up to 1500 mm • Drawer front thickness from 7 mm up to 60 mm • Drawer side thickness from 10 mm up to 30 mm • Milling template with 20 notches • Distance between notches approx. 25 mm • Milling motor working vertically from bellow • Motor power 1.10 KW-2820 rpm • 2 horizontal pneumatic clamps and 2 vertical onesweight approx.: 350 kg, Approx. Onsite Dimension. (l x w x h): 1,250 x 780 x 1,390 mm

Description: SPECIFICATIONS Character: Peddinghaus Type: 210 Super 11 Machine dimensions (L×W×H): 1,500 x 1,000 x 1,800 mm Capacity: 40 T Round: 34 mm ø Square: 30 mm ø Strip: 120 x 12 mm Angle iron: 100 x 10 mmweight approx.: 1,100 kg, Approx. Onsite Dimension. (l x w x h): 1,500 x 1,000 x 1,800 mm

Description: SPECIFICATIONS Character: Peddinghaus Type: 210 Super 20 Capacity: 95 T Punch: 30 x 25 mm Round: ø55 mm Square: ø50 Strip Angle iron Unloading: 500 mm Electrical installationweight approx.: 5,000 kg, Approx. Onsite Dimension. (l x w x h): 1,400 x 2,300 x 2,400 mm

• Machine number: 4221875989007 • Punching force max: 800kN • Material thickness max: 25 mm • Punching device max: Ø 90 mm • Accessories according to photos (sold separately on request)

Description: Seriennummer 4061353488001weight approx.: 500 kg, Approx. Onsite Dimension. (l x w x h): 1,080 x 600 x 1,700 mm

Hydropneumatic functioning Punching power: 50 kN Height: 140 mm

The notching machine is in used condition and is fully functional. Ideal for the production of round or square air ducts. - Incl. substructure table with castors - Pneumat. Actuation via foot switch Condition see pictures. Visit and demonstration possible. The indicated price is a net price for collection ex works. A chargeable transport within Germany can be organized on request.

Description: -weight approx.: 1,500 kg, Approx. Onsite Dimension. (l x w x h): 2,500 x 1,500 x 2,000 mm

plate width: 1,524 mm, plate length: 2,540 mm, plate thickness: 0,5 - 3,5 mm, max. punching diameter: 33 mm, weight approx.: 21,000 kg, Approx. Onsite Dimension. (l x w x h): 21,000 x 7,000 x 2,500 mm

Salvagnini S4.40 punching machine with shear system  CNC control: Salvagnini SysCon Specifications: Working area: 4064x 1803 mm Max dimension of the sheet: 4064x 1803 mm Min dimensions of the sheet: 370x 300 mm Min and Max Thickness: 0.5 -5 according to the material used Maximum weight of the sheet: no limit Grippers for automatic positioning of the blehe: 13x Technology: Multi-press punching head with hydraulic drive Time for the replacement of the punching tool: 0 sec (each tool is ready for use= Simulation Possibility of activating two or more punching units Weight : 19000 kg Machine dimensions: 9967x6426 mm Power 63kW Air supply: 5 bar Punching Productivity & Cutting Productivity  Maximum material thickness: Alumumuim with breaking strength 200M/mm²: 5.0 mm Steel with breaking strength 410N/mm² : 3.5 mm Stainless steel with breaking strength 680 N/mm²:  ...

Offer 22526 Specifications: - Pressure capacity at 10 bar 35 KN - Plunger stroke 12 mm - Projection 95 mm - Installation height approx. 134 mm - Table size approx. 230 x 190 mm - Air consumption per stroke 8.0 l - Air inlet 6 - 10 bar - Space requirement approx. W 520 x H 1450 x D 600 mm - Weight approx. 100 kg - with: - Foot switch - Pressure gauge + pressure regulator - 4 x punching tool

Offer 22523 Specifications: - Pressure capacity at 10 bar 35 KN - Plunger stroke 12 mm - Projection 95 mm - Installation height approx. 134 mm - Table size approx. 230 x 190 mm - Air consumption per stroke 8.0 l - Air inlet 6 - 10 bar - Space requirement approx. W 520 x H 1450 x D 600 mm - Weight approx. 100 kg - with: - Foot switch - Pressure gauge + pressure regulator - 4 x punching tool

5018 – PNEUMATIC PRESS, PUNCHING, FERRULE DEVICE Manafacture: Sepalumic Model No.: ZA00069 SH0011B Dimensions: 900 x 350 x 1 100 mm Operating pressure: 6 bar

Description: PUNCHING Punching force: 60 ton Punching capacity: Ø22 x 20 mm (Diameter x Thickness): Ø40 x 11 mm Throat depth: 200 mm Maximum stroke length: 40 mm Cycles / Min. (15 mm stroke): 34 mm Working height up to mould: 1050 mm  , ANGULAR CUTTING Cutting force: 60 ton With 90° cut: 100 x 100 x 8 mm Working height: 1070 mm  , FLAT SHEAR Flat bar shear: 350 x 15 mm Blade length: 360 mm Working height: 805 mm  , BAR SHEAR Shear for round bars: ø40 mm Shear for square bars: 38 x 38 mm Cutting channels: 102 mm optional tool I-beam cutting: 102 mm optional tool NOTCHING Rectangular notching (W x D x T): 50.8 x 90 x 8 mm V-cut (L x W x T): 90 x 90 x 8 mm optional tool Working height: 1050 mm  , SPECIAL TOOLS optional  , Single Vee press brake (W x T): 160 x 8 mm tool optional Multi Vee press brake (W x T): 250 x 6 mm tool optional Angle bending: 65 x 8 mm optional  ...

Description: PUNCHING Punching force: 55 ton Punching capacity: Ø22 x 18 mm (diameter x thickness): Ø50 x 8 mm  , Punching channel flange (height): 180 mm Throat depth: 510 mm Maximum stroke length: 100 mm Cycles/Min. (20 mm stroke): 28 Table dimensions (W x D): 700 x 700 mm Working height up to mould: 1050 mm  , OPTIONAL TOOLS. Largest bore: Ø160 x 3 mm optional tooling Single V-bending press (W x T): 250 x 15 mm optional tooling Multiple V-bending press (W x T): 500 x 5 mm optional tooling Angle bender: 102 x 9 mm optional tool Rectangular notching machine (W x D x T): 63.5 x 90 x 8 mm optional tool V-shaped notching machine (L x W x T): 145 x 145 x 6 mm optional tool Pipe notching machine (maximum diameter): Ø 100 mm optional tool Flat bar shearing: 175 x 7 mm optional tool Corner shearing: 100 x 100 x 7 mm optional tool Blanking of round bars: Ø 32 mm optional tool Squar ...

Description: pressure: 30 tons max punch stroke: 20 m/min. floor movement: 750 x 3000 mm max. range copying: 800 x 1500 mm important: oil pipe is leaking  , please also have a look at the PDF document of this machine weight approx.: 3,300 kg, Approx. Onsite Dimension. (l x w x h): 2,400 x 2,700 x 2,100 mm

Description: Serial Number: A15.564 CNC : TRUMPF Main Drive , Punching Force : 180 KN Max. sheet thickness: 6.4 mm Strokes: ,  ,X-AXIS: 1250 mm  ,Y-AXIS: 1280 mm Max. workpiece thickness , Steel: 4 MM Max. workpiece weight: 75 kg , Max. workpiece height: 38 mm , Programmable force: 4000-17000kn Speeds: , X-axis: 90 m/min Y-axis: 60 m/min Simultaneous: 108 m/min Power: 400 V / 50 HZ Installed power: 17 KVA Important note: , The machine is currently stored as shown in pictures 5-12.  ,max. punching diameter: 76 mm, weight approx.: 9,200 kg, Approx. Onsite Dimension. (l x w x h): 5,530 x 2,300 x 2,255 mm

Standard configuration? Stable C-frame? Coordinate guide with integrated linear magazine, 11 tool stations for tools and clamps? Drives: Maintenance-free, digital three-phase servo motors? Punching head: Hydraulic system with closed control loop, single tool adapter, 360? rotation of all tools? Automatic repositioning device with programmable presser foot ? Vacuum slug removal? Swarf bucket? Brush tables? Parts chute 200 x 200 mm and sorting of parts into 2 containers? 2 parts containers? Controller BOSCH Type 3, activity-oriented user interface, Online help,diagnostic functions, 3.5 disk drive, BNC/RJ45 connection, TFT color screen 10.4? Graphic programming ToPs 2000? Safety: CE marking, multi-beam light barriers, rapid hydraulic shutdownAdditional equipment? MultitShear? MultiBend? SoftPunch? Table extension? Start post

Punching machine Trumpf TruMatic TC3000-1300 FMC Year of construction 2004 87500 hours (03.2021) In this case, the configuration : TruMatic TC3000-1300 FMC Year of construction 2004 Working range : 2550 x 1280 mm Standard: • Sturdy C-frame • Coordinate guidance with integrated linear magazine, 21 seats for tools and clamps • 2 clamps • Drives: Maintenance-free digital three-phase servo motors • Punching head: hydraulic system with closed control loop, hydraulic mono tool holder, 360° rotation for all Tools, automatic tool length compensation, programmable scraper movement • Programmable hold-down • Tool spray lubrication • Punch butt suction • Partial slide 500 x 500 mm • Control Bosch PNC-P, activity-oriented user interface, Online Help, Diagnostics, 3.5" Floppy Drive, RJ45 Network Connection • Graphics programming ToPs 2000 • ToP ...

Key data: 22 t, 2535 mm, 1280 mm

Manufacturer / Manufacturer: Trumpf Typ / Type: Trumatic 500 Rotation Stocknummer / stock number: 1008 Year of Manufacture: 1995 Punching force: 22 tons Max. sheet thickness: 8 mm Connected load: 19 kVA Machine weight: 13,8 tons

Punching machine Trumpf TruMatic TC500-1300 FMC Year of construction 2000 Configuration : TruMatic TC500-1300 FMC Year of construction 2000 Working area : 2550 x 1280 mm The machine has the following options : • Function multi-tool control • Function thread forming • Winning function • Softpunch function • 1 additional Clamping claw • Sensor for parts chute • Vibration-damped installation • Automatic switch-off • Scratch arm machining for tables •Blow-out device for small parts •Trumasort L6 • Loading station with expansion magnets • TRL SheetMaster 1300 • TrumaGrip 200 mm with scissor lift table

Standard configuration? Stable C-frame? Coordinate guide with integrated linear magazine, 18 tool stations, automatic tool changer, 3 clamps? Automatic parts chute 500 x 500 mm? Parts container ? Drives: Maintenance-free, three-phase servo motors? Programmable presser foot for repositioning? Punching head: Hydraulic single tool adapter, 360? rotation of all tools, automatic tool length compensation, spray tool lubrication, 2nd lubricant container, programmable stripper movement, vacuum slug removal, swarf bucket? Control: 32 bit microprocessor control TRUMAGRAPH CC 220 S, 10.4 color screen, programmable logic controller, easy to use, diagnostic functions, graphic programming TRUMAGRAPH, integrated 3.5 disk drive, RJ45 network connection? Safety: CE marking, multi-beam light barriers, rapid hydraulic shutdownAdditional equipment? Function MultiTool? Pneumatic repositioning cylinders? Sens ...

Punching machine Trumpf TruMatic TC3000-1300 FMC Year of construction 2004 82500 Hours (03.2024) Here is the configration : TruMatic TC6000-1600 FMC Year of construction 2005 Working area: 2585 x 1650 mm Standard equipment: - Stable C-frame - Coordinate guidance with integrated linear magazine, 21 slots for tools and clamping claws. - 3 clamping claws - Drives: Maintenance-free three-phase servo motors - Programmable hold-down device for resetting - Sensor-monitored parts chute 500x500 mm for punching and laser station, ejection cylinder on laser chute - 2 boxes of good parts - Laser unit: High-frequency excited CO2 laser TLF 2000, vibration-isolated in the machine frame, incl. cooling unit and laser control DIAS 3 - HI-LAS high-pressure cutting - ContourLas for making small holes - Programmable cutting gas pressure setting - Laser cutting head: 5" lens, quic ...

Standard configurationMachine? Stable C-frame for easy access? Coordinate guide for high-precision machining? Linear magazine with 17 tool stations, 2 clamps? Drives with maintenance free 3-phase servo motors? Repositioning unit with programmable stripper? Ball tables? Parts chute 180 x 150 mm? Swarf bucket? Punching head? Hydraulic punching head? Rotatable single tool adapter? 360? rotation of all tools? Programmable presser foot? Tool length compensation? Spray lubrication for punches? Vacuum slug removal? FormingControl? Controller based on Bosch PNC-P? Control panel with 15 TFT color touch screen? Easy to use? Online-help? Integrated USB interface? RJ 45 network connection? Diagnostic functionsSafety? CE marking? Light barriers? Rapid hydraulic shutdownAdditional equipment? Function Multitool? Function MultiShear? Function Roller Technology? Adjustable support table? Sensor for parts ...

Standard configurationMachine? Stable C-frame for easy access? Coordinate guide for high-precision machining ? Linear magazine, 3 clamps? Maintenance free drives? Repositioning device with programmable presser foot? Parts chute 500 x 500 mm? Good parts container? Swarf bucketCutting head? Hydraulic punching head? Single tool adapter? 360? rotation of all tools? Programmable presser foot? Tool length compensation? Spray lubrication for punches? Vacuum slug removal ? FormingControl? Open control system based on BOSCH? Control panel with TFT colour screen 12.0? ? Program management? Online-help? Integrated technology data? Diagnostic functions? TeleserviceProgramming? Machine-oriented shopfloor programmingData transmission? Disc drive and network connectionSafety? CE marking? Light barriers? Rapid hydraulic shutdownAdditional equipment? Function Multitool? Function MultiShear? Function Tap ...

Description: SPECIFICATIONS Character: NN Type: 75 Capacity: 75 T Punch: ø20 mm Round: ø30 mm Strip: yes Angle iron: Yes Unloading: 350 mm Electrical installation: Yesweight approx.: 2,000 kg, Approx. Onsite Dimension. (l x w x h): 1,860 x 900 x 1,900 mm

Description: Control unit type ZHS-2/64 Nominal pressing force: 100 kN max. Nominal pressure: 6.5 bar Overrun time: 60 m sec Overtravel: 12 mm Safety distance: 110 mm weight approx.: 598 kg, Approx. Onsite Dimension. (l x w x h): 800 x 1,250 x 2,100 mm

• Description: Versatile punch with many inserts • Power: max. pressure: 35t • Working height: approx. 1000 mm • Dimensions: 1350 x 850 x 1724 mm • Weight: 1540 kg • In operation since: 06.1998 • Accessories: Trolley with many suitable tools
